Lissmac SMD 123 RE User manual

OPERATING MANUAL
GRINDING MACHINE
SMD 123 RE
EN
LISSMAC Maschinenbau GmbH
Lanzstraße 4
D-88410 Bad Wurzach
Telephone [phone] / 307 - 0
Fax [phone] / 307 - 500
[email protected]om
www.lissmac.com
METAL PROCESSING

Grinding machine SMD 123 RE 3
Imprint
Operating manual for
Grinding machine SMD 123 RE
Status: 02-2019
Translation of the original operating manual
Manufacturer:
LISSMAC
Maschinenbau GmbH
Lanzstraße 4
D-88410 Bad Wurzach
Telephone: [phone] / 307 - 0
Fax: + 49 (0) 7564 / 307 - 500
E-mail: [email protected]
Web: www.lissmac.com
The dissemination or duplication of this operating manual and the reuse or disclosure of its
contents are forbidden unless explicitly permitted. Non-compliance is subject to
compensation for damages. All rights reserved for the purpose of patent, utility model, or
design patent registration.

Table of contents
4 Grinding machine SMD 123 RE
Table of contents
1About this manual ........................................................................................6
1.1Target group..........................................................................................6
1.2Additional documents..............................................................................6
1.3Presentation of warnings..........................................................................7
1.4Additional representations........................................................................7
2Safety .........................................................................................................8
2.1Safety instructions..................................................................................8
2.2Organisational measures..........................................................................8
2.3Personnel selection and qualifications.........................................................8
2.4Transport ..............................................................................................8
2.5Normal operation ...................................................................................9
2.6Maintenance, Service and Troubleshooting ..................................................9
2.7Safety instructions for special types of dangers.............................................9
2.7.1Electric power ...........................................................................9
2.7.2Dust .......................................................................................9
2.7.3Fire hazard..............................................................................10
2.7.4Explosion hazard ......................................................................10
2.7.4.1Description of explosion hazard .........................................10
2.7.4.2Division of zones ............................................................10
2.8Symbols on the machine ........................................................................11
3Product description....................................................................................12
3.1Appropriate usage ................................................................................12
3.2Technical data .....................................................................................13
3.3Type plate...........................................................................................15
3.4Set up of grinding machine .....................................................................16
3.5Control elements ..................................................................................18
3.6Machining units ...................................................................................19
3.7Function ............................................................................................21
3.8Safety equipment .................................................................................22
4Preparation for use ....................................................................................23
4.1Transporting the machine .......................................................................23
4.2Storing the machine ..............................................................................24
4.3Installation and assembly .......................................................................24
4.3.1Installing machine ....................................................................24
4.3.2Connecting the extractor system..................................................24
4.3.3Connecting the machine ............................................................26
5Operation ..................................................................................................27
5.1Control elements ..................................................................................27
5.2Operating the control and display field ......................................................28
5.2.1Screen set up ..........................................................................28
5.2.2Screen symbols........................................................................29

Table of contents
Grinding machine SMD 123 RE 5
5.2.3Setting the sheet thickness ........................................................30
5.2.4Selecting/deselecting R-device ...................................................31
5.2.5Adjusting the cutting speed ........................................................32
5.2.6Power input R-Head..................................................................33
5.2.7Selecting/deselecting E-device....................................................34
5.2.8Calling up password level screen .................................................35
5.2.9Calling up service pages ............................................................36
5.2.10Calling up error messages ..........................................................37
5.2.11Setting the feed speed ..............................................................38
5.3Turning on the machine..........................................................................38
5.4Putting the machine into operation ...........................................................39
5.5Processing material...............................................................................40
5.6Change grinding belt .............................................................................41
5.7Setting the grinding belt height ...............................................................42
5.8Replacing the grinding mops ...................................................................44
5.9Adjust the grinding mop height................................................................45
5.10Turning off the machine .........................................................................46
6“Warm up” for the SMD 123 RE....................................................................47
6.1Dressing grinding belt R-aggregate...........................................................47
6.2Dressing E-aggregate ............................................................................49
6.3Rasing „traction“ of conveyor belt ............................................................51
6.4Checking traction/adhesion of conveyor belt...............................................52
6.5Correct adjustment of aggregates ............................................................52
7Service .....................................................................................................53
7.1Service intervals...................................................................................53
7.2Lubricant table / Conveyor Belt Cleaner .....................................................54
7.3Tightening torque for standard metric thread ..............................................55
7.4Cleaning ............................................................................................56
7.5Cleaning of Conveyor Belt.......................................................................57
7.6Lubricating the guide blocks....................................................................58
7.7Checking the service unit for compressed air ..............................................59
8Troubleshooting.........................................................................................60
9Customer service .......................................................................................61
10Decommissioning and disposal...................................................................62
11Warranty ...................................................................................................63
12FOREWORD INSTALLATION DECLARATION ..................................................64

About this manual
6 Grinding machine SMD 123 RE
1About this manual
1.1 Target group
The operating manual is directed at the machine operator and the operating and maintenance
personnel.
This operating manual contains important information on how to operate the machine safely,
properly and economically.
Each person responsible for operating and maintenance work on the machine must have read and
understood this operating manual.
The operating manual is to be supplemented by directives for accident prevention and
environmental protection, according to national requirements.
In addition to this operating manual, country-specific regulations for accident protection and also
recognised technical regulations for safety and proper work are to be observed.
1.2 Additional documents
Additional documentation of the respective manufacturers of individual components of the
machine are available as supplements to this operating manual:
Documentation exhaust system

About this manual
Grinding machine SMD 123 RE 7
1.3 Presentation of warnings
In this operating manual warnings are presented according to the following examples:
SIGNAL WORD!
Type and source of danger
Consequences of non-compliance
Actions to avert the danger
The signal word under the danger symbol indicates the degree of danger:
DANGER
This signal word signifies an extremely dangerous situation. If the situation is not avoided,
fatal injuries will result. The danger symbol can specify the danger.
WARNING
This signal word signifies a potentially dangerous situation. If the situation is not avoided,
fatal or serious injuries can result. The danger symbol can specify the danger.
CAUTION
This signal word signifies a dangerous situation. If the situation is not avoided, medium to
slight injuries will result. The danger symbol can specify the danger.
NOTE
This signal word signifies a situation which presents risks to objects. If the situation is not
avoided, property damage will result. The signal word is present without a danger symbol.
1.4 Additional representations
In this operating manual important information is presented according to the following examples:
Import information is denoted by "i".
Texts, which request action, are marked by a triangle (). The immediate effect of this action is
marked as result ().
The positions of the figures are marked by numbers
(1) in parentheses.
Requests and results
Position numbers

Safety
8 Grinding machine SMD 123 RE
2Safety
2.1 Safety instructions
The SMD 123 RE grinding machine is constructed according to the state of the art and recognised
technical safety rules. However, during its use, danger for persons and property damage can occur.
The machine is to be used only for intended use in technically faultless condition and in
observance of safety instructions.
2.2 Organisational measures
Personnel authorised to work on the machine must have read and understood the operating
manual before starting work. This applies notably to personnel who only work occasionally on the
machine, e.g. for changeovers and service.
The operating manual is to be kept permanently at the machine location and easily accessible.
Perform checks for safe and hazard awareness work by operators while following the
operating manual.
If necessary or required by country-specific regulation, use personal protective clothing (e.g.
work gloves, safety glasses, hearing protection).
Observe all safety and danger instructions on the machine.
Keep all safety instructions and danger warnings on the machine complete and in legible
condition.
No changes, removal or addition of parts to the machine without the written approval of the
manufacturer.
Only use original replacement parts from the manufacturer.
Keep intervals for service work which are given in the operating manual.
2.3 Personnel selection and qualifications
Only authorised personnel of legal minimum age may work on the machine.
Personnel who are being trained or orientated on the machine may only work on the machine
under continuous supervision of an experienced person.
Only use trained or orientated personnel. Clearly establish responsibilities of the personnel for
operating, maintaining and servicing.
Establish a machine operator responsibility. The machine operator must refuse to follow
instructions that are contrary to safety.
2.4 Transport
Only use lifting gear and load carrying equipment with sufficient lifting capacity during loading
work (see Technical Data for weights).
Name an expert instructor for the lifting process.
Only lift the machine properly with the lifting gear according to instructions in the operating
manual. Only use the provided attachment points for the load carrying equipment.
Only use suitable transport vehicles with sufficient load capacity.
Reliably secure the machine during vehicle transport. Use suitable attachment points.
Perform recommissioning after transport only according to the operating manual.

Safety
Grinding machine SMD 123 RE 9
2.5 Normal operation
Before beginning work become familiar with the operating location and working environment.
The work environment includes, for example, work area obstructions and assistance options in
case of accidents.
Only operate the machine in a safe and functional condition.
Refrain from working in any manner that is questionable in regard to safety.
Immediately stop and secure the machine in case of malfunctions. Immediately correct
malfunctions.
At least once per shift (display indication) check the machine for externally recognisable
damage and deficiencies. Report any changes occurring (including operating behaviour) to the
responsible department or person. If necessary, immediately stop the machine and secure it.
2.6 Maintenance, Service and Troubleshooting
Adjustment, maintenance and service work may only be carried out by authorised technical
personnel.
Perform adjustment, maintenance and service work according to instructions in the operating
manual. Keep the specified intervals for service work.
Inform operating personnel before beginning adjustment, repair, or maintenance work. Name
a supervisor.
Always disconnect the machine from electrical power during maintenance and repair work
(main switch in the 0 position).
When the machine is being cleaned of material residues, always disconnect the machine and
the extraction system from the mains supply.
Before cleaning with cleaning agents, close all openings with suitable materials in which no
water or cleaning agent can penetrate, for safety or functional reasons. Electric motors and
switches are especially at risk.
Do not perform any cleaning with high pressure cleaners.
Openings which were sealed before cleaning, must be completely opened after cleaning.
Always tighten loosened screw connections with the specified tightening torques during
maintenance and service work.
If safety equipment is dismantled during changeover, maintenance, service and repair,
remount and check the safety equipment immediately after the work is completed.
Dispose of operating and auxiliary materials and replacement parts safely and in accordance
with country-specific regulations.
2.7 Safety instructions for special types of dangers
2.7.1 Electric power
Work on the machine's electrical systems may only be carried out by electricians according to
the rules of electronics.
In case of problems with the electrical power supply, turn the machine off immediately.
When changing fuses only use original fuses with specified amperage.
Regularly check the machine electrical equipment. Immediately correct deficiencies, such as
loose connections or scorched cable.
2.7.2 Dust
The machine may only be operated with a working dust extraction system compliant with
country-specific regulations (e.g. EC Directive) and approved for steel dust.

Safety
10 Grinding machine SMD 123 RE
If carcinogenic substances are released during grinding (e.g. with stainless steel), the exhaust
system must be operated with an absolute filter.
The machine must be connected to a dust extraction system with wet extraction when
grinding aluminium.
Follow the operating manual of the exhaust system!
All federal requirements for extraction systems for potentially explosive steel dusts must be
met.
It must be guaranteed that the continued operation of machine is impossible if the dust
extraction system fails.
The volume flow rate of the dust extraction system must be at least 3000 m³/hr.
The flow velocity must be at least 20 m/sec.
No dust deposits should form in the extraction pipes.
2.7.3 Fire hazard
Do not process any workpieces which have been treated with a flammable corrosion resistant
agent or flammable additive.
Do not operate the machine near easily flammable materials.
Make sure that the machine is always cleaned of machining residues according to the
operating manual.
2.7.4 Explosion hazard
2.7.4.1 Description of explosion hazard
The machining of aluminium produces flammable dust by grinding that, when mixed with air, can
form a potentially explosive atmosphere. This also applies to the machining of steel and stainless
steel.
During machining of aluminium, wet separators must always be used.
A mixture of steel and aluminium dust can produce an explosive gas during corrosion
Moreover, there is always the possibility that contact between water (e.g. air humidity) and
aluminium dust can produce hydrogen gas, resulting in a gas explosions.
2.7.4.2 Division of zones
The extraction of the aluminium or steel dust with a suitable extraction system (see Section 2.7.2)
and performing the cleaning intervals (see Section 7.4) prevents the formation of an explosive
atmosphere within the machine or in the suction pipes.
Only if this is ensured may the machine be operated.

Safety
Grinding machine SMD 123 RE 11
2.8 Symbols on the machine
The following symbols are located on the machine and warn of dangers coming from the machine:
Symbol Meaning
This symbol on both conveyor belts indicates the danger,
that hands or body parts can be pulled in and sheared off.
This symbol on the control cabinet indicates dangerous electrical voltage.
Risk of shearing from moving parts
Read the operating manual and follow the information in the operating manual.
Wear protective gloves when placing and removing workpieces.
Wear safety glasses when working on the machine.
Lubrication point
Grinding mop height adjustment
Rotation direction

Product description
12 Grinding machine SMD 123 RE
3Product description
The SMD 123 RE grinding machine is described in the following (hereinafter referred to as
machine)
3.1 Appropriate usage
The SMD 123 RE grinding machine is intended exclusively for the deburring and edge rounding of
punch, laser, and fine plasma cut workpieces made of steel, steel alloys, aluminium or aluminium
alloys.
Workpieces of 1.0 mm to 50 mm in thickness may be processed.
During machining of steel dry dust extractor must always be connected.
During machining of aluminium a wet separator must always be connected.
Absolutely follow the instructions for explosion hazard (see Section 2.7.4) and for machine
cleaning (see Section 7.4). Only then is safe work possible.
Use for any other purposes is non-intended use.
The machine must only be installed in an indoor space, which meets the following conditions:
Fortified, level floor with a load carrying capacity of at least 1.8 t.
Temperature range from +10 to +40 °C
Humidity 5 to 95 % (not condensing).
The manufacturer accepts no liability for damages which occur for use which is non-intended use.

Product description
Grinding machine SMD 123 RE 13
3.2 Technical data
The following specifications apply to the SMD 123 RE grinding machine.
length 1788 mm
Width (incl. conveyor belt) 1595 mm
height 1906 mm
Total weight 1750 kg
Voltage 400V/50Hz / 480V/60Hz
Network structure 3 ~ PEN / 3~PEN + N
Rated current 41 A / 42 A
Rated power 23 kW / 28,1 kW
Rating power 28,5 kVA / 35 kVA
Protection class IP 42
Number of grinding motors 1
Drive power per grinding motor 15 kW
Grinding motor speed 2930 rpm
Grinding motor voltage 400V / 480V
Grinding motor power consumption 29 A
Running speed of abrasive belts 2 to 18 m/s
Number of motors 4
Drive power per motor 0,55 kW / 0,86 kW
Motor speed 1405 rpm / 1704 rpm
Motor voltage 400V / 480V
Power consumption of motor 1,4 A / 1,7 A
Number of feed motors 1
Drive power per feed motor 0.55 kW
Feed motor speed 3440 rpm
Feed motor voltage 400V / 480V
Power consumption of feed motor 3,2 A
Feed speed 0.5 to 8 m/min
Number of motors 1
Drive power 0.12 kW
Voltage 400V / 480V
Power consumption 0.82 A
Dimensions and weight
of the machine
Electrical data of the
entire machine
Grinding unit
(R)
Edge rounding
(E)
Feed
Sheet thickness

Product description
14 Grinding machine SMD 123 RE
Number of motors 1
Drive power 0.75 kW
Voltage 400V / 480V
Power consumption 2,0 A / 1,8 A
max. pressure 6 bar
Temperature range +10 to +40 °C (air conditioning / heating
otherwise required)
Humidity 5 to 95 %
(no condensation)
Emission noise pressure level at operator's place (average
value, since it depends on the workpiece processed)
approx. 80 dB
Material thickness (height of opening for workpieces) 1.0 to 50 mm
Aperture width for workpieces 80 mm to 950 mm
Minimum length of workpieces in the direction of travel 150 mm
Maximum workpiece weight 200 kg
Rotation
Pneumatics
Environmen
t
Noise pressure level
W
orkpieces

Product description
Grinding machine SMD 123 RE 15
3.3 Type plate
Abb. 1: Type plate
1 Name of machine
2 Serial number of machine
3 Connection values and weights
The type plate is located on the back of the grinding machine.

Product description
16 Grinding machine SMD 123 RE
3.4 Set up of grinding machine
Abb. 2: Components of the machine, input side
1 Control and display field
2 Control cabinet
3 Machine door, right
4 Safety shut off bar
5 Conveyor belt
6 Safety shut off bar
7 Adjustable machine foot
8 Machine door, left
9 Main switch
10 "EMERGENCY STOP" button
11 Control elements
1 2
3
4
5
6
7
7
8
9
10
11

Product description
Grinding machine SMD 123 RE 17
Abb. 3: Components of the machine, output side
1 Back wall, top
2 "EMERGENCY STOP" button
3 Type plate
4 Conveyor belt
12 2
4 3

Product description
18 Grinding machine SMD 123 RE
3.5 Control elements
Abb. 4: Control and display elements (front side)
1 Control and display field
2 "Stop" button
3 "Start" button
4 "EMERGENCY STOP" button
5 Main switch
1
2
3
4
5

Product description
Grinding machine SMD 123 RE 19
3.6 Machining units
Abb. 5: Machining unit, top
1 E-Assembly
2 R-Assembly

Product description
20 Grinding machine SMD 123 RE
Abb. 6: Interior control elements, left
1 Grinding mop height adjustment crank
2 Grinding mop button
3 Conveyor belt button
The crank and the buttons are only used for manual fine adjustment of the distance between
the abrasive and workpiece.
