LINDY USB Extender
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Fançais
Manuale d’uso Italiano
LINDY No. 42801
www.LINDY.com
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION(Mar-2003)
English Manual
Deutsches Benutzerhandbuch
I
ntroduction
The LINDY USB EXTENDER can be used to extend the
distance between a USB device and a host computer by up
to 50m / 150 feet. It consists of a local unit with USB TypeA
connector (host computer side) and a remote unit (device
side with built in USB type A female connector). Standard
Category 5 Network cable (UTP or STP) up to 50m length
(150 feet) is used to connect the two units.
For cert
a
in USB Low Speed devices like USB mice it may be
p
ossible to extend the distance even further up to 100m. This
w
ill depend very much on the device connected, as this
extended distance may not be guaranteed. In most cases
USB 1.1 Full Speed data transfer (
1
2Mbps) will not work over
e
xtended distances but is guaranteed to work up to 50m (150
feet).
Specification
USB INTERFACE: USB 1.1 type operation
Interconnect UTP/STP cable length up to 50m / 150 feet
Equivalent Hub Delay/Count: 20m / 60 feet 2 Hubs
30m / 100 feet 3 Hubs
50m / 150 feet 5 Hubs
Please note! The maximum number of hubs in any USB
connection from host to device cannot be more than 5
including any USB Hubs or Active Extension cables or the
equivalent Hub rating of this USB EXTENDER!
Therefore when using a 50m UTP/STP cable no extra
hubs or extension cables can be used between
computer and device!
Please note! When using a high current USB device
s
uch as
a modem, camera etc with the USB EXTENDER you must
connect the power supply supplied with the device!
Please note! The USB Extender does not support the USB
50uA maximum Suspend Mode current limit.
Technical Data
Supply Current Drawn: 20~40mA
Operating Temperature: 0~40°C
Storage Temperature -40~85°C
Caution!
This unit does not fully meet all USB Specifications and as
such does not register with the USB bus. It is capable of
extending the maximum distance of 5m imposed by USB by
one USB segment only. Please consider these limitations
otherwise the USB bus may not function correctly! It should
also be connected to an exclusive USB port on your
computer.
E
inführung
Der LINDY USB-EXTENDER wird verwendet um Distanzen
zwischen Computer und USB Geräten auf bis zu 50m zu er-
w
eitern. Er besteht aus einer lokalen Einheit (mit USB-
K
abel mit
Typ A Stecker, Computerseite) und einer Remote-Einheit
(Device-Seite mit eingebauter USB Typ A Buchse). Zur Ver-
bindung werden Standard-Netzwerkkabel bis zu 50m Länge
(Kategorie 5 oder höher) verwendet.
Für einige Low Speed USB Geräte wie Mäuse können auch
Distanzen bis 100m überbrückt werden, LINDY übernimmt
j
edoch keinerlei Verantwortung für das Funktionieren bei
Distanzen oberhalb von 50m. USB 1.1 Full Speed Datentrans-
fer mit 12Mbps wird oberhalb von 50m höchstwahrscheinlich
nicht korrekt funktionieren.
Spezifikation
USB INTERFACE: Typ USB 1.1 Funktion
Kabellänge für Netzwerkkabel (UTP/STP Cat.5) bis 50m
Äquivalenz-Hub-Signalverzögerung : 20m 2 Hubs
(Entspricht einer Anzahl von Hubs) 30m 3 Hubs
50m 5 Hubs
Achtung 1: Die Maximale Anzahl von Hubs in USB-Bussen
vom Computer bis zum letzten Device darf 5 nich
überschreiten! Einschließlich anderer Hubs oder Aktivverlänge-
rungen und der Äquivalenz-Hub-
A
nzahl dieses Extenders nach
Distanz (siehe oben)! Bei Einsatz eines 50m Verbindungs-
kabel darf daher
k
ein weiterer Hub zwischen Computer und
USB Device verwendet werden!
Achtung 2: USB High Current Devices wie USB-Modem etc.
müssen immer mit eigenem Netzteil verwendet werden!
Achtung 3: Dieser USB Extender unterstützt nicht das USB
50µA Suspend-Mode Stromlimit.
Technische Daten
Typischer Stromverbrauch: 20~40mA
Zulässiger Temperaturbereich für Betrieb: 0~40°C
Zulässiger Temperaturbereich für Lagerung: -40~85°C
! WARNUNG !
Dieser USB Extender erfüllt nicht alle USB Spezifikationen.
Daher kann er auch die maximale USB-Segmentlänge von 5m
überschreiten! Er registriert sich nicht im USB Bus beim Host.
Alle oben genannten Punkte müssen durch den Nutzer selbst
beachtet werden. Bei Überschreitung der Angaben kann das
Funktionieren nicht garantiert werden. Bei Verwendung von
50m Verbindungskabel darf kein weiteres Device zwischen
Computer und Endgerät eingesetzt werden!
F
or Home and Office Use
Tested to Comply with FCC Standards
USB Extender
Local Unit
(Computer side)
C
at.5 extension
cable 5…50m
not included
U
SB Extender
Remote Unit
(Device side)

Radio Frequency Energy, Certifications
Shielded cables must be used with this equipment to maintain
compliance with radiofrequency energy emission regulations and
ensure a suitably high level of immunity to electromagnetic
disturbances.
FCC Warning
This equipment has been tested and found to complywith the
limits for a Class B Digital device, pursuant topart 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in aresidential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
!Reorient or relocate the receiving antenna
!Increase the separation between the equipment and receiver
!Connect the equipment into an outlet on a circuit different from
that towhich the receiver is connected
!Consult the dealer or an experienced technician for help
You are cautioned that changes or modifications not expressly
approved by the party responsible for compliance could void your
authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This devicemust accept any interference received, including
interference that may cause undesired operation
LINDY No. 42801
© LINDY ELECTRONICSLIMITED & LINDY-ELEKTRONIK GMBH - First Edition - MAR 2003
Manuel Utilisateur
Manuale d’uso
I
ntroduction
L’ USB EXTENDER peut être utilisé pour étendre la distance
entre un ordinateur et un périphérique USB jusqu’à 50 mètres.
Cela consiste en une unité locale avec connecteur USB Type
A (côté ordinateur) et une unité distante (côté périphérique)
avec connecteur USB type A femelle intégré. Un câble Cat. 5
STP standard est utilisé pour connecter les deux boîtiers.
Pour certains périphériques USB bas débit, il est possible
d’étendre la longueur de connexion à 100m maximum.
Ceci n’est tout de même pas garanti.
Spécifications
INTERFACE USB: Type USB 1.1
Interconnexion par cable UTP/STP jusqu’à 50m
Equivalent avec connexion de Hubs:
20m 2 Hubs
30m 3 Hubs
50m 5 Hubs
Remarque Importante 1:
L
e nombre maximum de hubs pour
une connexion ne doit pas dépasser 5 hubs ! Si vous utilisez
un câble de 50m UTP/STP vous n’aurez pas besoin de
connecter de hubs supplémentaires!
Remarque Importante 2: Si vous utilisez un périphérique
consommant beaucoup de puissance, comme des modems,
etc…., vous devez obligatoirement utiliser l’alimentation
fournie avec ce périphérique!
Remarque Importante 3: Cette extension USB ne supporte
pas le mode suspend 50µa.
Données Techniques
Consommation: 20~40mA
Température d’utilisation: 0~40°C
Température de stockage -40~85°C
! ATTENTION !
Cet appareil ne répond pas à toutes les spécifications USB.
Il permet d’étendre la longueur maximale de 5m de la norme
USB pour un segment.
Il se peut que le port USB ne fonctionne pas correctement si
vous connectez plusieurs périphériques en supplément de
l’extension.
I
ntroduzione
Il Lindy USB EXTENDER permette di utilizzare periferiche
USB fino a 50 m di distanza da
l
computer. Questo sistema è
composto da un unità locale con un connettore USB tipo A
(lato del computer Host) ed un’unità remota con connettore
U
SB tipo A femmina (lato periferica) . Per connettore questo
due unità si utilizza un cavo per reti locali standard Cat. 5
(UTP o STP) lungo fino a 50 m.
P
er alcune periferiche USB a bassa velocità come i mouse è
possibile raggiungere una distanza fino a 100m ma questa
caratteristica on può essere garantita.
Specifiche:
INTERFACCIA USB: USB 1.1
Lunghezza cavo UTP/STP di interconnessione fino a 50m
Numero di Hub/Ritardo Equivalente: 20m -> 2 Hub
30m -> 3 Hub
50m -> 5 Hub
Raccomandazioni:
1: Il numero massimo di Hub in una connessione USB dal
PC alla periferica non può essere superiore a 5 inclusi
qualsiasi Hub USB, prolunga attiva o il numero di Hub
equivalenti di questo USB Extender!
Di conseguenza usando un cavo UPT/STP da 50 non si
p
otranno utilizzare altri Hub USB o prolunghe attive fra il PC
e la periferica.
2: Se utilizzato periferica USB ad alto assorbimento di
corrente (Modem, Drive Esterni, ecc..) con questo Extender
ricordatevi di collegare sempre l’alimentatore fornito in
dotazione
Caution 3: Questo extender non supporta il sistema di
sospensione automatica con limite a 50uA.
Dati Tecnici
Corrente assorbita: 20~40mA
Temperature di funzionamento: 0~40°C
Temperature di conservazione -40~85°C
! ATTENZIONE !
Q
uesta unità non rispetta completamente le specifiche USB
per cui esso può estendere oltre i 5m imposti dalla specifi
c
a
s
olo un segmento USB. Non verrà inoltre registrato nel BUS
USB. L’utente deve tener conto di tutte le raccomandazioni
precedentemente descritte; in caso contrario il BUS USB
potrebbe non funzionare correttamente. Questa periferica
dovrebbe essere connessa direttamente ad una porta USB
