Logitech Harmony 659 User manual

600-Series Harmony Remote
User Manual version 1.2

User Manual 600-Series Harmony Remote
Table of Contents
INTRODUCTION ......................................................................................................................................................1
GETTING TO KNOW YOUR HARMONY REMOTE ..........................................................................................................2
BEGINNING THE SETUP PROCESS .....................................................................................................................3
USING YOUR HARMONY REMOTE.......................................................................................................................4
SELECTING AN ACTIVITY ..........................................................................................................................................4
Switching Between Activities.............................................................................................................................4
DISPLAYING HELP ON YOUR HARMONY REMOTE.......................................................................................................4
CONTROLLING INDIVIDUAL DEVICES..........................................................................................................................5
Device Mode......................................................................................................................................................5
Sound Mode ......................................................................................................................................................5
Picture Mode .....................................................................................................................................................5
CUSTOMIZING YOUR HARMONY REMOTE.........................................................................................................6
CUSTOMIZING THE ACTIVITY BUTTONS .....................................................................................................................6
CHANGING THE BEHAVIOR OF BUTTONS WITHIN AN ACTIVITY ....................................................................................6
Adding Custom-Labeled Buttons.......................................................................................................................7
LEARNING INFRARED (IR) COMMANDS ......................................................................................................................7
Using the Infrared Sensor .................................................................................................................................7
Naming an Infrared Command ..........................................................................................................................7
ADDITIONAL HELP .................................................................................................................................................9
Finding Answers to Your Questions..................................................................................................................9
Troubleshooting Your Harmony Remote...........................................................................................................9
v. 1.2 page i

User Manual 600-Series Harmony Remote
Introduction
Congratulations on the purchase of your Harmony remote! This User Manual will introduce you to the basic
online setup process, customizations and main features of your Harmony remote.
If in doubt about how to set up your Harmony remote, follow the information and instructions using the Logitech
Harmony remote software (also referred to as Harmony remote software).
The Harmony remote is an Internet-powered universal remote control. Your Harmony remote can control most
devices that understand infrared (IR) signals.
The configuration of your Harmony remote is simple:
•You will be prompted to answer questions about your entertainment devices to create your own personal
Harmony remote configuration.
•Your answers will provide us with a description of the entertainment devices you want to control, how
they are set up, and your preferences for controlling them.
•If one of your devices is not in the Harmony remote’s database, the Harmony remote software will learn
about your device and add it to your configuration.
•Once you have told us about your devices, you will then be guided through setting up Activities.
•Creating Activities is simple: you will be prompted to indicate the devices you use within an Activity and
how you want to control specific features, such as the volume, within that Activity.
•An Activity is a set of commands the Harmony remote sends to your entertainment system to turn on the
necessary devices.
•Once you have selected an Activity, you are in Activity mode, and the functionality of each button on
your Harmony remote is automatically configured for that Activity.
•Additionally, the display buttons will give you access to other commands for that Activity, which cannot
be set to the standard buttons.
Example
For the Watch Television Activity, the Harmony remote sends commands to your entertainment system
to turn on the necessary devices so you can watch television. The remote will automatically be
configured for the Activity based on the answers you selected during the online setup process for the
Activity.
At the end of the setup process, you will have your own configuration loaded in your Harmony remote. Use your
Harmony remote software to:
•Customize any of your Harmony remote’s features.
•Add more entertainment devices.
•Add more Activities.
v. 1.2 page 1

User Manual 600-Series Harmony Remote
Getting to Know Your Harmony Remote
Many of the Harmony remote’s buttons are standard remote buttons. However, there are buttons and other
hardware that may not be so familiar to you. The extra buttons and hardware give you access to the special
features of the Harmony remote.
1. USB Connector: Connect one
end of the USB cable to this
connector and the other end to
your computer so that you can
download your configuration
using the Harmony remote
software.
2. Status Light: Illuminates when
the Harmony remote is sending
commands.
3. OFF: Turns all devices off with
one button press.
4. Help: Asks you simple questions
so that your Harmony remote
can fix problems you are having
within an Activity.
8. Device: Lists all your devices on the
display, and allows you to select and
directly control any device.
9. Next: Shows more options on the
display.
10. Menu: Gives you access to the
menu system on a device, if you
have a device with this feature.
11. Exit: Exits from the Guide feature.
12. Guide: Gives you access to view
program listings, if you have a device
with this feature.
13. Info: Gives you additional
information on program listings, if
you have a device with the Guide
feature.
14. Sound: Controls special sound
features.
15. Picture: Controls special picture
features.
16. Prev: Goes to previous television
channel.
17. Glow: Backlight glow.
18. Infrared Learning Port: The
Harmony remote uses this port to
learn commands from your original
remote.
7. Display Buttons: Use the
buttons at the side of the display
to select the corresponding
command.
6. Display: Shows a list of your
Activities and devices, help,
infrared (IR) commands and any
available listings.
5. Activity Buttons: Select an
Activity and the Harmony remote
will set up your entertainment
system.
655 680676
628 659 670
v. 1.2 page 2

User Manual 600-Series Harmony Remote
Beginning the Setup Process
Once you have installed the Logitech Harmony remote software, connect your remote and you will be guided
through a series of question-and-answer steps to complete the online setup process:
Login Information: Create your login information.
Check Connection: Ensures your computer and your Harmony remote are communicating properly.
Set Up Devices: Helps you provide us with information about the devices in your personal home theater system.
Set Up Activities: Helps you provide us with information about the way your devices work together to perform
Activities (e.g. Watch Television Activity).
Update Remote: Updates your remote with your personal settings.
Note: When using the Harmony remote software, click Help to view specific help for the step you are on.
v. 1.2 page 3

User Manual 600-Series Harmony Remote
Using Your Harmony Remote
This section provides you with information that will help you use your remote.
Selecting an Activity
View the Activities you have added by pressing the Activities button. The display will then list the Activities you
have added. Press the corresponding display button next to the Activity you want to start.
As a default, when you select an Activity, you will see a message on the remote’s display reminding you to keep
the remote pointed at your entertainment system while the Activity starts. This helps ensure that all infrared (IR)
signals are properly sent.
Use the Harmony Remote Software to turn on/off the “Starting Activity” message.
Switching Between Activities
To change to a different Activity:
1. Press any one of the Activity buttons to go directly to one of your favorite activities, or press the More
Activities button to see a list of your other Activities.
2. Press the button next to the Activity you want to switch to.
Displaying Help on Your Harmony Remote
From time to time when you select an Activity, the Activity may not work. This can happen when the Harmony
remote sends many infrared commands to set up all your devices for an Activity, but one or more devices are not
receiving some commands. The Harmony remote is then “out of sync” with your devices (e.g. it thinks one of
your devices is on, but it is actually off). Some of the reasons the Harmony remote can become “out of sync” with
your system are:
•Someone walks between the Harmony remote and your entertainment system while an Activity is
starting.
•You point your Harmony remote away from your system while an Activity is starting.
•There is an object blocking the line-of-sight between your Harmony remote and the system.
•You are very far away from your entertainment system.
You will need to use the Help button on your Harmony remote to resynchronize the remote with your devices.
Before re-synchronizing, ensure the cause of the problem has been addressed.
Example
Remove all obstructions so that the entertainment devices can receive the infrared commands from the Harmony
remote.
Note: If your devices are no longer responding consistently to your Harmony remote, but were doing so
before, you may need to recharge the battery.
To resynchronize:
1. Press the Help button on the remote.
v. 1.2 page 4

User Manual 600-Series Harmony Remote
Controlling Individual Devices
This section provides you with an overview of three modes you can use to access specific features of each
device.
Device Mode
Press Device to enter device mode. Device mode gives you access to all the possible commands for each
device included in your Harmony remote configuration. To access device mode you do not need to be in an
Activity. However, you should never need to use Device mode during normal use of your Harmony remote. This
mode should only be used to send a specific command to a specific device.
You can eliminate the use of device mode by customizing your Activities.
Example
You can put commands on the display or customize specific buttons for the commands.
See Customizing Your Harmony Remote.
At any time, press Device to switch into Device mode. Once in this mode, the Harmony remote will display a list
of all the devices you have in your configuration. Select a device from the list and the Harmony remote will only
control the device features for the device.
Example
If you choose Television as the device, the number, volume and channel buttons will all control your
television.
Press Device again to return to exit Device mode.
Sound Mode
Sound mode focuses on controlling the sound features of the device you have chosen to control your sound
(e.g. Stereo Receiver). When you are in any Activity, press Sound to switch to this mode. Once in Sound mode,
the Harmony remote will only control sound features.
Example
If you choose stereo receiver to control the sound in your Watch a DVD Activity, press Sound and your
Harmony remote buttons will now be set to control the sound features of the Stereo Receiver. The
display will provide you with access to other sound-related commands such as Surround Field or Bass+.
Press Sound or the appropriate Activity button to return to Activity mode.
Picture Mode
Picture mode focuses on controlling the picture features of the device (e.g. TV or Projector) you have chosen to
display video.
When you are in any Activity, press Picture to switch to this mode. Once in Picture mode, the Harmony remote
will only control picture features.
Example
If you have chosen your Projector to display the video in your Watch a DVD Activity, press Picture and
your Harmony remote buttons will now be set to control the picture features of the Projector. The display
will provide you with access to other picture-related commands such as Aspect or Picture Adjust.
Press Picture or the appropriate Activity button to return to Activity mode.
v. 1.2 page 5

User Manual 600-Series Harmony Remote
Customizing Your Harmony Remote
All customization of your Harmony remote is done from the Harmony remote software:
Use the Harmony remote software to:
•Troubleshoot
•Add or delete Activities
•Add or delete devices
•Change the settings for the remote
•Get support
•Update the remote
Update the remote after you have made changes your configuration or settings. This will ensure you have the
latest configuration and settings on your Harmony remote.
Customizing the Activity Buttons
The Harmony remote gives you dedicated buttons for selecting Activities. As a default, the Harmony remote will
automatically assign these buttons. You can keep the defaults, or use the Harmony Remote software to
customize your Activity buttons.
Any activities not assigned to a specific button will automatically be located under the More Activities button.
628 / 655 / 659 676/670/620 680 688
Changing the Behavior of Buttons Within an Activity
When you select an Activity, the Harmony remote will:
•Turn on all the correct entertainment devices
•Set the device inputs correctly
•Set up the remote’s buttons to control the Activity
Based on our knowledge of how each of your devices is controlled, the Harmony remote will make its best effort
to match all the buttons you need to control an Activity.
However, there may be some commands you want to add to buttons or access via the display. Commands can
be added to buttons quickly and easily by customizing any Activity to change the behavior of buttons.
Use the Harmony remote to change the behavior of buttons.
v. 1.2 page 6

User Manual 600-Series Harmony Remote
The change behavior of buttons feature shows you the:
•Buttons that have a command associated with them
•Device being controlled
•Command being sent to the device
Adding Custom-Labeled Buttons
Use the Harmony Remote Software to:
•Add custom-labeled buttons to a device.
•Add a custom-labeled button for an Activity.
Custom-labeled buttons are displayed on the Harmony remote’s display from left to right, top to bottom.
Learning Infrared (IR) Commands
The Harmony remote can learn infrared commands from other remote controls, and should only be used in
situations where the Harmony remote’s infrared database does not already contain an infrared command you
would like to use.
Using the Infrared Sensor
The Harmony remote has an infrared sensor at the end opposite to the USB connector. The Harmony remote
uses this sensor to learn commands from original device remotes.
A: Your original remote
B: Your Harmony remote
C: Distance between remotes: 5-10 cm (2”-5”) apart
The following steps outline what happens when you press a button on your original remote control:
1. The infrared sensor on the Harmony remote learns the infrared signal.
2. The Harmony remote uploads it via the USB cable (and your computer’s internet connection) to the
Harmony remote database.
3. The Harmony remote software will try to find a matching pattern for the infrared signal.
4. If no pattern is found, the signal will be stored as-is in its original format.
5. If a pattern is found, the Harmony remote software converts the signal into a format for convenient
storage.
Either way, the signal is then available for you to assign to a button on your Harmony remote.
Naming an Infrared Command
When you teach an infrared command to the Harmony remote, give the command a name. This way you can
refer to this command by name in various locations of the online setup process. It is best to use the default
names listed on the Learn infrared commands step so that automatic button function assignments can be
applied to your Harmony remote.
Example
If you teach the volume button infrared commands from your original remote control, name them
“Volume Up” and “VolumeDown” (i.e. with no space, and capitalization as shown). The remote software
v. 1.2 page 7

User Manual 600-Series Harmony Remote
looks for commands with these names to automatically assign them to the volume up and down buttons
on the Harmony remote.
Naming Conventions
When naming a command for which there is no default name on the Learn infrared commands feature, use the
following naming conventions to make button assignment and sharing infrared commands easier:
•Do not use spaces or special characters such as /, & or * in the name.
•Capitalize the start of words (e.g. NextDisc, ModeDigital).
•Start the command name with its main function (e.g. VolumeRearUp, VolumeRearDown,
VolumeFrontUp, VolumeFrontDown). This helps group related commands in lists.
•For infrared commands that select inputs (e.g. on a stereo receiver), start with the prefix “Input”. Do not
name the input based on what you have connected to your device, rather name it based on what it is
called on the front of the device, or on the remote control (e.g. InputAux, InputVideo1, InputTape,
InputDVD, Input VCR).
v. 1.2 page 8

User Manual 600-Series Harmony Remote
Additional Help
The Harmony remote provides you with several features to assist you with:
•Finding answers to your questions quickly and easily
•Troubleshooting the setup and customization process
Finding Answers to Your Questions
The help you find answers to your questions quickly and easily, consult any of the following tools:
Tool Description
Search A support tool that enables you to do a keyword search.
FAQs (Frequently-Asked Questions) A searchable list of customer questions, with answers provided by
Harmony’s support center.
User Manual The User Manual explains the concept of your Harmony remote and
provides information about setting up and using the remote.
Help button When running the Harmony remote software, click this button for
help specific to the step you are on.
Help button (on remote) Asks you simple questions so the Harmony remote can
automatically fix problems you are having with an Activity.
Troubleshooting Your Harmony Remote
In addition to the tools listed under Finding Answers to Your Questions, you can use the following tool to
troubleshoot your Harmony remote:
Tool Description
Troubleshoot To be used when the Harmony remote is not controlling your system
correctly.
If you cannot find the answer to your question(s) or troubleshoot your problem(s), contact your Harmony Support
Team.
v. 1.2 page 9
