LOWE'S 1922WC-24-267 User manual

1
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
1922WC-24-267 Nicole Collection 1922 Wall Cabinet Rustic Taupe
1922WC-24-341 Nicole Collection 1922 Wall Cabinet Wht Oak
MODEL NUMBER DESCRIPTION
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-855-571-1044, 9 a.m. - 5 p.m., EST, Monday - Friday.
Español p. 11
MODEL #
1922WC-24-267; 1922WC-24-341
24-IN WALL CABINET

2
TABLE OF CONTENTS
Package Contents...........................................................................................................................3
Hardware Contents..........................................................................................................................3
Safety Instructions...........................................................................................................................3
Preparation......................................................................................................................................4
Assembly or Installation Instructions..............................................................................................4
Adjustment Door Panels (Optional)...............................................................................................7
Care and Maintenance ...................................................................................................................8
Warranty.........................................................................................................................................8
Replacement Parts List...................................................................................................................9

3
PACKAGE CONTENTS
HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE)
SAFETY INSTRUCTIONS
Please read and understand this entire manual before attempting to assemble, operate or install the
product.
WARNING
• There are several assembly steps, including unpacking, that require two adults.
CAUTION
•
Before installation, carefully use scissors or utility knife to cut and unwrap all parts. Make sure
you DO NOT discard the hardware.
• Follow these instructions closely, take your time, and use care while assembling this wall cabinet .
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
PART DESCRIPTION QUANTITY
A Cabinet 1
B Wall Bracket 1
C Shelf 1
DLeft Door
(preassembled to cabinet (A)) 1
ERight Door
(preassembled to cabinet (A)) 1
FFlip Down Door
(preassembled to cabinet (A)) 1
P Metal Decoration 2
AA
Touch Up Pen
Qty. 1
Knob (2 Options)
Champagne Brass (Qty. 2)
Brushed Nickel (Qty. 2)
BB CC
Handle (2 Options)
Champagne Brass (Qty. 1)
Brushed Nickel (Qty. 1)
A
B
C
D
E
P
P
F

4
INSTALLATION INSTRUCTIONS
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with
package contents list and hardware contents list. If any part is missing or damaged, do not attempt
to assemble the product.
Estimated Installation Time: 20 minutes.
Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors,
power drill with drill bit.
Helpful Tools (not included): Measuring tape, level
1. Locate wall bracket (B) and set aside.
Locate and mark wall stud locations where
cabinet (A) will be placed. Center wall
bracket (B) in desired level location off the
floor and mark locations where wall bracket
(B) meets the location of the wall studs.
Using hardware appropriate for your wall
type (not included), secure the wall bracket
(B) to the wall into preferably 2 wall studs. Use
hardware such as a cabinet screw or toggle bolt
depending on your wall type. Make sure the
wall bracket (B) is level and centered well to the
desired location of the cabinet (A). Be careful
not to disturb any plumbing or electrical lines that
may be concealed in the wall.
!IMPORTANT SAFTEY STEP!
It is critical to have a strong secure
connection to the wall before continuing to
the next step.
B
1
1
2
2. With the help of another adult, carefully
lower the cabinet (A) down onto the wall
bracket (B). Be sure the cabinet (A) is secure
to the wall before letting go.
2
A
B

5
INSTALLATION INSTRUCTIONS
3. From the front of the assembly, insert shelf
pins at desired height, ensuring they are
level. Place shelf (C) on top of shelf pins.
4.
If you need to adjust the doors, do so in the following manner.
To adjust door up or down, loosen screws (a) on both hinges, adjust door, and retighten screws.
To adjust door left or right, turn screws (b) on both hinges, in and out.
To adjust door in or out, loosen screws (c) on both hinges, adjust door, and retighten screws.
3
2
AC
1
4
22
2
2
2
2
b
1
1
c
1
c
3
a
1
a
3

6
INSTALLATION INSTRUCTIONS
BB
5. One set of knobs (BB)/handle (CC) are packaged
separately in the box. If you would like to
switch handles, simply remove the existing
handles and attach the other finish, as
illustrated in the diagram.
Repeat the same step for the flip down door (F).
Hardware Used
Knob x 2
CC Handle x 1
Note: This wall cabinet comes with two
different handle/knobs options. 5
2
1
BB
F
D
E

7
ADJUSTMENT DOOR PANELS (OPTIONAL)
The pre-installed door panel can be switched from front to back.
1. Remove the silicone trim along the outer edges of the panel on the inside of the door. Start at
a corner and pull to remove the four pieces. Be careful not to damage the silicone trim as it will
be used to secure the panel.
2. Remove the panel from the door frame, then rotate the panel to reinsert it into the door frame.
3. Using your finger press the silicone trim back into place. Move around the outer edge of the
panels until all four sides are secure.
123
1
2
3
4
1
2
3
4

8
CARE AND MAINTENANCE
WARRANTY
• Dust the wall cabinet regularly with a soft, non-lint producing cloth or household dusting product.
• You can clean the wall cabinet with a gentle, non-abrasive household cleaner.
• Make sure to dry the wood immediately with a soft cloth or towel.
• Tips for using touch-up pen (AA): For scratches, stroke in direction of scratch. Rub off excess
colorant promptly with a soft cloth.
The manufacturer warrants this item against defects in materials and workmanship for a period of
one (1) year from the date of original retail purchase. This warranty applies only to the original
purchaser. This warranty does not apply to any damage on the product by accident, misuse, or
modified, improper installation or by affixing accessories not produced by the manufacturer. The
manufacturer is not accountable whatsoever for product installation during the warranty period.
There is no further expressed warranty. The manufacturer shall not be legally responsible for
incidental, consequential or special damages arising at or in connection with product use or
performance except as may otherwise be accorded by law. The manufacturer disclaims any and
all implied warranties.

9
REPLACEMENT PARTS LIST FOR 1922WC-24-267
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART #
B Wall Bracket WC-WALL BRACKET-267
C Shelf
1922WC-24-267 DOOR SET
1922WC-24-267-SHELF
D Left Door
E Right Door
AA Touch-up Pen M-1108
P
Metal Decoration-brushed nickel PU21-1922WC-24-BN
METAL DECORATION
Metal Decoration-champagne brass PU21-1922WC-24-CB
METAL DECORATION
F Flip Down Door 1922WC-24-267
FLIP DOWN DOOR
BB Knob-champagne brass 1922-CB KNOB
Knob-brushed nickel 1922-BN KNOB
CC Handle-champagne brass 1922-CB HANDLE
Handle-brushed nickel 1922-BN HANDLE
DD Shelf Pin B1044
EE Hinge C-90-107
FF Piston With Screw
GG Flip Door Hinge PU17-1480WC-DD/EE/FF
HH Door Catch
D
B
E
F
C
P
AA CC DD EE FF GG HHBB

10
REPLACEMENT PARTS LIST FOR 1922WC-24-341
For replacement parts, call our customer service department at 1-855-571-1044, 9 a.m. - 5 p.m.,
EST, Monday - Friday.
PART DESCRIPTION PART #
B Wall Bracket WC-WALL BRACKET-341
C Shelf
1922WC-24-341 DOOR SET
1922WC-24-341-SHELF
D Left Door
E Right Door
AA Touch-up Pen OF-0010
P
Metal Decoration-brushed nickel PU21-1922WC-24-BN
METAL DECORATION
Metal Decoration-champagne brass PU21-1922WC-24-CB
METAL DECORATION
F Flip Down Door 1922WC-24-341
FLIP DOWN DOOR
BB Knob-champagne brass 1922-CB KNOB
Knob-brushed nickel 1922-BN KNOB
CC Handle-champagne brass 1922-CB HANDLE
Handle-brushed nickel 1922-BN HANDLE
DD Shelf Pin B1044
EE Hinge C-90-107
FF Piston With Screw
GG Flip Door Hinge PU17-1480WC-DD/EE/FF
HH Door Catch
D
B
E
F
C
P
AA CC DD EE FF GG HHBB
