LOGICDATA TOUCH Series User manual

MANUAL
Document Version 1.0 / February 2019
TOUCHfamily
Valid for:
• TOUCHfx
• TOUCHdown
• TOUCHinlay

TOUCH FAMILY - OPERATING MANUAL // PAGE 2
TOUCH Family - Operating Manual
Document Version 1.0/February 2019
This document was originally published in English.
LOGICDATA Electronic & Software Entwicklungs GmbH
Wirtschaftspark 18
8530 Deutschlandsberg
Austria
Phone: [phone]
Fax: [phone]
Internet: http://www.logicdata.net
Email: o[email protected]

TOUCH FAMILY - OPERATING MANUAL // PAGE 3
CONTENTS
1 General information 5
1.1 Other applicable documents 5
1.2 Copyright 5
1.3 Royalty-free use of images and text 5
1.4 Trademarks 5
2Safety 6
2.1 Target audience 6
2.2 General safety regulations 6
2.3 Intended use 6
2.4 Reasonably foreseeable misuse 6
2.5 Explanation of symbols and signal words 7
2.6 Liability 7
2.7 Residual risks 8
2.8 Skilled Persons 9
2.9 Notes for Resellers 9
3 Scope of delivery 10
4Unpackaging 10
5 Products 11
5.1 Key Product Features 11
5.1.1 TOUCHfx 11
5.1.2 TOUCHdown 12
5.1.3 TOUCHinlay 12
5.2 Dimensions 13
5.2.1 TOUCHfx 13
5.2.2 TOUCHdown 13
5.2.3 TOUCHinlay 14
5.2.4 Dimensions for the milled cut-out 14
5.3 Drilling Templates 15
5.3.1 TOUCHfx 15
5.3.2 TOUCHdown 16
6 Assembly 17

TOUCH FAMILY - OPERATING MANUAL // PAGE 4
6.1 Safety During Assembly 17
6.2 TOUCHfx 18
6.2.1 Required Components 18
6.2.2 Process 18
6.2.3 Completing Assembly 18
6.3 TOUCHdown 19
6.3.1 Required Components 19
6.3.2 Process 19
6.3.3 Completing Assembly 20
6.4 TOUCHinlay 21
6.4.1 Required Components 21
6.4.2 Process 21
6.4.3 Completing Assembly 21
7 Operation 22
7.1 Adjusting the Table Top Height 23
7.2 Saving a Memory Position 23
7.3 Adjusting the Table to a Memory Position 24
7.4 Key Lock 25
7.5 Notes for TOUCHdown 26
7.5.1 Push-Push Function 26
7.5.2 Mechanical Release 26
8 Additional Information 27
8.1 Software-Dependent Functions 27
8.2 Disassembly 27
8.3 Maintenance 27
8.3.1 Cleaning 27
8.3.2 Replacing a Handset 27
8.4 Troubleshooting 28
8.5 Disposal 28

TOUCH FAMILY - OPERATING MANUAL // PAGE 5
1 GENERAL INFORMATION
Documentation for the TOUCH Family consists of this Operating Manual and several other documents
(Other applicable documents, page 5). Assembly personnel must read all documentation before starting as-
sembly. Keep all documentation for as long as the product is in your possession. Ensure that all documen-
tation is provided to subsequent owners. Go to www.logicdata.net for more information and support. This
Manual may change without notice. The most recent version is available on our website.
1.1 OTHER APPLICABLE DOCUMENTS
This Operating Manual contains assembly instructions for the Handsets within the TOUCH Family. Other
applicable documents include:
• Datasheet for the TOUCH Handset.
• Datasheet and Operating Manual for the Control Box in the Table System
1.2 COPYRIGHT
© January 2019 by LOGICDATA Electronic und Software Entwicklungs GmbH. All rights reserved, except for
those listed in Chapter 1.3 Royalty-free use of images and text on page 5.
1.3 ROYALTY-FREE USE OF IMAGES AND TEXT
After purchase and full payment of the product, all text and images in Chapter 2 “Safety”, may be used free of
charge by the customer for 10 years after delivery. They should be used to prepare end user documentation
for Height-Adjustable Table Systems. The license does not include logos, designs, and page layout elements
belonging to LOGICDATA. The Reseller may make any necessary changes to the text and images to adapt
them for the purpose of end user documentation. Texts and images may not be sold in their current state,
and may not be published or sublicensed digitally. The transfer of this license to third parties without per-
mission from LOGICDATA is excluded. Full ownership and copyright of the text and graphics remain with
LOGICDATA. Texts and graphics are oered in their current state without warranty or promise of any kind.
Contact LOGICDATA to obtain text or images in an editable format ([email protected]).
1.4 TRADEMARKS
Documentation may include the representation of registered trademarks of goods or services, as well as
information about copyright or other proprietary expertise of LOGICDATA or third parties. In all cases, all
rights remain exclusively with the respective copyright holder. LOGICDATA® is a registered trademark of
LOGICDATA Electronic & Software GmbH in the USA, the European Union, and other countries.

TOUCH FAMILY - OPERATING MANUAL // PAGE 6
2 SAFETY
2.1 TARGET AUDIENCE
This Operating Manual is intended for Skilled Persons only. Refer to Chapter 2.8 Skilled Persons on page 9 to
ensure that personnel meet all requirements.
2.2 GENERAL SAFETY REGULATIONS
In general, the following safety regulations and obligations apply when handling the product:
• Do not operate the product unless it is in a clean and perfect condition
• Do not remove, change, bridge, or bypass any protection, safety, or monitoring equipment
• Do not convert or modify any components without written approval from LOGICDATA
• In the event of malfunction or damage, faulty components must be replaced immediately
• Unauthorized repairs are prohibited
• Do not attempt to replace hardware unless the product is in a de-energized state
• Only Skilled Persons are allowed to work with TOUCH Handsets
• Ensure that national worker protection conditions and national safety and accident prevention
regulations are observed during operation of the system
2.3 INTENDED USE
The products in the TOUCH Family are Handsets for electrically Height-Adjustable Tables. They are installed
by Resellers into Height-Adjustable Table systems. They are used to control Height-Adjustable Table systems
via a Control Box. They are intended for indoor use only. They may only be installed in compatible Height-
Adjustable Tables and with LOGICDATA-approved accessories. Contact LOGICDATA for further details. Use
beyond or outside the intended use will void the product’s warranty.
2.4 REASONABLY FORESEEABLE MISUSE
Usage outside of the intended use may lead to minor injury, serious injury, or even death. Reasonably fore-
seeable misuse of the Handset includes, but does not extend to:
• Connecting unauthorized parts to the product. If you are unsure as to whether a part can be used
with a Handset, contact LOGICDATA for further information

TOUCH FAMILY - OPERATING MANUAL // PAGE 7
2.5 EXPLANATION OF SYMBOLS AND SIGNAL WORDS
Safety Notices contain both symbols and signal words. The signal word indicates the severity of the hazard.
DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a hazardous situation which, if not avoided, could result in minor or moderate
injury.
NOTICE Indicates a situation which, if not avoided, could result in damage to the product
through electrostatic discharge (ESD).
NOTICE Indicates a situation that will not lead to personal injury, but could lead to damage to
the device or the environment.
INFO Indicates the protection class of the device: Protection Class III.
Protection Class III devices may only be connected to SELV or PELV power sources.
INFO Indicates important tips for handling the product.
2.6 LIABILITY
LOGICDATA products comply with all currently applicable health and safety regulations. However, risk can
result from incorrect operation or misuse. LOGICDATA is not liable for damage or injury caused by:
• Improper product use
• Disregard of the documentation
• Unauthorized product alterations
• Improper work on and with the product
• Operation of damaged products
• Wear parts
• Improperly performed repairs
• Unauthorized changes to the operating parameters
• Disasters, external inuence, and force majeure
The information in this Operating Manual describes the characteristics of products without assurances.
Resellers assume responsibility for the LOGICDATA products installed in their applications. They must en-

TOUCH FAMILY - OPERATING MANUAL // PAGE 8
sure their product complies with all relevant directives, standards, and laws. LOGICDATA shall not be held
liable for any damage that is directly or indirectly caused by the delivery or use of this document. Resellers
must observe the relevant safety standards and guidelines for each product in the Table System.
2.7 RESIDUAL RISKS
Residual risks are the risks that remain after all relevant safety standards have been complied with. These
have been evaluated in the form of a risk assessment. Residual risks associated with the installation of
Handsets in the TOUCH Family are listed here and throughout this Operating Manual. See also Chapter 1.1
Other Applicable Documents on page 5. The symbols and signal words used in this Operating Manual are
listed in Chapter 2.5 Explanation of Symbols and Signal Words on page 7.
WARNING Risk of death or serious injury through electric shocks
TOUCH Handsets are electrical devices. Although you will not have to connect the
Handset to the Control Box during assembly, basic safety precautions must be taken at
all times. Failure to observe electrical safety precautions may lead to death or serious
injury through electric shocks.
• Never open the Handset
• Ensure that the Handset is not connected to the Control Box during assembly
• Do not convert or modify the Handset in any way
• Do not immerse the Handset or its components in liquid. Clean only with a dry or
slightly damp cloth
• Do not place the Cable of the Handset on heated surfaces
• Check the housing and cables of the Handset for visible damage. Do not install or
operate damaged products.
WARNING Risk of death or serious injury in explosive atmospheres
Operating the Handset in potentially explosive atmospheres may lead to death or seri-
ous injury through explosions.
• Read the relevant directives to determine if an atmosphere is potentially explosive
• Do not operate the Handset in potentially explosive atmospheres
CAUTION Risk of minor or moderate injury through tripping
During the assembly process, you may have to step over Cables. Tripping over Cables
may lead to minor or moderate injury.
• Ensure that the assembly area is kept clear of unnecessary obstructions
• Be careful not to trip over Cables
CAUTION Risk of minor or moderate injury through crushing
If any Handset Key becomes stuck while the system is in motion, the system may not
stop properly. This may lead to minor or moderate injury through crushing.
• Disconnect the system immediately if any Handset Key becomes stuck

TOUCH FAMILY - OPERATING MANUAL // PAGE 9
2.8 SKILLED PERSONS
CAUTION Risk of injury through incorrect assembly
Only Skilled Persons have the expertise to complete the assembly process safely.
Assembly by Unskilled Persons may lead to minor or moderate injury.
• Ensure that only Skilled Persons are allowed to complete assembly
• Ensure that persons with limited ability to react to danger do not take part in the
assembly process
TOUCH Handsets may only be installed by Skilled Persons. A Skilled Person is dened as someone who:
• Is authorized for installation planning, installation, commissioning, or servicing of the product
• Has read and understood all documentation relevant to the Handset
• Has the technical education, training, and/or experience to perceive risks and avoid hazards
• Has knowledge of the specialist standards applicable to the product
• Has the expertise to test, assess, and manage electrical and mechatronic products and systems in
accordance with the generally accepted standards and guidelines of electrical engineering and
furniture manufacturing
2.9 NOTES FOR RESELLERS
Resellers are companies that purchase LOGICDATA products for installation in their own products.
INFO For reasons of EU conformity and product safety, Resellers should provide end users
with an Operating Manual in their native EU ocial language.
INFO Operating Manuals must include all the safety instructions that end users require to
handle the product safely. They must also include an instruction to always keep the
Operating Manual in the immediate vicinity of the product.
INFO No unauthorized persons (young children, persons under the inuence of medications,
etc.) should be allowed to handle the product.
INFO Resellers must perform a risk assessment on their product that covers residual hazards.
It must include measures to mitigate risk, or reference the product's Operating Manual.

TOUCH FAMILY - OPERATING MANUAL // PAGE 10
3 SCOPE OF DELIVERY
The standard scope of delivery for Handsets in the TOUCH Family consists of the Handset and its pre-at-
tached cable. All other components necessary for installing the Handset (e.g. Mounting Screws for the
TOUCHdown and TOUCHfx) must be supplied separately by the reseller.
4 UNPACKAGING
NOTICE Ensure proper ESD handling during unpackaging. Damage that can be attributed to
electrostatic discharge will void warranty claims.
To unpackage the product:
1. Remove all components from the packaging
2. Check the contents of the package for completeness and damage
3. Provide the Operating Manual to the operating personnel
4. Dispose of the packaging material
NOTICE Dispose of the packaging material in an environmentally friendly manner. Remember
to separate plastic parts from the cardboard packaging.

TOUCH FAMILY - OPERATING MANUAL // PAGE 11
5 PRODUCTS
The TOUCH Family of Handsets consists of 3 products:
• TOUCHfx
• TOUCHdown
• TOUCHinlay
Each Handset may have several variants. Variants may be equipped with additional features or dierent
congurations. The exact variant is denoted by the product's order code. Consult the accompanying data
sheet to check ensure that you have received the correct variant.
5.1 KEY PRODUCT FEATURES
5.1.1 TOUCH-FX
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Drilling Holes
6 Strain Relief
*Cable not shown.
Fig. 1: Product features, TOUCHfx
4
5
61
2
3

TOUCH FAMILY - OPERATING MANUAL // PAGE 12
5.1.2 TOUCH-DOWN
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Drilling Holes
6 Supports for Cable Loop
*Cable not shown.
Fig. 2: Product features, TOUCHdown
5.1.3 TOUCH-INLAY
1 UP / DOWN Keys
2 Memory Position Keys
3 SAVE Key
4 Display
5 Rubber Ribs
*Cable not shown.
Fig. 3: Product features, TOUCHinlay
56
4
31 2
2
1
5
4
3

TOUCH FAMILY - OPERATING MANUAL // PAGE 13
5.2 DIMENSIONS
5.2.1 TOUCHFX
Length 85.9 mm | 3.380 "
Width 132.5 mm | 5.216 "
Height (to underside of Table Top) 32.8 mm | 1.289 "
Fig. 4: Product dimensions, TOUCHfx
5.2.2 TOUCH-DOWN
Length 150.3 mm | 5.917 "
Width 183.6 mm | 7.228 "
Height (to underside of Table Top) 38.8 mm | 5.917 "
Fig. 5: Product dimensions, TOUCHdown
3,380 "
85,9 mm
5,216 "
132,5 mm
1,289 "
32,8 mm
38,8 mm
150,3 mm
5.917 "
1.528 "
155,6 mm
6.126 "
75,0 mm
2.953 "
183,6 mm
7.228 "

TOUCH FAMILY - OPERATING MANUAL // PAGE 14
5.2.3 TOUCHINLAY
Length 42.0 mm | 1.654 "
Width 95.4 mm | 3.756 "
Height (to bottom of rubber ribs) 17.3 mm | 0.681 "
Fig. 6: Product dimensions, TOUCHinlay
5.2.4 DIMENSIONS FOR THE MILLED CUT-OUT
The milled cut-out for the TOUCHinlay shall have the following dimensions (image to scale):
Fig. 7: Dimensions for the milled cut-out, TOUCHinlay
INFO It is assumed that the milled cut-out will pass through the entire table top (i.e. milling
will create a hole rather than an indent). If you do not mill through the entire Table
Top, you will need to drill a separate hole to accomodate the TOUCHinlay's cable. In this
case, contact LOGICDATA for further information on dimensions.
0,681 "
35,7 mm
1,406 "
17,3 mm
1
2
SAVE
42,0 mm
1,654 "
95,4 mm
3,756 "
93,0 mm ± 0,193,0 mm ± 0,1
3,661 " ± 0,013,661 " ± 0,01
39,2 mm ± 0,139,2 mm ± 0,1
1,433 " ± 0,011,433 " ± 0,01

TOUCH FAMILY - OPERATING MANUAL // PAGE 15
5.3 DRILLING TEMPLATES
5.3.1 TOUCHFX
Fig. 8: Drilling Template, TOUCHfx
38 mm
1.496 "
70 mm
2.756 "
Side Edge
Front Edge

TOUCH FAMILY - OPERATING MANUAL // PAGE 16
5.3.2 TOUCH-DOWN
Fig. 9: Drilling Template, TOUCHdown
Side Edge
Front Edge
75.0 mm
2.95 "
34.0 mm
1.34 "
34.0 mm
1.34 "
170.4 mm
6.71 "
106.0 mm
4.17 "
106.0 mm
4.17 "

TOUCH FAMILY - OPERATING MANUAL // PAGE 17
6 ASSEMBLY
This chapter describes the process of installing the TOUCH Family Handset into the Height-Adjustable
Table System.
6.1 SAFETY DURING ASSEMBLY
The following safety instructions are valid for each Handset within the TOUCH Family. Hazards relating
only to the installation of a specic Handset are listed in that Handset's assembly instructions.
CAUTION Risk of minor or moderate injury through improper handling
Improper handling of the product during assembly may lead to minor or moderate in-
jury through cutting, pinching, and crushing.
• Avoid contact with sharp edges
• Be careful while handling tools that may cause personal injury
• Ensure assembly complies with the generally accepted standards and guidelines of
electrical engineering and furniture manufacturing
• Read all instructions and safety advice carefully
CAUTION Risk of minor or moderate injury through tripping
During assembly and operation, poorly routed Cables may become a trip hazard.
Tripping over Cables may lead to minor or moderate injury.
• Ensure that Cables are routed properly to avoid trip hazards
• Be careful not to trip over Cables when installing the Handset
NOTICE Ensure proper ESD handling during assembly. Damage that can be attributed to electro-
static discharge will void warranty claims.
NOTICE To avoid damage to the product, measure the dimensions of the Handset before
assembly.
NOTICE Before assembly, all parts must be acclimatised to the ambient conditions.
NOTICE Do not lift the Handset by its cable. This will cause irreparable damage to the product.
INFO Perform a product risk assessment so that you can respond to potential residual haz-
ards. Assembly instructions must be included in your end user Operating Manual.

TOUCH FAMILY - OPERATING MANUAL // PAGE 18
6.2 ASSEMBLY: TOUCHfx
6.2.1 REQUIRED COMPONENTS
1 TOUCHfx
2 2 Mounting Screws (supplied by Reseller)
Tool Screwdriver
INFO Screw specications
Thread diameter: max. 5 mm | Head diameter: 8.5 mm - 10.6 mm
If possible, do not use countersunk-head screws.
6.2.2 PROCESS
1. Position the Handset under the table top and mark the position of the drilling holes. If necessary,
use the Drilling Template in chapter 5.3.1 to help you.
2. Insert the Strain Relief into the designated slot on the Handset (Fig. 6).
NOTICE Inserting the Strain Relief incorrectly may cause damage to the Cable and Handset.
Ensure that the Cable does not protrude over the housing
Fig. 10: Inserting the TOUCHfx Strain Relief
3. Use the screwdriver and 2 Mounting Screws to attach the Handset to the Table Top at the
marked drilling points.
NOTICE The required tightening torque depends on the material of the Table Top. Do not exceed
2 Nm.
6.2.3 COMPLETING ASSEMBLY
After the TOUCHfx is attached to the Table Top, you must connect the Cable to the Control Box. Refer to the
manual for your chosen Control Box for instructions.

TOUCH FAMILY - OPERATING MANUAL // PAGE 19
6.3 ASSEMBLY: TOUCHDOWN
6.3.1 REQUIRED COMPONENTS
The following components are required to assemble the TOUCHdown:
1 TOUCHdown
2 4 Mounting Screws (supplied by Reseller)
Tool Screwdriver
INFO Screw specications
Thread diameter: max. 5 mm | Head diameter: max. 10 mm
If possible, do not use countersunk-head screws.
6.3.2 PROCESS
1. Position the Handset under the table top and mark the position of the drilling holes (Fig. 11).
Alternatively, use the Drilling Template in Chapter 5.3.2 to help you. Ensure that the corners
circled in the diagram below are ush with the edge of the Table Top.
INFO If the mounting area has a curved edge, move the Handset slightly backwards.
Fig. 11: Positioning the TOUCHdown on the Table Top
1
2

TOUCH FAMILY - OPERATING MANUAL // PAGE 20
2. Ensure the cable is routed correctly. For correct operation, a 10cm Cable Loop must be routed.
Use the Cable supports on the back edge of the Control Box to help you do this (Fig. 12).
Fig. 12: Creating a Cable Loop
3. Use the screwdriver and 4 Mounting Screws to attach the Handset to the Table Top at the
marked drilling points.
NOTICE The required tightening torque depends on the material of the Table Top. Do not exceed
2 Nm.
6.3.3 COMPLETING ASSEMBLY
After the TOUCHdown is attached to the Table Top, you must connect the Cable to the Control Box. Refer to
the manual for your chosen Control Box for instructions.
