Linak DESKLINE DESK FRAME 2 User manual

Page 1 of 24
LINAK.COM/DESKLINE
DESK FRAME 2 - DF2
User manual

Page 2 of 24
Contents
Preface .......................................................................................................................................... 3
Important information ................................................................................................................. 4
Safety instructions........................................................................................................................ 4
Before installation, re-installation or troubleshooting.................................................................. 5
Before start-up .......................................................................................................................... 5
During operation ....................................................................................................................... 5
Misc. ......................................................................................................................................... 5
Only for EU markets ..................................................................................................................... 6
Only for Non EU markets ............................................................................................................. 6
Misuse .......................................................................................................................................... 6
Repairs .......................................................................................................................................... 7
Manufacturer’s declaration.......................................................................................................... 7
Misc. on the DESKLINE®system .................................................................................................. 8
Warranty ................................................................................................................................... 8
Maintenance ............................................................................................................................. 8
Description of the DESKLINE®Desk Frame 2 ........................................................................... 9
Mounting guidelines for the Desk Frame 2............................................................................... 11
Disassembly .................................................................................................................................. 17
Accessories and repair ................................................................................................................. 18
Disposal of LINAK products ........................................................................................................ 19
Drawing appendix ........................................................................................................................ 20
Addresses ...................................................................................................................................... 24

Page 3 of 24
Preface
Dear User,
We are delighted that you have chosen a product from LINAK®.
LINAK systems are high-tech products based on many years of experience in the manufacture and development
of actuators, electric control boxes, controls and chargers.
This User Manual does not address the end-user. It is intended as a source of information for the manufacturer
of the equipment or system only, and it will tell you how to install, use and maintain your LINAK electronics.
It is the responsibility of the manufacturer of the end-user product to provide a User Manual where relevant
safety information from this manual is passed on to the end-user.
We are sure that your LINAK product/system will give you many years of problem-free operation.
Before our products leave the factory, they undergo full function and quality testing. Should you nevertheless
experience problems with your LINAK product/system, you are always welcome to contact your local contact.
LINAK subsidiaries and some distributors situated all over the world have authorised service centres, which are
always ready to help you.
LINAK provides a warranty on all its products. This warranty, however, is subject to correct use in accordance
with the specifications, maintenance being done correctly and any repairs being carried out at a service centre,
which is authorised to repair LINAK products.
Changes in installation and use of LINAK products/systems can affect the operation and durability of the
products/systems. The products are not to be opened by unauthorised personnel.
The User Manual has been written based on our present technical knowledge. We are constantly working on
updating the information and we therefore reserve the right to carry out technical modifications.
LINAK A/S

Page 4 of 24
Safety instruction
General
Important information
Important information on LINAK®products can be found under the following
headings:
Warning!
Failure to comply with these instructions may result in accidents involving
serious personal injury.
Failing to follow these instructions can result in the product being damaged
or being destroyed.
Safe use of the system is possible only when the operating instructions are read
completely and the instructions contained are strictly observed.
Failure to comply with instructions marked with the ”NOTE” symbol may result in
serious damage to the system or one of its components.
It is important for everyone who is to connect, install, or use the systems to
have the necessary information and access to this User Manual. Follow the
instructions for mounting – there is a risk of injury if these instructions are not
followed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage to the product, do not install it.
Please note that during construction of applications in which the system
is to be fitted, there must be no possibility of personal injury, for example
squeezing of fingers or arms.
Assure free space for movement of the application in both directions to avoid
blockades.

Page 5 of 24
Before installation, re-installation, or troubleshooting:
• Stop the frame.
• Switch off the power supply and pull out the mains plug.
• Relieve the frame of any loads, which may be released during the work.
Before start-up:
• Make sure that the system has been installed as instructed in this User Manual
describing the motor system.
• Make sure that the voltage of the control box is correct before connecting the
system to the mains.
• System connection. The individual parts must be connected before connecting the
control box to the mains. See the User Manual for LINAK actuators, if necessary.
During operation
• If the control box makes unusual noise or smells, switch off the mains voltage
immediately.
• The maximum total load on the frame is 160 kg equally loaded, i.e. 80 kg on each
column. The 160 kg include the tabletop.
• Duty Cycle: 5 %, Max. 1 min./19 min. pause
• Take care that the cables are not damaged.
• Unplug the mains cable on mobile equipment before moving it.
• The products must only be used in an environment, that corresponds to their IP
protection.
Misc.
For further information, installation guidelines etc. for the motor system, please see
the relevant user manual: www.linak.com/deskline.
Updated manuals and declarations can always be found here:
www.linak.com/deskline.

Page 6 of 24
Only for EU markets
This appliance can be used by children aged from aged 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Only for Non EU markets
Persons who do not have the necessary experience or knowledge of the
product/products must not use the product/products. Besides, persons with
reduced physical, sensory or mental abilities must not use the product/
products, unless they are under surveillance or they have been thoroughly
instructed in the use of the apparatus by a person who is responsible for the
safety of these persons.
Moreover, children must be under surveillance to ensure that they do not
play with the product.
It is the operator’s responsibility to ensure that there is free space for the
application to move without risk for the operator or bystanders before
operating the application.
Misuse
Do not overload the frame – this can cause danger of personal injury and
damage to the system.
Do not use the frame for lifting persons. Do not sit or stand on a table while
operating – risk of personal injury.
Do not use the system in environments other than the intended indoor use

Page 7 of 24
Repairs
In order to avoid the risk of malfunction, all DESKLINE®repairs must only be carried out by authorised LINAK workshops or
repairers, as special tools must be used and special gaskets must be fitted. Lifting units under warranty must also be returned
to authorised LINAK workshops.
Warning!
If any of the DESKLINE®products are opened, there will be a risk of subsequent malfunction.
Warning!
The DESKLINE®systems do not withstand cutting oil.
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
LINAK A/S
Smedevænget 8
DK - 6430 Nordborg
Herewith declares that LINAK DESKLINE®products as characterized by the following models and types:
Control Boxes CBD6S
Linear Actuators DB5, DB6, DB14, LA23, LA31
Lifting Columns DL1A, DL2, DL4S, DL5, DL5IC, DL6, DL6IC, DL7, DL8, DL8IC, DL9, DL9IC,
DL10, DL10IC, DL11, DL11IC, DL12, DL14, DL15, DL16, DL16IC, DL17,
DL19, DL19IC, BASE1
Desk Panels DPA, DPB, DPH, DPF, DPG, DPT, DP, DP1CS
RF Controls HB10RF, HB20RF, RFRL
Accessories BA001, BLE2LIN, DS1, DF2, Kick & Click, SLS, SMPS001, SMPS002, SMPS006
comply with the following parts of the Machinery Directive 2006/42/EC, ANNEX I, Essential health and
safety requirements relating to the design and construction of machinery:
1.5.1 Electricity supply
The relevant technical documentation is compiled in accordance with part B of Annex VII and that this
documentation or part hereof will be transmitted by post or electronically to a reasoned request by the
national authorities.
This partly completed machinery must not be put into service until the final machinery into which
it is to be incorporated has been declared in conformity with the provisions of the Machinery
Directive 2006/42/EC where appropriate.
Nordborg, 2019-05-27
LINAK A/S
John Kling, B.Sc.E.E.
Certification and Regulatory Affairs
Authorized to compile the relevant technical documentation
Original Declaration
Manufacturer’s declaration
If required, the RoHS mark must be obtained by the manufacturer of the end-use products. LINAK A/S can supply
the required material information on our products.
For more information, visit: https://www.linak.com/about/declarations/
or contact: [email protected]

Page 8 of 24
Misc. on the DESKLINE®system
This system is a DESKLINE system developed for desks and for indoor use in offices. Do not use it in industrial kitchens or in
other environments that have to be cleaned with aggressive detergents.
Warranty - 60 months on DESKLINE®
There is a 60 month warranty on Kick & ClickTM systems.
Read more about the warranty period of the motorsystems in the standard user manuals found on
www.linak.com/deskline.
Maintenance
Clean dust and dirt off the outside of the system at appropriate intervals and inspect them for damage and breaks.
Inspect the connections, cables, and plugs and check for correct functioning as well as fixing points.

Page 9 of 24
Description of the DESKLINE®Desk Frame 2
The Desk Frame 2 (DF2) is, as the name indicates, a complete frame from LINAK®. It is characterized by a rethought frame concept,
evolved around a new top frame called the Beam.The Beam contains all electronics including the motor and all cable wiring.The
DF2 is very fast and intuitive to assemble as the few parts are carefully designed to be either clicked together or attached with
only a few screws.
The DF2 has a clean design. The lifting columns have no visible gliding pads and no punch holes in the profiles, and the internal
wiring and pre-installed motor in the beam ensure that only the mains cable and the cable to the desk panel are visible. The DF2
is of the well-known LINAK quality and performance similar to other 3-part columns. As standard, the DF2 features the new anti-
collision technology, Desk Sensor™ 1, ensuring that collisions with obstacles do not damage the furniture. The DF2 reuses the
existing DESKLIFT™ Feet for mounting the lifting columns either on top of or recessed in the foot construction.
The method of packing ensures optimized logistics.All main components are packed individually and the quantity is aligned.
Figure 1 Names of the DF2 parts
The DF2 can be delivered with a mounting kit consisting of:
• 22 mounting screws for the beam and the cables (4.5 x 20 mm)
• 2 mounting screws for the desk panel (4.0 x 35 mm)
• 3 cable clamps (Ø6.6 mm)

Page 10 of 24
Disassembly tool
Ordering code: 1023W1241.
The DF2 is available as a set-packed solution.
For the set-packed solution the main components of a DF2 frame are packed in separate boxes meaning that a DF2 frame
consists of 4 boxes:
• The beam (1 piece)
• The lifting columns (2 pieces)
• The cantilevers (2 pieces), the selected DPG, mains cable and optionally a mounting kit containing screws for mounting
the tabletop and the DPG as well as cable relief clamps
• The feet (2 pieces including the screws for mounting and the adjustment screws for the foot)
The set-packed solution simplifies logistics at the OEM end, making it easy to select the right components for the desk and
ensuring that all parts are included.
A bulk-packed solution is typically an advantage for high volume OEMs who assemble the frames or the complete desks at
their factories.
Beam Cantilevers,
Desk Panel,
mains cable Feet
Columns

Page 11 of 24
Mounting guidelines for the Desk Frame 2
Assembling DF2 system
1. Gather all parts for desk including tabletop.
2. Turn tabletop upside down.
3. Fix beam length.
3.1. Extend beam to required length (width 1150 to 1750 mm), adjustable in 50 mm steps).
The beam must not be pulled completely apart in order not to pull the drive shaft apart.
Minimum adjustment in the connection end is 100 mm (to keep power and RJ45 sockets accessible),
otherwise adjustable in 50 mm steps.
Recommended tabletop:
Material Veneered chipboard
Plywood
Thickness Min. 21 mm (13/16”)
Size Min. 700 x 1200 mm (27” x 47”)
Max. 1000 x 1830 mm (39” x 72”)

Page 12 of 24
4. Mount cantilevers.
4.1. Place a cantilever slightly tilted at end of beam.
4.2. Press cantilever into place until a click is heard and pawls lock cantilever in correct position.
5. Place assembled DF2 frame in correct position.
Use tape measure to ensure central placement of DF2 frame.
4.3. Mount cantilever in other end of beam.
Check that the cantilever is placed correctly and cannot be twisted off the DF2 beam.
Do not extract the beam using the cantilevers as handles.

Page 13 of 24
6. Fasten DF2 frame to tabletop using 20 mounting screws as follows:
6.a. 8 screws at ends of beam.
Use one of these to fix mains cable to beam with cable clamp creating a cable relief, see step 13.
Connect power cable.
6.b. 4 screws at extension points.
6.c. 8 screws in cantilevers.
7. Mount columns.
7.1. Ensure columns are completely retracted.
a
c
cc
c
ba
If the column extracts when turned upside down, press by hand to completely retracted position.

Page 14 of 24
7.2. Tilt columns and place correctly on beam using guiding notches.
7.3. Fix column to beam by pressing down until a “click” is heard and both pawls lock column in correct position.
8. Mount desk panel
8.1 Connect desk panel in one of RJ45 sockets.
8.2. Fasten desk panel to tabletop using mounting screws.
8.3. Fasten cable to tabletop using two screws and two cable clamps.
Check that both pawls are visible after mounting of the columns. Otherwise, remove column and try again
(see Disassembly, steps 4 and 5).
Ensure that only one desk panel at the time is connected to the DF2.

Page 15 of 24
9. Connect power cable.
Ensure to make a cable relief using the cable clamp when fastening the cable to the tabletop.

Page 16 of 24
10. Mount feet
10.1 Mount feet on columns using eight M6 mounting screws.
The DF2L06 columns are supplied with four M6 and two M8 threaded holes. For mounting the feet,
always use four M6 or two M8 bolts with the following specifications:
Quality: Min. grade 8.8
Length: Min. 10 mm (plus foot thickness); max. 16 mm (plus foot thickness)
10.2. Fasten bolts thoroughly (torque: max. 10 Nm).
10.3. Mount adjustment screws.
11. Turn table around.
12. Connect to mains supply.
Your desk is now ready for use.

Page 17 of 24
For disassembling the DF2, use a disassembly tool (ordering code 1023W1241).
Disassembling DF2
1. Drive desk to its minimum height so columns are completely retracted.
2. Disconnect from mains supply.
3.Turn table upside down.
4. Disconnect, unscrew and remove desk panel.
5. Unscrew and remove feet.
6. Place disassembly tool on beam to make pawl release column.
8. Unscrew DF2 beam from tabletop.
9. Turn DF2 beam upside down.
10. Press screwdriver down on pawl. Slightly tilt cantilever to remove it.
11. Disassemble rest of system.
Disassembly
A disassembling instruction video is available here.
Figure 6 Disassembly tool
7.At the same time press disassembly tool down and
tilt column to remove from beam.

Page 18 of 24
Accessories and repair
Ordering accessories
Order from your nearest LINAK®contact, distributor or subsidiary.
Accessories
Please contact your nearest LINAK®contact, distributor or subsidiary.
Repairs
Systems should only be repaired by an authorised LINAK service centre or engineer. Systems to be repaired under warranty
must be sent to an authorised LINAK service centre.
Warning!
By unauthorised opening of the system there is a risk that it may malfunction at a later date.
Spare parts
Please contact your nearest LINAK contact for information on spare parts.

Page 19 of 24
Main groups of disposal
Disposal of LINAK products
As LINAK customers often ask us how our products can be disposed or scrapped we have prepared this guide that enables a
classification to different waste fractions for recycling or combustion.
Guide
We recommend our products to be disassembled as much as possible and divided into different waste groups for recycling or
combustion.
For example, waste can be sorted into metals, plastics, cable scrap, combustible material, and recoverable resources.
Some of these main groups can be further divided into subgroups; e.g. metal can be divided into steel/aluminium/copper and
plastic can be divided into ABS/PA/PE/PP.
As an example, the table below breaks down the different components in LINAK products to various recycling groups:
By now almost all our cast plastic parts are supplied with an interior code for plastic type and fibre content, if any.
Product Component Recycling group
Column/Actuator Spindle and motor
Plastic housing
Cable
PCB board
Metal Scrap
Plastic recycling or combustion
Cable scrap or combustion
Electronics scrap
Control box PCB board
Plastic housing
Transformer
Electronics scrap
Plastic recycling or combustion
Metal scrap
Product main groups Metal
scrap
Cable
scrap
Electronics
scrap
Plastic recycling
or combustion
Comments
DF2 Beam xxxx
DF2 Cantilever x
DF2 Column xxxx
DF2 Feet x

Page 20 of 24
Desk Frame 2 Beam
DRAWING APPENDIX
