ProSpec® Accent Lighting System 28B10E
Page 1 of 1 PowerArc™ Modular 100W Electronic Metal Halide Ballast Module
Features
1. Housing: .10" thick extruded aluminum body with die cast end caps.
2. Track Attachment Fitting: Molded polycarbonate; rotates into track.
3. Ground Clip: Ensures proper grounding of module.
4. Safety Locking Lever: Locks and supports module in track.
5. On/Off Switch: Rocker switch to disconnect power to the ballast.
6. Power Receptacle: 5kv rated, insulated. Accepts power connector
from fixture.
7. Integral Track Groove: To mount PowerArc™ Modular spots and wall
wash fixtures.
Electrical
Electronic Ballast
Input Voltage: 120V, 60Hz
Power Factor: High
Input Power: 110W
Max. Input Current: 0.90A
Total Harmonic Distortion: <15%
ANSI Code: M90 or M140
Do not use on dimming circuit.
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Ordering Information
Catalog No. Finishes Track Mountings Luminaires Lamp
28B10EWH
28B10EBK
28B10EAL
Matte White
Matte Black
Metallic Aluminum
All ProSpec® Track Systems. DO NOT USE with any other
mounting accessories, stem mounted Radius®Track,
Lytespan® Track systems, or ATOM®.Can be wall mounted.
Use one of:
8317 83W7
8318
100W Ceramic
Metal Halide
3 17/64"
(83mm)
2 1/16"
(52mm)
3 7/8"
(98mm)
4 1/4"
(108mm)
7 1/8"
(181mm)
2
5
1
3
6
7
4
