Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Logik Portable Boombox with Cassette.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it oers. You will also
nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
CD Stereo with Cassette
Instruction Manual
LCCSTR10 / LBOOMPK11
4
LCCSTR10_LBOOMPK11_IB_final110518.indd 4 18/05/2011 2:41 PM

Product Overview
Top View
1. Handle
2. Telescopic FM
Aerial
3. CD Door
4. Control Panel
Front View
Control Panel (Cassette)
1
2
3
4
7. Button
• Press to pause a tape during playback
8. Button
• Press to stop a tape during playback
or to open the cassette door
9. Button
• Press to perform fast forward playback
10. Button
• Press to perform fast backward
playback.
11. Button
• Press to play a tape
12. Button
• Press to start recording
N
E
X
T
R
E
P
E
A
T
B
A
C
K
P
L
A
Y
/
P
A
U
S
E
P
R
O
G
.
S
T
O
P
FM Stereo
10 11 12987
5. Speakers
6. Cassette Door
6
5
5
LCCSTR10_LBOOMPK11_IB_final110518.indd 5 18/05/2011 2:41 PM

21. TUNING Control
• To tune to a AM or FM radio station
22. BAND Selector
• To select AM, FM or FM Stereo radio
in RADIO mode
23. Earphone Socket
24. VOLUME Control
• To adjust the volume
Rear View
Control Panel (CD)
N
E
X
T
R
E
P
E
A
T
B
A
C
K
P
L
A
Y
/
P
A
U
S
E
P
R
O
G
.
S
T
O
P
FM Stereo
1615 2017 1813 1914
25. FUNCTION Selector
• To switch between CD, TAPE (OFF)
and RADIO mode
26. Battery Compartment
27. ~AC IN
• To connect the mains cable to the
mains socket
27
24
25
23
21
22
26
13. BACK Button
• Press and hold to perform fast
reverse playback
• Press to skip backwards between
tracks on a CD
14. NEXT Button
• Press to perform fast forward
playback.
• Press to skip forwards between tracks
on a CD
15. REPEAT Button
• Press to repeat a single track or entire
tracks on a CD
16. FM Stereo Indicator
17. CD Track Display Window
18. STOP Button
• Press to stop a CD during playback
19. PLAY/PAUSE Button
• Press to play or pause a CD
20. PROG. Button
• Press to program a CD to play tracks
in a specied order
• Visible and invisible laser radiation. If the cover is open, do not look at the beam.
• High voltage! Do not open. You run the risk of getting an electric shock.
• The machine does not contain any user-serviceable parts.
• Modication of the product could result in hazardous radiation of EMC or other
unsafe operation.
6
LCCSTR10_LBOOMPK11_IB_final110518.indd 6 18/05/2011 2:41 PM

Power Source
Whenever convenient, use the mains cable if you want to conserve battery life. Make sure you
remove the plug from the unit and mains socket before inserting batteries.
Battery Power
1. Open the battery door and insert 6 batteries, type UM-2 or C-cells (not included) with the
correct polarity as indicated by the “+” and “–” symbols inside the compartment.
2. Replace the battery door making sure the batteries are rmly and correctly in place. The
unit is now ready to operate.
Handling the Batteries
• Improper or incorrect use of batteries may cause corrosion or battery leakage, which could
cause personal injury or damage to property.
• Install the batteries correctly by following the polarity (+ and –) indications in the battery
compartment.
• Use only the types of the batteries which are indicated in this manual.
• Do not install new batteries with used ones and do not mix dierent types of batteries.
• Do not dispose of the used batteries as domestic waste. Dispose of them in accordance with
local regulations.
• If you are not going to use the unit for a long time, remove the batteries to avoid damage
from battery leakage and corrosion.
Always switch the unit o after use to conserve the battery life.
7
LCCSTR10_LBOOMPK11_IB_final110518.indd 7 18/05/2011 2:41 PM

1. Check that the power voltage shown on the rating label located on the bottom of the
unit, corresponds to your local power supply. If it does not, consult your dealer or service
centre.
2. Connect the mains cable to the ~AC IN socket and the mains socket. The unit is now
connected and ready for use.
3. To switch the unit o completely, withdraw the mains cable from the mains socket.
4. Install the unit near a mains socket where the mains plug can be easily reached.
Mains Power
Using Earphones
Turn down the volume before connecting the earphones. Slowly raise the volume with the
earphones on until you reach your desired volume. When earphones are connected, the
speaker is automatically disabled.
Always check you have completely switched o the unit, before you change or
disconnect the power supply.
Disconnect the mains cable from the mains socket to protect your unit during
heavy thunderstorms. Children could seriously injure themselves as the free end of
the cable may still be live if only the connector is removed from the mains socket at
the back of the unit.
Long-term exposure to loud music may cause hearing damage. It if best to avoid
extreme volume when using earphones, especially for extended periods.
8
LCCSTR10_LBOOMPK11_IB_final110518.indd 8 18/05/2011 2:41 PM

Compatible Disc Types
Disc Types Disc Logo Recorded Content
CD-R (CD Recordable) AUDIO
CD-RW (CD-Rewritable) AUDIO
AUDIO-CD (Compact Disc Digital Audio) AUDIO
General Operation
Switching the Unit On/O and Selecting the Function
1. To switch on and select your operation source, set the FUNCTION selector to CD or
RADIO.
2. To switch o the unit, set the FUNCTION selector to TAPE (OFF) position.
Adjusting the Volume and Sound
Adjust the volume with the VOLUME control.
Radio Reception
1. Set the FUNCTION selector to RADIO.
2. Set the BAND selector to select your desired waveband, AM, FM or FM Stereo.
3. Turn the TUNING control to tune to a radio station.
For Better Reception
FM - This unit has a FM aerial located on the top of the main unit. This wire should be
extended and rotated for better reception.
AM - This unit is equipped with a built-in directional ferrite AM aerial. Reorient the unit around
to get a better reception.
To avoid unnecessary energy consumption, always set the FUNCTION selector
to TAPE (OFF) after using the unit.
• MP3, CD-ROM, CD-I, CDV, VCD, DVD or computer CDs are not possible for
playback.
• CDs encoded with copyright protection technologies by some record companies
may be unplayable by this unit.
9
LCCSTR10_LBOOMPK11_IB_final110518.indd 9 18/05/2011 2:41 PM

Playing a CD
1. Set the FUNCTION selector to CD.
2. Open the CD door, and insert a CD with the printed side facing
up, then press the CD door gently to close it. The total number of
tracks on the disc will show in the display.
• If there is no disc inside or the CD door is not closed,
“ ” will show in the display.
3. Press the PLAY/PAUSE button to start playback, the rst
track will be played. The number of the currently playing track
will show in the display.
Total Track
4. To pause playback, press the PLAY/PAUSE button. The “ ”
will ash continuously in the display. To resume playback, press
the PLAY/PAUSE button again.
5. To stop the CD playback, press the STOP button.
Selecting a Dierent Track
• Press the BACK or NEXT button once or repeatedly until the desired track number
appears in the display.
Finding a Passage within a Track
1. During playback, press and hold the BACK or NEXT button. The CD is played at
high speed and with reduced volume.
2. When you recognise the passage you want, release the BACK or NEXT button to
resume normal playback.
Programming Track Numbers
You may store up to 20 tracks in the desired sequence. Be sure to press the STOP button
before use to ensure no prior program has been set.
1. In stop mode, press the PROG. button to activate programming.
” ” and “PROGRAM“ indicator will ash in the display.
PROGRAM
10
LCCSTR10_LBOOMPK11_IB_final110518.indd 10 18/05/2011 2:41 PM
