Lorex CVC7993 User manual

It’s all on the web
Quick Set-u
p
Guide
* This camera is not designed for direct exposure to water, rain or snow
Image Sensor
1/4” Interline transfer type color
CCD
Effective Pixels NTSC 510H x 492V (250K)
Scanning System (NTSC) 525 Lines 2:1 Interlace
Scanning Frequency (NTSC) 15.734KHz (H),
59.94Hz (V)
Resolution Horizontal 350 TV Lines
Shutter Speed (NTSC) 1/60 – 1/100,000 sec.
S/N Ratio More than 48dB (AGC off)
Sync. System Internal/Line Lock Mode
Min. Illumination 1.0 (no LED) / 0.1 Lux (LED)
White Balance AWB
Video Output VBS 1.0 Vp-p (75 Ωload)
Lens Varifocal Lens (4 - 9 mm)
Power Supply DC12V ±10%(Regulated)
Power Consumption 100mA (no LED)/200mA (LED)
Operating Temperature 14F to 113F (-10 ~+50)
Operating Humidity 90% RH max
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
www.lorexcctv.com
VISIT
Strategic Vista International Inc.
Copyright © 2005 Strategic Vista International Inc
As our products are subject to continuous improvement, SVII and its
subsidiaries reserve the right to modify product design, specifications
and prices, without notice and without incurring any obligation. E&OE
¼” COLOR
DAY-NIGHT
CAMERA
WITH VARIFOCAL LENS
BUSINESS & HOME
Model CVC7993
Specifications
Take Sunshade Off
1. Hold body of housing (rear of camera faces you)
2. Pull sunshade backwards (towards you)
Put Sunshade On
1. Hold body of housing (rear of camera faces you)
2. Push the sunshade forward (away from you)
4. Removable Sunshade

Features:
•Color Day/ Night Bullet Camera
•1/4” advanced CCD Image Sensor
•15 IR LED’s provides illumination up to 20 ft (6M)
•Color in the day, automatically switches to B/W at night
•Excellent low light sensitivity with buit-in infrared LED
•Weatherproof camera with removable sunshield
•4-9 mm Varifocal Lens
63 ft extension cable
Camera Mounting Bracket
CVC7993 Camera with
sunshade and mounting
bracket
a. Attach the camera to the mounting bracket and tighten
the swivel.
b. Connect the supplied cable to the back of the camera.
See diagram below.
Power Supply
2. To set the Angle (Focal Length):
a. Turn screw clockwise (to unlock) and move to T or W
b. Adjust the variable lens between T W (Tele
Wide).
c. Turn screw counter-clockwise to lock position.
3. To set the Focus:
a. Turn screw clockwise (to unlock) and move to or N
b. Adjust the variable lens between N.
c. Turn screw counter-clockwise to lock position.
4. Turn camera housing clockwise to secure.
1. Confirm Package Contents 2. Mount and Install the Camera 3. Varifocal Lens (4mm-9mm) Adjustment
Focus
adjustment
A
n
g
le adustmen
t
1. Turn camera housing counter clockwise to remove
Sunshield
Mounting
Bracke
t
Yellow: Video
Out
Black: DC 12V
Input
Swivel
The 6 ft camera cable has a female BNC connector (for video
output) and a female power jack
The mounting bracket is designed to permanently mount the
camera (i.e. to wall or ceiling)
