Linak HOMELINE LA18 IC Standard Series User manual

Page 1 of 26
LINAK.COM/HOMELINE
Actuator LA18 IC Standard
User manual

Page 2 of 26
Contents
Preface................................................................................................................................................3
Valid for..............................................................................................................................................4
Important information .....................................................................................................................5
Safety instructions..........................................................................................................................5
Safety issues..................................................................................................................................6
Before installation, re-installation or troubleshooting......................................................................7
Before Start-up ..............................................................................................................................7
During operation........................................................................................................................... 7
Misc. ............................................................................................................................................ 7
Only for EU markets ........................................................................................................................ 8
Only for Non EU markets ............................................................................................................... 8
Misuse ............................................................................................................................................... 8
Repairs............................................................................................................................................... 9
Manufacturer’s declaration............................................................................................................. 9
Misc. on the HOMELINE®system...................................................................................................10
Warranty......................................................................................................................................10
Maintenance................................................................................................................................10
ETL-marking.....................................................................................................................................11
System overviews ..........................................................................................................................12
How to pair .....................................................................................................................................13
How to mount the locking device ................................................................................................14
Disposal of LINAK’s products .......................................................................................................15
Main groups of disposal ................................................................................................................15
Disposal of batteries ......................................................................................................................15
Labels................................................................................................................................................16
Drawings ..........................................................................................................................................18
Addresses.........................................................................................................................................26

Page 3 of 26
Preface
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development
of actuators, electric control boxes, controls and chargers.
This User Manual does not address the end-user. It is intended as a source of information for the manufacturer
of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics. It
is the responsibility of the manufacturer of the end-use product to provide a User Manual where relevant safety
information from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation.
Before our products leave the factory they undergo full function and quality testing. Should you nevertheless
experience problems with your LINAK product/system, you are always welcome to contact your local dealer.
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are
always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance
with the specifications, maintenance being done correctly and any repairs being carried out at a service centre,
which is authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect their operation and durability.
The products are not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge. We are constantly working on
updating the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S

Page 4 of 26
Valid for:
This User Manual is valid for the following products:
(See the first 3 - 5 characters on the label)
Actuators: LA18 IC Standard Master and a LA18 IC Standard Follower
Power supply: SMPS001, SMPS002 or SMPS006
Wireless controls: HC05, HC10, HB10, HC40 Standard
Accessories: LEDLightRail001

Page 5 of 26
Safety instruction
General
Important information
Important information on LINAK®products can be found under the following
headings:
Warning!
Failure to comply with these instructions may result in accidents involving
serious personal injury.
Failing to follow these instructions can result in the product being damaged
or being destroyed.
Safe use of the system is possible only when the operating instructions are read
completely and the instructions contained are strictly observed.
Failure to comply with instructions marked with the ”NOTE” symbol may result in
serious damage to the system or one of its components.
It is important for everyone who is to connect, install, or use the systems to
have the necessary information and access to this User Manual. Follow the
instructions for mounting – risk of injury if these instructions are not followed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage on the product it must not be installed.
Note that during construction of applications, in which the actuator is to
be fitted, there must be no possibility of personal injury, for example the
squeezing of fingers or arms.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system.
The power supply shall not be covered while operating to allow sufficient
cooling of this appliance.
...to be continued

Page 6 of 26
Assure free space for movement of application in both directions to avoid
blockade.
The appliance is only to be used with the power supply unit provided with the
appliance.
Safety issues
The builder of the equipment shall ensure that the use of the component
complies with relevant standards – like the Machine Directive. Care must be
taken to avoid squeezing of cables as it can cause movement of the system!
The SMPS001/002/006 must not be packed in heat insulating material, but
must be placed so that it can emit waste heat to the surroundings. There are
no ventilation holes to consider, the SMPS emits heat through its surface.
Only the power supply type SMPS001, SMPS002 or SMPS006, shall be used
with the system.

Page 7 of 26
Before installation, re-installation, or troubleshooting:
• Stop the actuators
• Pull out the mains plug.
• Relieve the actuators of any loads, which may be released during the work.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual.
• Make sure that the voltage of the actuator system/SMPS is correct before the
system is connected to the mains.
• System connection. The individual parts must be connected before the actuator
system/SMPS is connected to the mains. See the User Manual for LINAK actuators,
if necessary.
During operation
• If the actuator system makes unusual noise or smells, switch off the mains voltage
immediately.
• Take care that the cables are not damaged.
• The products must only be used in an environment, that corresponds to their IP
protection.
Misc.
Updated manuals and declarations can always be found here:
www.linak.com/homeline

Page 8 of 26
Only for EU markets
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Only for Non EU markets
Persons who do not have the necessary experience or knowledge of the
product/products must not use the product/products. Besides, persons with
reduced physical, sensory or mental abilities must not use the product/products,
unless they are under surveillance or they have been thoroughly instructed in
the use of the apparatus by a person who is responsible for the safety of these
persons.
Moreover, children must be under surveillance to ensure that they do not
play with the product.
Misuse
Do not overload the actuators – this can cause danger of personal injury and
damage to the system.
When the actuator is in fully retracted position, the load on the actuator
must not exceed specified max. self-lock.
Do not use the system in environments other than the intended indoor use

Page 9 of 26
Repairs
In order to avoid the risk of malfunction, all HOMELINE®repairs must only be carried out by authorised LINAK®workshops or
repairers, as special tools must be used and special gaskets must be fitted. Lifting units under warranty must also be returned
to authorised LINAK workshops.
Warning!
If any of the HOMELINE®products are opened, there will be a risk of subsequent malfunction.
Warning!
The HOMELINE®systems are not resistant to cutting oil.
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
2006/42/EC ANNEX II B
LINAK A/S
Smedevænget 8
DK - 6430 Nordborg
Herewith declares that LINAK HOMELINE® products as characterized by the following models and
types:
Control Boxes CB9H, CBH Advanced, CBH Basic
Linear Actuators LA27, LA29, LA31 HOMELINE
Dual Actuators TD3, TD4, TD5
Controls HB10 RF, HB20RF, HB60, HC10, HC10RF, HC20RF, HC40
Accessories Bluetooth Adapter, DC CONNECTOR, LED Lightbox, Lightplug001, Massage
Motor, SMPS001, SMPS001, SMPS002, SMPS006
comply with the following parts of the Machinery Directive 2006/42/EC, ANNEX I, Essential health and
safety requirements relating to the design and construction of machinery:
1.5.1 Electricity supply
The relevant technical documentation is compiled in accordance with part B of Annex VII and that this
documentation or part hereof will be transmitted by post or electronically to a reasoned request by the
national authorities.
This partly completed machinery must not be put into service until the final machinery into
which it is to be incorporated has been declared in conformity with the provisions of the
Machinery Directive 2006/42/EC where appropriate.
Nordborg, 2019-10-21
LINAK A/S
John Kling, B.Sc.E.E.
Regulatory Affairs Manager
Authorized to compile the relevant technical documentation
Original Declaration

Page 10 of 26
Misc. on the HOMELINE®system
Warranty
There is a 36 months’ warranty on the HOMELINE products against manufacturing faults from the production date of the
individual products (see label). LINAK A/S’ warranty is only valid in so far as the equipment has been used and maintained
correctly and has not been tampered with. Furthermore, the system must not be exposed to violent treatment. In the event of
this, the warranty will be ineffective/invalid. For further details, please see LINAK A/S’ ordinary conditions of sale.
Maintenance
Clean dust and dirt on the outside of the system at appropriate intervals and inspect for damage and breaks.
Inspect the connections, cables, and plugs and check for correct functioning as well as fixing points.
The cleaners and disinfectants must not be highly alkaline or acidic (pH value 6-8).
