LIVARNO LUX Z31906 Technical specifications

SOLAR-POWERED
GROUND LAMP
Assembly, operating and safety instructions
IAN 106346
SOLAR-POWERED GROUND LAMP
SOLAR-
BODENEINBAUSTRAHLER
Montage-, Bedienungs- und Sicherheitshinweise
SOLAR-VLOERINBOUWSPOT
Montage-, bedienings- en veiligheidsinstructies
TALNI SOLARNI VGRADNI REFLEKTOR
Navodila za montažo, uporabo
in varnostna navodila
ΗΛΙΑΚΟ ΦΩΤΙΣΤΙΚΟ ΔΑΠΕΔΟΥ
Οδηγίες συναρμολόγησης, χειρισμού και
ασφάλειας
106346_livx_Solar-Bodeneinbaustrahler_Cover_IE_NL_SI_CY.indd 4 08.12.14 14:25

GB/IE/CY Assembly, operating and safety instructions Page 3
NL Montage-, bedienings- en veiligheidsinstructies Pagina 21
SI Navodila za montažo, uporabo in
varnostna navodila Stran 39
GR/CY Οδηγίες συναρμολόγησης, χειρισμού
και ασφάλειας Σελίδα 59
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 80
106346_livx_Solar-Bodeneinbaustrahler_Cover_IE_NL_SI_CY.indd 5 08.12.14 14:25

3GB/IE/CY 3GB/IE/CY
Intended use......................................................................................... Page 4
Description of parts........................................................................ Page 4
Technical data...................................................................................... Page 5
Includes...................................................................................................... Page 6
Safety advice ....................................................................................... Page 6
Product-specific safety instructions .............................................................. Page 8
Safety instructions for rechargeable batteries............................................ Page 9
Functioning............................................................................................. Page 11
Charging the rechargeable Battery............................................................ Page 12
Installation.............................................................................................. Page 12
Installing the floor light in soil or wooden substrates................................. Page 13
Installing the floor light in concrete substrates ........................................... Page 14
Replacing the rechargeable batteries ......................... Page 15
Care and cleaning............................................................................ Page 16
Trouble-shooting............................................................................... Page 17
Disposal..................................................................................................... Page 18
Warranty.................................................................................................. Page 19
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 3 08.12.14 14:25

4 GB/IE/CY
4 GB/IE/CY
Solar-powered
ground lamp
Intended use
This product is intended to be
used as an orientation aid or
as mood lighting in an outdoor
environment. The floor light
can be inserted in the soil or
recessed in a wooden (patio)
or concrete substrate. Any use
other than the aforementioned
or any product modification is
prohibited and can lead to in-
juries and/or product dam-
age. The manufacturer is not
liable for any damages caused
by any use other than its
intended purpose. This product
is not intended for commercial
use.
Description of parts
1Screw
2Decorative collar
3Lamp glass
4Sealing ring
5Light body
6Screw (solar cell)
7Solar cell
8LEDs
9ON/ OFF switch
10 Battery compartment
11 Floor insert
12 Screws (floor insert /
light body)
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 4 08.12.14 14:25

5GB/IE/CY 5GB/IE/CY
Technical data
Operating
voltage: 2.4 V
Rechargeable
batteries: 2 x NiMH/
AAA/1.2V /
800 mAh
(included)
(preinstalled)
Bulbs: 2 x LED (non-
replaceable)
Protection
type: IP65 (total dust
ingress protec-
tion/ protection
against low pres-
sure water jets
from any direc-
tion) IP67
(dust-tight/ pro-
tected against
temporary
immersion)
Dimensions: Z31906:
approx.
14 x 4.5 cm
(without floor
insert), approx.
14 x 5.5 cm
(with floor insert)
Z31906A:
approx.
10.5 x 4.5 cm
(without floor
insert), approx.
10.5 x 5.5 cm
(with floor insert)
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 5 08.12.14 14:25

6 GB/IE/CY
6 GB/IE/CY
Includes
Immediately after unpacking
please check the package con-
tents for completeness and if
all parts and the product are in
good condition. Do not assem-
ble the product if the package
contents are
incomplete.
1 Solar-Powered Ground Light
1 Floor insert
4 Screws (floor insert / light
body)
1 Hexagon key
2 Batteries, NiMH rechargea-
ble batteries, 1.2 V ,
AAA (preinstalled)
1 Installation instructions
Safety advice
BEFORE USING THIS PROD-
UCT, PLEASE READ THE
INSTRUCTIONS FOR USE!
PLEASE KEEP THE INSTRUC-
TIONS FOR USE IN A SAFE
PLACE!
WARN-
ING! RISK
OF LIFE AND
ACCIDENTS IN
IN-
FANTS AND CHILDREN !
Never leave children unat-
tended with the packaging
material. Risk of suffoca-
tion. Keep children away
from the product.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 6 08.12.14 14:25

7GB/IE/CY 7GB/IE/CY
This appliance can be used
by children aged from 8
years and above and per-
sons with reduced physical,
sensory or mental capabil-
ities or lack of experience
and knowledge if they
have been given supervi-
sion or instruction concern-
ing use of the appliance in
a safe way and understand
the hazards involved. Chil-
dren shall not play with
the appliance. Cleaning
and user maintenance
shall not be made by chil-
dren without supervision.
This product is not a toy
and should be kept out of
the reach of children.
Children are not aware of
the dangers associated
with handling electrical
products.
Do not use the article if
you detect any kind of
damage.
CAUTION!
DANGER OF
EXPLOSION!
Do not operate the lamp
in potentially explosive en-
vironments in which there
are inflammable vapours,
gases or dusts.
CAUTION!
RISK OF IN-
JURY! Broken
lamp glass must be
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 7 08.12.14 14:25

8 GB/IE/CY
8 GB/IE/CY
replaced before any fur-
ther use is made of the
lamp.
Product-specific
safety instructions
Do not expose the solar
lamp to extreme tempera-
tures, strong vibrations or
heavy mechanical loads.
Make sure that the solar
panel is free of dirt and
free of snow and ice in
winter. Otherwise the per-
formance of the solar
panel will diminish.
Cold temperatures have a
negative influence on the
operating life of the re-
chargeable batteries.
In the event of damage,
repairs or other problems
with the light, please con-
tact an electrician. The
LEDs cannot be replaced.
DANGER
TO LIFE AND RISK OF
INJURY! Before installing
the product, ensure that
there are no water pipes
or electrical wiring in or
under the ground or sub-
strate.
The floor light must be in-
stalled only in areas to
which there is limited ac-
cess (e.g. footway edge/
path). The floor light is
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 8 08.12.14 14:25

9GB/IE/CY 9GB/IE/CY
adequately anchored only
when installed in a con-
crete substrate. Therefore,
in the case of installation
in soil or in wooden sub-
strates, you should ensure
that the floor light is not
placed in areas that are
accessed by vehicles
(e.g. parking spaces, vehi-
cle drives) or on which
you use garden equipment
(e.g. snow clearers). Fail-
ure to observe this advice
could result in the floor
light being lifted out of the
substrate and possible
damage to the product
and/ or injury.
Dispose of the light in the
proper way if the lamp
glassor the cover of the
solar cell 7is damaged.
Safety in-
structions for
rechargea-
ble batteries
WARN-
ING! DAN-
GER TO LIFE
AND RISK OF ACCI-
DENTS FOR INFANTS
AND CHILDREN! Keep
batteries out of the reach
of children. Do not leave
the batteries lying around.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 9 08.12.14 14:25

10 GB/IE/CY
10 GB/IE/CY
There is a risk of children
or animals swallowing
them. Consult a doctor im-
mediately if a battery is
swallowed.
CAUTION!
DANGER OF
EXPLOSION!
Use only rechargeable
batter-ies of the recom-
mended type. Other re-
chargeable or single-use
batteries could explode
during charging.
FIRE HAZ-
ARD! Do not
allow recharge-
able batteries to short-
circuit. Otherwise the re-
chargeable batteries may
overheat, become a fire
hazard or explode.
RISK OF EX-
PLOSION!
Never throw re-
chargeable batteries into
fire or water.
Chemical fluids that dam-
age the product may leak
out of outdated or used
rechargeable batteries.
Remove, therefore, the
rechargeable batteries
when the lamp is not re-
quired for any length of
time.
Wear protective
gloves! If they
come into con-
tact with skin, leaked or
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 10 08.12.14 14:25

11GB/IE/CY 11GB/IE/CY
damaged rechargeable
batteries could cause
chemical burns; you
should therefore wear suit-
able protective gloves at
all times if such an event
occurs.
Only use rechargeable
batteries of the right size
and of the recommended
type (see section on
”Technical data”).
Ensure correct polarity.
This is indicated in the bat-
tery compartment for the
rechargeable battery.
Functioning
The solar panel installed in the
article converts sunlight into
electrical energy and stores it
in 2 NiMH batteries. Switches
on the light as it begins to get
dark. The in-built light-emitting
diodes are a very long-life and
energy-saving light source. The
light duration depends on the
amount of sunlight, the angle
of light on the solar panel and
the temperature (the battery
capacity is temperature-de-
pendent). A vertical angle of
light at temperatures above the
freezing point is ideal. The
battery does not achieve maxi-
mum capacity until after
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 11 08.12.14 14:25

12 GB/IE/CY
12 GB/IE/CY
several charge and discharge
cycles.
Charging the
rechargeable
Battery
The charging time of the bat-
tery depends on the intensity
of the sunlight and the angle
of incidence of the light on the
solar cell 7.
Place the solar cell as perpen-
dicular as possible to the an-
gle of incidence of the light. In
this way you will receive the
highest light levels.
Note: While charging the
lamp must be switched on.
Installation
CAUTION! RISK OF
BURNS! The surface of the
light can reach a temperature
of 60°C.
Note: The load capacity of
the lamp glass 3is max.
400kg (4000 N).
Note: Before you start work
make yourself familiar with
each step of the installation,
otherwise have the product
installed by electrician.
Note: The batteries have
been preinstalled in your de-
vice at the factory.
Note: Ensure that the light is
installed so that the solar cell 7
is exposed to direct sunlight.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 12 08.12.14 14:25

13GB/IE/CY 13GB/IE/CY
Note: You have the choice of
installing the light in the
ground or in a substrate such
as wood (e.g. patio) or con-
crete. Installation in a wooden
or concrete floor requires a
drill and hole cutter suitable
for use on wood respectively.
Note: To do this you will re-
quire a crosshead screwdriver
and a hexagon key.
DANGER
TO LIFE AND RISK OF IN-
JURY! Before installing the
product, ensure that there are
no water pipes or electrical
wiring in or under the ground
or substrate.
CAUTION! RISK OF
INJURY! Consult the drill
manufacturer‘s operating man-
ual before you use your drill.
Installing the
floor light in soil
or wooden
substrates
1. Choose a suitable location
for the floor light.
2. First excavate a hole with
a depth to match the
height of the light in the
ground or drill a corre-
spondingly sized hole in a
wooden substrate.
Note: Bear in mind that
the decorative collar 2
must be placed on top of
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 13 08.12.14 14:25

14 GB/IE/CY
14 GB/IE/CY
the substrate surface later
(see Fig. G).
3. Switch the light on by
pressing the ON/ OFF
switch 9.
Note: Please bear in mind
that the light will only switch
itself on or off under twilight
conditions automatically if
the light is switched on.
4. Insert the light into the
substrate.
Your light is now ready for
operation.
Installing the floor
light in concrete
substrates
Note: A quantity of mixed
concrete is required for this
stage of the installation. Follow
the manufacturer’s instructions.
1. Choose a suitable location
for the floor light.
2. Drill a hole in the concrete
substrate. Note: Ensure
that the depth of the hole
corresponds with the depth
of the floor insert 11 with
concrete socket including
the floor light. Bear in
mind that the decorative
collar 2must be placed
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 14 08.12.14 14:25

15GB/IE/CY 15GB/IE/CY
on top of the substrate
surface later (see Fig. G).
3. Pour a little mixed concrete
into the predrilled hole.
4. Place the floor insert in the
hole and let the concrete
harden (see Fig. D). Follow
the manufacturer’s instruc-
tions.
5. Assemble the product as
shown in Figs. A and D.
6. Press the ON/ OFF button
9to switch on the light
(see Fig. C).
7. Insert the light body 5
into the floor insert (see
Fig. E).
8. Fix the light body and
floor insert together with
the screws 12 (see Fig. E).
9. Install the product as
shown in Fig. F.
Your light is now ready for
operation.
Replacing the
rechargeable
batteries
Replace the rechargeable bat-
teries when you notice that the
period of illumination provided
by the light has considerably
reduced over time, despite full
exposure to solar radiation.
Note: Ensure that you switch
off the light before you replace
the rechargeable batteries.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 15 08.12.14 14:25

16 GB/IE/CY
16 GB/IE/CY
Note: To do this you will re-
quire a crosshead screwdriver
and a hexagon key.
Change the rechargeable
batteries as shown in Figs.
A, B and C.
Note: Make sure you fit
the batteries the right way
round (polarity). The cor-
rect polarity is shown in-
side the battery
compartment.
Note: Ensure that the
light is correctly assembled
and installed before use.
Care and cleaning
The LEDs 8cannot be
replaced.
Do not use corrosive
cleaning agents.
Clean the light regularly
with a dry, fluff-free cloth.
Use a slightly moist cloth
to remove any stubborn dirt.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 16 08.12.14 14:25

17GB/IE/CY 17GB/IE/CY
Trouble-shooting
Error Cause Solution
The light will
not switch on
even though the
sun shone on
the lamp all day.
Artificial sources of
light, e.g. street light-
ing, are interfering
with the lamp.
Mount the lamp in a
place where it cannot
be disturbed by other
sources of light.
The light does
not come on or
comes on only
briefly.
The rechargeable
batteries are broken
or there was not
enough daylight.
Replace the rechargea-
ble batteries or mount
the lamp in a place
where it
can receive
more sun
light.
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 17 08.12.14 14:25

18 GB/IE/CY
18 GB/IE/CY
Disposal
The packaging is
made entirely of re-
cyclable materials,
which you may
dispose of at local
recycling facilities.
Contact your local refuse
disposal authority for more
details of how to dispose of
your worn-out product.
To help protect the
environment, please
dispose of the
product properly when it has
reached the end of its useful
life and not in the household
waste. Information on collec-
tion points and their opening
hours can be obtained from
your local authority.
Defective or used rechargeable
batteries have to be recycled in
line with Directive 2006/66/EC .
Return rechargeable batteries
and/ or the device via the
recycling facilities provided.
Pb
Improper
disposal of
rechargeable
batteries can
damage the
environment!
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 18 08.12.14 14:25

19GB/IE/CY 19GB/IE/CY
Rechargeable batteries must
not be disposed of with the
household refuse. They may
contain toxic heavy metals
and require to be handled as
special waste. The chemical
symbols of heavy metals are:
Cd = cadmium, Hg = mercury,
Pb = lead. For this reason, you
must dispose of discarded bat-
teries at a communal disposal
centre.
Warranty
The device has been manufac-
tured to strict quality guidelines
and meticulously examined be-
fore delivery. In the event of
product defects you have legal
rights against the retailer of
this product. Your legal rights
are not limited in any way by
our warranty detailed below.
The warranty for this device is
3 years from the date of pur-
chase. Should this device show
any fault in materials or manu-
facture within three years from
the date of purchase, we will
repair or replace it – at our
choice – free of charge to you.
The warranty period begins on
the date of purchase. Please
keep the original sales receipt
in a safe location. This docu-
ment is required as your proof
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 19 08.12.14 14:25

20 GB/IE/CY
20 GB/IE/CY
of purchase. This warranty be-
comes void if the device has
been damaged or improperly
used or maintained.
The warranty applies to faults
in material or manufacture.
This warranty does not cover
product parts subject to nor-
mal wear, thus possibly consid-
ered consumables (e.g.
batteries) or for damage to
fragile parts, e.g. switches, re-
chargeable batteries or glass
parts.
IP65
IP67
106346_livx_Solar-Bodeneinbaustrahler_Content_IE_NL_SI_CY.indd 20 08.12.14 14:25
