LIVARNO LUX 351874 2007 User manual

SOLAR GROUND LIGHT CHAIN
SOLAR-BODENLICHTERKETTE
Bedienungs- und Sicherheitshinweise
IAN 351874_2007
SOLCELLELYSKÆDE MED JORDSPYD
Brugs- og sikkerhedsanvisninger
SOLAR GROUND LIGHT CHAIN
Operation and safety notes
BALISES SOLAIRES
Instructions d‘utilisation et consignes de sécurité
SOLAR-TUINLAMPEN KETTING
Bedienings- en veiligheidsinstructies

GB/IE/NI Operation and safety notes Page 5
DK Brugs- og sikkerhedsanvisninger Side 13
FR/BE Instructions d‘utilisation et consignes de sécurité Page 21
NL/BE Bedienings- en veiligheidsinstructies Pagina 29
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 37
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of
the device.
Før du læser, vend begge sidene med billeder frem og bliv bekendt med alle apparatets funktioner.
Avant de lire le mode d‘emploi, ouvrez les deux pages contenant les illustrations et familiarisez-vous ensuite
avec toutes les fonctions de l‘appareil.
Vouw vóór het lezen de beide pagina‘s met de afbeeldingen open en maak u vertrouwd met alle functies
van het apparaat.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

A1
2
3
B
4
5
4
5
10605A
10605C10605B

CW
OFF
MODE
D
211
12
10
9
C
6
6
8 7
8
6
8 7
7
10605A
10605B
10605C

5GB/IE/NI
List of pictograms used........................................................................................................Page 6
Introduction...................................................................................................................................Page 6
Intended use........................................................................................................................................Page 6
Parts description..................................................................................................................................Page 7
Technical data.....................................................................................................................................Page 7
Scope of delivery................................................................................................................................Page 7
Safety instructions...................................................................................................................Page 7
Product-specific safety instructions .....................................................................................................Page 7
Safety instructions for rechargeable batteries...................................................................................Page 8
Functionality.................................................................................................................................Page 8
Initial use.........................................................................................................................................Page 8
Assembling the fairy lights..................................................................................................................Page 8
Installing the fairy lights ......................................................................................................................Page 8
Switching the fairy lights on/off........................................................................................................Page 9
RGB mode...........................................................................................................................................Page 9
Replacing the rechargeable battery..................................................................................................Page 9
Charging..............................................................................................................................................Page 9
Maintenance and cleaning...............................................................................................Page 9
Troubleshooting ........................................................................................................................Page 9
Disposal............................................................................................................................................Page 10
Warranty and service...........................................................................................................Page 10
Service address...................................................................................................................................Page 11
Manufacturer.......................................................................................................................................Page 11

6 GB/IE/NI
List of pictograms used
Please read the operating
instructions! Wear safety gloves!
/DC Direct current/voltage Solar panel
Volt RGB mode/Colour changing
Observe the warning and
safety instructions! Lock/Release
This product is not suitable as
residential room lighting.
Improper disposal of
rechargeable batteries may
result in environmental damage!
Never leave children unsuper-
vised with packaging materials
and the product. b
a
Dispose of packaging and
device in an environmentally-
friendly way!
Potential of serious to fatal
injuries. Lighting duration of up to 8 hours
For outdoor use 5 LED modules
Caution! Danger of explosion! This product is suitable for
extreme temperatures up to
-21°C.
Caution! Fire hazard! Battery included
Dimensions
Solar Ground Light Chain
Introduction
Congratulations on the purchase of your
new device. You have selected a high
quality product. The instructions for use
are a part of this product. They contain important
information about safety, using the product and dis-
posal. Before using the product, please familiarise
yourself with all the operating and safety instruct ions.
Only use the product as described and for its indica ted
purpose. When passing this product on to others,
please be sure to include all its documentation.
Intended use
The solar fairy lights garden set is an ambient light
or a decorative light for outdoor use. The integrated
solar cell and the rechargeable battery allow usage
independent from the electricity grid. Any modifica-
tion to the product are considered improper use and

7GB/IE/NI
may result in considerable hazards. The manufac-
turer will not accept liability for loss or damage
arising from improper use. This device is not intended
for commercial use.
This product is not suitable as
residential room lighting.
This product is suitable for extreme temperatures
up to -21°C.
Parts description
1Solar panel
2Solar cell housing
3Ground stake (solar panel)
4Light cover
5Base plate
6Lantern
7Ground stake (lantern)
8Fairy lights
9MODE button
10 Switch
11 Power cable
12 Fixing screws
Technical data
Model-no.: 10605A/10605B/10605C
Rechargeable
battery: 1 x 18650 Li-ion rechargeable
battery, 1500mAh, 3.2V
Illuminant: white and RGB LEDs
Rated power: ca. 0.2W per LED
Degree of
protection: IP44 (splash-proof)
Scope of delivery
1 Solar ground light chain
1 18650 Li-ion rechargeable battery
(1500mAh/3.2V )
1 Ground stake 3for the solar panel 1
5 Ground stakes 7for the lanterns 6
1 Set of instructions for use
Safety instructions
PLEASE READ THE OPERATING INSTRUCTIONS
PRIOR TO USE! PLEASE KEEP THE INSTRUC-
TIONS IN A SAFE PLACE! IF PASSING THIS
PRODUCT ON TO A THIRD PARTY, INCLUDE
ALL DOCUMENTS!
This device may be used by children aged 8
years and up, as well as by persons with reduced
physical, sensory or mental capacities, or lack-
ing experience and/ or knowledge, so long as
they are supervised or instructed in the safe use
o
f the device and understand the associated ri sks.
Do not allow children to play with the appliance.
Cleaning and user maintenance should not be
performed by children without supervision.
Do not use the product if you detect any type
of damage.
Switch the product off whilst storing in a dark
environment to prevent draining the battery.
This product is only suitable for the specified use.
Product-specific safety
instructions
CAUTION! RISK OF INJURY! Make sure
that when the light is removed, the ground stakes
are also removed, so that they cannot pose any
risk (e.g. stumbling over them).
Make sure the solar cell is free of dirt and free
of snow and ice in winter. Otherwise the per-
formance of the solar panel will be diminished.
Cold temperatures negatively impact the battery
operating time. If the solar fairy lights garden
set will not be used for extended periods, e.g.
in winter, it should be cleaned and stored in a
dry, warm location.
The solar fairy lights garden set must not be
connected with the power supply while it is still
in its packaging, provided that the packaging
has not been adjusted for exhibition purposes.
The LEDs are non-replaceable.

8 GB/IE/NI
Safety instructions for
rechargeable batteries
RISK OF
ACCIDENT AND DANGER TO
LIFE FOR INFANTS AND CHIL-
DREN! Rechargeable batteries are not intended
to be in the hands of children. Do not leave the
batteries lying around. There is a danger that
these will be swallowed by children or pets. If
they are accidentally swallowed seek immediate
medical attention.
CAUTION!
EXPLOSION HAZARD! Use only
rechargeable batteries of the recom-
mended type. Other rechargeable or single-use
batteries could explode during charging.
FIRE HAZARD! Never short-circuit
rechargeable batteries. Otherwise the
rechargeable batteries may overheat,
become a fire hazard or explode.
CAUTION!
EXPLOSION HAZARD! Never
throw rechargeable batteries into
fire or water.
Expired or drained rechargeable batteries may
leak chemicals which will damage the product.
Therefore remove the rechargeable battery if
the fairy lights will not be used for extended
periods.
WEAR PROTECTIVE GLOVES!
Leaked or damaged rechargeable
batteries could cause chemical burns
on contact with the skin; you should therefore
wear suitable protective gloves at all times if
such an event occurs.
Only use rechargeable batteries of the correct
size and and the recommended type (see section
”Technical data”).
Make sure you fit the battery with the right po-
larity. This is displayed on the solar cell housing.
Functionality
The solar cell built into the product converts sunlight
into electricity and stores it in a LI-ION rechargeable
battery. The light switches on at dusk. The built-in
LED is an energy-saving illuminant with a very long
life. The light duration depends on the amount of
sunlight, the angle at which light hits the solar panel,
and the temperature (the battery capacity varies by
temperature). A vertical angle of light at temperatures
above the freezing point is ideal. The rechargeable
battery will only achieve its maximum capacity after
several charging and discharging cycles.
Initial use
Before first use, remove the protective film from
the solar panel 1.
Assembling the fairy lights
Insert the ground stake 3into the solar cell
housing 2(see Fig. A).
Place the light cover 4onto the base plate 5.
Pay attention to the recesses (see Fig. B).
Only model 10605A: Then, tighten the
light cover 4by turning it anticlockwise.
Only model 10605A: To loosen the con-
nection, turn the light cover 4clockwise from
the base plate 5.
Attach the ground stakes 7to the base plates
5by inserting the ground stakes 7into the
prefabricated notches on the underside of the
base plates 5and tighten them by turning them
counterclockwise.
Installing the fairy lights
Wear protective gloves when assem-
bling and setting up the fairy lights.
Ensure when setting them up that they are
securely positioned.
Push the ground stake 3for the solar panel
1far enough into the ground (lawn, flower
bed) so that it is in a firm and upright position
in the ground.

9GB/IE/NI
Make sure it is firmly positioned. Do not use
any force when assembling or setting up the
product, e.g. hammer blows. This will damage
the product. In order to achieve the best result,
set the solar fairy lights garden set up in a place
where the solar cell will get direct sunlight for
as long as possible.
Make sure the solar cell is not impacted by other
light sources, e.g. yard- or street lighting, or the
light will not switch on at twilight. In low light the
light will automatically switch on, and automati-
cally switch off in normal ambient light.
Insert the lanterns
6
with the ground stakes
7
so far into the ground (lawn, flower bed) that
they are positioned securely and upright in the
ground (see Fig. C).
Switching the fairy lights
on/ off (see Fig. D)
Slide the switch 10 to position “W“ or “C“ to
switch the fairy lights 8on. The fairy lights 8
will automatically switch on or off at twilight.
Slide the switch 10 to the “OFF” position to
switch the fairy lights 8off.
RGB mode
Slide the switch 10 to position “C” to activate
RGB mode.
When colour changing is activated, you can
press the MODE button 9to freeze the cur-
rent colour or you can continue with the colour
changing by pressing the MODE button 9
again. In position “W”, the LEDs light up white.
Replacing the
rechargeable battery
Note: For optimal performance, the rechargeable
battery should be replaced every 12 months.
Slide the switch 10 to the “OFF” position to
switch the fairy lights off.
Use a small cross-tip screwdriver to remove the
fixing screws 12 . Then use a slotted screwdriver
to pry open the solar panel 1on the solar
cell housing 2(see Fig. D).
Replace the old battery with a new one; be sure
not to damage the cables. Be sure to insert the
batteries in the correct direction. This is indicated
in the battery compartment. Use only recharge-
able batteries of the recommended type (see
“Technical data“).
Place the solar panel 1onto the solar cell
housing 2again and tighten the fixing screws
12 using a small cross-tip screwdriver (see Fig.
A and D).
Slide the switch 10 to position “W” or “C” to
switch on the fairy lights 8with white light or
RGB light respectively.
Charging
The battery charging period using the solar cell de-
pends on the intensity of the sunlight and the angle
incidence of the light on the solar cell. Place the so-
lar cell as perpendicular as possible to the angle of
light incidence. In this way you will receive the high-
est light levels. The rechargeable battery only charges
when the product is switched on. For this purpose,
slide the switch 10 to position “W” or “C”.
Maintenance and cleaning
The LEDs cannot be replaced. The solar fairy lights
garden set is maintenance-free, except for any nec-
essary change of rechargeable battery.
Routinely clean the solar fairy lights garden
set with a dry, lint-free cloth. Use a slightly
moist cloth if very dirty.
Troubleshooting
Note: The device contains sensitive electronic
components. Radio transmitting equipment in the
immediate vicinity may therefore cause interference.
If you notice the device is malfunctioning, remove

10 GB/IE/NI
any sources of interference from the area around
the device.
Note: Electrostatic discharge can lead to malfunc-
tions. In the event of such malfunctions, remove the
rechargeable battery briefly and reinsert it.
Error Cause Solution
The light will
not switch on
even though
the sun shone
on the solar
cell all day.
Artificial
sources of light,
e.g. street light-
ing, are inter-
fering with the
solar cell.
Install the solar
cell in a loca-
tion where it
will not be af-
fected by other
light sources.
The light does
not come on or
comes on only
briefly.
The recharge-
able battery
is broken or
there was not
enough day-
light.
Replace the
rechargeable
battery or in-
stall the solar
cell in a loca-
tion where it
has greater
exposure to
sunlight.
Disposal
The packaging is made entirely of recyclable mate-
rials, which you may dispose of at local recycling
facilities.
b
a
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics/ 20–22: paper and fibre-
board/ 80–98: composite materials.
The product and packaging materials
are recyclable, dispose of it separately
for better waste treatment. The Triman
logo is valid in France only.
Contact your local refuse disposal
authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information
on collection points and their opening
hours can be obtained from your local
authority.
Faulty or used batteries / rechargeable batteries
must be recycled in accordance with Directive
2006/66/EC and its amendments. Please return
the batteries/rechargeable batteries and/ or the
product to the available collection points.
Environmental damage through
incorrect disposal of the batter-
ies/rechargeable batteries!
Batteries/rechargeable batteries may not be dis-
posed of with the usual domestic waste. They may
contain toxic heavy metals and are subject to haz-
ardous waste treatment rules and regulations. The
chemical symbols for heavy metals are as follows:
Cd = cadmium, Hg = mercury, Pb = lead. That is
why you should dispose of used batteries/recharge-
able batteries at a local collection point.
Warranty and service
Note: This product includes a 36 month warranty
from the date of purchase. The product has been
produced to the highest standards and thoroughly
checked before dispatch. However, if defects in
manufacturing or material arise during the warranty
period, please contact your retailer immediately.
The warranty does not cover damages due to impr oper
handling, failure to comply with the operating instruc-
tions, or manipulation by unauthorised persons. Most
malfunctions are caused by incorrect operation. Th ere-
fore please first refer to the operating instructions if
a malfunction occurs.
Please contact the Uni-Elektra GmbH service address
with any questions. The product can only be returned
to us after contacting us. Postage due shipments will
