4 CHANNEL digitAL vidEo
rECordEr
BUSINESS AND HOME SECURITY
SEE WHAT YOU’VE BEEN MISSING
• Four Channel digital video recorder
• Supports 2 disk drives (1 internal/1 removable)
• Password Security Protected
• Remote Control or Main Panel operation
• 4 camera inputs (4 BNC)
• Viewing options: Quad, Full Screen
• Quick Multiple Search Capability
• On Screen Display and Real Time Clock Function
• 3 Adjustable Video Quality Settings: High, Normal,
Basic
• High quality recording with modified MJPEG
compression (5~20Kbyte/frame)
• Alarm terminal block - integrated
FEAtUrES
L164 SEriES www.lorexcctv.com
The L164 Series of advanced digital video recorders
(DVR) offer market-leading features, easy installation
and ‘professional grade’ performance. The DVR
provides high quality recording with modified
MJPEG video compression, four input channels
and is designed to operate as part of any CCTV or
Observation system.
Includes remote controller

4 CHANNEL digitAL vidEo
rECordEr
SPECiFiCAtioNS
©2005 Strategic Vista International Inc.
As our product is subject to continuous improvement,
SVII & subsidiaries reserve the right to modify product
design, specifications & prices without notice and without
incurring any obligation. E&OE
3700 Koppers Street, Suite 100
Baltimore, Maryland 21227,
USA.
Strategic Vista International Inc.
300 Alden Road, Markham,
Ontario L3R 4C1
Canada.
BUSINESS AND HOME SECURITY
Hard Disk Storage: IDE Type, UTMA 66 above (supports 2 HDD - up to 250GB each)
Camera support: 4 analog CCTV
Video Compression: Modified MJPEG (5~20Kbyte/frame)
Video Resolution up to: 720 x 480
Recording Resolution up to: 640 x 224 (full screen)
Record Modes: Alarm External / Timer / Manual
Camera inputs: 4 BNC Video inputs
Video output: 2 RCA Video outputs
Alarm history log: 1000 events
Security Protection: Password protection
Display refresh rate: 30 FPS NTSC, 25 FPS PAL
Record refresh rate: 30 FPS NTSC, 25 FPS PAL
Recording Time: up to 3360 HRS with 80GB HDD
Video loss detection: Yes
On Screen display: Yes
HDD Key Lock: Yes
Playback Searching: Date & Time / Full list Searching
Alarm input: TTL input, High (5V), Low (GND)
Alarm output: COM / N.O / N.C
Power source: AC100-240V switching adaptor
Power consumption: 25W
Dimension: 385(W) X 73(H) X 290(D) mm
Weight: 5 kg
Operating temperature: 0°C - 50°C
Dimensions:
UPC Code:
Front Panel
Back Panel
Product Views:
Top Side
Front
Model#: L164000: Four Channel DVR
with No HDD
7-78597-16400-8
Model#: L164-81: Four Channel DVR
with 1-80 GB HDD
7-78597-16481-7
Model#: L164161: Four Channel DVR
with 1-160 GB HDD
7-78597-16416-9
14.75”
11.5”
3”
Weight: 10.0 lbs
