2-½” AIR MOTOR
Series “C”
MIN.AIR PRESSURE-30 PSI
MAX.AIRPRESSURE-200 PSI
OWNERSMANUAL
IT ISTHE RESPONSIBILITY OF THE OWNERAND/OR OPERATORTO PROPERLY USEAND MAINTAIN THIS EQUIPMENT.
CAREFULLY READAND UNDERSTAND THE INSTRUCTIONSAND WARNINGS INTHIS MANUAL BEFORE OPERATING
THISEQUIPMENT.
If the operator is not fluent in English the instructions and warnings shall be read and discussed in the operator’s native
language, making sure the operator comprehends the contents.
This equipment complies with OSHA Standards where applicable.
DO NOT exceed the stated maximum working pressure of the pump or of the
lowest rated component in your system.
DO NOT alter or modify any part of this equipment.
DO NOT operate this equipment with combustible gas.
DO NOT attempt to repair or disassemble the equipment while the system is
pressurized.
TIGHTEN all fluid connections securely before using this equipment.
ALWAYS read and follow the fluid manufacturer’s recommendations regarding
fluid compatibility. and the use of protective clothing and equipment.
CHECK all equipment regularly and repair or replace worn or damaged parts
immediately.
IMPORTANT: Failure to heed these warnings including misuse, overpressuriz-
ing, modifying parts, using incompatible chemicals and fluids, or using worn or
damaged parts, may result in equipment damage and/or serious personal
injury, fire. explosion, or property damage.
This air pressure specification is for the air motor only. Never exceed the
maximum air or fluid working pressure of the lowest rated system component.
CONTENTS
SafetyInstructions...........................................................................................................................................................................................2
InspectionInstructions....................................................................................................................................................................................2
Installation........................................................................................................................................................................................................2
Operation..........................................................................................................................................................................................................2
Maintenance.....................................................................................................................................................................................................2
DisassemblyProcedure.................................................................................................................................................................................3
PartsBreakdown.........................................................................................................................................................................................3-4
ServiceParts.....................................................................................................................................................................................................5
TroubleshootingChart....................................................................................................................................................................................5
Accessories.....................................................................................................................................................................................................5
Warranty.............................................................................................................................................................................................................6
This manual contains IMPORTANT WARNINGS and INSTRUCTIONS READ AND RETAIN FOR REFERENCE
Page Number - 2 Form 403295
SAFETY INSTRUCTIONS
This equipment for professional use only. Observe all
warnings Read and understand all instructions before oper-
ating equipment Extreme caution should be used when
operating this equipment as personal injury and/or property
damage can result from equipment misuse.
ALWAYS check equipment for proper operation before each
use, making sure safety devices are in place and operating
prop-erly. Tighten all connections before each use. DO
NOT alter or modify any part of the equipment as this may
cause a malfunction and result in serious bodily injury.
ALWAYS disconnect air to pump and relieve system
pres-sure before checking, cleaning and lubricating, or
servicingair motor. Periodic inspection of air motor parts at
least once each year is recommended.
INSPECTION INSTRUCTIONS
If overpressurizing of the equipment is believed to have
occurred, contact the factory authorized warranty and service
center nearest you for inspection of the pump.
Any equipment that appears to be damaged in any way, is
badly worn, or operates abnormally shall be removed from
use until repairs are made. Specialized equipment and
knowledge is required for repair of this air motor. Contact
the factory authorized warranty and service center nearest
you for repair oradjustments otherthan maintenance
specified in this manual.
Annual inspection by the factory authorized warranty and
service center nearest you is recommended.
A list of factory authorized warranty and service centers is
available upon request.
INSTALLATION
Use of an airline filter/regulator/lubricator is recommended
to remove harmful dirt and moisture from the compressed
air supply, and to provide automatic lubrication to your
Lincoln air motor.
Contact your Lincoln representative for assistance in
designing a system to meet your specific needs.
Flush supply lines and hoses with mineral spirits or oil
based solvent and blow dry with air before connecting them
to the system. This is to purge any contaminants such as
dirt, moisture, or metal shavings that could damage the air
motor.
OPERATION
To start the pump, turn on the main airsupply. Slowly open
the air regulator until the air motor runs smoothly.
In a direct supply system, with adequate air pressure
supplied to the air motor, the pump starts when the dis-
pensing valve is opened and stalls against pressure when
dispensing valve is closed.
In a circulating system, the pump runs continuously and
slows down or speeds up as supply demands until the air
supply is shut off.
Use the air regulator to control pump speed and fluid
pressure. Always use the lowest pressure required to
achieve the desired results. Higher pressures will cause
pump packings to wear pre-maturely.
To reduce the risk of serious bodily injury or property
damage, NEVER exceed the maximum air or fluid
working pressure of the lowest rated system component.
To reduce the risk of serious bodily injury, ALWAYS
disconnect air to pump and relieve system pressure
before checking, cleaning and lubricating, or servicing air
motor.
Page Number - 3
Form 403295
DISASSEMBLY PROCEDURE
1. Unscrew Body Cap (14963) securing air motor to the
pump body.
2. Lift air motor straight up to move air piston to its
extreme “down” position,
3. Shift airmotor to one side to disengage the air motor
coupling from the pump rod and lift upward to
complete separation.
4. Remove Valve Cap (11470) and Trip Rod Pin (11472).
5. Unscrew four Nuts (51009) from Tie Rods (14960) and
lift Air Valve Casting (236612©) off ofAir Cylinder
(61041).
6. Remove Packing Nut (11904) and Packing Cap
(11905) from Air Valve Casting.
7. Remove four Screws (236868) and Cover (236286).
8. Remove four Screws (236869), Toggle Plate (91331)
and Trip Shoe Assembly (11947).
9. Remove four Valve Seat Bolts (236870), Springs
(55138), Valve Guide Plate (45605) and Valve Slide
(11482©), Seat (14919©)and Gasket (38162©).
10. Unscrew Trip Rod Packing Nut (245425©) from Air
Valve Casting and remove all packing parts.
11. Unscrew Tube (61570) from Adapter Casting (40666).
12. Remove Air Cylinder (61041) and Air Passage Tube
(61502) from adapter casting.
13. Place wrenches on Piston Bolt (13300) and on
wrench flats of Piston Rod (14961) and loosen.
14. Remove Piston Bolt, Trip Rod (91964©), Air Piston
Washers (48212), Air Piston Packing (34090) and
Washer (48511) from Piston Rod.
15. Remove Piston Rod through bottom of Adapter
Casting.
16. Unscrew Gland Packing Nut (14090) from Adapter
Casting and remove all gland parts.
17. To reassemble, reverse procedure. Tighten
fasteners per torque specifications provided.
IMPORTANT: To prevent damage to Air Piston Packing and
Pump Gland Packing, and to help increase packing life,
Lube Air Cylinder and Air Piston Rod before assembly.
NOTES:
1. If complete disassembly is required, replace all
Gaskets, 0-rings and Packings. (Order 236464 Repair
Kit.)
2. Before tightening four Valve Seat Screws (236870),
align Slide Plate (11482©), Valve Seat Gasket (38162)
and Air Valve Casting (236612©) by placing a rod or ink
pen through the center port hole.
3. Start all fasteners by hand to avoid stripping threads
when reassembling.
© Indicates Change
©
©
©
33039
Page Number - 4 Form 403295
Page Number - 5
Form 403295
Part Qty. Description Part Qty. Description
815 1 Aircoupler *35135 1 Gland packing
11470 1 Valve cap **38162 1 Valve seatgasket
11471 1 Collar,Trip Rod 40666 1 Adapter casting
11472 1 Trip rod pin 45605 1 Valve guide plate
11475 1 Trip shoe assembly 48212 2 Airpiston washer
11659 1 Airnipple 48237 1 Washer
11904 1 Packing nut 48448 1 Washer
11905 1 Packing cap 48511 1 Washer
11947 1 Sleeve,Trip 51009 4 Nut
12834 1 Spring retainer **55138 4 Spring
13300 1 Piston bolt 55231 1 Spring
14090 1 Gland packing nut 56038 2 Spring
14959 1 Gland packing spacer 61041 1 Aircylinder
14960 4 Tie rod 61502 1 Airpassage tube
14961 1 Piston rod 61570 1 Tube
14962 1 Coupling adapter *69102 2 Ball
14963 1 Bodycap 91331S 1 Toggle plate
*30003 1 Packing nutgasket 91964 1 Trip rod
*30011 1 Valve gasket 236286 1 Cover
*31050 1 Gland gasket 236612 1 Airvalve casting
*33014 2 Gasket 236615 1 Mufflercover
33039 1 Gasket *236616 1 Gasket
34090 1 Airpiston packing 236833 1 Mufflerpacking
*34110 1 Packing 236835 1 Packing
*34158 1 0-ring 236868 4 Screw
*34310 1 Packing 236869 6 Screw
*34368 2 O-ring 236868 4 Valve seatbolt
* Included in 236464 Repair Kit. 245425 1 Trip rod packing nut
** Included in 83063 Valve SeatAssembly.
SERVICE PARTS
Problem Solution
1.Pump does not operate. Check air supplyto air motor.
Replace 11475©Trip Shoe Assembly,
11947 Trip Sleeve and 91331 Toggle Plate
.
2.Air seepage from airexhaustport Replace 11482 Valve Slide©,14919 Valve
while pump is notoperating. Seat© & 38162 Valve Gasket©,236835 Trip
Rod Packing and 236616 Gasket.
3.Excessive amountofair entrapped in Replace 34310 Packing,35135 Gland
fluid orexcessive amountof fluid coming Packing and 31050 Gland Gasket.
from air exhaust.
Note: Some fluid exhausts with air
normally.
TROUBLESHOOTING
ACCESSORIES
Filter/regulator & Gauge/Lubricator
Eyebolt Kit
1709 Hoist
83321 Low Pressure Kit
84148 Wall mount Bracket Kit
© Indicates change
©
©
©
©
©
©
©
©
©
©
©
©
Page Number - 6 Form 403295
Americas:
One Lincoln Way
St. Louis, MO 63120-1578
USA
Phone +1.314.679.4200
Fax +1.800.424.5359
Europe/Africa:
Heinrich-Hertz-Str 2-8
D-69183 Walldorf
Germany
Phone +49.6227.33.0
Fax +49.6227.33.259
Asia/Pacific:
25 Int’l Business Park
#01-65 German Centre
Singapore 609916
Phone +65.562.7960
Fax +65.562.9967
© Copyright 2003
Printed in USA
Web site:
www.lincolnindustrial.com
