Teknik 5427872 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS
IMPORTANT SAFETY
INFORMATION.
PLEASE READ AND KEEP
FOR FUTURE REFERENCE.
10/08/21 Lot # 572582
Purchased:
__________________
English pg 1-24
Français pg 25-28
Español pg 29-32
2-Drawer Mobile
Pedestal
Hudson Elm finish | Model 5427872
Teknik
www.teknikoffice.co.uk

Table of Contents Assembly Tools Required
Part Identification
Hardware Identification
Hardware Usage Guide
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
3
4
6
5-24
25-28
29-32
33-34
35
Page 2
Adjustable Wrench

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BACK (1)
D78 DRAWER BACK (2)
D581 RIGHT DRAWER SIDE (2)
D582 LEFT DRAWER SIDE (2)
D707 DRAWER BOTTOM (2)
E BOTTOM (1)
F BASE (1)
G DRAWER FRONT (1)
H LOCKING DRAWER FRONT (1)
Page 3
A
B
C
D
E
F
H
D78 D581
D707
D582
G
D78 D581
D707
D582

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
(EXTENSION SET SHOWN SEPARATED)
EXTENSION
SLIDE - 4
40MC
EXTENSION
RAIL - 4
40MA 10A SLIDE
CAM - 4 8B FILE ROD - 4 15B FILE GLIDE - 4 8CN NON-SWIVEL CASTER - 2
8CS SWIVEL
CASTER - 2 42F WOOD DOWEL - 16 4G METAL
BRACKET - 4 34G INTERLOCK
MECHANISM - 1 62G DRAWER ACTUATOR - 2
76G L - LOCK
BRACKET - 1 77G Z - LOCK BRACKET - 1 21J LOCK PACK - 1 202K PULL - 2 10M TOUCH-UP PEN - 1
1S BLACK 9/16" LARGE HEAD SCREW - 28 3S GOLD 5/16" FLAT HEAD SCREW - 16
37S BLACK 7/8" MACHINE SCREW - 4 51S BLACK 9/16" PAN HEAD SCREW - 3
Page 4
30S BLACK 1-9/16" FLAT HEAD SCREW - 8 11S BLACK 1/2" FLAT HEAD SCREW - 6

Page 5
Hardware Usage Guide
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
2.
Push a TWIST-LOCK® FASTENER
into the large hole in the part.
1.
HOW TO USE A TWIST-LOCK®FASTENER

å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Insert two WOOD DOWELS (42F) into the BACK (D).
å NOTE: You may need to gently tap the WOOD DOWEL in
with your hammer.
å Fasten the BOTTOM (E) to the BACK (D). Tighten one
TWIST-LOCK® FASTENER.
å NOTE: Be sure the WOOD DOWELS in the BACK insert
into the BOTTOM.
Step 1
Page 6
D
E
Surface with
TWIST-LOCK®
FASTENERS
Surface with
TWIST-LOCK®
FASTENERS
Just think. The sooner
you do this, the sooner
you do something else.
42F
42F

Step 2
Page 7
å Separate the EXTENSION SLIDES (40MC) from the EXTENSION RAILS (40MA) as shown in the upper diagram below. Be
prepared, the parts are greasy.
å Fasten two EXTENSION RAILS (40MA) to the RIGHT END (A). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through
holes #1 and #4.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlarged diagram. Then, slide the inner cartridge
of the EXTENSION RAIL in to find the other hole that lines up with the hole in the END. Turn a SCREW into this hole.
å NOTE: The EXTENSION SLIDES will be used later for the DRAWERS.
Push the black lever in and pull the SLIDE from the RAIL.
40MA40MC
1
2
3
4
A
1
2
3
4
Open end
These holes
must be here.
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Edge with
TWIST-LOCK®
FASTENERS

Step 3
å Fasten the INTERLOCK MECHANISM (34G) to the RIGHT END (A).
Use three BLACK 9/16" PAN HEAD SCREWS (51S).
å Fasten the L-LOCK BRACKET (76G) to the RIGHT END (A) exactly
as shown. Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
Page 8
BLACK 9/16" LARGE HEAD SCREW
(2 used for the BRACKET)
1S
A
34G
76G
BLACK 9/16" PAN HEAD SCREW
(3 used for the MECHANISM)
51S

å Insert four WOOD DOWELS (42F) into the
RIGHT END (A).
å NOTE: You may need to gently tap the WOOD DOWEL
in with your hammer.
å Fasten the BACK (D) and BOTTOM (E) to the RIGHT
END (A). Tighten four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the END and
insert into the BACK and BOTTOM.
Step 4
Page 9
A
D
E
42F
(4 used)

Step 5
Page 10
3
2
1
4
Open end
å Fasten two EXTENSION RAILS (40MA) to the LEFT END (B).
Use four GOLD 5/16" FLAT HEAD SCREWS (3S) through
holes #1 and #4.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the
hole shown in the enlarged diagram. Then, slide the inner
cartridge of the EXTENSION RAIL in to find the other hole that
lines up with the hole in the END. Turn a SCREW into this hole.
B
3
2
1
4
Edge with
TWIST-LOCK®
FASTENERS
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S

Step 6
Page 11
B
D
E
å Insert four WOOD DOWELS (42F) into
the LEFT END (B).
å NOTE: You may need to gently tap the WOOD DOWEL
in with your hammer.
å Fasten the LEFT END (B) to the BACK (D) and
BOTTOM (E). Tighten four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the BACK and
BOTTOM insert into the END.
42F
(4 used)

å Insert six WOOD DOWELS (42F) into the TOP (C).
å NOTE: You may need to gently tap the WOOD DOWEL in
with your hammer.
å Fasten the ENDS (A and B) and BACK (D) to the
ENDS (A and B). Tighten five TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the TOP insert into
the ENDS and BACK.
Step 7
Page 12
A
D
B
C
42F
42F
Now might be a
good time to refresh
your drink.
(6 used)

Step 8
å Fasten four METAL BRACKETS (4G) to the
ENDS (A and B) and BOTTOM (E). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edges of
the ENDS and BOTTOM.
å Fasten the BASE (F) to the METAL BRACKETS on the
ENDS and BOTTOM. Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
Page 13
4G
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S
4G
4G
A
B
E
F
Edge with
wrapped seam

å Fasten the CASTERS (8CN and 8CS) to the BOTTOM (E)
exactly as shown. Use sixteen BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 9
Page 14
BLACK 9/16" LARGE HEAD SCREW
(16 used in this step)
1S
E
8CN
8CS
The small tab
should be here.

å Fasten the Z-LOCK BRACKET (77G) to the
DRAWER FRONT (G). Use two BLACK 9/16"
LARGE HEAD SCREWS (1S).
Step 10
Page 15
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
1S
G
77G

Step 11
Page 16
With the palm of
your hand, tap
the DRAWER
BOTTOM down
into the groove.
å Fasten the DRAWER BACK (D78) to the DRAWER SIDES (D581 and D582). Use four BLACK 1-9/16"
FLAT HEAD SCREWS (30S).
å NOTE: Be sure the DRAWER BOTTOM (D707) inserts into the groove of the DRAWER BACK (D78).
å Repeat this step for the other drawer.
1 2
3
å Insert the DRAWER SIDES (D581 and D582) at an angle
into the slot at each end of the DRAWER FRONT (G). å Slide the DRAWER BOTTOM (D707) into the grooves in the DRAWER SIDES (D581 and D582) and
DRAWER FRONT (G).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
30S
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(8 used in this step)
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
G
D707
D707
D78
Unfinished
surface
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK groove.
D582
D581 D582
D581
G
D582
D581

Step 12
Page 17
å Insert a SLIDE CAM (10A) into each DRAWER SIDE (D581 and D582).
å Fasten the EXTENSION SLIDES (40MC) to the DRAWER SIDES (D581 and D582). Use four
GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4.
å NOTE: The screw head in the CAM must be visible through the slotted hole in the SLIDE.
å Repeat this step for the other drawer.
Open end 10A
Open end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S Drawer Slide
Center the screw in the oval hole.
1
2
3
4
1
2
3
4
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
D582
D581

å Fasten one PULL (202K) to the DRAWER FRONT (G). Use
two BLACK 7/8" MACHINE SCREWS (37S).
å Repeat this step for the other drawer.
Step 13
Page 18
G
202K
BLACK 7/8" MACHINE SCREW
(4 used in this step)
37S

å Fasten one DRAWER ACTUATOR (62G) to the RIGHT DRAWER
SIDE (D581) of the LOCKING DRAWER FRONT (H) exactly as
shown. Use three BLACK 1/2" FLAT HEAD SCREWS (11S).
å Fasten one DRAWER ACTUATOR (62G) to the RIGHT DRAWER
SIDE (D581) of the DRAWER FRONT (G) exactly as shown. Use
three BLACK 1/2" FLAT HEAD SCREWS (11S).
Step 14
Page 19
H
G
D581
D581
This DRAWER ACTUATOR
is closer to hole in the
LOCKING DRAWER FRONT.
This DRAWER ACTUATOR is
closer to the bottom edge of
the DRAWER SIDE.
62G
BLACK 1/2" FLAT HEAD SCREW
(6 used in this step)
11S

Step 15
Page 20
å Push a FILE GLIDE (15B) onto the RIGHT DRAWER SIDE (D581).
å Slide the FILE RODS (8B) into the FILE GLIDE (15B) on the RIGHT
DRAWER SIDE.
å Slide another FILE GLIDE (15B) onto the other end of the FILE RODS (8B),
then press this FILE GLIDE over the LEFT DRAWER SIDE (D582).
å Repeat this step for the other drawer.
Insert the FILE RODS into the holes
of your choice in the FILE GLIDES,
depending on your file sizes.
D582
D581
8B
15B
15B 8B
