Lightolier TCU Series User manual

Under Shelf Luminaire TCU SERIES
Page 1 of 2 18", 24", 36", 48" Lengths, One Lamp, Rapid Start T8 and Trigger Start T12
Features
•
1-7/8" shallow depth.
• Four nominal lengths: 18", 24", 36", 48".
•
Grounded convenience outlet (optional).
• On-off switch supplied standard with supply pack.
• Baked white enamel.
Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2003 Lightolier Section 3A/Folio H150-10 Rev. B
1-7/8"
(48mm)
All K.O.’s are 7/8" unless otherwise noted.
Attractive, unobtrusive lighting
1-3/8" (35mm)
1-1/2" (38mm)
9/03
1-7/8"
(48mm)
5-1/4" (133mm)
9/32" Mounting Holes
15-3/8" (391mm)
21-3/8" (543mm)
33-3/8" (848mm)
45-3/8" (1153mm)
5"
(127mm)
18-1/8" (467mm)
24-1/8" (619mm)
36-1/8" (924mm)
48-1/8" (1229mm)
5-1/4"
(133mm)

Under Shelf Luminaire TCU SERIES
Page 2 of 2 18", 24", 36", 48" Lengths, One Lamp, Rapid Start T8 and Trigger Start T12
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
Copyright 2003 Lightolier Section3A/Folio H150-10 Rev. B
Job Information Type:
Ordering Information
Options/Accessories
Accessories that ship separately order
• GLR-B (6 pack of 3 amp fusing)
• RIF-SUPR 1-RFI suppressor)
• CONV OUTLET 10-PACK (10 pack of outlets and hardware)
Accessories are for field installation.
Specifications
Materials: Chassis parts are die-formed code gauge cold rolled steel.
Lens: White opal acrylic.
Finish: Cavity–white baked enamel, minimum 85% reflectance. Phosphate
undercoating. Chassis exterior–white baked enamel.
Electrical: Rapid start LPF, termally protected class “P” ballast C.B.M. approved,
non PCB. If K.O. is within 3" of ballast, use wire suitable for at least 90°.
Labels: I.B.E.W./UL and ULc Listed.
Warning (277 BPR)
Bulk pack rocker switch
can not be installed on
fixture if 277 voltage is
being run.
Fixture Lamp
Type
Length Watts/Type Catalog No.
Taskmaster II 18-1/8" 15W TS-T12 TCU15W120P BPR
Under Shelf 24-1/8" 20W TS-T12 TCU20W120P BPR
Luminaire 36-1/8" 30W RS-T12 TCU30W120P BPR
48-1/8" 40W RS-T12 TCU40W120P BPR
24-1/8" 17W-T8 TCU20WUNVRO BPR
36-1/8" 25W-T8 TCU30WUNVRO BPR
48-1/8" 32W-T8 TCU40WUNVRO BPR
TCU
Taskmaster II
Under Shelf
Luminaire
Lamp/Fixture
Length/Watts:
15 = 15W TS T12
(Nominal 18")
20 = 20W TS T12
or 17W T8
(Nominal 24")
30 = 30W RS T12
or 25W T8
(Nominal 36")
40 = 40W RS T12
or 32W T8
(Nominal 48")
W
Finish:
W=White
Voltage:
120 T12 Only
UNV T8 Universal
Voltage 120-277
Volt Electronic
T8 Ballast Ballast:
P= Standard Magnetic T12
RO = Rapid Start <10THD T8
BPR
Bulk Pack
Rocker Switch
