DESCRIPTION The Delta-3 DR4V & DR4-12 digital receivers are
four-channel wireless radio controls designed for use with
automatic garage/gate operators and access control systems. The
receivers can be activated by any of the Delta-3 format
transmitters. Receivers must be mounted at least 8 feet apart.
The Delta-3 radio format provides 256 different digital codes. The
codes are set using the 8-position coding switches in the units.
✶
CAUTION: All transmitters and receivers should be
recoded by the installer prior to operation.
In order to avoid the possibility of duplicating codes in adjacent
systems, factory set codes should not be used. In addition, among
the valid codes available, four others should not be used. These
include: all keys set ON or OFF and keys set alternating ON/OFF.
Activate each transmitter to test the equipment.
☞WARNING! BE SURE DOOR OR GATE
AREAS ARE CLEAR OF OBSTRUCTIONS
STEP 1
Locate coding switch.
Locate the digital coding switch
which is recessed in the center of the back of the receiver case.
Notethatthecodingswitchhaseightkeys.Thekeysarenumbered
1 through 8. Key No. 1 and Key No. 2 are not used for coding the
receiver; their functions are permanently wired on the circuit
board.
STEP 2
Code the receiver.
Pick any combination of ON/ OFF
codes and set them on switch keys 3 through 8. Ignore Keys 1 and
2. The ON position is when the top of the switch is down. The OFF
position is when the top of the switch is up and the bottom is down.
The code set on Keys 3 through 8 on the receiver must now be
matched by all transmitters used in the system.
STEP 3
Code the transmitters.
Remove the battery access door
located onthebackof the transmittercase to settransmittercodes.
Transmitter keys 1 and 2 determine which channel the transmitter
will activate. Keys 3 through 8 must match keys 3 through 8 on
the receiver. Refer to transmitter code set instructions to code
multi-button transmitters.
STEP 4A
Connecting receiver (using transformer power).
A
Model T12A (used with DR4-12) or 524 (used with DR4-V)
transformer can be used to power the receiver when connecting
receiver to any operator. Connect as shown, then plug the
transformer into a convenient (unswitched) 120 VAC outlet.
STEP 4B
Connecting receiver (using operator power).
Connect the receiver to the garage door or gate operator as shown
in the diagram. Power will be supplied from the operator.
STEP 5
Connecting receiver to 3-button commercial operator.
Connect normally open outputs to up and down inputs. Connect
normally closed output in series with the stop output. Connect
receiver power input to operator radio power or transformer
.
