Lorex CVC6975HR User manual

Quick Set-up Guide
English Version 1.0
LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
It’s all on the web
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
VISIT
www.lorexcctv.com
4. Camera Specifications H O M E & B U S I N E S S S E C U R I T Y
HIGH RESOLUTION INDOOR/
OUTDOOR COLOR CAMERA
with Night Vision
Specifications:
Dimensions:
Model: CVC6975HR
Image Sensor 1/4” Advanced Color
Lens / Lens Mount
Video Format / Pixels
Horizontal Resolution
Minimum Illumination
Termination
IR / Night Vision Range
FOV (diagonal)
S/N Ratio
Sync. & Scan. Systems
Video Output
Power Consumption
NTSC: 656(H) x 492 (V)
480 TVL
0.6 LUX @ F1.2 (IR Off)
0 LUX (IR LEDs ON)
Video: BNC Female
Power: Barrel Female
30 IR LEDs / 850nm /
75’(23m)
50 Degree
> 48dB
Internal; 2:1 Internlace
Comp. 1.0 Vpp @ 75ohm
220mA or 3W max
Operating Temp.
Dimensions
(H x D x Dia)
14°F ~ 122°F
(-10°C ~ 50°C)
5.0mm F2.8/ Fixed
Iris & Shutter Speed AES; 1/60 ~ 1/50,000 sec.
Power Requirement 12V DC ±10%
Weight (with stand) 10.4 oz / 294.8 g
3.9” x 2.7” x 3.2”
100mm x 68mm x 80mm

1. Package Contents 2. Installing the Video Camera
1 x 60 ft. Extension Cable
1 x BNC to RCA Adaptor
1 x AC Power Adaptor
1 x High Resolution
Indoor / Outdoor Color
CamerawithNightVision
& Sunshade
1 x Mounting Bracket /
Stand
1. Mount the camera stand to the desired mounting
surface
2. Attach the camera to the supplied stand at either
of the two connection points.
3. Connect the 60ft Extension cable to the camera:
Features:
• Advanced Image Sensor (AIS) provides High
Resolution image (480 TV Lines)
• Automatic Mechanical IR Cut Filter removal func-
tion ensures accurate color reproduction
• Durable Weatherproof Indoor/Outdoor camera*
• Enhanced Night Vision Capability - up to 75 ft **
• Easily connects to any TV, VCR or DVR
• Ceiling and wall mounting bracket included
* Not recommended for submersion in water
** IR Illumination range of 75 ft. (23m) under ideal conditions.
Objects at or beyond this range may be partially or completely
obscured, depending on the camera application.
WARNING - REGULATED 12V DC 500mA power supply is
REQUIRED for use with this camera. Use of a non-regulated,
non-conforming power supply can damage this product and will void
the warranty.
BNC (VIDEO)
(Yellow Connector)
POWER
(Black Connector)
CAMERA
CONNECTIONS:
Connect the BNC and
Power cables to the
Camera
VIDEO INPUT
CONNECTIONS:
Connect the BNC cable to
the video input of the
monitor, and connect the
power adaptor to an outlet.
3. Connecting the Camera
4. Connect the BNC end of the 60ft Extension Cable
to the DVR / Observation System or to a TV/VCR.
5. Connect the A/C Power Adaptor to the 60ft Exten-
sion cable (Black connector). Plug the Power
adaptor to a wall outlet
Setup Diagram:
Connect the BNC to RCA Adaptor as needed to
allow for proper connectivity.
NOTE - This Camera includes a Automatic Mechanical IR Cut Filter.
When the camera changes between Day/Night Lighting, an audible
clicking noise may be heard coming from the camera. This clicking is
normal, and indicates that the Camera filter is working.
NOTE: Test the cameras prior to selecting a permanent
mounting location by temporarily connecting the Cameras and Cables
to the Observation System or DVR.
