Living Spaces XPLORER 51 User manual

XPL5125
XPLORER 51 GAMING CHAIR
ASSEMBLY INSTRUCTIONS
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and pull lever (1) up.
To lower seat height sit on chair and pull lever (1) up.
NOTE: It is normal for chair to slightly lower under body weight.
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped with an
adjustment that will allow the user to change the tension of
the tilting feature. Turn knob (2) clockwise to increase tension
and counter-clockwise to decrease or ease the tension. To lock
return chair to the upright position and push lever (1) in. To
unlock pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob completely.
• FLIP ARM
To flip arms up, simply pull up on arm. To lower arm, simply pull
down on arm.
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and knobs are
securely tightened.
3. Check that all bolts screws and knobs are tight every three
months or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic cover
as head covering. It may cause suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
XPL5125
XPLORER 51 GAMING CHAIR
ASSEMBLY INSTRUCTIONS
1
2
STEP 5 STEP 6
G
5
FL
2FR
4

HARDWARE LIST
NO DRAWING DESCRIPTION SIZE QUANTITY
1Screw 4 PCS
8 PCS
4 PCS
8 PCS
Screw
Flat Washer
Plastic Cap
Allen Wrench
6 X 20mm
8 X 25mm
6 X 18mm
Ø
2
3
4
1 PCM65
(A) Caster (5 PCS) (B) Base (1 PC)
(C) Pneumatic Cylinder (1 PC) (D) Bellows (1 PC)
(E) Seat Plate (1 PC) (F) Arms (L & R) (2 PCS)
PARTS
(G) Back Cushion (1 PC) (H) Seat Cushion (1 PC)
XPL5125
XPLORER 51 GAMING CHAIR
ASSEMBLY INSTRUCTIONS
STEP 1 STEP 2
D
C
H
5
1
3
B
A
STEP 3 STEP 4
C52
FR
FL
H
E
