LogTag UTRED30-16 User manual

Release Version A.
www.logtagrecorders.com
Quickstart Guide
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

What’s Included 3
Battery Installation 4
Downloading LogTag Analyzer 5
Configuring your UTRED30-16 6
Starting your UTRED30-16 7
Downloading Results 8
Quickstart Guide Contents
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 3
What’s Included
Please check you have each of the items shown below before
continuing with setting up your UTRED30-16.
UTRED30-16 USB Cable
2x AAA Battery
(Not included)
ST100X
External Probe
(Not included)
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 4
Battery Installation
1. You will need a small phillips (cross-shaped) screwdriver to
remove the cover on the back of the UTRED30-16 case.
2. Once you have removed the battery cover, install the 2x AAA
batteries provided in the product. Take note of the direction
each battery must be installed.
3. Once both batteries are securely installed, replace the battery
cover and secure via the screw you used to open the cover.
The AAA batteries are the main power source for your UTRED30-16.
A 5V/5W USB power supply is another power backup source if you
wish to power the unit permanently via the USB socket.
Warning: Please note the UTRED30-16 will not start if AAA
batteries are low and there is no USB power. This is in addition to
the internal coin cell (backup battery) being low.
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 5
Downloading LogTag Analyzer
To download the latest LogTag Analyzer, open your browser and
type in the URL:
https://logtagrecorders.com/software/LTA3/
1. Fill in the form with your details, then click ‘Go to downloads
page’
2. Click the ‘Download Now’ button to start the download
3. Click ‘Run’ or ‘Save File’ then double-click on the downloaded file
to open Analyzer Setup Wizard
4. Once the Analyzer Setup Wizard is open, follow the on-screen
prompts to install Analyzer onto your computer
5. Click the ‘Finish’ button to exit Analyzer Setup Wizard
Warning: Please ensure no other LogTag software is currently
running on your computer before running the Analyzer software.
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 6
Configuring your UTRED30-16
Firstly, connect your
UTRED30-16 to your computer via
the USB cable provided. The USB
socket on the device is located on the
bottom, protected by a rubber seal.
1. Open LogTag Analyzer
2. From the menu, click on ‘LogTag’ then ‘Configure’ from the
drop-down or click on the ‘Wizard’ icon
3. Adjust your logger configuration settings as required.
For more information on configuration settings, please refer to
Configuring the UTRED30-16 in the user manual or press ‘F1’ for
help from your keyboard
4. Click the ‘Configure’ button again, please wait while configuration
settings are being updated
5. Click ‘Close’ to exit the configuration page
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 7
Starting your UTRED30-16
Press and hold the START/
Clear/Stop button.
STARTING will appear along
with READY.
Release the button once
READY disappears.
The UTRED30-16 now records
temperature data.
The Logger will not start if:
• You release the
button before READY
disappears.
• You keep holding the
button for more than 2
seconds after READY
disappears.
• The backup battery is
critically low and the
logger is not connected
to power.
Please ensure you have connected a ST100X external probe to
your device before starting.
Please ensure you have connected a ST100X external probe to
your device be
f
ore startin
g.
Distributed by MicroDAQ.com, Ltd. www.MicroDAQ.com [phone]

Page 8
Downloading Results
Alternatively, you can follow the steps below:
1. Open LogTag Analyzer
2. From the menu, click on ‘LogTag’ then ‘Download’ from the
drop-down or press ‘F4’ from your keyboard
3. Click ‘Close’ to exit the download page
Firstly, connect your UTRED30-16
to your computer via the USB cable
provided. The USB socket on the
device is located on the bottom,
protected by a rubber seal.
If you have configured your UTRED30-16 to generate files
automatically, these will be created every time you plug the logger
into the USB port
By default, auto-download is enabled in LogTag Analyzer so
when you open the program, data results will be displayed after
connecting your UTRED30-16 to your computer
