Lightolier H.I.D. FRAME-IN KITS User manual

READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regulations. To
assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electric shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTRUCTIONS FOR H.I.D. FRAME-IN KITS AND FINISHING SECTIONS WITH OPTIONAL
AUXILIARY AND EMERGENCY LIGHTING
INSTRUCTION SHEET NO.
IS: AUX-E
A0504 Page 1 of 2
A COMPANY
631 Airport Road, Fall River, MA 02720
CAUTION: (RISK OF FIRE) DO NOT INSTALL INSULATION ABOVE NOR WITHIN 3 INCHES (76mm) OF ANY
PART OF THE LUMINAIRE (LIGHTING FIXTURE)
SEE OPPOSITE SIDE FOR ELECTRONIC
BALLAST WIRING DIAGRAMS
Installing 120V Auxiliary Lampholder onto Reflector
(NOTE: For Emergency Lighting applications, use same Auxiliary
Lampholder Accessory without Auxiliary Lighting Control.)
1. Remove NUT from end of AUXILIARY LAMPHOLDER ASSEMBLY.
2. Insert threaded end of of AUXILIARY LAMPHOLDER ASSEMBLY into
hole in REFLECTOR.
3. Secure AUXILIARY LAMPHOLDER ASSEMBLY on inside of
REFLECTOR with NUT.
4. Some REFLECTORS are provided with a threaded insert. In these
cases, simply screw end of AUXILIARY LAMPHOLDER ASSEMBLY
directly into threaded insert, and discard NUT.
5. Follow directions included with Frame-in Kit and Trim to complete
installation.
6. Refer to REFLECTOR labeling for correct wattage information installing
auxiliary lamp.
120V AUXILIARY
LAMPHOLDER
NUT
REFLECTOR
120V Tungsten Halogen Lamp, D.C. Bayonet Base (not provided).
Refer to labeling on Frame and Trim for correct lamp and wattage
AUXILIARY LIGHTING WIRING DIAGRAM FOR
METAL HALIDE MAGNETIC BALLASTS
(120V/277V DUAL TAP)
A
UXILIAR
Y
LIGHTING
CONTROL
CONNECT BLUE WIRE WITH
CONNECTOR TO APPROPRIATE
120V (BLK) OR 277V (RED)
BALLAST LEAD WITH
CONNECTOR
120V/277V
MAGNETIC
BALLAST
THERMAL PROTECTOR

READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE INSTALLING FIXTURE
This fixture is intended for installation in accordance with the National Electrical Code and local regulations. To
assure full compliance with local codes and regulations, check with your local electrical inspector before
installation. To prevent electric shock, turn off electricity at fuse box before proceeding.
Retain these instructions for maintenance reference.
INSTRUCTION SHEET NO.
IS: AUX-E
A0504 Page 2 of 2
A COMPANY
631 Airport Road, Fall River, MA 02720
CAUTION: (RISK OF FIRE) DO NOT INSTALL INSULATION ABOVE NOR WITHIN 3 INCHES (76mm) OF ANY
PART OF THE LUMINAIRE (LIGHTING FIXTURE)
INSTRUCTIONS FOR H.I.D. FRAME-IN KITS AND FINISHING SECTIONS WITH OPTIONAL
AUXILIARY AND EMERGENCY LIGHTING
AUXILIARY LIGHTING WIRING DIAGRAM FOR
120V METAL HALIDE ELECTRONIC BALLAST
AUXILIARY LIGHTING WIRING DIAGRAM FOR
277V METAL HALIDE ELECTRONIC BALLAST
120V ELECTRONIC
H.I.D. BALLAST
277V ELECTRONIC
H.I.D. BALLAST
AUXILIARY LIGHTING
CONTROL
THERMAL PROTECTOR
AUXILIARY LIGHTING
CONTROL
THERMAL PROTECTOR
