LIVARNO LUX HG06492A User manual

SMART LED LIGHT BULB
Operation and safety notes
IAN 334392_2001
SMART LED LIGHT BULB

GB/IE/NI/MT/CY Operation and safety notes Page 3

3GB/IE/NI/MT/CY
SMART LED LIGHT BULB
Warnings and symbols used ..........................................Page 4
Introduction .............................................................Page 5
Intended use ............................................................Page 5
You will need............................................................Page 5
Technical data ...........................................................Page 6
Pairing product and mobile device...................................Page 7
Creating a product group .............................................Page 9
Removing a product group............................................Page 9
Unpairing product from mobile device ..............................Page 9
Switching on / off.......................................................Page 10
Settings ..................................................................Page 10
Time settings ............................................................Page 13
Additional functions ....................................................Page 16
Privacy policy ...........................................................Page 17
Tap-to-Run / Automation ..............................................Page 18
Resetting product manually...........................................Page 18
Cleaning and care ......................................................Page 19
Troubleshooting.........................................................Page 19
Disposal..................................................................Page 20
Warranty ................................................................Page 20
Simplified EU declaration of conformity .............................Page 21

4 GB/IE/NI/MT/CY
Warnings and symbols used
The following warnings are used in the instruction manual, quick start guide, safety instructions and on
the packaging:
DANGER! This symbol in combination
with the signal word “Danger” marks
a high-risk hazard that if not prevented
could result in death or serious injury.
Luminous flux
Number of switching cycles before
premature failure
WARNING! This symbol in combination
with the signal word “Warning” marks a
medium-risk hazard that if not prevented
could result in death or serious injury.
Nominal lifetime of the product
GU10 E14 E27
Lamp socket
CAUTION! This symbol in combination
with the signal word “Caution” marks a
low-risk hazard that if not prevented could
result in minor or moderate injury.
38° Beam angle (for HG06492A only)
Dimmable via the app or remote control.
ATTENTION! This symbol with the signal
word “Attention” indicates a possible
property damage.
Ambient temperature
Warm-up time up to 60 % of the full light
output is less than 1 second.
NOTE: This symbol in combination
with “Note” provides additional useful
information.
The product is not suitable for use in dusty
and moist conditions.
Alternating current / voltage
Zigbee 3.0 wireless technology

5GB/IE/NI/MT/CY
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product.
They contain important information concerning
safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety
information and instructions for use. Only use
the product as described and for the specified
applications. If you pass the product on to anyone
else, please ensure that you also pass on all the
documentation with it.
Intended use
This smart LED light bulb (hereinafter called
“product”) is used for lighting up interiors.
Suitable Not suitable
Private use Industrial/commercial purposes
Use in tropical climates
Any other use is considered improper. Any claims
resulting from improper use or due to unauthorised
modification of the product will be considered
unwarranted. Any such use is at your own risk.
The Lidl Home app is required to
control and set up the product.
You will need
Gateway:
IAN 341809_1910 /
IAN 341809_2001 /
IAN 343820_1910 /
IAN 343820_2001 /
IAN 343821_1910 /
IAN 343821_2001
Router:
2.4 GHz, IEEE 802.11b/g/n
Mobile device:
iOS 9.0 or higher
Android 5.0 or higher
Safety notices
BEFORE USING THE PRODUCT, PLEASE
FAMILIARIZE YOURSELF WITH ALL OF THE
SAFETY INSTRUCTIONS AND INSTRUCTIONS
FOR USE! WHEN PASSING THIS PRODUCT ON
TO OTHERS, PLEASE ALSO INCLUDE ALL THE
DOCUMENTS!
mWARNING! DANGER TO LIFE AND
RISK OF ACCIDENT FOR INFANTS AND
CHILDREN!
mDANGER! Risk of suffocation!
Never leave children unsupervised with the
packaging material. The packaging material
poses a suffocation hazard. Children frequently
underestimate the dangers.
The packaging material is not a toy.
mDANGER! Risk of electric shock! To
prevent risk of electric shock, turn off the power
at the main circuit breaker box or disconnect
the luminary from the socket-outlet before
installation.
Use in dry locations only! The product
is not suitable for use under dust and
moisture.
The increased weight may reduce the
mechanical stability of certain luminaires and
lampholders and may impair contact making
and lamp retention.
LEDs emit bright light. Avoid looking directly
into the light source for prolonged periods.
The LEDs is/are not replaceable.

6 GB/IE/NI/MT/CY
Technical data
Model HG06492A HG06492B HG06492C
Rated power 5 W 5.5 W 9 W
Lamp socket GU10 E14 E27
Total luminous flux (6500 K) 350 lm
(90° cone: 280 lm)
470 lm 806 lm
Measurements (mm) (Ø x L) 50 x 55 39 x 120 60 x 115
Operating voltage 230 V∼, 50 Hz
Frequency band 2.4 to 2.485 GHz
Max. transmitted power 13 dBm
Life 30000 h
Switching cycles 100000
Communication protocol ZigBee 3.0
Reception range approx. 70 m (free area)
Operating temperature –10 to +40 °C
Operating humidity 10 to 80 %
Colour temperature 2200 to 6500 K
Colour rendering index Ra> 95
Warm-up time (60 %) < 1 s = 60 % light
Brightness control Dimmable via the app or remote control
Trademark notices
iOS and Apple are registered trademarks of
Apple Inc. in the USA and other countries.
App Store is a registered trademark of
Apple Inc.
Android, Gmail, Google Play and
Google Assistant* are registered trademarks of
Google Inc.
Zigbee is a registered trademark of The Zigbee
Alliance.
The LIVARNOLUX trademark and trade name
is the property of their respective owners.
Any other names and products may be
trademarks or registered trademarks of their
respective owners.
* Google Assistant is not available in certain
languages and countries.

7GB/IE/NI/MT/CY
Pairing product and mobile
device
NOTES:
Screenshots are from the iOS 13.3 app version
(if not otherwise marked). Older iOS versions
may have functional limitations.
The Android version of the app follows the
same principles as the iOS version; you might
encounter discrepancies between the two
platforms, such as slightly different on-screen
commands or icons.
Updating the firmware might result in changes
to the app’s functionality.
An updated instruction manual can be found
here:
{ Me } tab:
Tap { User Manual } .
Preparation
Install Lidl Home app and setup Gateway
( Gateway instruction manual).
1. Light switch off.
2. Screw product into lamp socket.
3. Light switch on. Product flashes slowly.
4. Ready for pairing.
5. Open Lidl Home app.
6. { Home } tab:
Tap (add further devices).
7. Select category: { Lighting }
8. Select: Smart LED light bulb
– iOS: { White }
– Android: { White }

8 GB/IE/NI/MT/CY
9. Select Gateway.
Only necessary, if you have 2 or more
Gateways.
10. Follow the app instructions.
11. Establishing connection.
12. Naming the product:
Tap and enter a name.
13. Tap one of the rooms to set location of product
(selected room is grayed out).
If more than one product is connected: You can
rename the product and define its location.
14. Tap { Done } .
15. Pairing completed.
16. Return to home screen:
Tap { < } .

9GB/IE/NI/MT/CY
Creating a product group
1. Open Lidl Home app.
2. { Home } tab:
Tap on one of the connected LED bulbs.
3. Tap (top right).
4. Tap { Create Group } .
5. Select devices.
6. Tap { Confirm } .
7. Enter a group name.
8. Tap { Save } .
Removing a product group
1. Open Lidl Home app.
2. { Home } tab:
Tap on the group you want to remove.
3. Tap (top right).
4. Tap { Dismiss Group } .
5. Tap { Confirm } .
Unpairing product from mobile
device
1. Open Lidl Home app.
2. { Home } tab:
Tap { White } .
3. Tap .
4. Tap { Remove Device } .
Select:
– { Disconnect }
or
– { Disconnect and wipe data }
( “Additional functions”).
5. Tap { Confirm } .

10 GB/IE/NI/MT/CY
Switching on / off
1. Tap .
Settings
Colour temperature /
brightness (white)
Tab { White } :
1. Adjust settings using the 2 sliders.
: Colour temperature
(warm white to cool white)
: Brightness
: Current setting

11GB/IE/NI/MT/CY
Scenes
Tab { Scene } :
1. Select one of the default light scenes:
Name Setting
Brightness Temp.
{ Night }
low warm
{ Read }
high neutral white
{ Working }
high cold
{ Leisure }
medium neutral white
{ Add Scene }
user-defined
2. { Edit } : Adjust settings of selected light scene.

12 GB/IE/NI/MT/CY
Add scenes
1. Tap { Add Scene } .
2. { Edit Scene Pic } : Replace default photo.
Select:
– { Take Photo }
– { Choose From Library }
or
– { Cancel }
(cancel photo replacement)
Access to the mobile devices’ camera and
photo library is required.
3. { Scene Name } :
Change scene name.
4. { Colour Flash Mode } :
Choose flash mode.
{ Static }
=Static light
{ Flash }
= * Flash light
{ Breath }
= * Pulsing light
{ Done }
=Confirm setting
* { Colour Flash Speed } : Adjust flash speed
setting using the slider.
5. { Scene Colour } tab:
Tap and adjust settings using the slider.
6. Adjust colour temperature / brightness .

13GB/IE/NI/MT/CY
7. Tap { Scene Colour } :
– Add colours:
Tap .
– Delete colours:
Tap .
{ Delete } .
8. { Reset } :
Reset of selected scene to default settings.
9. { Confirm } :
Confirm settings.
Time settings
Countdown
Switches the product automatically on/off after
a countdown (this function is available for a
single product only).
1. Tap { Left time } .
2. Set { Hour } (00 to 11) and { Minute }
(00 to 59).
3. Tap { Confirm } .
4. Remaining time is displayed on the bottom left.
5. Cancelling countdown prematurely:
Tap the remaining time.
Tap .
Countdown deactivated.
Tap { Confirm } .

14 GB/IE/NI/MT/CY
Schedule
Switches the product automatically on/off
following a user-defined time plan.
1. Tap { Schedule } .
2. Tap { Add } .
3. Set the time.
4. Optional: Tap { Repeat } .
Select weekday(s).
= selected weekdays
Cancel selection: Tap on weekday again.
Selection completed: Tap { < } .

15GB/IE/NI/MT/CY
5. Tap { Note } .
Put down your notes for this schedule.
Tap { SAVE } .
6. { Notification } :
Tap to turn on function.
7. Tap { Switch } .
Select:
– { On }
or
– { Off }
Selection completed:
– iOS:
Tap { < } .
– Android:
Tap { Done } .
8. Tap { SAVE } .
Action is added to the time plan.
1. Deactivate action: Tap .
2. Delete action:
– iOS:
Wipe action to the left.
– Android:
Tap and hold.
Tap { Delete } .
3. Add more actions, if desired.

16 GB/IE/NI/MT/CY
Additional functions
1. Tap (top right).
2. Tap .
Select:
– { Icon } :
* { Take Photo }
or
* { Select from Album }
– { Name } :
Rename product.
– { Location } :
Assign a room to the product.
* Access to the mobile devices’ camera
and photo library is required.
3. { Device Information } :
Virtual ID and product’s time zone are
displayed.
4. { Tap-to-Run and Automation } :
View smart scenes/automations involving the
product.
5. { Offline Notification } :
A notification is sent when the product is offline
for more than 30 minutes.
– Offline notification on:
Tap .
– Offline notification off:
Tap .
6. { Share Device } :
Share access to the device with other family
members.
7. { Create Group } :
Add product to a group in order to synchronise
the use of all grouped devices.
= selected devices.
Tap { Confirm } .
Name group.
Tap { Save } .
Group is shown on the app’s home screen.

17GB/IE/NI/MT/CY
8. { FAQ } :
Check FAQ related to the product.
9. { Check for Firmware Upgrade } :
Displays the ZigBee module’s Firmware version.
10. { Remove Device } :
Select:
– { Disconnect }
Remove product from the app. Data
remaining the product’s memory.
This operation only resets the product to
offline mode and starts the pairing mode.
If you want to remove all data of the product
and the cloud, read the following point.
– { Disconnect and wipe data }
Reset to factory settings.
This function deletes all data from the
product and in the cloud.
Use this function if you pass on,
dispose of or return the product to the
manufacturer.
Make sure that all data on the product
and in the cloud has been deleted.
Follow the instructions in the app.
or
– { Cancel }
Cancel removing the product.
Privacy policy
 { Me } tab:
{ Privacy Policy } :
Our complete privacy policy is available here.

18 GB/IE/NI/MT/CY
Tap-to-Run / Automation
The app offers the possibility to integrate the
product together with other smart Home devices
in user-defined scenarios and automatic actions.
1. { Smart } tab:
2. Select:
– { Tap-to-Run }
or
– { Automation }
NOTE: Detailed description of these functions
can be found in the Gateway manual.
{ Me } tab:
Tap { User Manual } .
Resetting product manually
1. Light switch on/off 3 times.
2. Light switch on. Product flashes slowly.
Reset successful.
This function only resets the data which is
stored in the local memory of the product. If
you want to reset the cloud memory as well,
perform a reset via the app (see “Additional
functions”, { Disconnect and wipe data } ).

19GB/IE/NI/MT/CY
Cleaning and care
Cleaning
mWARNING! Risk of electric shock!
Before changing luminary, cleaning or
maintenance: Switch off the product. Remove
fuse or switch off the circuit breaker in the fuse
box (position O).
mWARNING! Risk of electric shock!
During cleaning or operation, do not immerse
the electrical parts of the product in water or
other liquids. Never hold the product under
running water.
Let product cool for at least 5 minutes.
Clean the product and its accessories with a
slightly moistened cloth.
Do not allow any water or other liquids to enter
the product’s interior.
Do not use abrasives, harsh cleaning solutions
or hard brushes for cleaning.
Let all parts dry afterwards.
Storage
When not in use, store the product in its
original packaging.
Store the product in a dry, secure location
away from children.
Troubleshooting
Problem Cause Solution
Product
cannot be
controlled.
Distance between
Gateway and
product too large. Re-position
Gateway or
sub-device.
Walls or obstacles
between Gateway
and product.
Light switch on. Light switch
off.

20 GB/IE/NI/MT/CY
Disposal
Before passing on, disposing of or returning the
product to the manufacturer, make sure that all
data has been deleted from the product and
the cloud.
To do this, refer to the chapter:
“Additional functions”, menu point:
{ Disconnect and wipe data }
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics / 20–22: paper and
fibreboard / 80–98: composite
materials.
The product and packaging materials are
recyclable, dispose of it separately for
better waste treatment.
The Triman logo is valid in France only.
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information
on collection points and their opening
hours can be obtained from your local
authority.
Warranty
The product has been manufactured to strict quality
guidelines and meticulously examined before
delivery. In the event of product defects you have
legal rights against the retailer of this product.
Your legal rights are not limited in any way by our
warranty detailed below.
The warranty for this product is 3 years from the
date of purchase. Should this product show any
fault in materials or manufacture within 3 years
from the date of purchase, we will repair or replace
it – at our choice – free of charge to you.
The warranty period begins on the date of
purchase. Please keep the original sales receipt
in a safe location. This document is required as
your proof of purchase. This warranty becomes
void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material
or manufacture. This warranty does not cover
product parts subject to normal wear, thus
possibly considered consumables (e.g. batteries)
or for damage to fragile parts, e.g. switches,
rechargeable batteries or glass parts.
