LORUS NREY704E User manual

■CHARACTERISTICS
1. Time/Calendar Display:
Hour, minute, second, month, date and the day of
the week
Automatic Calendar Function
The calendar adjusts automatically for odd and even
months including Februaries of leap years.
Time Display Format
12-hour display format with AM/PM indicator and
24-hour display format are available.
2. Stopwatch:
Thestopwatchcanmeasureupto9hours59minutes
and 59 seconds in 1/100-second increments.The
stopwatch features the following functions.
• Standard measurement
• Accumulated Time measurement
• Lap time measurement
• Split time measurement
Maximum 99 lap/split times can be displayed,
among which the first 30 lap/split times can be
recorded.
Memory Recall Function:
Each recorded lap/split times can be recalled after
measurement is finished.
3. Daily Alarm:
The alarm can be set to sound on a 24-hour basis.
4. Illuminating light:
Thebuilt-inelectroluminescentbacklightilluminates
the display for viewing in darkness.
■BUTTONS AND DISPLAYS
Press Button C to select a display mode. The display
mode changes over in the following order.
B: RECALL
E: LIGHT
AM/PM
indicator Hour
A: LAP/RESET C: MODE
INSTRUCTION MANUAL
CAL. Y704(R23 SERIES)
NREY704E 7-2002
Minute
Second
Day of the
week
D: START/STOP
Month
Date

1. Press Button C to go to the Time/Calendar Mode.
2. Press Button B for 2 seconds, the display changes
to the Time/Calendar Setting Mode. The second
numeralstarts flashing, andtheyearappearsinplace
of the day of the week.
While the second numeral is flashing, press
Button D in accordance with a time signal. The
second numeral is reset to “00” and starts
counting immediately.
When the second numeral read any number
between 30 and 59, and Button D is pressed, one
minute is added.
3. Press Button A to select an item to be adjusted. The
item changes over in the following order.
✥When an item is selected for adjustment, it starts
flashing.
4. Use Button D to adjust each item.
✥For the minute, hour, month, date and year settings,
each press of Button D advances the displayed
numeral by one. Keep Button D pressed to advance
the numeral quickly.
✥For the choice of time display format, each press of
Button D selects alternatively 12-hour display or 24-
hour display.
✥Press Button A to confirm the adjustment of the
selected item and move on to the next item.
5. Upon completion ofall necessaryadjustments,press
Button B to return to the Time/Calendar Mode.
✥Under 12-hour display, an “AM” indicator in the
morning and a “PM” indicator from the afternoon
are displayed.
✥Once year, month and date are set, the day of the
week is automatically set accordingly.
■HOW TO USE THE STOPWATCH
■HOW TO SET THE TIME/CALENDAR
Date
AM
Hour
AM/PM indicator
for 12-hour display only
Second
Minute
Day of the week BC
Month
D
Time/Calendar Mode
Alarm Mode
Lap Mode
Split Mode
AM
LAP
[]
SPLIT
[]
AM
Second setting
Year
Second Minute Hour
12H/24H
(time display format)
Month
Date

DDA
Start Stop Reset
Reset
A
RestartStop
Start
D
D
D
Stop
D
Lap 3
D
A
Up to Lap 99
Stop
Lap 2Start Lap 1
D AA
Reset
A
Memory Recall
Function
AD
LAP
[]
Lap
number
C
Lap time
Total running time
in progress
• The stopwatch can measure up to 9 hours, 59
minutesand59secondsin1/100-secondincrements.
When the measurement is over 9 hours 59 minutes
99, the stopwatch will be reset to “0:00’00”00” and
start counting again.
Standard Measurement
Standard time can be measured either in the Lap Mode
or in the Split Mode.
1. Press Button C to go to the Lap Mode or Split Mode.
2. Press Button D to start and stop the stopwatch.
3. Press Button A to reset the stopwatch.
Accumulated Elapsed Time Measurement
Accumulated Elapsed Time can be measured either in
the Lap Mode or in the Split Mode.
1. Press Button C to go to the Lap Mode or Split Mode.
2. Press Button D to start, stop and restart the
stopwatch as many times as required.
3. Press Button A to reset the stopwatch
❖Lap/Split Time Measurement
Up to 99 lap/split times can be displayed, among which
the first 30 lap/split times can be recorded during each
measurement. In order to recall the recorded lap times
aftermeasurement, use Memory Recall Function before
resetting the stopwatch.
Lap Time Measurement
1. Press Button C to go to the Lap Mode.
2. Press Button D to start the stopwatch.
3. Press Button A to check lap times. The lap time and
its lap number are displayed in the upper low of the
display, while the total running time, which is still in
progress, is displayed in the lower low of the display.
4. Press Button D to stop the measurement.
✥In order to check the recorded lap times, refer to
Memory Recall Function.
5. Press Button A to reset the stopwatch.

Split 2 Split 3 Start Split 1
D
Up to Split 99
Reset
Stop
Memory Recall
Function
A
DA
A
A
AD
LAP
[]
Split
number
C
Split time
Total running time
in progress
Split Time Measurement
1. Press Button C to go to the Split Mode.
2. Press Button D to start the stopwatch.
3. Press Button A to check split times. The split time
and its split number are displayed in the upper low
of the display, while the total running time, which is
still in progress, is displayed in the lower low of the
display.
4. Press Button D to stop the measurement.
✥In order to check the recorded lap times, refer to
Memory Recall Function.
5. Press Button A to reset the stopwatch.

Memory Recall Function
1. When lap/split time measurement is finished, press
Button B to go to the Memory Recall Display.
“RECALL” indicator appears on the display.
2. Press Button A to read each recorded lap/split time.
The recorded lap/split times are shown in order of
their lap number. The recorded lap time with its lap
number is displayed in the upper low of the display,
whiletherecorded split time isdisplayedinthelower
low of the display.
✥In order to read the recorded lap/split times in the
reverse order, press Button D.
3. Press Button B to exit the Memory Recall Function.
The display returns to the previous mode, either the
Lap Mode or the Split Mode.
✥When starting a new game to take new lap/split
times, the recorded memories will be automatically
replaced by the new ones.
Remarks on Stopwatch Operation
Even if the display is changed from the
Stopwatch Mode to another while measurement
is in progress, the stopwatch continues timing
properly. However, in order to avoid wasting its
battery energy, be sure to stop the stopwatch,
after measurement is finished.
■HOW TO SET THE ALARM
1. Press Button C to go to the Alarm Mode. Alarm
Mode indicator “AL” appears.
2. Press Button B for 2 seconds to change the display
to the Alarm Setting Mode. The hour numeral of the
alarm time starts flashing.
3. Use Button D to set the hour.
✥Each press of Button D advances the displayed
numeralby one. Keep the button pressed to advance
the numeral quickly.
4. PressButtonA to confirm the hoursetting and move
on to the minute setting. The minute numeral starts
flashing.
5. Use Button D to set the minute.
✥Each press of Button D advances the displayed
numeralby one. Keep the button pressed to advance
the numeral quickly.
LAP
[]
SPLIT
RECALL
“RECALL”
indicator
BD
Alarm indicator
Alarm Mode
indicator
Current time
AM/PM for alarm time
AM
AM/PM for current time
AD
C
B
Alarm time

6. Press Button B to complete the alarm setting.
7. Press Button D to engage the alarm. The alarm
indicator appears.
8. Upon completion ofall necessaryadjustments,press
Button C to return to the Time/Calendar Mode.
• Alarm engagement/disengagement
Press Button D in the Alarm Mode. Each press of the
Button Alternatively engages or disengages the alarm.
When the alarm is engaged, the alarm indicator appears
on the display regardless of the display mode.
• How to stop the alarm while sounding
Thealarm sounds for one minute at thedesignated time.
To stop it manually while sounding, press any button in
any display mode.
AM
Alarm engaged
Alarm disengaged
■ILLUMINATING LIGHT
Press Button E. The light illuminates the display with 3
seconds delay. Keep Button E pressed to light the
display for a longer time.
■LUMIBRITE WATCH
(dial, hands, buttons, case, bezel,
strap, etc.)
✥If your watch is a LORUS LUMIBRITE watch, it has
following features.
LORUS LUMIBRITE watches absorb and store light
energy from natural and artificial light sources and emit
light in the dark. They are made of environmentally
friendly material, and therefore, are harmless to human
beings and the environment.
• With a full charge, LORUS LUMIBRITE watches
glow in the dark hours longer than conventional
luminous watches of this type. If exposed to a light
of more than 500 lux (i.e., the brightness of a typical
office) for approximately 10 minutes, or direct
sunlight for 2 minutes, they will glow for hours.
• Since LORUS LUMIBRITE watches emit the light
they store, the brightness will decrease gradually
over time. The length of time they will glow may
also differ slightly depending on such factors as the
brightnessof and distancefromthelightsourceused
to charge the watch.
AM
E

Do not expose the old battery to fire or recharge
it. Keep it out of the reach of children. If a child
swallows it, immediately consult a doctor.
CAUTION
• WATER RESISTANCE
If your watch is 200 M/20 BAR, 100 M/10 BAR or 50
M/5 BAR water resistant, it is so indicated on the dial/
case back.
• Do not operate the buttons when the watch is wet.
• If the watch is exposed to salt water, rinse it in fresh
water and then wipe it thoroughly dry.
• Should you find any water or condensation inside
the watch, immediately have it checked. Water can
corrode electric parts inside the case.
NO NO NO
YES
YES
YES NO
YES YES NO
Condition
of use Accidental
contact with
water, such
as splashes
and rain
Swimm-
ing and
taking a
shower
Skin
diving Scuba
diving
Indica-
tion on
the dial/
case back
No
Indication
NO NO NO
YES
WATER
RESISTANT
WATER
RESISTANT
WATER
RESISTANT
50M/5 BAR
100M/10 BAR
or above
NO
NO
Caution:
Leather straps are not water resistant unless so
indicated, even if the watch head is water resistant.
•ALLERGIC REACTION
Because the case and band touch the skin directly, it is
important to clean them regularly. If not, shirt sleeves
maybe stained and those withdelicate skin may develop
a rash. Please wear the watch with some play to avoid
any possible allergic reaction. If you develop a rash on
your wrist, stop wearing and consult a physician.
•MAGNETISM/ STATIC ELECTRICITY
■BATTERY CHANGE
The miniature lithium battery Maxell battery
CR2032,which powers your watch, should last
approximately 2 years. However, because it is inserted
at the factory, the actual life of the battery once in your
possession may be less than 2 years. Be sure to replace
the battery to prevent any possible malfunction as soon
as it runs down. To replace the battery, we recommend
taking the watch to a local watch repair shop.
■CARE OF YOUR LORUS WATCH
This watch contains precise electronic components.
Neverattempttoopenthecaseorremovethebackcover.
• BATTERY

Your watch will not be affected by magnetism generated
by household electric appliances but keep your watch
away from a place where the watch is subject to strong
electric field and static electricity.
•SHOCKS AND VIBRATIONS
Your watch may be worn for normal sports activities,
However, be careful not to drop it or hit it against hard
surfaces as it may cause damage.
•TEMPERATURE
Yourwatch is preadjusted sothat constant accuracy may
be insured at normal temperature.
■SERVICE
When your LORUS watch requires repair or sevicing,
please see the enclosed WARRANTY/GUARANTEE.
Printed in China
