LIVARNO LUX HG00896B User manual

LED SENSOR LIGHT
IAN 285414
LED-SENSORLEUCHTE
Bedienungs- und Sicherheitshinweise
LED SVIETIDLO
Pokyny pre obsluhu a bezpečnostné pokyny
LED-SVETILKA S
SENZORJEM
Navodila za upravljanje in
varnostna opozorila
LED SENZOROVÉ SVÍTIDLO
Pokyny pro obsluhu a bezpečnostní pokyny
LED SENSOR LIGHT
Operation and Safety Notes
SZENZOROS LED LÁMPA
Kezelési és biztonsági utalások

LED SENSOR LIGHT
GB Operation and Safety Notes Page 5
HU Kezelési és biztonsági utalások Oldal 16
SI Navodila za upravljanje in varnostna opozorila Stran 27
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 39
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 50
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 61

A
4
4
1
3
1
3
2
HG00896B/HG00896D
HG00896C
2
2

B
7
HG00896C
HG00896B/HG00896D
65
8109
9
10
11

5GB
List of pictograms used.............................. Page 6
Introduction......................................................... Page 6
Intended use.............................................................. Page 7
Description of parts................................................... Page 7
Scope of delivery...................................................... Page 7
Technical data........................................................... Page 8
General safety instructions.................... Page 8
Safety instructions for batteries/
rechargeable batteries............................................. Page 9
Before use............................................................. Page 11
Inserting/ changing batteries ................................... Page 11
Mounting the product............................................... Page 12
Setting up the product............................................... Page 12
Start of operation .......................................... Page 13
Cleaning and care.......................................... Page 13
Disposal.................................................................. Page 13
Warranty............................................................... Page 14

6 GB
List of pictograms used
Direct current (Type of current and voltage)
splashproof
Detection angle: 80°–100°
Detection range: 3m
LED sensor light
Introduction
We congratulate you on the purchase of your new product.
You have chosen a high quality product. The instructions for
use are part of the product. They contain important
information
concerning safety, use and disposal
. Before using the product,
please familiarise yourself with all of the safety information and
instructions for use. Only use the product as described and for
the specified applications. If you pass the product on to
anyone else, please ensure that you also pass on all the
documentation with it.

7GB
Intended use
The product is only intended for use in private households.
This product is designed for indoor and outdoor use. The
product is not intended for commercial use or for use in other
applications.
Not suitable for household room illumination.
This product is suitable for extreme temperature
up to -21 °C.
Description of parts
1Battery compartment cover
2Screws
3Batteries
4Battery compartment
5Mounting screws (only for HG00896B and HG00896D)
6Dowels (Ø 6mm) (only for HG00896B and HG00896D)
7Wall bracket (only for HG00896B and HG00896D)
8Caps (only for HG00896B and HG00896D)
9Light
10 Sensor
11 Ground spike (only for HG00896C)
Scope of delivery
1 LED Sensor light
6 Batteries, 1.5V AAA
2 Dowels (Ø 6mm) (only for HG00896B/HG00896D)

8 GB
2 Mounting screws (only for HG00896B/ HG00896D)
2 Caps (only for HG00896B/ HG00896D)
1 Ground spike (only for HG00896C)
1 Instructions for assembly and use
Technical data
Model No.: HG00896B (white, with screw/dowel)
HG00896C (titanium, with ground spike)
HG00896D (titanium, with screw/dowel)
Illuminant: 6 LEDs, max. 0.06W per LED
Detection range: approx. 3m
Detection angle: approx. 80°–100°
Light on time: approx. 45s
Battery: 6 x 1.5V , AAA
Protection class: IP54 (splashproof)
LED lifespan: 20,000 hours
General safety instructions
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN
A SAFE PLACE FOR FUTURE REFERENCE!
This is not a toy.
This product can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruc-
tion concerning use of the product in a safe way and

9GB
understand the hazards involved. Children shall not play
with the product. Cleaning and user maintenance shall
not be made by children without supervision.
Electrostatic discharges may cause malfunctions. In the
event of such malfunctions, remove the batteries briefly
and reinsert them.
CAUTION! RISK OF INJURY! Please do not use this
product if you find that it is damaged in any way.
Never cover the product when it is in operation.
This product does not contain any parts that need to be
maintained by the user. The LED cannot be replaced.
The LEDs are not replaceable.
If the LEDs fail at the end of their lives, the product must
be replaced.
Never open one of the products of electrical equipment or
insert any objects into them.
For HG00896C:
When the product is not in use, the ground spike 11
should also be removed to avoid any risk, for example,
stumbling.
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries / rechargeable bat-
teries out of reach of children. If accidentally swallowed
seek immediate medical attention.
DANGER OF EXPLOSION! Never re-
charge non-rechargeable batteries. Do not
short-circuit batteries/rechargeable batteries

10 GB
and/ or open them. Overheating, fire or bursting can be
the result.
Never throw batteries/ rechargeable batteries into fire or
water.
Do not exert mechanical loads to batteries/ rechargeable
batteries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures,
which could affect batteries/rechargeable batteries, e.g.
radiators/direct sunlight.
Avoid contact with the skin, eyes and mucous membranes.
In the event of contact with battery acid, thoroughly flush
the affected area with plenty of clean water and seek
immediate medical attention.
WEAR PROTECTIVE GLOVES! Leaked or
damaged batteries/rechargeable batteries
can cause burns on contact with the skin. Wear
suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/ rechargeable bat-
teries, immediately remove it from the product to prevent
damage.
Only use the same type of batteries/rechargeable batter-
ies. Do not mix used and new batteries/ rechargeable
batteries.
Remove the batteries/ rechargeable batteries if the
product will not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable
battery!

11GB
Insert batteries/ rechargeable batteries according to
polarity marks (+) and (-) on the battery/rechargeable
battery and the product.
Clean the contacts on the battery/rechargeable battery
and in the battery compartment before inserting!
Remove exhausted batteries/rechargeable batteries from
the product immediately.
Before use
Note: Remove all packaging materials from the product.
Inserting/changing batteries
(see Fig. A)
Open the battery compartment 4on the back side of
the product by loosening the screws 2anti-clockwise
with a cross type screw driver.
Open the battery compartment cover 1.
Insert the batteries 3. Only use batteries of the specified
type (see “Technical data”).
Note: When inserting the batteries 3ensure the correct
polarity! This is indicated in the battery compartment 4.
Close the battery compartment 4again with the battery
compartment cover 1.
Make sure the narrow of symbol and marked on
cover and enclosure face to each other, which means
cover is place at a correct position.
Fix the cover by screwing the screws 2tightly in clock-
wise direction.

12 GB
Mounting the product
For HG00896B and HG00896D only (see Fig. B):
Note: You will need an electric drill to install the product.
CAUTION! RISK OF INJURY! Refer to the operating
instructions for your electric drill.
CAUTION! Ensure that you do not damage any cables in the
wall.
Use the round holes of the wall bracket 7intended for
the mounting screws 5to mark the holes for drilling.
Now drill the mounting holes.
Insert the dowels 6into the drilled holes.
Fix the wall bracket
7
using the included mounting screws
5
.
Press the caps 8on the screws.
Your product is now ready for use.
Setting up the product
For HG00896C only (see Fig. B):
Insert the ground spike 11 to the light 9. Ensure the
product is correctly seated.
Your product is now ready for use.
Insert the product far enough into the ground (lawn,
flower bed) for it to be stable.
Make sure you keep proper footing and balance at all
times. Do not use any force when assembling or setting-up
the product, e.g. hammer blows. This will damage the
product.

13GB
Start of operation
The product will automatically switch on when motion is
detected in a dark environment.
The product will automatically switch off when motion is
no longer detected for a period of time.
Cleaning and care
Clean the product regularly with a dry, lint-free cloth.
Use a slightly dampened cloth to remove more stubborn
dirt.
Disposal
The packaging is made entirely of recyclable materi-
als, which you may dispose of at local recycling
facilities. The Green Dot is not valid for Germany.
b
a
Observe the marking of the packaging materials
for waste separation, which are marked with
abbreviations (a) and numbers (b) with following
meaning: 1–7: plastics/20–22: paper and
fibreboard/80–98: composite materials.
The product and packaging materials are recycla-
ble, dispose of it separately for better waste
treatment. The Triman logo is valid in France only.

14 GB
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.
To help protect the environment, please dispose of
the product properly when it has reached the end
of its useful life and not in the household waste. In-
formation on collection points and their opening
hours can be obtained from your local authority.
Faulty or used batteries must be recycled in accordance with
Directive 2006/66/EC and its amendments. Please return
the batteries and/or the product to the available collection
points.
Environmental damage through incorrect
disposal of the rechargeable batteries!
Batteries may not be disposed of with the usual domestic
waste. They may contain toxic heavy metals and are subject to
hazardous waste treatment rules and regulations. The chemi-
cal symbols for heavy metals are as follows: Cd = cadmium,
Hg = mercury, Pb = lead. That is why you should dispose of
used rechargeable batteries at a local collection point.
Warranty
The product has been manufactured to strict quality guidelines
and meticulously examined before delivery. In the event of
product defects you have legal rights against the retailer of
this product. Your legal rights are not limited in any way by
our warranty detailed below.

15GB
The warranty for this product is 3 years from the date of
purchase. Should this product show any fault in materials or
manufacture within 3 years from the date of purchase, we will
repair or replace it – at our choice – free of charge to you.
The warranty period begins on the date of purchase. Please
keep the original sales receipt in a safe location. This docu-
ment is required as your proof of purchase. This warranty
becomes void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material or manufacture.
This warranty does not cover product parts subject to normal
wear, thus possibly considered consumables (e.g. batteries) or
for damage to fragile parts, e.g. switches, rechargeable batte-
ries or glass parts.

16 HU
Az alkalmazott piktogramok
jelmagyarázata..............................................Oldal 17
Bevezető...............................................................Oldal 17
Rendeltetésszerű használat .....................................Oldal 18
Alkatrészleírás..........................................................Oldal 18
A csomag tartalma...................................................Oldal 18
Műszaki adatok .......................................................Oldal 19
Általános biztonsági utasítások.......Oldal 19
Az elemekre/akkukra vonatkozó
biztonsági tudnivalók...............................................Oldal 20
Az üzembe helyezés előtt......................Oldal 22
Elemek behelyezése/ cseréje..................................Oldal 22
A termék rögzítése...................................................Oldal 22
A termék felállítása ..................................................Oldal 23
Üzembe helyezés..........................................Oldal 23
Tisztítás és ápolás.........................................Oldal 24
Mentesítés ...........................................................Oldal 24
Garancia...............................................................Oldal 25

17HU
Az alkalmazott piktogramok jelmagyarázata
Egyenáram (áram- és feszültségfajta)
Fröccsenő víztől védett
Hatószög: 80°–100°
Hatóterület: 3m
Szenzoros LED lámpa
Bevezető
Gratulálunk új termékének vásárlása alkalmából. Ezzel a
döntésével vállalatunk értékes terméke mellett döntött. A hasz-
nálati utasítás ezen termék része. A biztonságra, a használa-
tára és a megsemmisítésre vonatkozó fontos tudnivalókat
tartalmazza. A termék használata előtt ismerje meg az összes
használati és biztonsági tudnivalót. A terméket csak a leírtak
szerint és a megadott felhasználási területeken alkalmazza.
A termék harmadik személy számára való továbbadása ese-
tén kézbesítse vele annak a teljes dokumentációját is.

18 HU
Rendeltetésszerű használat
A termék csak magánháztartásokban való használatra
készült. A termék bel- és külterületeken történő alkalmazásra
készült. A terméket nem közületi felhasználásra, vagy egyéb
alkalmazásra szánták.
Ez a termék nem alkalmas arra, hogy háztartá-
sok központi fényforrásaként szolgáljon.
Ez a termék -21°C-ig extrém hőmrséklethez is megfelelő.
Alkatrészleírás
1Elemrekesz-fedél
2Csavarok
3Elemek
4Elemrekesz
5Rögzítőcsavarok (csak HG00896B és HG00896D)
6Tipli (Ø 6mm) (csak HG00896B és HG00896D)
7Fali rögzítés (csak HG00896B és HG00896D)
8Zárókupakok (csak HG00896B és HG00896D)
9Lámpa
10 Érzékelő
11 Talajnyárs (csak HG00896C)
A csomag tartalma
1 LED-es érzékelős lámpa
6 elem, 1,5V AAA
2 tipli (Ø 6mm) (csak HG00896B és HG00896D)
2 rögzítőcsavar (csak HG00896B és HG00896D)

19HU
2 zárókupak (csak HG00896B és HG00896D)
1 talajnyárs (csak HG00896C)
1 Szerelési és kezelési útmutató
Műszaki adatok
Modellsz.: HG00896B (fehér, csavarokkal/tiplikkel)
HG00896C (titán, talajnyárssal)
HG00896D (titán, csavarokkal/tiplikkel)
Izzó: 6 LED, max. 0,06W LED-enként
Érzékelési tartomány: kb. 3 m
Érzékelési szög: kb. 80°–100°
Világítási időtartam: kb. 45 mp
Elem: 6 x 1,5V AAA
Védelmi jelleg: IP54 (fröccsenő vízzel szemben védett)
LED-élettartam: 20 000 óra
Általános biztonsági utasítások
Őrizzen meg minden biztonsági tudnivalót és utasítást a
jövőbeni felhasználás céljából!
A termék nem játékszer.
A terméket 8 éves kor feletti gyermekek, valamint korlátozott
fizikai, érzékszervi vagy szellemi képességgel élő vagy
nem megfelelő tapasztalattal és tudással rendelkező sze-
mélyek csak felügyelet mellett, illetve a termék biztonsá-
gos használatára vonatkozó felvilágosítás és a lehetséges
veszélyek megértése után használhatják. A gyermekek

20 HU
nem játszhatnak a termékkel. A tisztítást és az ápolást
gyermekek felügyelet nélkül nem végezhetik.
Az elektrosztatikus kisülések működési zavarokhoz vezet-
hetnek. Ilyen működési zavarok előállása esetén távolítsa
el a készülékből rövid időre az elemet és utána helyezze
azt újra vissza.
VIGYÁZAT! SÉRÜLÉSVESZÉLY! Ne használja a
terméket, ha rajta bármilyen sérülést fedez fel rajta.
Soha ne fedje le a terméket, amíg az üzemel.
Ez a termék nem tartalmaz olyan részt, amely a felhasználó
részéről karbantartást igényelne. A LED-eket nem lehet
kicserélni.
A LED-ek nem cserélhetők.
Amennyiben a LEDek élettartamuk végén kiiktatódnak,
úgy a terméket ki kell cserélni.
Soha ne nyisson fel elektromos üzemi eszközt, illetve ne
dugdosson bele tárgyakat.
HG00896C-hez:
Ha a terméket nem használja , akkor a talajnyársat 11 is
el kell távolítani a taajból, hogy elkerüljük a veszélyeket,
pl. botlás által.
Az elemekre/akkukra vonatko-
zó biztonsági tudnivalók
ÉLETVESZÉLY! Tartsa távol az elemeket/ akkumulátoro-
kat a gyermekektől. Lenyelés esetén azonnal forduljon or-
voshoz!
ROBBANÁSVESZÉLY! Soha ne töltse a nem
feltölthető elemeket. Az elemeket / akkukat tilos
