Lopi ProBuilder 36 CleanFace GSB2 User manual

ProBuilder
36 CleanFace GSB2
• Direct Vent Fireplace
• Natural Gas or Propane
• Vent Horizontally or Vertically
• Standard Residential
• Mobile Home Approved
Listed by
AS/NZS 5263.1.3 GMK10026
IAPMO-R&T OCEANA
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
DO NOT MODIFY THIS APPLIANCE.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This appliance may be installed in
an aftermarket permanently
located, manufactured home (USA
only) or mobile home, where not
prohibited by local codes.
This appliance is only for use
with the type(s) of gas indicated
on the rating plate. A conversion
kit is supplied with the appliance.
Installation Manual
Installer: After installation give this manual to the home-
owner and explain operation of this heater.
Copyright 2019, T.I. $10.00 100-01503 11/9/20
Dragon Wholesaling Pty. Ltd.
Unit 4, 16 Lexington Drive
Bella Vista NSW
Australia 2153



2 Introduction
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Overview
This manual details the installation
requirements for the ProBuilder 36
CF GSB2 fireplace. For operating
and maintenance instructions, refer
to the ProBuilder 36 CF GSB2
fireplace Owner's Manual.

Table of Contents 3
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Overview ................................................................... 2
Installation Options.................................................. 6
Heating Specifications............................................. 6
Dimensions ............................................................... 6
Packing List .............................................................. 7
Additional Items Required....................................... 7
Recommended Installation Procedure................... 7
Optional Equipment Installation ............................. 7
Fireplace Placement Requirements ....................... 8
Clearances ......................................................................8
Raised Fireplaces............................................................8
Minimum Framing Dimensions............................... 9
Nailing Brackets ....................................................... 10
Standard vs. Extended Position ............................. 12
Header and Pipe Shield Installation ....................... 13
Corner Installations.................................................. 16
Televisions Placed Above the Fireplace................ 17
Gas Line Requirements ........................................... 18
Fuel .................................................................................18
Gas Line Connection .......................................................18
Gas Inlet Pressure...........................................................18
Gas Line Location............................................................19
Electrical Connection............................................... 20
Optional Wall Switch or Thermostat Installation .. 21
Parallel ConnectionSeries Connection ...................21
Vent Requirements................................................... 22
Vent Clearances ..............................................................22
Vent Firestop or Thimble .................................................22
Altitude Considerations....................................................22
Approved Termination .....................................................22
Approved Vent.................................................................22
Vent Installation ...............................................................23
Exhaust Restrictor Position..............................................23
Diffuser ............................................................................24
Vent Configurations ................................................. 25
Minimum Vent Configuration ...........................................25
Vent Configuration: Vertical Termination .........................26
Vent Configuration: Horizontal Termination with
Vertical Rise ....................................................................27
Termination Requirements...................................... 28
Hearth Requirements ............................................... 29
Facing Requirements............................................... 30
Standard vs. Extended Position.......................................31
Thick Facing Guide..........................................................32
Thick Facing (Facing Thicker than 39mm) ......................33
THICK FACING GUIDE SIZE..........................................34
Thin Facing (13mm to 39mm)..........................................35
Screen Assembly Mounts ................................................35
Mantel Requirements ............................................... 36
Mantel Column Clearances .............................................36
Use of a Non-Combustible Mantel Below Listed
Mantel Clearances .................................................... 37
Finalizing the Installation ........................................ 38
Pilot Flame Inspection .....................................................38
Air Shutter Adjustment ....................................................39
Location of Controls ........................................................40
Glass Frame Removal and Installation............................41
Barrier Screen Visual Deflector Adjustment ....................43
Log Set Installation .................................................. 44
Installation Warnings .......................................................44
Log Set Overview ............................................................44
Rear Log..........................................................................45
Left Log ...........................................................................45
Right Log.........................................................................46
Right Front Twig ..............................................................46
Right Rear Twig...............................................................47
Center Log.......................................................................48
Ember Chunk Identification .............................................48
Left Ember Chunk ...........................................................49
Right Ember Chunk .........................................................49
Ember Installation............................................................50
Rock Wool Placement (All Models) .................................50
Wiring Diagram ......................................................... 55
CoolSmart TV - Installation Overview (Optional) .. 56
CoolSmart TV - Installation Requirements ......................57
CoolSmart TV - Framing the Chase ................................58
CoolSmart TV - Fireplace Preparation ............................59
CoolSmart TV - Reduced Mantel Height .........................61

4 Safety Precautions
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Safety Warnings
Failure to follow all of the requirements may result in property damage, bodily injury, or even death.
Young children should be carefully supervised when they are in the same room
as the appliance. Toddlers, young children and others may be susceptible to
accidental contact burns. A physical barrier is recommended if there are at risk
individuals in the house. To restrict access to a fireplace or stove, install an
adjustable safety gate to keep toddlers, young children and other at risk
individuals out of the room and away from hot surfaces.
Children and adults should be alerted to the hazards of high surface temperature
and should stay away to avoid burns or clothing ignition. Do not touch the hot
surfaces of the heater. Educate all children of the danger of a high-temperature
heater.
Due to the high temperature, the heater should be located out of traffic and away
from furniture and draperies.
This unit must be installed by a qualified installer to prevent the possibility of an explosion.
This appliance must be installed in accordance with all local codes, if any; if not, in U.S.A. follow ANSI Z223.1
and NFPA 54(88), in Canada follow CSA B149.1.
A manufactured home (USA only) or mobile home OEM installation must conform with the Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a standard is not applicable, the
Standard for Manufactured Home Installations, ANSI/NCSBCS A225.1, or Standard for Gas Equipped
Recreational Vehicles and Mobile Housing, CSA Z240.4. This appliance may be installed in Manufactured
Housing only after the home is site located.
All exhaust gases must be vented outside the structure of the living-area. Combustion air is drawn from outside
the living-area structure. The venting must not be connected to a chimney flue serving a separate solid-fuel
burning appliance.
Notify your insurance company before hooking up this fireplace.
The instructions in this manual must be strictly adhered to. Do not use makeshift methods or compromise in the
installation. Improper installation will void the warranty and safety listing.
This heater is approved for use with natural gas (NG) or propane (LP). Burning the incorrect fuel will void the
warranty and safety listing and may cause an extreme safety hazard. Direct questions about the type of fuel
used to your dealer.
Contact your local building officials to obtain a permit and information on any installation restrictions or inspection
requirements in your area.
If the flame becomes sooty, dark orange in color, or extremely tall, do not operate the heater. Call your dealer
and arrange for proper servicing.
It is imperative that control compartments, screens, or circulating air passageways of the heater be kept clean
and free of obstructions. These areas provide the air necessary for safe operation.
Do not operate the heater if it is not operating properly in any fashion or if you are uncertain. Call your dealer for
a full explanation of your heater and what to expect.
Do not store or use gasoline or other flammable liquids in the vicinity of this heater.
Do not operate if any portion of the heater was submerged in water or if any corrosion occurs. Immediately call a
qualified service technician to inspect the appliance and to replace any part of the control system and any gas
control which has been under water.

Safety Precautions 5
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Safety Warnings (continued)
Because this heater can be controlled by a thermostat there is a possibility of the heater turning on and igniting
any items placed on or near the appliance.
Light the heater using the built-in igniter. Do not use matches or any other external device to light your heater.
Never remove, replace, modify or substitute any part of the heater unless instructions are given in this manual.
All other work must be done by a trained technician. Don't modify or replace orifices.
The viewing glass should be opened only for conducting service (or lighting the pilot on millivolt units).
Allow the heater to cool before carrying out any maintenance or cleaning.
Operate the heater according to the instructions included in this manual.
If the main burners do not start correctly turn the gas off and call your dealer for service.
This unit is not for use with solid fuel.
Do not place anything inside the firebox (except the optional artwork).
Warning: Do not operate appliance with the glass front removed, cracked or broken. Replacement of the
glass should be done by a licensed or qualified service person.
Do not throw this manual away. This manual has important operating and maintenance instructions that you will
need at a later time. Always follow the instructions in this manual.
Instruct everyone in the house how to shut gas off to the appliance and at the gas main shutoff valve. The gas
main shutoff valve is usually next to the gas meter or propane tank and requires a wrench to shut off.
A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk individuals.
If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance.
Clothing or other flammable material should not be placed on or near the appliance.
Any safety screen, guard, or barrier removed for servicing an appliance must be replaced prior to operating the
appliance.
Installation and repair should be done by a qualified service person. The appliance should be inspected before
use and at least annually by a professional service person. More frequent cleaning might be required due to
excessive lint from carpeting, bedding material, et cetera. It is imperative that control compartments, burners,
and circulating air passageways of the appliance be kept clean.
Travis Industries, Inc. grants no warranty, implied or stated, for the installation or maintenance of your
heater, and assumes no responsibility of any consequential damage(s).
SAFETY WARNINGS:
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE.
DO NOT USE OR STORE FLAMMABLE MATERIALS NEAR THIS APPLIANCE.
DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN
OPERATION.
DO NOT MODIFY THIS APPLIANCE.
THIS INSTALLATION MUST CONFORM WITH THE FOLLOWING:
Manufacturer’s Installation instructions
Local Gas Fitting Regulations
Municipal Building Codes,
Refer to AS/NZS 5601.1 for Gas Installations.
S.A.A. Wiring Code
Local Electrical Regulations
Any other statutory regulations
NOT SUITABLE FOR MARINE USE.
NOT INTENDED FOR FIREPLACE INSERT.
APPLIANCES INCORPORATING A LIVE FUEL EFFECT, AND DESIGNED TO OPERATE WITH
LUMINOUS FLAMES, MAY EXHIBIT SLIGHT CARBON DEPOSITION.
Travis Gas Fireplaces, Stoves, and Inserts are protected by one or more of the following patents; U.S. 8,469,021,
7,066,170, 6,602,068, 6,443,726, 6,953,037; Canada 2755517 as well as other U.S. and Foreign Patents pending.

6 Features and Specifications
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Installation Options
Residential or Mobile Home
Straight or Corner Placement
Raised or Floor Placement
Internal or External Chase
Bedroom Approved
Heating Specifications
Natural Gas Propane
36 CF ProBuilder Approximate Heating Capacity (in square meters)* Up to 107 Up to 107
Maximum Input megajoules Per Hour 26 26
* Heating capacity will vary with floor plan, insulation, and outside temperature.
Dimensions
35"
889mm



Left
a' gauche
Front
avant
Right
droit
Rear
arrie're
40-7/8"
1039mm
* Includes the required 1/2" clearance to each side and rear of the fireplace.
1-5/8"
42mm
36" 915mm
34-1/8"
867mm
1-1/16"
27mm
3"
77mm
15-1/4"*
388mm*
36-5/8"*
931mm*
37-3/8"
950mm
170 lbs. 77 Kg.
9-3/8"
239mm
24-1/2"*
623mm*
IDB01001

Installation (for qualified installers only) 7
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Packing List
LP (Propane) Conversion Kit:
Rear Burner Orifice (#57), Front Burner Orifice (#63), Pilot Orifice (0.14 LP), LP Regulator
Thimble (2-Piece
Assembly)
Pipe Shield
Header Shield
Includes a log set.
Wall Switch, Cover Plate, and Wire.
Additional Items Required
Gas Line Equipment (shutoff valve, pipe, etc.)
Electrical Equipment (min. 14 gauge, grounded line)
Recommended Installation Procedure
Frame the opening for the fireplace. Make sure to allow for vent installation.
Install the vent, gas line and electrical hook-up.
Install the drywall.
Install the hearth (if applicable).
Install the facing (if applicable).
Install the mantel (if applicable).
Finalize the installation (see page 36).
Optional Equipment Installation
If using Propane, convert the appliance.
Install fireplace.
If using optional firebacks, install them.
Install logs, ember chunks, and rockwool.

8 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Fireplace Placement Requirements
Fireplace must be installed on a level surface capable of supporting the fireplace and vent
Fireplace must be placed directly on wood or non-combustible surface (not on linoleum or carpet)
Fireplace should be located out of traffic and away from furniture and avoid burns.
Fireplace must be placed so the gaps below and above the glass frame do not become blocked.
Fireplace may be placed in a bedroom. Please be aware of the large amount of heat this appliance produces
when determining a location.
Clearances
(a) Clearance to Side of Fireplace 1/2” (13mm). Do not place insulation in this space.
NOTE: Drywall (or other combustible) may contact the first ½” of the sides of the fireplace.
(b) Clearance to Back of Fireplace 1/2” (13mm). Do not place insulation in this space.
(c) When installed, walls in front of the fireplace must be a minimum 0” (0mm) to the side of the fireplace
standoffs.
Raised Fireplaces
The fireplace (and hearth, if desired) may be placed on a platform designed to support the fireplace and vent.
The base of the fireplace must be a minimum 60” below the room ceiling.
The top of the control door (firebox opening) is approximately 8-3/4” (223mm) above the base of
the fireplace. For a typical raised fireplace of 36” (915mm), place the fireplace on a platform 27-
1/4” (693mm) tall.
a
c
b
IDB01002

Installation (for qualified installers only) 9
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Minimum Framing Dimensions
Min. Framing - Without CoolSmart TV kit
WARNING
When using a CoolSmart TV kit, see section: “CoolSmart TV - Framing the Chase”
on page 58.
The fireplace enclosure must be a minimum 61-7/8” (1572mm) tall. Do not build into the fireplace
enclosure.
Min Framing – With CoolSmart TV Kit
When using a CoolSmart TV kit, see section: “CoolSmart TV - Framing the Chase” on page 58 of this
manual or the installation instructions included with the kit for minimum framing dimensions.
41"
1042mm
a
61-7/8"
1572mm
15-3/4"
401mm
37-1/8" (943mm)
Max. 3"
77mm
a

10 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Minimum Vent “Bump Out” application
PB36 CF LP & NG Installations
12” Vertical Vent Section (Min. Rise)
Vent
Centerline Approx. 53-1/2” (1359mm)
FP Base to
Roof Eave Approx. 67-1/2” (1715mm)
Certain configurations
may require vertical vent
sections (see “Vent
Requirements” for details.
* See “Vent Termination
Requirements” for full details
Ven t
Centerline
8” (204mm)
Min. 6”
(153mm)*
Min. 11”
(280mm)*
SIDE OF
FIREPLACE
F
ireplac
e
B
ase o
f
a
b
a
b

Installation (for qualified installers only) 11
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Nailing Brackets
The fireplace has nailing brackets on both sides. Secure the fireplace to the framing with the nailing brackets.
NOTE: Make sure the fireplace is square and plumb when placed in the framing. Measured corner-to-corner the
fireplace should be square. Use shims to insure the fireplace is square.
NOTE: The nailing brackets have two positions: standard and extended. See the section “Facing Requirements”
for details on which position is best for your installation.




NOTE: 2 holes are provided on
each side of the fireplace if you
wish to secure the base of the
fireplace to the floor (platform).
Rotate the two nailing
brackets out (each side)
a
Bend the two nailing
brackets out (each side)
b
Extended Position
(rotate nailing brackets as shown below)
Standard Position
(nailing brackets as shown below)
Secure the fireplace to
the framing using the
nailing brackets
c

12 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Standard vs. Extended Position
There are two positions that the standoff/heat shield assembly can be installed. The standoffs are
shipped in the standard (forward) position.
If the unit is installed in the standard position no modification is needed.
If the unit is being installed in the extended position, the standoff/heat shield assembly must
be repositioned back ½” (see illustration below).
NOTE: see pages 10 & 31.for additional details about standard vs. extended installations.



Standard Position
Extended Position

Installation (for qualified installers only) 13
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Header and Pipe Shield Installation
The header and pipe shield must be installed as shown below.
NOTE: The header and pipe shields may be installed after the fireplace is in place and vent attached (this allows
for the fireplace to fit into the framing underneath the header and for the vent to be installed more easily).
1 At each of the perforations, bend the sides of the pipe shield backwards 90°asshownbelow.
NOTE: The bottom flanges should be facing outward
2 Remove the (4) screws, (2) from each side of the starter collar. Line up the holes on the pipe shield tabs
with the holes from the screws you just removed. Use the screws to attach the pipe shield to the top of
the fireplace.
Bend at perforations
Tabs face out.
Remove screws

14 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
3 The (2) header standoffs are screwed down flat to front edge of the top of the fireplace. On each
standoff, remove the screw that is closest to the center of the fireplace (keep screw for reinstallation).
Bend the legs at the perforations as shown below and attach the foot of the standoff to the top of the
fireplace using the screw removed earlier in this step.
Remove screw

Installation (for qualified installers only) 15
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
4 On the header shield, bend the two tabs downward approximately 90 degrees. Set the header shield
onto the standoffs with the 90°bend facing the pipe shield. The tips of the standoffs will protrude through
the heat shield. Attach the heat shield to the standoffs by aligning the holes on the heat shield tabs with
the holes in the header standoffs and secure using the included screws
5 When finished the fireplace should be configured like the picture below.


Bend tabs
down 90°
Align holes

16 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Corner Installations
A typical 45° installation uses the framing dimensions shown in the illustration below (NOTE: all clearances still
apply).
36 CF PB
(a) Corner to Wall (minimum) 38-1/2” (978mm)
(b) Corner to Center of Flue (typical) 13” (331mm)






































Minimum 1/2" (13mm) Clearance
a
b
NOTE ON PIPE SHIELD:
When venting horizontally in a
corner application, one side of
the pipe shield may be
disconnected from the top of the
fireplace and bent at a 45° angle
.

Installation (for qualified installers only) 17
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Televisions Placed Above the Fireplace
The following section gives guidelines to place a television above the fireplace.
IMPORTANT NOTE REGARDING TELEVISIONS AND THIS FIREPLACE
Most television manufacturers instruct the homeowner not to place the television above a heat source like this fireplace. Doing
so may decrease the longevity of the television and negate the warranty. If you do place a television above the fireplace, you
should place a mantel (or build-out) between the fireplace and television (or use a CoolSmart TV Wall™ kit). Follow the
guidelines below to reduce the amount of heat reaching the television. Travis Industries does not take responsibility for any
negative impact to televisions placed near this fireplace.
Minimum Dimensions:
(a) Minimum Mantel Height above Base of Fireplace* 43-1/2” (1106mm) with 8” (203mm) mantel depth*
(b) Mantel Depth* Minimum 8” (203mm)*
(c) Optional Columns (or Build-Out) Must Meet Side Wall Clearances
(Measured to the side of fireplace ZC-can)
* Minimum mantel depth must be 8” (203mm) to allow heat to dissipate. If using a mantel larger than 8” (203mm,
make sure to adjust the mantel height (a) to meet the mantel clearance (see mantel requirements and/or chart above).
The mantel must extend 2” (51mm) in front of the television and 1” (26mm) to both sides.
If you have a television that is greater than 6” deep (including the 1” (26mm) gap behind), you will need to alter the
mantel depth and height (see the example below).
The television must have a 1” (26mm) gap to the wall to allow for proper cooling. Any build-out near the television must
maintain a 3” (77mm) gap to the top and sides to prevent heat from being trapped near the television.
WIRING NOTE: If running wiring into the enclosure, you may wish to use thermal insulating wrap around the wiring. Secure
the wiring to protect from contact with hot surfaces.
Fireplace
Min. 1" (26mm)
Min. 1" (152mm) Min. 2" (51mm)
a
b
c
Optional Column
or Build-Out

















Min. 1" (26mm) Air Gap Behind TV
Min. 3"
(77mm)
Television (TV)



















(b) Depth
(a)
Height
Above
Base of
Fireplace
46" (1169mm)
0" (0mm)
1" (25mm)
2" (51mm)
8" (203mm)
7" (178mm)
6" (152mm)
5" (127mm)
4" (102mm)
3" (76mm)
9" (229mm)
10" (254mm)
11" (279mm)
12" (305mm)
45" (1143mm)
44" (1118mm)
43" (1093mm)
47" (1194mm)

18 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Gas Line Requirements
The gas line must be installed in accordance with all local codes and the requirements listed below. In the
absence of local codes, follow ANSI 223.1 in US/Canada or AS/NZS 5601.1 in Australia.
The fireplace and gas control valve must be disconnected from the gas supply piping during any pressure
testing of that system at test pressures in excess of 1/2 psig (3.5 kPA). For pressures under 1/2 psig (3.5
kPA), isolate the gas supply piping by closing the manual shutoff valve.
Leak test all gas line joints and the gas control valve prior to and after starting the fireplace.
This unit has been listed using the included internal gas shutoff valve.
Fuel
This fireplace is designed either for natural gas or for propane (but not for both).
Gas Line Connection
Installation must be performed by a qualified installer, service agency or the gas supplier (In Massachusetts a
licensed plumber/gasfitter).
The gas inlet accepts 1/2" MPT.
Gas Inlet Pressure
Gas Pressure
Max. Input Pressure Min. Input Pressure Max. Manifold Pressure Min. Manifold Pressure
Natural Gas
7" W.C. (1.74 kPA) 4.6” W.C. (1.13 kPA) 3.7” W.C. (0.93 kPA) 1.1” W.C. (0.27 kPA)
Propane
13" W.C. (3.23 kPA) 11” W.C. (2.74 kPA) 10.6” W.C. (2.64 kPA) 2.9” W.C. (0.72 kPA)
If the pressure is not sufficient, make sure the piping used is large enough, the supply regulator is adequately
adjusted, and the total gas load for the residence does not exceed the amount supplied.
The supply regulator (the regulator that attaches directly to the residence inlet or to the propane tank) should
supply gas at the suggested input pressure listed above. Contact the local gas supplier if the regulator is at
an improper pressure.
GSB2

Installation (for qualified installers only) 19
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Gas Line Location
NOTE FOR RIGID PIPE: When using rigid pipe, you may wish to disconnect the shutoff valve from the fireplace
and route the pipe through the fireplace wall. First, disconnect the gas line from the shutoff valve. Disconnect
the shutoff valve from the cover plate (4 screws outside fireplace). The pipe may be routed through the cover
plate and the shutoff valve and gas line may be re-attached inside the fireplace.
Gas line must be plumbed to the left side. See illustration and table below to determine gas line location.
Fireplace accepts 1/2” MPT fitting.
a b
Left Side Gas Pass-Through Location 7” (178mm) 1-3/4” (45mm)
a
b

20 Installation (for qualified installers only)
© Travis Industries 11/9/20 - 1503 PB36 CF Install (Aust)
Electrical Connection
The electrical line to the grounded receptacle inside the fireplace must be installed by a qualified installer and
must meet all local codes.
Make sure the household breaker is shut off prior to working on any electrical lines.
The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of
local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.
The electrical line must be a min. 14 gauge, and supply 240 Volts, 60 Hz, and 5.7 Amps.
Route the electrical connection through the junction box cover plate and attach to the hookup wires pictured
below.
Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause
improper and dangerous operation.
Do not connect 110-240 VAC to the gas control valve or wiring system of this fireplace.
a b
Electrical Junction Box Location 7” (178mm) 1-3/4” (45mm)
ab
1234
