Lithe Audio LWF1V2 User manual

WWW.LITHEAUDIO.COM/REGISTER
DONT FORGET TO REGISTER YOUR SPEAKER:
INSTRUCTION MANUAL

THANK YOU FOR
CHOOSING LITHE AUDIO
Innovative design and advanced engineering are built in to our wireless Wi-Fi ceiling mount
speakers. Designed for easy installation and high quality sound, within seconds each room is setup
and ready.This manual describes the installation of the speakers within conventional stud and
sheetrock (Joist and plasterboard) ceilings.
1

IMPORTANT SAFETY WARNING
BEFORE USE PLEASE READ COMPLETELY AND USE THE PRODUCT
IN ACCORDANCE WITH THESE SAFETY INSTRUCTIONS.
Before commencing any electrical work ensure the supply is switched OFF at the mains. Either
by switching off the consumer unit or by removing the appropriate fuse.This product should
be installed in accordance with the relevant sections of the building regulations code and in
accordance with the latest edition of IEE regulations (BS 7671).
If the unit is to be used as a replacement for an existing product, remove the existing unit from its
location and disconnect the wiring. Connect the wires as shown in diagram. Ensure terminals are
properly tightened and ensure no bare wires are visible. When tting the speaker into the ceiling,
ensure no wires are trapped.
READ THE INSTRUCTIONS CAREFULLY BEFORE STARTING THE
INSTALLATION PROCESS AND KEEP THEM SAFE FOR FUTURE
REFERENCE.
• Failure to follow the instructions in this guide voids all warranties on your speakers.
• Warning: Do not use the product in water.
• Warning: Do not install speaker directly above any heat sources such as radiators, or other
apparatus that produce heat.
• Warning: To reduce the risk of re or electric shock, do not expose this speaker to rain or
moisture (directly above bath or shower area) or in Bathroom Zone 0 or Zone 1.
• Protect the power cable from being damaged, do not over stretch cable.
• Only use attachments/accessories specied by the manufacturer Lithe Audio.
• Turn off the power to the speaker when unused for long periods of time.
• A Fire and Acoustic speaker hood must be used in accordance with UK building and IEE
Regulations with a re rating of up to 60 minutes, is Parts B, L, C and E compliant.
• Do not open the back cover to the speaker as this protects the PCB as this will invalidate the
warranty and could cause electric shock.
• Ensure speaker location is free from obstructions such as electrical conduit, HVAC ducts or
Water lines.
2

IMPORTANT SAFETY WARNING
USA REGULATIONS
BEFORE USE PLEASE READ COMPLETELY AND USE THE PRODUCT
IN ACCORDANCE WITH THESE SAFETY INSTRUCTIONS.
The Power adaptor (supplied) should not be placed in a dead space such as a wall or ceiling. In
accordance with US National Electrical Code. A DC extension cable must be used in conjuction
with the power adaptor supplied and placed inside / on top of cabinet or anywhere where you
have accessibility. (Each situation is unique to the install, consult your local building codes or con-
tact Authorized Dealer or Installer)
If the unit is to be used as a replacement for an existing product, remove the existing unit from its
location and disconnect the wiring. Connect the wires as shown in diagram. Ensure terminals are
properly tightened and ensure no bare wires are visible. When tting the speaker into the ceiling,
ensure no wires are trapped.
READ THE INSTRUCTIONS CAREFULLY BEFORE STARTING THE
INSTALLATION PROCESS AND KEEP THEM SAFE FOR FUTURE
REFERENCE.
• Failure to follow the instructions in this guide voids all warranties on your speakers.
• Warning: Do not use the product in water.
• Warning: Do not install speaker directly above any heat sources such as radiators, or other
apparatus that produce heat.
• Protect the power cable from being damaged, do not over stretch cable.
• Only use attachments/accessories specied by the manufacturer Lithe Audio.
• Turn off the power to the speaker when unused for long periods of time.
• A Fire and Acoustic speaker hood must be used in accordance with UK building and IEE
Regulations with a re rating of up to 60 minutes, is Parts B, L, C and E compliant.
• Do not open the back cover to the speaker as this protects the PCB as this will invalidate the
warranty and could cause electric shock.
• Ensure speaker location is free from obstructions such as electrical conduit, HVAC ducts or
Water lines.
3

3
Please ensure you read the entire instruction manual carefully before you commence any work.
Carefully unpack the speakers from the packaging. Please check to ensure all the parts shown
below are included.
If any parts of the speaker appear damaged, please contact your dealer/reseller immediately or
contact www.Litheaudio.com for contact details.
BOX CONTENTS
Listed below is the hardware equipment needed to install the speaker, with the addition of
a ladder to ensure the installation is done safely. A cutting template is included in the box.
PREPARATION EQUIPMENT YOU WILL NEED
WI-FI CEILING
SPEAKER
CUTTING GUIDE 5M SPEAKER CABLE
SCREWDRIVER
MEASURING TAPE
PENCIL
PROTECTIVE EYEWEAR
SPEAKER CABLE
POWER ADAPTOR
CUTTING SAW
DRILL
STUD FINDER
TAPE
WIRE CUTTERS
SPEAKER GRILLE
MODEL LWF1V2 PAIR MODELS
ALSO INCLUDE
PASSIVE CEILING SPEAKER
4
20’ DC EXTENSION
CABLE (OPTIONAL)

5
KNOW YOUR SPEAKER
The Lithe Audio LWF1V2 range of Wi-Fi ceiling wireless speakers have various inputs and outputs:
SPEAKER OUTPUT - To connect one additional passive (Slave) speaker (Gold Plated)
RCA INPUT - To connect directly from existing Hi-Fi equipment
POWER INPUT - To connect (as supplied) transformer
6.5” (165mm) Glass Fibre Woven/Polyproplene cone
In built over voltage, under voltage, over temperature, and short circuit protection, if there is an electrical fault,
the power supply to the amplier will cut off automatically and restart when the speaker has stabilised.
Power input 24V/2.5A
RCA-(Black)
Left for Stereo and Right for Mono
R+ (Red) R- (Black)
RCA+(Red)
Speaker output (Right)
RCA Input
Dog leg easy install xings (4)
Titanium tweeter
Stereo & Mono switch
Built in Amplier
& Wi-Fi chipset
Magnets for Cover (8)
Environmental equalizer
(+/- 3db)
LED indicator
Connection Reset Button
97mm ceiling
depth required
210mm
hole
cutout
(template
supplied)

SPEAKER PLACEMENT
IMPORTANT: BEFORE COMMENCING ANY WORKS, DETERMINE YOUR PRIMARY
LISTENING POSITION. IF YOU ARE UNSURE SEEK HELP FROM AN AV INSTALLER
FOR OPTIMUM RESULTS.
2 SPEAKER PLACEMENT
In an ideal scenario, the two speakers should be spaced equally apart from the primary listening
position.Where posible, place the speakers approx 3” / 1m from the wall
4 SPEAKER PLACEMENT
Ideally, the two speakers to the front and two speakers to the rear should be spaced equally apart
from the primary listening position to provide balanced listening experience. Where posible, place
the speakers approx 3” / 1m from the wall.
NOTE: For optimal sound when using speaker in vaulted ceilings switch the environmental equaliser
switch to +3dB, when using speakers in a tiled environment (Bathroom) switch equaliser to -3dB.
5 6

















210mm
hole
cutout
(template
supplied)

A
B
B
B
A
B
B
B
INSTALLATION
IMPORTANT: BEFORE COMMENCING ANY ELECTRICAL WORK ENSURE
THE SUPPLY IS SWITCHED OFF AT THE MAINS. IF YOU ARE UNSURE HOW TO
FIT SEEK HELP FROM A PROFESSIONAL ELECTRICIAN / AV INSTALLER
1. Mark out the position of the speaker using a
tape measure and mark using a pencil with the
template supplied. Check using a stud nder to
make sure no obstruction is present prior to
cutting.
3. Connect the power lead from the
transformer (supplied) to a 13A mains plug
socket or terminate to a dedicated 3A fused spur.
Ensure the power lead is not overstretched.
2. Drill a pilot hole and cut the speaker hole
using a cutting saw. Take caution when
cutting to keep ngers away from cutting
blade and wear protective eyewear.
4. Insert speaker into the ceiling then using a
screwdriver lock the 4 dog leg xings to secure
the speaker in place, do not over tighten.
Attach the magnetic grille to the speaker front.
PAINTING THE SPEAKER GRILLE
Do not paint the speaker grilles whilst attached to the speaker. Lithe Audio reccomends spray
painting using 5 parts thinning agent to 1 part paint. Spray thinly to ensure speaker cover grille holes
are not blocked as this will effect the sound quality of the speakers.
INSTALLATIONS IN FIRE-RATED CEILINGS
If you plan to mount your speakers in a re-rated ceiling, you should purchase a re hood for the
speaker.Visit www.litheaudio.com for more information and reccomended hoods.

INSTALLATION USA
IMPORTANT: BEFORE COMMENCING ANY ELECTRICAL WORK ENSURE
THE SUPPLY IS SWITCHED OFF AT THE MAINS. IF YOU ARE UNSURE HOW TO
FIT SEEK HELP FROM A PROFESSIONAL ELECTRICIAN / AV INSTALLER
1. Mark out the position of the speaker using a
tape measure and mark using a pencil with the
template supplied. Check using a stud nder to
make sure no obstruction is present prior to
cutting.
3. To meet the NEC code for this type on install,
connect the DC extension cable to power adap-
tor and place power adapter inside/ on top of
cabinet or anywhere you have easy access.
2. Drill a pilot hole and cut the speaker hole
using a cutting saw. Take caution when
cutting to keep ngers away from cutting
blade and wear protective eyewear.
4. Insert speaker into the ceiling then using a
screwdriver lock the 4 dog leg xings to secure
the speaker in place, do not over tighten.
Attach the magnetic grille to the speaker front.
PAINTING THE SPEAKER GRILLE
Do not paint the speaker grilles whilst attached to the speaker. Lithe Audio reccomends spray
painting using 5 parts thinning agent to 1 part paint. Spray thinly to ensure speaker cover grille holes
are not blocked as this will effect the sound quality of the speakers.
INSTALLATIONS IN FIRE-RATED CEILINGS
If you plan to mount your speakers in a re-rated ceiling, you should purchase a re hood for the
speaker.Visit www.litheaudio.com for more information and reccomended hoods.
A
B
B
B
8

YOUR HOME WI-FI NETWORK
To enable the Lithe Audio Wi-Fi ceiling speakers, your device must be on the same network.
• Ensure your network has a high speed internet connection, as the speakers are designed to
provide you with free online software/rmware updates.
• High speed DSL / cable modem, or ber to the home broadband is recommended for best
possible playback of music services.
• Lithe Audio communicates over a 2.4GHz & 5GHz Wi-Fi home network supporting 802.11
a, b, g, n, ac wireless technology only.
• For larger homes where Wi-Fi signal is not stable, we suggest adding access points/mesh
network to strengthen the network or updating your router to a higher specication model
to suit the demand.
LITHE AUDIO APP
• To enhance your listening experience download Lithe Audio app via the app store on your
device follow the setup procedures within this instruction manual.
• The app will allow you to setup singular rooms, groups of speakers or play in Party Mode.
• You can connect multiple speakers simultaneously and control them all from the app.
STATUS INDICATOR LIGHT
Located on the front face of the speaker, the LED Indicates the status of your speaker:
• Red solid: Speaker booting up
• Red quick ash (1s 4 times): Speaker under restart operation
• Red slow ash (3s 1 time): Speaker under standby mode, waiting for user operation
• Green solid: Speaker is active and connected to Wi-Fi
• Blue Solid: Bluetooth speaker connected
• Green slow ash(1s 1 time): Speaker trying to connect to the precongured Wi-Fi
• Solid purple: Speaker under RCA mode
• Green quick ash(1s 4 times): Speaker in WAC/SAC mode, user to congure Wi-Fi

CONNECTING TO BLUETOOTH
10
1. Open the setting menu
and select Bluetooth
2. Turn on Bluetooth
and search devices
3. Click Lithe Audio Speaker to
connect and pair to the speaker.

SETUP FOR APPLE IOS
1. Ensure the Wi-Fi speaker is connected to the power supply and is
turned on,The LED indicator light will be red.
2. Press and hold the ‘Connection Reset Button’ for 10 seconds &
release, the LED indicator will  ash Green fast and the speaker is now
ready to connect to your Wi-Fi network.
3. Open the Wi-Fi setting menu on
your phone or tablet
4. Select the new AirPlay speaker listed you
would like to add to your network
5. Select your network and change the
‘Speaker Name’ to something easily
identi able e.g. Kitchen and click Next
4. The Lithe Audio Wi-Fi speaker
setup is now complete, return to
the Lithe Audio app
3.
Open the Wi-Fi setting menu on
your phone or tablet
Image shows Apple iPhone but visuals may change from device to device.
Apple and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
Select your network and change the
Select your network and change the
identi able e.g. Kitchen and click Next
4.
The Lithe Audio Wi-Fi speaker
setup is now complete, return to
the Lithe Audio app
OPEN CAMERA & SCAN TO
DOWNLOAD THE APP

12
1. Swipe down from the top
right of the screen
2. Click on the right corner icon
to show available AirPlay devices
PLAY VIA IOS AIRPLAY 2
To play directly to speaker(s) using a iOS devices (iPad, iMac, iPhone,Apple TV etc) you can
connect via AirPlay. Please follow the steps below:
ENSURE THE SPEAKER IS CONNECTED TO THE POWER SUPPLY, AND THE WIFI
NETWORK.
Note:When using AirPlay the Lithe app grouping and playback functions for multiple speakers
becomes redundant.The ability to play any source is is now possible. As well as playing with other
brands in an multi room environment.
3. Audio display screen shall show
available devices to play music
through as per list
4. Select the speaker(s) to play music through
open any app and play your music
AirPlay
Image shows Apple iPhone but visuals may change from device to device.
Apple and iPhone are trademarks of Apple Inc., registered in the U.S. and other countries.
Use of the Works with Apple badge means that an accessory has been designed to work specifi cally with the technology identifi ed in the badge and
has been certifi ed by the developer to meet Apple performance standards. To control this AirPlay–enabled speaker, iOS 11.4 or later is required.
Apple, iPad, iPad Air, iPad Pro, iPhone and AirPlay are trademarks of Apple Inc., registered in the U.S. and other countries.

5. Click set up device, New devices Setup
new device
7. Select speaker, Next, click on Lithe
Audio Speaker all set.
SETUP FOR GOOGLE HOME
1. Download the Google Home app from thhe Google Play store
2. Ensure the Wi-Fi speaker is connected to the power supply and is turned on,The LED indicator
light will be red.
3 . When the LED indicator blinks green quickly press the + top left hand corner, Click set up
device, choose home to start looking for devices on your network, choose Speaker, Next.
4. Open Google Home and click the +
sign top left hand corner
6. Select existing home or create new
home to start looking for devices

1. To group speakers, click +,
create speaker group
2. Click on the speakers you want to
group, next, name group
PLAY VIA GOOGLE
To play directly to speaker(s) using Google Cast. Please follow the steps below:
ENSURE THE SPEAKER IS CONNECTED TO THE POWER SUPPLY, AND THE WIFI
NETWORK.
Note:When using Google Cast the Lithe app grouping and playback functions for mutiple speak-
ers becomes redundant.The ability to play any source is is now possible. As well as playing with
other brands with Google Cast built in within an multi room environment.
3. Audio display screen shall show
available devices to play music
through as per list
4. Select the speaker to play music
through and press play on your source
player
Google, Chromecast built-in are trademarks of Google LLC.
Chromecast Built-in
14

11
SPOTIFY CONNECT
Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect
to learn how.
The Spotify Software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
HARD WIRED INPUT- RCA
To connect other devices such as CD player, BluRay player etc) to play through the Wi-Fi speakers
please follow the steps below:
RCA Connection:
To play music via speaker RCA connection connect an RCA cable to the speaker and play
through your device. Within the Lithe Audio App click on source to activate RCA to be able to
play through the speaker.
Note:To ensure the best posible sound without humming or noise, we recommend a shielded
RCA cable be used.
CREATE STEREO PAIR
PLEASE NOTE: LWF1V2 DOES NOT INCLUDE PASSIVE SPEAKER
The Lithe Audio Master Wi-Fi ceiling speaker is able to connect to and power an
addtional passive speaker via the Right speaker output.
Use wire cutters to strip the ends of the speaker cable (if required).

SPECIFICATIONS
GENERAL
• Power Input Supply : 100 - 240V, 50/60Hz / 2A
• Transformer Output Supply : DC24V / 2.5A
• Dimensions (W x D) 230 x 110mm
(6.5 x 4.3 in)
• Weight 1.75kg (3.85 lbs)
• IP rating: IP44 (Bathroom models only)
• Operating Temperature 0º to 40º C
(32º to 104º F)
• Storage Temperature -20º to 70º C
(4º to 158º F)
• Standby power: 1.3W / 0.02A
• Connected power: 1.5W / 0.03A
• Playing Music: 2.8W - 10.5W / 0.03A -
0.09A**
* Specications subject to change without notice.
** Power Consumption depends on the type of music & volume
- Increased Bass & volume requires more power loading on the
amplier.
- Internet functionality may require payment of separate fee to a
service provider.
SPEAKER
• Sound Quality THD+N<0.009%,
55Hz-20kHz (+/- 3dB)
• RMS Power: 60W RMS (2x 30W)
• Impedance: 8 Ohms nominal
• Sensitivity (1W/1m): 90dB
• Line In Analog (RCA), auto-detecting
• Type: Class D (Digital)
• Audio Compression: 192kHz 24bit
• Woofer: 6.5”Woven Glass Fiber cone /
Polypropylene Cone (IP44)
• Tweeter: 0.75” Titanium Cone
MUSIC ACCESS
• Audio Formats Supported: MP3,WMA,
AAC (MPEG4), AAC+, ALAC, FLAC, APE,
WAV, OGG, LPCM
• Audio Sample Rate: up to 192kHz 24bit
• Music Services Supported by Lithe Audio
include; Airable Radio, Podcast,Tidal,
Deezer, Soundmachine, Amazon Music,
Napster, Spotify, etc..
• Operating Systems (for stored les)
Windows XP SP3 and higher; Mac OS X
10.6.8 and higher; NAS (network-
attached storage) devices supporting CIFS
MULTI ROOM
• Group speakers within same Wi-Fi
network
WIRELESS NETWORKING
• Wi-Fi Connectivity:Wi-Fi CERTIFIED™
802.11 a, b, g, n, ac WPA™ - Personal
WPA2™ -
Personal WMM®, Wi-Fi
Protected Setup™
• Wireless connectivity works on
your home Wi-Fi network with both
2.4GHz/5GHz broadcast routers
• Internet connection required for access
to Internet radio stations, online music
services and software updates.
11 16

13
TROUBLESHOOTING
If a problem arises, please try the troubleshooting guide below. If the problem is not listed
please contact Lithe Audio Customer Service Support
Q: Speaker has not been found during setup
A: Please check power cord is correctly connected into speaker and transformer, Check the
red light is ON. Press reset button for 5 seconds on the speaker (discoverable mode), green
light shall ash, follow the instructions for Android or AirPlay setup.
*Before commencing any electrical work ensure the supply is switched OFF at the mains.
Q: Speaker connected to AirPlay but not playing through device
A: Please ensure device has good Wi-Fi strength and battery power, check the led indicator is
solid green, if not press reset button for 3 secs. Failing this, turn the speaker power off then on.
Q: Device is connected to Wi-Fi speaker but no sound
A: Ensure your device volume is NOT muted, increase the volume within app and try again.
Restart the app which the audio is playing from and try again.
Q: Lithe Audio App not showing connected speakers
A: Ensure your speakers green light are on, and connected as per setup.The app shall
automatically nd active speakers, if not, restart app or press reset on speaker for 3 secs to
wake speaker. to show green status light.
Q: Lithe Audio App not working correctly
A: Ensure your speaker rmware/app are up to date, OR restart/reinstall app fully.
Q: Can the speaker be installed into the bathroom ceiling.
A: The IP rated models can be installed in zone 2 or 3 of a bathroom. Ensure you read the
saftey precautions before installation.
Warning: Do not use the product in water or directly above the bath or shower area.
Q: I have a new router and speakers are not visible anymore
A: If you have purchased a new router or reset the router back to defualt, you shall need to
install the speakers again. Please follow the setup procedures for IOS or Android.
For further queries and support questions please visit www.support.litheaudio.com
email us at [e-mail] or via our website’s live chat service (during working
hours)

REGULATION INFORMATION
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a class b digital device,
pursuant to part 15 of the FCC rules. these limits are designed to provide reasonable
protection against harmful interference in a residential installation. this equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. however, there is
no guarantee that interference will not occur in a particular installation. if this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/tv technician for help.
To assure continued compliance, any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this equipment.
(example- use only shielded interface cables when connecting to computer or peripheral
devices).
FCC RADIATION EXPOSURE STATEMENT
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.This equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your body.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
EUROPE
Lithe Audio declares that this product herewith complies with the requirements of the EMC
Directive 2004/108/EC, Low Voltage directive 2006/95/EC, Eco-Design Directive 2005/32/EC,
RoHS Directive 2011/65/EU and the R&TTE Directive 1999/5/EC when installed and used
in accordance with the manufacturer’s instructions. A copy of the full Declaration of Confor-
mance may be obtained at www.litheaudio.com/support/policies.
Lithe Audio Speakers have a standby mode or remove the power cord from the AC mains.
13 18

RECYCLING INFORMATION
This symbol on the product or on its packaging indicates that this product shall not be treated as household
waste. Instead please deliver it to the applicable collection point for the recycling of electrical and electronic
equipment. By recycling this product correctly, you will help
conserve natural resources and prevent potential negative environmental consequences. For more detailed
information about recycling of this product, please contact your local council of ce, your household waste
disposal service or the shop where you
purchased the product(s) from.
THIS DOCUMENT CONTAINS INFORMATION THAT IS SUBJECT TO CHANGE WITHOUT
NOTICE.
No part of this publication may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including but not limited to photocopying, recording, information retrieval systems, or computer
network without the written permission of Lithe Audio Ltd
Use of the Works with Apple badge means that an accessory has been designed to work speci cally with
the technology identi ed in the badge and has been certi ed by the developer to meet Apple performance
standards.
To control this AirPlay–enabled speaker, iOS 11.4 or later is required.
Apple, iPad, iPad Air, iPad Pro, iPhone and AirPlay are trademarks of Apple Inc., registered in the U.S. and other
countries.
Windows® is a registered trademark of Microsoft Corporation in the United States and other countries.
Android™ is a trademark of Google, Inc.
Google, Chromecast built-in are trademarks of Google LLC.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by Lithe Audio Ltd is under license. Other trademarks and trade names are those of their
respective owners.
Wi-Fi CERTIFIED™ is a registered trademark of Wi-Fi Alliance®
Spotify software is subject to third party licenses found here:
http://www.spotify.com/connect/third-party-licenses
All other products and services mentioned may be trademarks or service marks of their
respective owners.
©2021 by Lithe Audio Ltd. All rights reserved.
FCC ID: 2AQOB-LWF1V2
REGULATION INFORMATION
