Lopi Stove User manual

Gas Stove and
Fireplace Inserts

Direct Vent Gas
Stoves & Inserts
America’s favorite Fire
Lopi heating appliances are designed and hand-assembled at our state-of-the-art plant in Mukilteo, Washington.
With over 30 years of experience manufacturing innovative hearth products, Lopi has gained a reputation for
standing behind every single product we make. And one thing that hasn’t changed through the years is the quality
of the construction, the beauty of our gas stoves and fireplace inserts, performance you can trust, along with our
commitment to your satisfaction.
Whether you are new to the family of Lopi heating products or already a part of our family, we invite you to take
a look at our newest gas products. We know you’ll find your favorite fire.
How Do You Say Lopi?
We hear a lot of different pronunciations - Lopey...Loopee...loppy!
It’s actually pronounced Low-pie, and was created by our president, Kurt Rumens. The name was inspired by a love
of the Northwest, a fascination with Native American culture and the nature and wildlife that live in this beautiful
place. Lopi means beauty, strength and independence and has become a legend all its own.
Why We Only Make Direct Vent Gas Appliances
The American Lung Association discourages the use of vent-less appliances or appliances that take combustion air
from the inside of the home for health and environmental reasons. They recommend homeowners choose only
sealed, direct vent gas appliances to preserve indoor and outdoor air quality and to prevent by-products such as
carbon monoxide, soot and nitrogen dioxide from entering your home. Sealed gas appliance also prevent excess
moisture from building up in your home. All Lopi direct vent gas stoves and fireplace inserts are sealed from the
inside of the home and meet the guidelines of the American Lung Associations Health House program.
Seven Year “Real World” Warranty
Lopi’s “Real World Warranty” puts other manufacturers lifetime warranties to shame. You will have the peace of
mind knowing that your gas stove or insert is supported by certified factory trained installers and retailers. The
firebox on Lopi gas appliance is covered for a FULL SEVEN YEARS. All parts and labor are covered for a FULL 2
YEARS. Compare our warranty to other manufacturer’s and you will find most won’t tell you about their one year
parts warranty or that there is no labor coverage after the first year on ANYTHING! Lopi truly offers the BEST
WARRANTY ON GAS APPLIANCES!
“Lopi is not so much a brand name as it is a tradition - of craftsmanship in the
construction of our gas fireplaces, and of pride to the families who own them.
We invite you to share this proud tradition”
Kurt Rumens
President
1

Is It A Wood Or Gas Fire?
Patented Ember-Fyre™ Burner
U. S. Patented #6,602,068; 6,443,726 and other patents pending.
Lopi gas stoves and fireplaces inserts feature the patented Ember-Fyre™ burner
system in all the gas fireplaces in this brochure. Popular Science® magazine
awarded the prestigious “BEST OF WHAT’S NEW” award to the Ember-Fyre as
one of the year’s top achievements in Science and Technology.
This combustion system delivers an efficiency of up to 82.2%. The level of
realism is so remarkable it is difficult to tell apart from our wood burning
appliances. Unlike other gas burners, the pilot is hidden. There are
no unsightly burner tubes or metal pans and the fire and
glowing embers are just as beautiful on the low flame
setting as they are on high.
How It Works:
1. Natural gas or propane is piped to a sophisticated
1. SIT™ gas valve and started with the reliable Piezo
1. ignition system. This gas burner is designed to
1. provide reliable, continuous operation even if the
1. power goes out in your home.
2. The low-pressure gas then flows to a precisely engineered
2. burner orifice.
3. A hidden mixing tube combines the gas with outside air. The
2. standard mix is set by the installer to compensate for variations in
2. altitude, fuel type and line pressure.
4. The gas/air mixture flows through a unique array of burner
2. ports in the ceramic base, where it ignites and burns.
5. As the Ember-Fyre™ burner heats to a deep red 1200°F,
it mimics the look of glowing wood embers and 2. 2.
2. charred logs. Dancing yellow flames further enhance
2. the look and feel of a real wood fire.
6. The fire passes over the hand-carved logs that are so incredibly detailed, you’ll be
2. amazed they are not the real thing.
7. For hands-free operation the optional remote control, modulating control or
2. wall thermostat allows you to set and maintain the comfort level of your home.
Popular
Science
1.
4.
5. 6.
7.
2.
3.
2

Aromatherapy
Lopi cast iron freestanding gas stoves will not only warm
your home, but has an optional Aromatherapy kit to
promote physical and psychological well-being.
Essential Oil Kit
The essential oils provided in the kit have been found to be successful in
soothing, relaxing and energizing mind and body.
On Cloud Nine - Lavender oil to calm and relieve stress. It can also help
you sleep.
Somebody Wake Up Edna - Eucalyptus oil to stimulate and energize. This
essence is commonly used to improve mood as well as memory.
Passion Potion - Ylang Ylang oil intoxicates you with sensuality.
Perfect for exciting your senses, and creating a loving mood.
Be sure to ask your Lopi dealer for a demonstration!
Pull-out Aromatherapy Tray and fill with
your choice of essential oils.
Berkshire shown in our Antique Slate porcelain enamel finish.
3

Why Buy a Lopi Gas Stove?
Lopi offers 3 distinct models to choose from:
The small cast iron
rear vent Sturbridge™
The large cast iron, top vent
Berkshire™
The large steel, top vent
Heritage™
Incredible Technology
You’ll be amazed at the realism of our gas fire thanks to our patented Ember-Fyre™ burner technology. Dancing
yellow flames and glowing embers capture all the beauty of a real wood fire. It’s the most realistic gas fire
available - so real, you’ll be tempted to stir the embers and add more wood. Why not have a little fun fooling your
friends?
Heater Rated
Like all Lopi gas products, our gas stoves are serious heaters. All stoves are listed as a heater rated furnace, with
efficiencies exceeding 80%. Lopi gas stoves provide radiant heat to the immediate area with the added benefit of
a built-in convection chamber, which circulates room air around the appliance and returns it to your room as heat.
All stoves come equipped to burn natural gas (NG) or can easily be converted to propane (LP). The LP conversion
kit is included with every stove at no additional cost.
Flexible Installation
All Lopi gas stoves feature direct vent technology and can be vented vertically or horizontally (out the back on the
Sturbridge or off the top with the Berkshire and Heritage) adding location flexibility, and in many cases lowering
installation cost.
Our gas stoves do not require any type of hearth pad in many installations, including wood flooring. Lopi gas
stoves are approved for close clearances to the back wall without expensive heat shields. This saves valuable floor
space and eliminates the requirement of an expensive non-combustible wall protection.
Lopi dealers are experts at assisting where to best install a stove or stoves in your home.
4

SturbridgeTM
Cast Iron Gas Stove
The Sturbridge is shown in the Oxford Brown
porcelain enamel finish. Shown with optional
Brick Fireback and Spice Granite Stone Kit.
Heating Capacity
Up to 850 sq. ft. with fan
Steady State Efficiency
Up to 80.1% (NG & LP)
Maximum BTU Input per Hour
18,000 (NG & LP)
Minimum BTU Output per Hour
9,900 (NG & LP)
5

Named for Sturbridge Village, a New England center of Yankee craftsmanship, the
award winning Sturbridge stove blends the efficiency of gas, with the look and feel of
a traditional wood stove. This smaller more detailed version of our Berkshire gas stove
offers cast iron construction, early American architectural details, and double doors that
open up for direct fire viewing. The petite Sturbridge is designed to provide warmth for
small rooms and is ideal for zonal heating. The Sturbridge gas stove was recognized for
innovation by hearth industry experts with the VESTA®award as the year’s best new
gas stove.
Aromatherapy Tray
Add the optional hidden Aromatherapy
Tray to your Sturbridge. Aromatherapy
soothes the spirit, invigorates the mind
and relaxes the body. Add the optional
Essential Oil selection of Eucalyptus,
Lavender, and Ylang Ylang oils.
6
The Sturbridge shown in New Iron paint finish

Sturbridge™
Cast Iron Gas Stove
The economical and efficient rear vent Sturbridge gas
stove offers finely cast, Early American architectural
details and includes a beautiful warming/cooking tray.
The Sturbridge has the option of matching side and
top panels or your choice of beautiful stone sides and
top in Travertine, Soapstone or Spice Granite. Double
Palladian doors are a standard feature on all models.
Because it can operate without electricity, the Sturbridge
will continue to heat no matter how severe the
elements. Better still, gas can be affordable when used
to zone heat, which means heating only the room you
are using at the time.
The Sturbridge gas stove, so enchanting to watch and
a treasure to own.
The Sturbridge gas stove is available in three finishes:
New Iron - a soft paint tone that echoes the richness of
new cast iron.
Oxford Brown - a porcelain enamel features a strong
translucent earthen tones that are similar to the rich
glazes found in early American pottery.
Antique Slate - the beautiful slate blue hue features
a double enameled majolica finish where the lighter
cream undercoat enamel shows through the highlights
on the slate blue enamel. By accenting the edges
and raised detail the finish takes on a unique three-
dimensional appearance.
The New Iron painted Sturbridge is shown with
standard cast side and top panels.
Any of the above three Sturbridge stoves can be
enhanced with your choice of optional stone kits.
The New Iron model shown here features the
standard doors displayed with Spice Granite
Stone Kit option.
Options
Aromatherapy
Tray
Essential
Oils Kit
Cast Ceramic
Fireback
7

The Antique Slate porcelain enamel Sturbridge
is shown with standard cast side and top
panels.
The Oxford Brown porcelain enamel
Sturbridge is shown with standard cast side
and top panels.
The New Iron painted Sturbridge model is
picture with the polished Travertine Stone Kit.
The New Iron painted Sturbridge model is
picture with the Soap Stone Kit.
Remote
Control
Wall
Thermostat
130 CFM
Convection Fan
Omega™ Modulating
Remote Control
8

Heating Capacity
Up to 1,500 sq. ft. with fan
Steady State Efficiency
Up to 86.5% (NG & LP)
Maximum BTU Input per Hour
31,000 (NG & LP)
Minimum BTU Output per Hour
16,608 (NG & LP)
The Berkshire is shown in the Oxford Brown
porcelain enamel finish. Enhancements include
the Brick Fireback, Linenfold side and top panels,
and painted flue pipe .
9
BerkshireTM
Cast Iron Gas Stove

Think of the Berkshire as a functional work of art. It’s classical balance and symmetry
resembles a piece of fine furniture. This solidly built stove features decorative cast
iron on the outside with a heavy-gauge unibody steel firebox for added durability.
Design details include a large viewing area (18 inches wide by 10 3/4 inches high),
raised Linenfold side panels, and delicate moldings typical of early American
architectural style. Even when not in use, it’s a standout element in any room. No
wonder it’s the best selling cast iron gas stove in America.
Aromatherapy Tray
Add a touch of magic to your Berkshire.
Aromatherapy is known to soothe the
spirit, invigorate the mind and relax
the body. Add the optional Essential
Oil selection of Eucalyptus, Lavender,
and Ylang Ylang oils to stimulate your
senses.
The Berkshire is shown above in the New Iron painted finish. The Brick Fireback completes the unit.
Accent Light
Add a warm glow even when the fire is
turned off. The accent light option adds
a glowing backlight behind the logs
and against the optional ceramic brick
fireback. It’s perfect as a night-light or
soft indirect light for the room.
10

Berkshire™
Cast Iron Gas Stove
Options
The New Iron painted Berkshire understates the durability
and beauty of cast iron construction. This soft paint finish
highlights the delicate moldings and design details. This
model comes with the Linenfold side and top panels.
Any of the Berkshire stoves can be enhanced with
your choice of optional travertine, soapstone or spice
granite stone kits. The New Iron stove is shown with the
optional Soapstone Kit.
When the temperature drops, snow drifts blow against
your door and the streets are dark because the power
fails, nothing gives you peace of mind like the heat from
your Lopi cast iron gas appliance. Rapid heat transfer
and outstanding durability are built into the steel fire-
box, “patent-worthy technology” perfected over the past
twenty five years.
The traditional early American look of the Berkshire
gas stove is a collaboration of efforts between the
famous Red House Design team and the renowned Lopi
designers.
This stove embodies a sense of balance and symmetry
that one experiences in the finest furniture.
With all its design quality and styling, the Berkshire gas
stove is sure to provide warmth and security to your
family today and for years to come.
The Berkshire gas stove is available in three finishes:
New Iron - a soft paint tone that echoes the richness of
new cast iron.
Oxford Brown - a porcelain enamel similar to the earth
tones of early American pottery.
Antique Slate - the beautiful slate blue hue features a
double enameled majolica finish where the lighter cream
undercoat enamel shows through the highlights on the
slate blue enamel. By accenting the edges and raised
detail the finish takes on a unique three-dimensional
appearance.
Aromatherapy
Tray
Essential
Oils Kit
Accent
Light Kit
11

Cast Ceramic
Fireback
The Oxford Brown model features
porcelain enamel in the earth hues and
tones found in early American pottery.
This gloss finish softly reflects light
from the relief carving of the Linenfold
side panels and the traditional,
colonial architectural details featured
throughout the Berkshire line.
Shown with optional Brick Fireback
and Linenfold side panels.
The panels comes standard on the
New Iron Berkshire, they are optional
on the Antique Slate and Oxford
Brown models.
The Oxford Brown
enameled Berkshire
model is picture with
the Spice Granite
Stone Kit.
The subtle appeal and riches of granite is universal.
This rugged material is mined then polished with
precision to bring out the warm color and earth tones
of the minerals locked in the stone.
The Antique Slate enameled Berkshire
is pictured with the Brick Fireback and
optional Linenfold Side Kit.
Remote
Control
Wall
Thermostat
130 CFM
Convection Fan
Omega™ Modulating
Remote Control
12

HeritageTM
Steel Gas Stove
Heating Capacity
Up to 2,000 sq. ft.
Steady State Efficiency
Up to 78% NG & 81% LP
Maximum BTU Input per Hour
43,000 (NG & LP)
Minimum BTU Output per Hour
23,384 NG & 20,800 LP
The Heritage is shown with the optional
Pewter door, Pewter convection grill
and Brick Fireback.
13

The Heritage DVL Freestanding Stove features a remarkable balance of beauty and
performance. It generates up to 43,000 BTUs per hour, yet offers an overall efficiency of
78% with natural gas and 81% with propane. The Heritage is certified as a “direct vent
furnace” distinguishing it from non-heating “decorative” gas appliances. This makes it the
most versatile heat source for your home, townhouse, or for zonal heating in large homes.
A state-of-the-art ignition system keeps the fire burning even when your electricity fails.
Add splendor to the standard black model with an optional cast brick fireback, or enhance
the arched bayview door and decorative grill in a 24 karat gold or pewter finish.
The Heritage is shown above in the charcoal painted finish. The Brick Fireback completes the unit.





14

Gas Stove Specifications
Select Your Stove
Sizing, heating and performance specifications. The information on this page is for reference ONLY! Installation
information is available through your Lopi dealer or through the Lopi website at www.lopifire.com
15

Gas Stove Specifications
16

Why Buy a Lopi Fireplace Insert?
Most of us enjoy sitting around an open fireplace in our home. Sadly we now know the fireplace chimney
is actually drawing heat out of the home. In fact an open fireplace sends up to 80% of the fire’s heat up the
chimney and depletes warm air from surrounding rooms. A Lopi gas insert is more than five times as efficient
as an open fireplace and distributes warm air throughout the home. You can convert your wasteful masonry
or metal fireplace into a super-efficient hearth system that can heat your home for a fraction of what you’d
pay for electricity or oil.
Lopi gas inserts feature standard 130 CFM convection fans and an optional remote control or thermostat for
added home owner convenience and comfort.
1. Determine Your
Existing Fireplace
The first step is determining
whether you have a metal (zero
clearance) or masonry fireplace.
Your Lopi dealer can help you if
you need it. They can also provide
you with your new air intake and
exhaust systems. It is important
that this work is done by a hearth
professional.
2. Select Your Fireplace Insert
Next determine which insert best fits your needs
based on your heating requirements and
the size of your fireplace opening. We
offer DVS (Direct Vent Small) and DVL
(Direct Vent Large) sized inserts. Size
your fireplace by using the chart on the
bottom of page 23. Again, your Lopi
dealer is an expert in guiding you.
3. Choose Your
Surround Panel
Choose the correct size and preferred
style of insert panel. (see page 24)
3. Add A Custom Face
There are four custom door frames available for
the DVS & DVL inserts:
Wilmington (Black paint or Pewter plated)
Discovery (Black paint, Pewter or Antique Gold plated)
Cast Iron Bedford (New Iron paint - DVS only)
How To Select A Fireplace Insert
17

Looking for an insert that reflects the charm and beauty of classic early American architecture? Then look no
further than the Bedford gas insert. Made from real cast iron, the Bedford features the traditional look of a cast iron
fireplace merged with amazing performance of the latest heating
technology. This lovely insert takes the performance of a modern
fireplace and adds the heat benefit of radiant cast iron surfaces
to triple the efficiency of your old fireplace. The Bedford features
large opening double doors for a real wood-insert look and comes
with beautifully detailed cast iron panels to perfectly finish off
your fireplace. The Bedford cast iron fireplace insert face is only
available on the DVS insert.
Bedford DVS Insert shown with the optional Common Brick Fireback
Bedford™ DVS
Fireplace Insert
18
29 1/4”
40 7/16”
34 1/8”
22 3/4”

Want to turn your old inefficient fireplace into a beautiful source of heat? Then let the Lopi Discover fireplace insert
transform your drab, drafty masonry or metal, zero clearance fireplace into the focal point of your home. Enjoy
the warmth as realistic flames leap above the glowing logset. The Ember-Fyre™ burner and unique two stage heat
exchange system achieves up to a remarkable 80% efficiency with natural gas and 80.5% with propane. You will
also find the Discovery is economical to operate and easy to install in to your existing fireplace.
DVS Insert shown with the Discovery face 8” panels and optional pewter door.
Discovery™
Fireplace Insert
Black Painted Door Antique Gold Plated Door Pewter Plated Door
19
