  9. Lorex L19WD800 Series User manual

Lorex L19WD800 Series User manual




High Resolution 19” Wide LCD Monitor provides Superior Image Quality in Live View and Playback
Built-in Pentaplex Digital Video Recorder: View, Record, Playback, Back Up & Remotely Control the system simultaneously
Real Time Recording: 240FPS @ CIF Resolution
H.264 Video Compression to maximize your recording time
Internet Remote Monitoring* (Software included) and Web Browser access
(4) High Resolution Weather Proof ** Cameras included with up to 50ft (15m) Night Vision range***
Large Capacity Security Certified Hard Drive pre-installed expandable up to 1000GB****
USB port for back up and convenient transferring of critical data
Mouse Driven Navigation (mouse included) and Graphical User Interface
Message Master software (included) allows you to send text and pictures from a remote location
Installer Friendly - Easy Quick Start Guide and Toll Free Tech Support
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
 INTEGRATED SURVEILLANCE
www.lorexcctv.com
HOME & BUSINESS SECURITY

H.264
VIDEO COMPRESSION
Monitor/Interface:
19” High Resolution (1400X900) Wide screen LCD
Easy to use Graphical User Interface with transparent menus
and mouse navigation (mouse included)
Multiple control options: mouse, front panel buttons, remote
control, remote access software
Multiple video out options: Spot Video Out lets you control what
shows on your Public View Monitor. Monitor Out also allows
you to view images on a slave monitor
Tri-lingual Display (English, Spanish, French)
Screen saver for energy efficiency
Wall mountable (VESA standard)
Stand with cable management solution for tidier installation
Environmentally friendly, recyclable packaging material
Digital Video Recorder:
8 channels allows you to connect up to 8 cameras
Pentaplex operation - View, Record, Playback, Back Up &
Remotely Control the system simultaneously
H.264 Video Compression Technology increases recording time
by up to 30%
Real Time Recording: Frames Per Second (FPS): 240/200
(NTSC/PAL) @CIF resolution
Recording Resolution: 352x240(NTSC), 352x288(PAL)
Covert Camera - record without displaying camera image
Continuous Recording with Motion Event logging for easy event
searching
Panic recording mode assures best quality of recording in
emergency situations
Selectable audio recording
Programmable motion detection
Capture activities prior to an event with programmable pre-
event recording
Quick search with bookmark recording
Advanced user authorization supporting up to 10 users
Security Certified Hard Drive with SATA interface, 100% duty
cycle for optimal performance in the commercial video security
market. Expandable up to 1000GB****
USB port for convenient transferring of critical data to USB
flash drive
Automatic watermarking of video files for secure data
encryption
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
 INTEGRATED SURVEILLANCE
www.lorexcctv.com
8 Programmable Alarm Inputs, 1 Relay Alarm output for convenient
integration with alarm systems
Pan/Tilt/Zoom Camera Control: RS-232 interface
Network Protocol: TCP/IP, DDNS and Web
Cameras:
Advanced high resolution image sensor produces sharp and clear
video with 450 TV Lines
30 IR LEDs provides class leading night vision range of 50ft (15m)
True Day/Night operation using built-in IR Filter Changeable
Mechanism to achieve accurate color representation in changing
lighting conditions
Advanced Day/Night mode: picture automatically switches to B&W
delivering better clarity in low light conditions
Weatherproof Design: ideal for Outdoor and Indoor applications
(IP66*)
Software:
Internet Remote Functions*: View, Search & Playback, Back-up
and Setup
Message Master DID software sends text and pictures from a
remote location
Full management flexibility. Use advanced Lorex Remote Access
Software (included) or web browser
Microsoft Windows Vista™ Compatible
Free Lorex DDNS (Dynamic Domain Name System) service keeps
you connected anywhere all the time
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
* Requires a high speed internet connection and router - not included
** Not intended for submersion in water
*** IR illumination range up to 50 ft (15M) under ideal conditions. Objects at or beyond this range may be partially or
completely obscured, depending on the camera application.
**** Recording capacity may vary based on recording resolution & quality, lighting conditions and movement in the scene


Model#: L19WD804321
L19WD804321F - Universal Package
UPC: L19WD804321 7-78597-19806-5
L19WD804321F 7-78597-19810-2
Weight: 18.4 kg / 40 lb
Package Dimensions: 604mm/23.8” x 584mm/23” x 334mm/13.2”
(W x H x D)
Includes: 19” LCD DVR, 320GB HDD Pre-Installed,
Remote Control, Power Supply, 4 Cameras
& stands, 60 ft. camera extension cables (4),
10 ft. Ethernet cable, Software application CD,
Mouse
©2008 Lorex Technology Inc.
As our product is subject to continuous improvement,
Lorex Technology & subsidiaries reserve the right to modify
product design, specifications & prices without notice and
without incurring any obligation. E&OE
3700 Koppers Street
Baltimore, Maryland 21227,
USA.
Lorex Technology Inc.
300 Alden Road, Markham,
Ontario L3R 4C1
Canada.

1-26092008
Monitor:
LCD: 19” Wide Screen
LCD Resolution: 1400 X 900
Monitor display: 16ch: Real time: 480/400 FPS (NTSC/PAL)
8ch: Real time: 240/200 FPS (NTSC/PAL)
Image size: 1.5 Kbyte (352 x 240)
Video inputs: 1Vp-p, CVBS, 75ohms, BNC (16ch)/ 8 BNC, 4 DIN(8 ch)
Audio inputs: 16ch: 4x line-in, RCA
8ch: 2 x line-in, RCA
Audio output: 1 x line-out, RCA
Audio: 2-way Audio conference (via network)
Supply Voltage: 100VAC-240VAC, 12VDC , 6.67A, 50/60Hz
Power consumption: Approx. 80 watts
Temperature range: 14° F ~ 113° F (-10°C ~ 45°C)
Weight: 8.8 kg/ 19.5 Lbs
Unit Dimensions: 18.2” / 462mm X 14.5”/369mm X 2.5”/62mm (W X D X H) (Without stand)
DVR:
Hard disk capacity: Preinstalled SATA HDD (Max 1000GB), Security Certified ,
100% duty cycle
Operating System: WinCE 5.0
Secondary Storage: USB Flash Drive
Back-up file formats: Proprietary
Compression: H.264
Recording speed: 352x240 : 16 channel 480/400 (NTSC/PAL) ,
352x240 : 8 channel 240/200 (NTSC/PAL)
352x240 : 4 channel 120/100 (NTSC/PAL)
Record Scheduling: Daily, Weekly, Hourly per 4 channel group
Pre/Post alarm recording: 1~5 seconds (Pre); 5~99 seconds (Post), programmable per
4 channel group
Event search: Up to 12,000 events
Playback: 16ch: Single, Quad or 9, 16 ch split screen
8ch: Single, Quad or 8 ch, split screen
Alarm inputs: 16ch: 16 x TTL, programmable as NC/NO
8ch: 8 x TTL, programmable as NC/NO
Alarm outputs: 1 x Relay with NO/NC contact; 24V DC/600mA
Activity detection: 16x12 grid, Sensitivity levels: 4
PTZ Control: RS-232 interface
Remote Functions: Live View, Search, Playback, Back-up, Configuration
Network Speed Control: 4 levels (100Kb ~ 2.5MB)/sec.
Network Protocol: TCP/IP, DDNS and Web
Network Interface: 10/100-Base-TX, RJ-45

462mm/18.2”
Monitor
67mm/2.6”
425mm/
16.8”
200mm/7.8”
Camera
3.2” /
80mm
3.9” /
100mm
2.7” /
68mm
Camera: CVC6993R
Image Sensor: High Resolution 1/4” Advanced Color Image Sensor
Video Format: NTSC
Effective Pixels: H: 656, V: 492
Resolution: 450 TV Line
Scan System: 2:1 Interlace
Sync System: Internal
S/N Ratio: More than 48dB
Iris: AES
AES Shutter Speed: 1/60~1/50,000 Sec
Min Illumination: 0.6 Lux without IR LED, 0 Lux with IR LED
Video Output: Composite 1.0Vpp @ 75 ohm
Lens/ Lens Mount: 5mm F 2.0/ Fixed
FOV (Diagonal): 50 degree
Termination: BNC
IR LED/ Night Vision Range: 30 pieces / 850 nm / 50ft
Power Requirement: 12Vdc
Power Consumption: 220 mA or 3W max
Operating Temp Range: -10° ~ 50° C
Environmental Rating: IP 66
BNC Video inputs
DIN camera inputs
Audio inputs
Alarm Block
Monitor Out
Audio Out
Ethernet PS/2
Spot Out PTZ
