LOWE'S 1658MR-22-267 User manual

1
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
1658MR-22-267 ED by Ellen Collection 1658 Sm Mirror Rustic Taupe
1658MR-22-278 ED by Ellen Collection 1658 Sm Mirror Washed Oak
MODEL NUMBER DESCRIPTION
MODEL #
1658MR-22-267; 1658MR-22-278
22-IN MIRROR
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-855-571-1044, 9 a.m. - 5 p.m., EST, Monday - Friday.
Español p. 8

2
TABLE OF CONTENTS
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................3
Safety Instructions...........................................................................................................................3
Preparation......................................................................................................................................3
Assembly or Installation Instructions...............................................................................................5
Care and Maintenance....................................................................................................................7
Warranty..........................................................................................................................................7
Replacement Parts List....................................................................................................................7

3
PACKAGE CONTENTS
HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE)
SAFETY INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
CAUTION
•
Before installation, carefully use scissors or utility knife to cut and unwrap all parts. Make sure
you DO NOT discard the hardware.
• Follow these instructions closely, take your time, and use care while assembling this mirror.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
PART DESCRIPTION QUANTITY
A Mirror 1
B 4
Mounting Hanger
(preassembled to
mirror (A))
AA CCBB
Anchor
Qty. 2
Screw
Qty. 2
Touch Up Pen
Qty. 1
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Installation Time: 10 minutes.
Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors.
Helpful Tools (not included): Measuring tape, level
A
B

4
BEFORE YOU INSTALL, MAKE A CHOICE!!
OPTION 1: Vertical Mounting.
OPTION 2: Horizontal Mounting.

5
INSTALLATION INSTRUCTIONS
1. Measure the distance between the holes in the
mounting hangers (B) on the back of the mirror (A).
Note: Make sure to allow height clearance along the
bottom of the mirror for your faucet if necessary.
2. Measure and mark location for mounting hardware on
the wall using the measurement from Step 1. Make
sure the marks are level and located at the desired
height.
2
1
A
B
B
B
B

6
INSTALLATION INSTRUCTIONS
4. With the assistance of another adult, lift mirror (A)
to the wall and hang mounting hangers (B) on
screws (BB).
3. If the wall is drywall, there is no need to drill pilot
holes for wall anchors (AA). Screw anchors (AA)
flush into the wall. Then, insert screws (BB) into
anchors (AA), leaving approximately 1/4 in. protruding
out from the wall. If the wall is not drywall, please
choose appropriate mounting hardware (not included)
for your installation site, and follow the installation
instructions to secure the mounting hardware to
the wall.
Anchor x 2
AA
Screw x 2
BB
Hardware Used
1/4 in.
3
AA
BB
3
1
2
AA
BB
1
2
AA
BB
4
Vertical Mounting
Horizontal Mounting
BB
B
A
A

7
CARE AND MAINTENANCE
WARRANTY
• Dust the frame regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the mirror frame with a gentle, non-abrasive household cleaner.
• Make sure to dry the wood immediately with a soft cloth or towel.
• The glass can be cleaned using standard household glass cleaning agents.
• Tips for using touch-up pen (CC): For scratches, stroke in direction of scratch; for worn areas,
stroke in direction of wood grain. Rub off excess colorant promptly with a soft cloth.
The manufacturer warrants this item against defects in materials and workmanship for a period of
one (1) year from the date of original retail purchase. This warranty applies only to the original
purchaser. This warranty does not apply to any damage on the product by accident, misuse, or
modified, improper installation or by affixing accessories not produced by the manufacturer. The
manufacturer is not accountable whatsoever for product installation during the warranty period.
There is no further expressed warranty. The manufacturer shall not be legally responsible for
incidental, consequential or special damages arising at or in connection with product use or
performance except as may otherwise be accorded by law. The manufacturer disclaims any and
all implied warranties.
REPLACEMENT PARTS LIST
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
BB
PART DESCRIPTION PART#
B
Screw
PU16-1.75x1-MH
AA
Touch-up Pen for
22" Rustic Taupe Finish Mirror
(1658MR-22-267) M-1108
Touch-up Pen for
22" Washed Oak Finish Mirror
(1658MR-22-278) M-1108
CC
Mounting Hanger
Anchor
B AA BB CC
