Linus HEADLAMP User manual
HEADLAMP INSTALLATION
guide
HEADLAMP PARTS:
• Headlamp
• Rubbercoatedclamp
• Matting
• Brakeboltbracket
• ’L’Bracket
• M5X15mmbolt(Qty.2)
• Washers(Qty.4)
• 4mmLocknuts(Qty.2)
[SEE FIGURE 1.]
TOOLS NEEDED:
• 5mmHexWrench
• 8mmBoxWrench
[SEE FIGURE 2.]
BRAKE BOLT/FENDER BOLT MOUNT
ABOVE THE FRONT WHEEL
ClamptheHeadlampintotheBrakebolt
bracket,betweenarms,usingaBoltand
washer.Installtheoppositesquareendof
Brakeboltbracketbetweenbrakeandfork.
[SEE FIGURES 3. & 4.]
HARDWARE
NEEDED:
FIGURE 1.
FIGURE 2.
FIGURE 3.
FIGURE 4.
FIGURE 5.
HANDLEBAR MOUNT
ClampRubbercoatedclamparoundthe
handlebar,usemattingfortightert.Boltthe
‘L’BracketintheclampwithBolt,2Washers,
andLocknut.ClampHeadlamptootherendof
‘L’BracketusingaBolt,2Washers,&Locknut.
‘L’Bracketisparalleltothehandlebartoensure
theHeadlampispointedforward.
[SEE FIGURES 6. & 7.]
HARDWARE NEEDED:
FORK MOUNT
ClampRubbercoatedclamparoundthefront
forkashighontheforkaspossible.Boltthe
‘L’BracketintheclampwithaBolt,2Washers,
andLocknut.ClampHeadlamptootherend
of‘L’BracketusingaBolt,2Washers,&Locknut.
EnsureHeadlampispointedforward.
[SEE FIGURES 10. & 11.]
HARDWARE NEEDED:
FIGURE 6.
FIGURE 7.
FIGURE 8.
FIGURE 9.
FIGURE 11.
FIGURE 10.
TO SUCCESSFULLY INSTALL YOUR HEADLAMP:
