Advent Lytespan®1 and 2 Circuit Track 6101
Page 1 of 4
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • G0309
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier is a Philips group brand
47-7/8"
95-7/8"
47-7/8"
95-7/8" 95-7/8" 95-7/8"
95-7/8"
43-3/8"
91-3/8"
139-3/8"
1/16"
1-5/32"
2
5
1-3/32"
7
1
6
4
3
Plain Track
Individual Track Joiner Track
Individual Track Joiner Track Joiner Track
910
8
Features
1. Advent Lytespan Track: 6063-T5 Aluminum 0.070" wall thickness.
2. Track Mounting Clips: 0.024 Spring steel, in black or white; order separately.
3. Toggle Bolt & Screws: furnished with track units.
4. Conductor (3): 20A current carrying capacity.
5. Insulating Liner: 0.040" wall, thermoplastic.
6. Neutral Conductor: on bead side of track.
7. Polarity Bead: identifies the neutral conductor.
8. Live End: molded thermoplastic. Includes contacts for power supply leads.
9. Dead End Cover: molded thermoplastic.
10. Mini Coupler: connects track units mechanically and electrically.
Mechanical
Track units plug together and lock securely to prevent accidental separation.
Track units can be field cut.
Finish
All painted finishes are baked enamel.
Mounting
Track may be surface mounted to ceilings or walls. The track may be stem mount-
ed. The track is not intended to be cable mounted. The track can also be recessed,
see Specication Sheet 7515.
Electrical
Two circuits individually controllable, rated 20 amps. at 120 volts 60 Hz per track
circuit (40 amps total for the two circuits), when supplied by a 120/240 volt, 60-Hz,
single phase 3-wire branch circuit with a grounded neutral. The track is polarized
and continuously grounded throughout.
Electrical (continued)
Electrical conductors are concealed in a insulating liner. Lytespan lighting units
attach to the track at any point and can be adjusted to operate on either track
circuit. Not intended for use with a power cord or a convenience receptacle
adapter. Magnetic and electronic transformers require different dimmer controls.
Use the proper control device on the track. Caution should be used when operat-
ing dimming controls on 3 wire circuiting (the neutral conductor may overload).
For additional information on dimming, call 1-800-833-3664. All wiring must be in
accordance with National and Local Codes.
Labels
cUL, IBEW.
Finishes Individual Track Joiner Track Plain Track
4’ Catalog No. 8’ Catalog No. 8’ Catalog No. 4’ Catalog No. 8’ Catalog No. 12’ Catalog No.
Matte White 6101NWH 6102NWH 6103NWH 6104NWH 6108NWH 6112NWH
Matte Black 6101NBK 6102NBK 6103NBK 6104NBK 6108NBK 6112NBK
Aluminum 6101NAL 6102NAL 6103NAL 6104NAL 6108NAL 6112NAL
6060NAL
6060WH
6060BK
6061NAL
6061WH
6061BK
6096WH
6096BK
6101NAL
6101NWH
6101NBK
6102NAL
6102NWH
6102NBK
6103NAL
6103NWH
6103NBK
6104NAL
6104NWH
6104NBK
6108NAL
6108NWH
6108NBK
6112NAL
6112NWH
6112NBK
6146NAL
6146NWH
6146NBK
6148NAL
6148NBK
6148NWH
6149NAL
6149NWH
6149NBK
6150NAL
6150NWH
6150NBK
6151NAL
6151NWH
6151NBK
6152NAL
6152NWH
6152NBK
6153NAL
6153NWH
6153NBK
6154NBK
6154NAL
6154NWH
7480
7480AL
7481
7582
7582AL
7584
7584AL
7681AL
7681
7683

Advent Lytespan®1 and 2 Circuit Track 6101
Page 2 of 4
Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • G0309
Lightolier is a Philips group brand
A
1097
4" Octagon
Outlet Box
(by others)
T-Bar
T-Bar Mounting
Clip
Track
Direct Mounting
Toggle bolts and nylon insulators are furnished
with Track, two per 2' and 4' track, three per 8'
and 12' track. Mount through existing holes in
track. Top of track sits flush to mounting surface.
Recommended for wall and ceiling mounting.
Regressed Edge Panels and 9/16"- 15/16"
T-Bar Clip is supplied assembled. Mounts
easily onto T-Bars by rotating clips. Use two
per 2' and 4' track, three per 8', and four per
12' track.
6087 (9) Clips
Grid Ceiling Mounting Clips
Square Edge Panels and 9/16- 15/16" T-Bars
Clip is supplied assembled. Mounts onto
T-Bars by rotating clips. Use two per 2' and
4' track, three per 8', and four per 12' track.
6089 (9) Clips
9/16"-
15/16"
Regressed
Edge Panel
T-Runner
5/16" -
13/32
9/16" - 15/16"
Square
Edge Panel
T-Runner
Slotted Grid Ceilings such as Donn Fineline
and Chicago Metalic Ultraline 3500 and 3600.
Use two per 2' and 4' track, three per 8', and
four per 12' track.
6088 (9) Clips
Slotted Grid
Runner
5/16"
9/16"
1/4"
6096WH Matte White
6096BK Matte Black
Toggle Bolt
Nylon Spacer
Screw
End Feed Canopy Kit
Mounts directly Live End, 'L', 'T', X', In-Line
and Variable Angle Connectors. Mounts to a
4" or 3" octagonal outlet box. For track
installed with mounting clips or direct
mounted. Canopy is 3/32" thick and 4-1/2"
square.
6060WH Matte White
6060BK
6060NAL
Matte Black
Matte Aluminum
6061WH Matte White
6061BK Matte Black
3" or 4" Octagon
Outlet Box
(by others)
Square Canopy
1/8" &
3" or 4" Octagon
Outlet Box
(by others)
Square Canopy
Grid Ceiling Canopy Kit
Mounts to a 4" or 3" octagonal outlet box. Use
two per 2' or 4' track, three per 8" and 12'
track. When making a run of track don't
exceed 4' between stems. Includes a special
outlet box to fit onto runners. Power can be
fed to Feed Track, Live End, "L", "T", "X", and
In-Line connectors. Mounts along runner or at
the intersection of runners.
Floating Canopy Kit
Mounts to a 4" or 3" octagonal outlet box.
Canopy is positioned anywhere along track,
up to 4' from edge of track extrusion. Power
can be fed to Live End, 'L', 'T', X', In-Line
and Variable Angle Connectors. Mount track
using track mounting clips. Canopy is 3/32"
thick and 4-1/2" square.
6061NAL Matte Aluminum
Track Mounting Clips
Recommended: 2 clips per 2' & 4' track, 3 clips
per 8' and 12' track units, order separately.
Attaches to track at any point. Clip is nylon
coated. Spaces track 1/16" from ceiling.
Not recommended for wall mounting.
56451WH Matte White
56451BK Matte Black
Set of 10
Track Mounting and Power Feed Systems

Advent Lytespan®1 and 2 Circuit Track 6101
Page 3 of 4
Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • G0309
Lightolier is a Philips group brand
Stem Mounting Kits
Mounts to a 4" or 3" octagon outlet box. Use
two per 2' and 4' track, three per 8' and 12'
track. When making a run of track do not exceed
4' between stems. Use additional stems for
additional support. Power is fed to the track
with the stem closest to the track feed-in point.
For power feed to Feed Track and Live End, "L",
"T", "X", In-line, and Variable Angle Connectors.
Stem can be field cut.
Not recommended for wall mounting.
Stem mounts to track
not feed connector.
18" Stem 48" Stem
TRA
C
K M
O
UNTIN
G
AND P
O
WER FEED
S
Y
S
TEM
S
Stem Extension
1/2" O.D. Steel
Tube
1/4-18 NPSM
Thread.
Clamp Set
Stem Extension Kit
Mounts to any stem kit to extend its length
by 48".
Cannot be field cut.
7582
7582AL
Matte White
7680
Matte Black
Live End
Energizes Track from the beginning of a run. It
is included with Individual Track Units. Use
with plain track units.
6148NWH Matte White
Wiring Diagram
(3) wire two circuit 120/240, 60Hz single
phase with grounded neutral. Maximum load.
2400W (incand.) 20 amp per track circuit,
4800W 40 amps total.
In-Line Connector
Permits power feed between track units in a
straight run of track. The In-Line Connector is
polarized and pre-wired. KO permits direct
feed with electrical connector.
6154NWH Matte White
6154NBK Matte Black
Swivel Stem Mounting Kits
Adjusts from 0 to 90. Mounts to a 4" or 3"
octagon outlet box. Use two per 2' and 4' track,
three per 8' and 12' track. When making a run of
track do not exceed 4' between stems. Use
additional stems for additional support. Power is
fed to the track with the stem closest to the
track feed-in point. For power feed to Feed Track
and Live End, "L", "T", "X", In-line, and Variable
Angle Connectors. Can be field cut. 48" stem.
Not recommended for wall mounting.
Actual length from
ceiling to top of track: 17 3/8" 47 3/8"
Matte White 7584 7586
Matte Black 7683 7681
7681AL
Mini-Coupler
Used to connect two pieces of track together
mechanically and electrically.
Power cannot
be fed to the Mini-Coupler.
It is included with
Joiner Track Units.
6149NWH Matte White
120V 60Hz single branch circuit, 20 amp
supply. Maximum load, 2400W (incand.)
distributed between track circuits.
Switches Track
240V 120V Circuit 1
Neutral
Circuit2
B
W
R
120V
Switches Track
120V
Circuit 1
Neutral
Circuit2
B
W
3" or 4" Octagon
Outlet Box
(by others)
This end may be
field cut.
Stem 1/4"-18
NPSM Thread
Clamp Set
Track
7480 Matte White
7481 Matte Black
3" or 4" Octagon
Outlet Box
(by others)
0-90 Ceiling
Slope
This end may be
field cut.
Stem 1/4"-18
NPSM Thread
Clamp Set
Track
Stem mounts to track not feed connector.
7584AL
Matte Aluminum
7480AL Matte Aluminum
Matte Aluminum
6148NAL Matte Aluminum
6148NBK
Matte
Black
6149NAL Matte Aluminum
6154NAL Matte Aluminum
6149NBK Matte Black
Track Mounting and Power Feed Systems

Advent Lytespan®1 and 2 Circuit Track 6101
Page 4 of 4
Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • G0309
Lightolier is a Philips group brand
Direct Feed into Connectors
The Live End, "L", "T", "X", In-line, and
Variable Angle Connectors contain a nut with
a 1/2"-14 thread to accept a 3/8" or 1/2" (trade
size) electrical connector, 3/8" connector
recommended. Does not require a separate
power feed kit.
Variable Angle Connector
The Variable Angle Connector is pre-wired
and polarized. It contains a nut with a thread
1/2"-14 to accept a 3/8" (trade sized) electrical
connector. Flexes in all directions.
6153NWH Matte White
6153NBK Matte Black
6153NAL Matte Black
Floating Invisible Feed
Can be mounted anywhere along the track at
a maximum distance of 4' from edge of track
extrusion. Accepts conduit or cable with 3/8" or
1/2" electrical connector (by others). Can be
used with Live End, "L", "T", "X", and In-Line
and Variable Angle connectors. Use Track
Mounting Clips to mount the track.
26082 Zinc Plated
Power Extension Connector
Replaces Dead End Cover at end of track to
permit power continuity around structural
obstacles to another track section.
Accepts same power feed-in kits as Live End.
6146NWH Matte White
6146NBK Matte Black
6146NAL Matte Aluminum
Over Beam or Through Beam
3/8"
Connector
Track
Power Extension
Connector
Beam
Jump
Track
Power Extension
Connector
Wall
Through Wall or Column
Track
Power Extension
Connector
Track
Power Extension
Connector
3/8" Connector Jump
Wall
(Conduit)
"L" Connector
The "L" connector is polarized and pre-wired.
It may be rotated for right angle or left angle
turn. KO permits direct feed with electrical
connector.
6150NWH Matte White
6150NBK Matte Black
6150NAL Matte Aluminum
6151NAL Matte Aluminum
6152NAL Matte Aluminum
"X" Connector
The "X" connector is not pre-wired or
polarized. Used to make "X" pattern with
track. 12ga. copper jumper wires supplied to
make all necessary connections. KO permits
direct feed with electrical connector.
6152NWH Matte White
6152NBK Matte Black
3/8"
Electrical
Fitting
(by others)
Clamp Set
Track
Wire Cover
"T" Connector
The "T" connector is not pre-wired or
polarized. Used to make "T" pattern with
track. 12 ga. copper jumper wires supplied to
make all necessary connections. KO permits
direct feed with electrical connector.
6151NWH Matte White
6151NBK Matte Black
5-1/2"
3-11/32"
5-1/2"
11-3/4"
0-90
Ceiling to Wall
Wall
Inside
Corner
Wall
Outside
Corner
3/8" Connector
(by Others)
Cast Plug
Live End Cover
Track Unit
Locknut 1/2"-12
Live End
1/2"-14 Thread, Integral with
Live End
3/8" or 1/2" Connector, 3/8" recommended
(by Others)
Live End
Track Unit
Track Mounting, Power Feed Systems and Mounting Patterns
