Lindy 6104 User manual

USB Guitar Cable
User Manual English
LINDY No. 6104
www.lindy.com
Garageband Introductions
Thank you for purchasing the LINDY USB Guitar Cable. This
high performance guitar cable is the perfect for use with
Garageband on your Mac.
This manual provides you with a quick guide on how to set up
the LINDY USB Guitar Cable to record guitar using Garageband.
Requirements
What you need-
•Mac with Garageband installed
•LINDY USB Guitar Cable
•A guitar/bass
•Speakers/headphones
Installation
Firstly power up your Mac and plug the USB Guitar Cable into a
spare USB port. There is no need to install any special drivers.
To check that the cable is installed properly take a look at your
Sound settings in System Preferences:
Under the Input tab, make sure C-Media USB Audio Device is
highlighted. Next plug the cable into your guitar (you won’t hear
anything yet). Now adjust your Input Volume by setting it rather
low to avoid distortion. Once you are up and running, adjust the
settings while playing to get the perfect sound.
Next, turn your attention to the Output tab. Make sure that Built-
in Audio is highlighted, this can also be selected later:
You can now close the Sound window. Next, see your Audio
MIDI Setup. This is found in Applications>Utilities folder:

Select the Audio Devices tab. Make sure the default input is set
to C-Media USB Audio Device and that both Default Output
and System Output are set to Built-in Audio. You can now
close the Audio MIDI Setup folder.
Recording in Garageband
(Note: these instructions are for Garageband 2.02, layouts and
menus of other versions may be slightly different)
Launch Garageband and select the Preferences menu. This is
under the Garageband menu. Select Audio/MIDI and set the
settings to match those below:
Now close the Preferences window and create a new track in
Track>NewTrack. Make sure real instrument is selected and
guitars. Now select one of the example sounds, such as Classic
Rock. You MUST now select On next to the monitor option
otherwise you won’t hear anything you play. After this is selected
you should now hear something, even if it’s just noise.
Note: if you can’t hear anything you may have forgotten to turn
your guitar volume control up.
Now you can adjust and alter different amp simulation types,
effects settings etc.
Note: you will almost definitely want to tinker with the noise
settings as your pickups may be too loud, especially when using
distortion effects
Tip: for the best results keep an eye on your input levels
Latency
Note: latency occurs when there is a notable delay from the time
you hit the strings to the sound coming out of the speakers.
Tip: if you experience any Latency issues try this:
Press record, wait a few seconds and then press stop. Now try
playing again and the latency issues should be gone.
LINDY No. 6104
1
st
Edition August 2009
