Linak Desk Frame 1 User manual

DESK FRAME 1 ASSEMBLY
MANUAL
DESK FRAME
DESK FRAME

2
Designed in Denmark

3
Made in the USA
Dear User,
We are delighted that you have chosen a sit-stand desk that uses LINAK®
components.
We are sure that your height-adjustable table will give you many years of
problem-free operation.
Before our products leave the factory, they undergo full function and quality
testing. Should you nevertheless experience problems with your table, you
are always welcome to get in-touch with your local contact.
Changes in installation and use of LINAK products/systems can affect the
operation and durability of the products/systems. The products are not to
be opened by unauthorized personnel.
The assembly manual has been written based on our present technical
knowledge. We are constantly working on updating the information and
we therefore reserve the right to carry out technical modifications.
Requests for information or replacement parts should be directed to the
equipment manufacturer.
Contact information is generally found on the manufacturer’s label or in
your user manual. LINAK supplies manufacturers only. We do not provide
technical support to end-users or service companies.

4
Designed in Denmark
CONTENTS
What is Included in the Box 05
Hardware Packages 06
Product Ratings 07
Full Product Details 08
Tools Needed 08
Assembly Process 09
Getting the Most From Your New Sit-Stand Desk 17
Benefits of Moving 18
Troubleshooting 19
Contact Information 24

5
Made in the USA
WHAT IS INCLUDED IN THE BOX
B. Kick & Click™Frame
1. Clamp
2. Kick Lock
3. (2) Cantilevers
4. Inner Rail
5. Outer Rail
6. (2) Clips
C. Electronics Kit
Control Box
Desk Switch
Cables
Hardware pack
Anticollision Desk Sensor (Optional)
A. DESKLIFT™SetPack
Setpack Desk Legs

6
Designed in Denmark
D. Feet (and/or) Bench Beams
T-Feet or C-Feet
E. Hardware Pack
1: Electronics Hardware Pack:
(2) Desk Switch Flathead screws, black finish
(2) Control Box screws, silver finish
2: Desk Frame Hardware Pack
(1) Locking Clip for Rails
(2) Kick Locks
(13-20) #8-15x0.75” Screws for table top
3: Desk Feet Hardware Pack
(8) Mounting screws for the feet, M6 x 16
(4) Levelers for feet

7
Made in the USA
Inner Rail x 1 Outer Rail x 1 Cantilever x 2 2
Foot x 2
Leveler for
Foot x 4 Control Box x 1
Motor
Cable x 2
Tapping
10-12 x 2"
Tapping M6 x 16 mm
PACKING LIST
Kick Lock x 2
Screw x 13-20
8-15 x 0.75”
Clamp x
Desk Switch Desk Leg x 2
Mains Cable x 1 Screw x 2 Allen Bolt x 8
PRODUCT RATINGS
Application of the DESKLINE® DL5/6 system:
Irrespective of the load the duty cycle 10% ~ 2
minutes of continuous use at full load, followed
by 18 minutes of pause stated in the data sheets, must
NOT be exceeded as this will result in super heating of the
motor, the brake and the spindle nut. Exceeding the duty
cycle will result in a dramatic reduction of the life of the
system.
This product is inteded for indoor use only.
Weight limit for two-leg DL5/6 desk: 1600N (363 lbs
including weight of the desk top.
Kick & Click Fixed Frame: Fits desks with 47.25”+ tops.
(Actual frame width of 44.9”)
Kick & Click Large Adjustable Frame: Fits desks from 54” to
84” (actual frame width of 52.75” to 76.3”).
Kick & Click Short Adjustable Frame: Fits desks from 41” to
60” (actual frame width of 38.25” to 50”).

8
Designed in Denmark
FULL PRODUCT DETAILS
For full product details, see additional LINAK documentation:
Online Manuals
Kick & Click User’s Manual
Desk Troubleshooting Manual
DL5/6 w/ CBD6S User’s Manual
Youtube Videos
Assembling Your Desk Video
Using Your DPG1C
Using Your DPG1M
TOOLS NEEDED (INCLUDED)
M6 Allen Wrench

9
Made in the USA
TOOLS NEEDED (NOT INCLUDED)
ASSEMBLY PROCESS
1. Place work-surface up-side down on a pad,
blanket, or cardboard box.
Don’t forget to place a protective
blanket, pad or cardboard box, to
protect the desk top during floor
assembly.
Cordless Drill
(Optional)
Rubber Mallet
(Optional)
Phillips Head
Drill Bit (Optional)
Phillips Head
Screwdriver
2. Gather all parts for Desk Frame.
Image shows the two-piece Adjustable
Length Frame. Some desks use a one-
piece Fixed Length Frame. If the length
of the frame is fixed, skip Step 3.”

10
Designed in Denmark
3. Fix inner rail inside outer rail.
3.1 Extend to approximately 1” from the table
top end using holes on rails as a length indicator.
(frame width from 44 7/8 to 76 3/8 inches)
3.2 Fix length with clip.
4. Slide cantilevers over inner and outer rail tabs.
5. Align cantilevers.
Align middle marker on cantilever with center
on inner/outer rail.
Outer markers on cantilever indicates 2” maximum
displacement from center on inner/outer rail.
T-Desk C-Desk
