Lighting Systems LSB-13
1BHFPG -ZUFTQSFBEÜ-4#3BEJBM-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Features
1. Housing: Extruded aluminum. Die-cast end cap mechanically attached with
no exposed fasteners or hardware.
2. Lamping: One T5, 28 or 54 watt (as specified) fluorescent lamp per 4-foot
nominal section. Provided by others.
3. Reflector: Precision die-formed semi-specular aluminum.
4. Radial Louver: Precision die-formed aluminumstraight blade louver, blades
Electrical
Ballast is <10% THD, .98 ballast factor, pre-heat start. 18 gauge wire. Color-
coded quick connectors allow ease of connection for joiner modules. Power feed
is 18 gauge white SJT. For special circuiting consult factory. Factory installed
ballast disconnect allows the ballast to be disconnected fromand reconnected to
incoming power under load without turning the entire circuit off.
Dimming: - 120/277 VAC 1% dimming level, 4 wire feed required.
Emergency Battery Pack: - 28 watt: 520 lumens @ 90 minutes, 54 watt: 700
lumens @ 90 minutes, 4 wire feed required.
Mountings
Finish
Powder coated baked white or aluminumfinish. Customcolors available, consult
factory.
Options and Accessories
Emergency circuiting; special circuiting; X, T & L joiner blocks - consult factory.
Labels
UL, cUL, and I.B.E.W.
Ordering Instructions
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete
run.
3. Order one POWER FEED END SET per run.
4. Order one CABLE ASSEMBLY per MODULE minus one
per run.
5. For runs that exceed amperage limits, order the appropriate
number of CABLE/CORD ASSEMBLIES.
Complete ordering instructions below.
Ordering Information
Family Lamps Voltage Finish
1= 1-Lamp T5 D= Radial Louver AL = Aluminum
WH = White
LSB 1 D
Length Shielding Ballast
1 = 120 volt
2 = 277 volt
28 = 28W T5
54 = 54W T5
5E = 54W T5 Emergency Pack
2E = 28W T5 Emergency Pack
5D = 54W T5 Dimming
4= 4-Foot
8= 8-Foot
are 5/8” (1.59cm) high and 5/8” (1.59cm) O.C.
Cable suspension (not shown) - 4-1/2" (11.43cm) diameter canopy finished white
enamel, 1/16" (0.16cm) diameter stainless steel aircraft cable adjustable up to 36”
(91.44cm). Dual-screw draw-tight connector to create hairline seambetween joiner
modules.
Half Scale
1
24
3
3-1/2" (8.89 cm)
2" (5.08 cm)
8-1/2" (21.60 cm)
1-3/4" (4.45 cm)

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt
Lighting Systems LSB-13
1BHFPG -ZUFTQSFBEÜ-4#3BEJBM-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Performance
CANDLEPOWER CURVE CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
180 371 371 371 371 371
175 373 373 373 373 373
165 373 374 372 371 363
155 361 365 365 372 370
145 332 342 358 377 375
135 280 300 338 379 381
125 229 260 342 433 438
115 156 206 394 499 520
105 85 189 302 387 399
95 23 75 12 41 43
90 0 0 0 0 0
85 6 8 1 14 15
75 22 24 26 30 49
65 36 39 45 56 31
55 61 63 78 169 208
45 78 82 120 221 303
35 112 228 175 254 310
25 183 195 224 277 308
15 249 255 272 298 303
5 303 305 310 313 313
0 313 313 313 313 313
REPORT NO: LRL 300-1R
CAT NO: LSB14D28
LAMPS: 1 F28T5
LUMENS: 2900
EFFICIENCY: 84.0%
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50
WALL REFLECTANCE
70 50 30 70 50 30 50 30 10
085 858576 7676 59 5959
178 757270 6764 52 5049
271 666164 5955 46 4441
365 585358 5247 41 3835
460 524653 4741 37 3330
555 464049 4236 33 2926
651 413545 3732 30 2623
747 373142 3328 27 2320
843 332739 3025 24 2017
940 302436 2722 22 1815
10 37 28 22 33 25 20 20 16 14
20% FLOOR CAVITY REFLECTANCE
DISTRIBUTION
Zone Lumens % Lamp% Luminaire
0-90 641 22.1 26.3
90-180 1794 61.9 73.7
0-180 2435 84.0 100.0
Calculations are for 28 watt T5 lamps, for 54 watt T5 lamps multiply by 1.7
Fixture Lengths & Mounting Locations
48"
(121.92cm)
4' 5-1/8"
(134.94cm)
96" (243.84cm)
8' 5-1/8" (256.86cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm) 96" (243.84cm)
96" (243.84cm) 96" (243.84cm) 96" (243.84cm)
48"
(121.92cm)
48"
(121.92cm)
12' 5-1/8" (378.78cm)
16' 5-1/8" (500.70cm)
20' 5-1/8" (622.62cm)
24' 5-1/8" (744.54cm)
4-Foot 8-Foot
12-Foot
16-Foot
20-Foot
24-Foot
Mounting Accessories
Power Feed End Set
Straight Cord: LSBEC36WH (white)
LSBEC36AL (aluminum)
4 Wire Cord*: LSBEC36WHX4 (white)
LSBEC36ALX4 (aluminum)
Cable Assembly
Single Cable: LSBC36
Ceiling Grid Kit
CGK
Includes both Standard 1” (2.54cm)
Tee Bar Clip & Slot Tee Clip
*Use for dimming, switching, and emergency battery packs.
Cable/Cord Assembly
Single Cable & Cord: LSBCC36
Single Cable & 4 Wire Cord*: LSBCC36X4
4-Foot
Module
8-Foot
Module
Cable/
Assembly
Power Feed
End Set
4-Foot Run 11
8-Foot Run 11
12-Foot Run 11 1 1
16-Foot Run 21 1
20-Foot Run 12 2 1
24-Foot Run 32 1
