LINET Sprint 100 Parts list manual

Sprint 100
Universal Transport Stretcher
D9U001ES1-0101
Version: 08
Publication Date: 2021-08
Instructions for Use
and Technical Description

D9U001ES1-0101_082
Manufacturer:
L I N E T spol. s r.o.
Želevčice 5
274 01 Slaný
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
http://www.linet.com
Service department: [email protected]
Sprint 100
Universal Transport Stretcher
Author: L I N E T, s.r.o.
Related links: www.linet.com
D9U001ES1-0101
Version: 08
Publication Date: 2021-08
Copyright © L I N E T, s.r.o., 2021
Translation © L I N E T, 2021
All rights reserved.
All trademarks and brands are the property of the appropriate owners. The manufacturer reserves the right to changes in the
contents of the instructions for use that relate to the product´s technical regulations. It is for this reason that the contents of the in-
structions for use may indicate di󰀨erences from the current manufacture of the product. Reproduction, also excerpts, only with prior
permission of the publisher. Subject to changes due to technical developments. All technical data are rated data and are subject to
construction and manufacturing tolerances.

D9U001ES1-0101_08 3
 .............................................4
1.1 Warning Notices..........................................................4
1.1.1 Types of Warning Notices ........................................4
1.1.2 Structure of Warning Notices ...................................4
1.2 Instructions..................................................................4
1.3 Lists.............................................................................4
1.4 Symbols on the Package ............................................5
1.5 Symbols on the Bed....................................................6
1.6 Symbols on the Mattress ............................................9
1.7 Serial Label with UDI ..................................................10
1.8 Denitions ...................................................................11
1.9 Abbreviations ..............................................................11
2 Safety Instructions.......................................................12
3 Intended use (Sprint 100) ............................................ 14
3.1 User population...........................................................14
3.2 Contraindications ........................................................14
3.3 Operator......................................................................14
4 Intended use (Sprint 100 mattresses) ........................ 14
4.1 User population...........................................................14
4.2 Contraindications ........................................................14
4.3 Operator......................................................................14
5 Product Description.....................................................15
 ...............................................17
6.1 Identication of Applied Parts (Type B) ....................... 17
6.2 Mechanical Specications ..........................................17
6.2.1 Sprint 100 with Standard Mattress Support Platform
..........................................................................................17
6.2.2 Sprint 100 with Wide Mattress Support Platform .....18
6.3 Environment Conditions (Sprint 100) .......................... 19
7 Use and Storage Conditions.......................................19
8 Scope of Delivery and Bed Variants........................... 20
8.1 Delivery .......................................................................20
8.2 Scope of Delivery........................................................20
8.3 Sprint 100 Variants......................................................20
9 Putting into Service .....................................................21
9.1 Mattress Support Platform ..........................................22
9.2 Potential Interconnection (optional) ............................23
9.3 Before Use ..................................................................23
9.4Transport.....................................................................23
10 Manipulation...............................................................25
10.1 Collapsible Siderails..................................................26
10.2 Castor Control...........................................................27
10.2.1 Braked Bed ............................................................28
10.2.2 Forward Movement (Steering) ...............................28
10.2.3 Unrestricted Movement..........................................29
10.3 Bed Positioning .........................................................30
10.3.1 Backrest .................................................................30
10.3.2 Thighrest (only 4-part Mattress Support Platform).31
10.3.3 Calfrest (only 4-part Mattress Support Platform) ...32
10.3.4 Lifting ....................................................................33
10.3.5 Lowering ...............................................................34
10.3.6 Trendelenburg Position ..........................................35
10.3.7 Anti-Trendelenburg Tilt ........................................... 36
10.3.8 Cardiac Chair Position (only 4-part Mattress Support Plat-
form) .................................................................................37
10.4 CPR Backrest Release .............................................38
10.4.1 The 2-part Mattress Support Platform....................38
10.4.2 The 4-part Mattress Support Platform....................39
11 Equipment...................................................................40
11.1 Accessory Holders (optional).....................................40
11.2 Accessory Rail with plastic hooks..............................41
11.3 DIN Rail .....................................................................42
11.4 Undercarriage Cover.................................................43
11.5 FlexiDrive (Sprung Retractable Fifth Castor) ............ 43
11.6 IV&Drive (Foldable Infusion Stands) .........................44
11.7 Handles .....................................................................45
11.7.1 Removable handles................................................45
11.7.2 Foldable handles....................................................46
11.7.3 Fixed handles.........................................................47
11.8 Angle Indicators (optional).........................................47
11.9 Examination with C-arm (in-bed uoroscopy) ........... 48
12 Mattress ......................................................................49
12.1 Anti-slip coating.........................................................50
12.2 Installation of Passive Mattress ................................50
12.2.1 Straps with side release buckles............................50
12.3 Mattresses Specications .........................................52
12.3.1 Sprint 100 with Standard Mattress Support Platform
..........................................................................................52
12.3.2 Sprint 100 with Wide Mattress Support Platform ...53
12.4 Cleaning of Passive Mattress ...................................54
12.4.1 General Guidance..................................................54
12.4.2 Routine Cleaning and Disinfection.........................55
12.4.3 Complete Cleaning and Disinfection......................55
12.4.4 Mattress Core ........................................................55
13Accessories ................................................................56
13.1 Infusion Stand ...........................................................57
13.2 Telescopic Infusion Stand .........................................58
13.3 Chart Holder..............................................................58
13.4 Monitor Shelf.............................................................59
13.5 Paper Roll Holder......................................................60
13.6 Storage Space ..........................................................60
13.7 Oxygen Bottle Holder................................................61
13.8 X-Ray Cassette Holder (optional) .............................62
13.8.1 Instructions for X-Ray Examination........................67
14 Cleaning/Disinfection ................................................69
14.1 Cleaning (Sprint 100) ................................................70
14.1.1 Cleaning before Changing Patients .......................70
14.1.2 Daily Cleaning........................................................70
14.1.3 Complete Cleaning and Disinfection......................71
15 Troubleshooting .........................................................71
16 Maintenance ...............................................................72
16.1 Regular maintenance................................................72
16.2 Spare Parts ...............................................................72
16.3 Safety Technical Checks...........................................72
17 Disposal ...................................................................... 73
17.1 Environment Protection.............................................73
17.2 Disposal ....................................................................73
17.2.1 Within Europe ........................................................73
17.2.2 Outside Europe ......................................................73
18 Warranty...................................................................... 73
19 Standards and Regulations ......................................73
Table of Contents

D9U001ES1-0101_084
1 
1.1 Warning Notices
1.1.1 Types of Warning Notices
󰀨
► CAUTION warns about the risk of material damage.
► WARNING warns about the risk of physical injury.
► DANGER warns about the risk of fatal injury.
1.1.2 Structure of Warning Notices
SIGNAL WORDS!
Type and source of danger!
► Measures to avoid the danger.
1.2 Instructions
Structure of instructions:
► Perform this step.
Results, if necessary.
1.3 Lists
Structure of bulleted lists:
 List level 1
 List level 2
List level 3

D9U001ES1-0101_08 5
1.4 
FRAGILE, HANDLE WITH CARE
THIS WAY UP
KEEP DRY (PROTECT FROM HUMIDITY)
PAPER RECYCLING SYMBOL
DO NOT USE HAND TRUCK HERE
DO NOT STACK DURING STORAGE

D9U001ES1-0101_086
1.5 Symbols on the Bed
READ INSTRUCTIONS FOR USE
SAFE WORKING LOAD
WARNING AGAINST CRUSHING OR TRAPPING
JACK FOR ATTACHMENT OF CONDUCTOR FOR POTENTIAL
EQUALISATION
POSSIBLE RISK
APPLIED PARTS TYPE B
ONLY SUITABLE FOR INDOOR USE
MAXIMUM WEIGHT OF PATIENT
WEIGHT OF BED (depending on con guration)
CE MARKING
RECYCLING SYMBOLS
DO NOT POLLUTE THE ENVIRONMENT

D9U001ES1-0101_08 7
MAXIMUM LOAD OF THE MONITOR SHELF 15 KG
PLACE MONITOR ON THIS SIDE OF THE MONITOR SHELF
MAXIMUM LOAD OF THE MONITOR SHELF 15 KG
DO NOT PLACE MONITOR ON THIS SIDE OF THE MONITOR SHELF
INSTRUCTION FOR PLACEMENT OF THE MONITOR SHELF
(L=LEFT, R=RIGHT)
MAXIMUM LOAD OF ONE HOOK 5 KG
FOLD THE MARKED FOLDABLE INFUSION STAND AS THE FIRST ONE
MAXIMUM LOAD OF ONE HOOK 5 KG
FOLD THE MARKED FOLDABLE INFUSION STAND AS THE SECOND ONE
MANUFACTURER
MANUFACTURING DATE
REFERENCE NUMBER
(PRODUCT TYPE DEPENDING ON CONFIGURATION)
SERIAL NUMBER

D9U001ES1-0101_088
MEDICAL DEVICE (COMPATIBLE WITH MEDICAL DEVICE REGULATION)
WEEE SYMBOL (RECYCLE AS ELECTRONIC WASTE,
DO NOT PUT INTO THE HOUSEHOLD WASTE)
BATCH NUMBER (ACCESSORIES)
UNIQUE DEVICE IDENTIFICATION (FOR MEDICAL DEVICES)
MASS OF MOBILE HOSPITAL BED (MASS OF EMPTY BED + SAFE WOR-
KING LOAD)
Fig. Warning, read
instructions for use

D9U001ES1-0101_08 9
READ INSTRUCTIONS FOR USE
CE MARKING
COVER MATERIALS ARE FIRE RESISTANT
TO BS7175, SOURCE 0, 1 AND 5
DO NOT IRON
DO NOT USE PHENOL
DO NOT WRING
REGULARLY INSPECT THE INSIDE OF THE COVER FOR CONTAMINATION
MACHINE WASH AT MAX. 71°C FOR 3 MINUTES
DISINFECT USING SOLUTION CONTAINING LESS THAN 1000 ppm OF
CHLORINE (REFER TO INSTRUCTIONS FOR USE)
RINSE WITH WATER
1.6 Symbols on the Mattress

D9U001ES1-0101_0810
TUMBLE DRY ON LOW HEAT SETTING (MAX. 60°C)
MATTRESS FOOT PART
HANDWASH WITH DETERGENT (INITIAL TEMPERATURE OF HOT WATER
SHOULD NOT EXCEED 50°C)
1.7 
There is a serial label of the bed under the Backrest.
Fig. Position of serial label on the bed

D9U001ES1-0101_08 11
1.8 
 the pricelist model conguration, not including a mattress
Bed Weight The value depends on the product conguration, accessories or
customer adjustments.
Clearance of Undercarriage the height from the oor to the lowest point of the undercarriage
between the castors, for the manipulation of accessories under a
braked bed in the standard position
Reference number Reference number depends on conguration.
 the highest allowable load on the bed (patient, mattress, accesso-
ries and the load supported by those accessories)
Siderail Height the height of the upper crossbar or the edges of the siderails (not
the highest point of the siderail controls) from the patient surface
Standard Bed Position - The height of the mattress support platform with regard to the
oor is 56,5 cm (2-part Mattress Support Platform) or 55,5 cm (4-
part Mattress Support Platform)
- The Mattress Support Platform, including the individual parts, has
to be in a horizontal (level - 0°) position.
- The siderails are always locked in the upper position.
Adult Patient having a physical size equal to or more than 146 cm, a
mass equal to or more than 40 kg and a body mass index (BMI)
equal to or more than 17 (according to IEC 60601-2-52).
Mass of mobile hospital bed Sum of empty bed mass and Safe Working Load.
CE European Conformity
CPR Cardiopulmonary Resuscitation
dBA Sound Intensity Unit
CUC Conguration number
HPL High Pressure Laminate
ICU Intensive Care Unit
IV Intravenous
ON Activation
OFF Deactivation
ppm parts per million, millionth (1000 ppm = 0,1%)
REF Reference Number (product type depending on conguration)
SN Serial Number
SWL Safe Working Load
UDI Unique Device Identication (for medical devices)
WEEE Waste Electrical and Electronic Equipment
1.9 Abbreviations

D9U001ES1-0101_0812
2 Safety Instructions
WARNING!
Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the

WARNING!
This medical device is not intended for oxygen enriched environment!
WARNING!

WARNING!
This medical device is not portable medical electrical equipment!
WARNING!



WARNING!
󰀨
WARNING!
-
-
re!
WARNING!

support platform!

D9U001ES1-0101_08 13
Additional instructions for correct use:
► Follow the instructions for use carefully.
► Use the bed exclusively if it is in perfect working order.
► If necessary, check the bed functions daily or at each shift change.
► Ensure any user has read and understood this manual completely before operating the product.
► Ensure that the bed is operated exclusively by qualied personnel who have been trained according to the instructions for
use.
► Ensure that the patient (health permitting) has been informed about the operation of the bed and all applicable safety
instructions.
► Move the bed exclusively on even, hard-surfaced oors.
► Replace any damaged parts immediately with original spare parts.
► Ensure that maintenance and installation are performed exclusively by qualied personnel who have been trained by the
manufacturer.
► Before peak loads or unavoidable excess loads (CPR), place Mattress Support Platform in the lowest position.
► Ensure that only one adult patient uses the bed at any time.
► Take care to avoid injuries or squeezing when operating moving parts.
► When using lifting poles or infusion stands, ensure that nothing will be damaged when you move or adjust the bed.
► Brake the castors when the bed is occupied.
► Keep the Mattress Support Platform in the lowest position at any time when the healthcare personnel are not treating the
patient in order to prevent the patient from falling or injuries.
► Ensure that Siderails are operated exclusively by healthcare personnel.
► Never use the bed in areas where there is a hazard of explosion.
► Ensure that parts of the bed intended for movement are not blocked.
► To prevent failures, use exclusively the manufacturer’s original accessories and mattresses.
► Ensure that the stipulated safe working load is not exceeded.
► If the patient‘s condition could lead to an entrapment, leave the mattress support platform in the at position whilst una-
ttended.
► Adjust bed height when transporting the bed in order to facilitate overcoming possible obstacles.
► Do not modify bed and its components without the manufacturer´s approval.
► Use the mattress system exclusively as specied in this manual and in perfect working order.
► Use the mattress system exclusively in its original state and do not modify it in any way.
► Have the mattress system used exclusively by or under supervision of trained and qualied nursing personnel.
► Have the mattress system serviced and installed exclusively by qualied personnel trained and authorised by the manu-
facturer.
► Do not exceed the maximum patient weight limit (see Mechanical Specications).
► Do not use the bed in the case its parts have been removed unless these parts are designed to be removed.
► To avoid injury or crushing, take extra caution when operating any moving parts of the bed.
► When using infusion stands, ensure that nothing will be damaged when you move or adjust the bed.
► Hydraulic units and gas springs cointain an mineral oil. These mineral oils should not get into the sewerage because of
toxicity for water organisms.

D9U001ES1-0101_0814
3 Intended use (Sprint 100)
-

► Patient transport in the stretcher in the indoor environment. For the outdoor environment specic precautions in the in-
structions for use are valid.
► Adjustment of the positions needed for the, examinations, treatments, physiotherapy, sleeping, relaxation, preventive and
mobilization reasons, routine nursing. These positions are further specied and described in the clinical evaluation of this device,
together with their potential clinical outcomes and benets.
► Providing the safe environment for the patient during all relevant procedures. The particular requirements on patient safety
are the subject of the clinical evaluation, including evaluation of the risk/benet ratio. The relevant safety issues are the part of the
risk management le.
► Providing the suitable working conditions for the caregivers to perform the routine and specic tasks during the patient
hospitalization.
3.1 User population
► Adult patients (weight >= 40 kg, height >= 146 cm, BMI >= 17) in the emergency and one day care units (Application Envi-
ronment 1, 2 and 5 as in IEC 60601-2-52)
► Caregivers (nurses, doctors, technical personnel, transport personnel, cleaning personnel)
3.2 Contraindications
► The medical device is not intended for the pediatric patients use.
► The medical device is not intended for the use with patients exceeding the Maximum Patient Weight and whose body
constitution is disproportionate to the size of Mattress Support Platform.
► The medical device is not intended for the long-term hospitalization with respect to dimensional parameters of the device
and the used mattress.
► Certain positions are not suitable for specic diagnoses/medical conditions (e.g. spinal cord injuries vs. Fowler position,
higher ICP patients vs. Trendelenburg). Sta󰀨 expert assessment / nursing consideration is needed in all individual case of contrain-
dication.
3.3 Operator
► Caregiver
► Patient (based on individual patient status assessment by caregiver the patient can utilize dedicated device functions)
4 Intended use (Sprint 100 mattresses)
The intended use is provide basic support surface for patient being treated on LINET’s sprint range of Stretchers only. They are
designed to provide comfort and reduce likelihood of pressure ulcers during short term use. The use of these mattresses does not
remove the need for regular repositioning in line with best clinical practice (ref: NPUAP, EPUAP).
4.1 User population
► Adult patients (weight >= 40 kg, height >= 146 cm, BMI >= 17) in the emergency and one day care units (Application Envi-
ronment 1, 2 and 5, as in IEC 60601-2-52)
► Caregivers (nurses, doctors, technical personnel, transport personnel, cleaning personnel)
4.2 Contraindications
► patient with higher risk of pressure ulcers than the mattress is designed for
► patients with higher weight than mattress weight limit
► patient’s showing signs of pressure related tissue damage should be stepped on onto an alternative support surface ba-
sed on risk assessment, clinical reasoning and best clinical practice (EPUAP, NPUAP guidelines)
4.3 Operator
► Caregiver

D9U001ES1-0101_08 15
5 Product Description
SPRINT 100 WITH 4-PART MATTRESS SUPPORT PLATFORM
1. Mattress Support Platform
2. Collapsible Siderail
3. Thighrest Handle
4. Bushings for Accessories
5. Corner Bumper
 
7. Siderail Release Mechanism
8. Thighrest Control
 
 
 
12. Lifting Pedal
 
14. Castor
15. Siderail Release Mechanism (optional)
 
Fig. Bed Overview (Sprint 100 with 4-part Mattress Support Platform)
5
1213 11 10 96
7
8
14
2 3 41
15
16

D9U001ES1-0101_0816
SPRINT 100 WITH 2-PART MATTRESS SUPPORT PLATFORM
1. Mattress Support Platform
2. Collapsible Siderail
3. Bushings for Accessories
4. Corner Bumper
 
6. Siderail Release Mechanism
 
 
 
10. Lifting Pedal
 
12. Castor
13. Siderail Release Mechanism (optional)
 
Fig. Bed Overview (Sprint 100 with 2-part Mattress Support Platform)
4
1011 9875
6
12
2 31
13
14

D9U001ES1-0101_08 17
6 
All technical data are rated data and are subject to construction and manufacturing tolerances.
6.1 
All part of the bed (and accessories) the patient can reach are type B Applied Parts.
 Mattress Support Platform Frame, Parts of Mattress Support Platform
 Siderails
 Bed Ends
 Mattress
6.2 
6.2.1 
SPRINT 100 WITH 4-PART MATTRESS SUPPORT PLATFORM
Parameter Value
 211 cm x 76 cm
Siderail Height above Mattress Support Platform 4 cm (minimum), 36,5 cm (maximum)
Siderail Length 125 cm
 21 cm
 193 cm x 66 cm
Maximum Mattress Height 13 cm
Castor diameter 20 cm
Minimum-Maximum Mattress Support Platform Height above

55,5 cm - 88 cm
 90°
Maximum Thighrest Angle 40°
Maximum Calfrest Angle 21°
Trendelenburg/Anti-Trendelenburg Position (Angle) +18°/-18°
Bed Weight 
 320 Kg
Maximum Patient Weight 280 Kg

D9U001ES1-0101_0818
SPRINT 100 WITH 2-PART MATTRESS SUPPORT PLATFORM
Parameter Value
 211 cm x 76 cm
Siderail Height above Mattress Support Platform 3 cm (minimum), 35,5 cm (maximum)
Siderail Length 125 cm
 21 cm
 193 cm x 66 cm
Maximum Mattress Height 13 cm
Castor diameter 20 cm
Minimum-Maximum Mattress Support Platform Height above

56,5 cm - 89 cm
 90°
Trendelenburg/Anti-Trendelenburg Position (Angle) +18°/-18°
Bed Weight 
 320 Kg
Maximum Patient Weight 280 Kg
6.2.2 
SPRINT 100 WITH 4-PART MATTRESS SUPPORT PLATFORM
Parameter Value
 211 cm x 86 cm
Siderail Height above Mattress Support Platform 4 cm (minimum), 36,5 cm (maximum)
Siderail Length 125 cm
 21 cm
 193 cm x 76 cm
Maximum Mattress Height 13 cm
Castor diameter 20 cm
Minimum-Maximum Mattress Support Platform Height above

55,5 cm - 88 cm
 90°
Maximum Thighrest Angle 40°
Maximum Calfrest Angle 20,5°
Trendelenburg/Anti-Trendelenburg Position (Angle) +18°/-18°
Bed Weight 
 320 Kg
Maximum Patient Weight 280 Kg

D9U001ES1-0101_08 19
SPRINT 100 WITH 2-PART MATTRESS SUPPORT PLATFORM
Parameter Value
 211 cm x 86 cm
Siderail Height above Mattress Support Platform 3 cm (minimum), 35,5 cm (maximum)
Siderail Length 125 cm
 21 cm
 193 cm x 76 cm
Maximum Mattress Height 13 cm
Castor diameter 20 cm
Minimum-Maximum Mattress Support Platform Height above

56,5 cm - 89 cm
 90°
Trendelenburg/Anti-Trendelenburg Position (Angle) +18°/-18°
Bed Weight 
 320 Kg
Maximum Patient Weight 280 Kg
6.3 Environment Conditions (Sprint 100)
Parameter Value
Use Conditions
Ambient Temperature 10°C-40°C
Relative Humidity 30% - 75 %
Atmospheric Pressure 795 - 1060 hPa
Storage and Transport Conditions
Ambient Temperature -20°C- 50°C
Relative Humidity 20% - 90 %
Atmospheric Pressure 795 - 1060 hPa
7 Use and Storage Conditions

use and storage of the product.


D9U001ES1-0101_0820
8 Scope of Delivery and Bed Variants
8.1 Delivery
► Upon receipt, check that the shipment is complete as specied on the delivery note.
► Notify the carrier and supplier of any deciencies or damages immediately as well as in writing or make a note on the
delivery note.
8.2 Scope of Delivery
 Sprint 100 Universal Transport Stretcher
Instructions for use
8.3 Sprint 100 Variants

 2-part Mattress Support Platform
4x Tente 200 mm castors
 directional castor on head end
 directional castor on foot end
 Brakes from Head End and from Foot End
 Undercarriage Cover
 Siderails
 Foot Siderail Release Mechanism
Optional bed features:
 Mattress Support Platform
 4-part Mattress Support Platform
 Wide Mattress Support Platform
 Fifth Castor (FlexiDrive)
 Head and Foot Siderail Release Mechanism
 X-Ray Cassette Holder (2-part Mattress Support Platform)
 X-Ray Cassette Holder (4-part Mattress Support Platform)
 C-arm ready bed
 Siderails
 Siderail shock absorber (SoftDrop)
 Infusion stand and handles
 1x pair of Foldable handles (Head End)
 1x pair of Foldable handles (Foot End)
 1x pair of Foldable Infusion Stands (IV&Drive) and handles (Head End or Foot End)
 1x pair of Removable handles
 1x pair of Fixed handles
 Undercarriage
 Brakes on side
 Accessory Holders
 on side
 on Head End
 on Foot End
 Angle Indicators
 Backrest and Seat section of Mattress Support Platform (on side)
 Mattress Support Platform frame (on side in seat section)
Potential Interconnection
 with Potential Interconnection
 without Potential Interconnection
