LSI LSI53C810A User manual

®
S14067
LSI53C810A
PCI to SCSI I/O
Processor
TECHNICAL
MANUAL
March 2001
Version 2.1

ii
This document contains proprietary information of LSI Logic Corporation. The
information contained herein is not to be used by or disclosed to third parties
without the express written permission of an officer of LSI Logic Corporation.
LSI Logic products are not intended for use in life-support appliances, devices,
or systems. Use of any LSI Logic product in such applications without written
consent of the appropriate LSI Logic officer is prohibited.
Document DB14-000168-00, First Edition (March 2001)
This document describes the LSI Logic LSI53C810A PCI to SCSI I/O Processor
and will remain the official reference source for all revisions/releases of this
product until rescinded by an update.
To receive product literature, visit us at http://www.lsilogic.com.
LSI Logic Corporation reserves the right to make changes to any products herein
at any time without notice. LSI Logic does not assume any responsibility or
liability arising out of the application or use of any product described herein,
except as expressly agreed to in writing by LSI Logic; nor does the purchase or
use of a product from LSI Logic convey a license under any patent rights,
copyrights, trademark rights, or any other of the intellectual property rights of
LSI Logic or third parties.
Copyright © 1995–2001 by LSI Logic Corporation. All rights reserved.
TRADEMARK ACKNOWLEDGMENT
The LSI Logic logo design, TolerANT, SDMS, and SCRIPTS are registered
trademarks or trademarks of LSI Logic Corporation. All other brand and product
names may be trademarks of their respective companies.

Preface iii
Preface
This book is the primary reference and technical manual for the LSI Logic
LSI53C810A PCI to SCSI I/O Processor. It contains a complete
functional description for the product and includes complete physical and
electrical specifications.
Audience
This manual provides reference information on the LSI53C810A PCI to
SCSI I/O processor. It is intended for system designers and programmers
who are using this device to design a SCSI port for PCI-based personal
computers, workstations, or embedded applications.
Organization
This document has the following chapters and appendix:
•Chapter 1, General Description, includes general information about
the LSI53C810A and other members of the LSI53C8XX family of PCI
to SCSI I/O processors.
•Chapter 2, Functional Description, describes the main functional
areas of the chip in more detail, including the interfaces to the SCSI
bus.
•Chapter 3, PCI Functional Description, describes the chip’s
connection to the PCI bus, including the PCI commands and
configuration registers supported.
•Chapter 4, Signal Descriptions, contains the pin diagrams and
definitions of each signal.
•Chapter 5, Operating Registers, describes each bit in the operating
registers, organized by address.

iv Preface
•Chapter 6, Instruction Set of the I/O Processor, defines all of the
SCSI SCRIPTS instructions that are supported by the LSI53C810A.
•Chapter 7, Electrical Characteristics, contains the electrical
characteristics and AC timings for the chip.
•Appendix A, Register Summary, is a register summary.
Related Publications
For background please contact:
ANSI
11 West 42nd Street
New York, NY 10036
[phone]
Ask for document number X3.131-199X (SCSI-2)
Global Engineering Documents
15 Inverness Way East
Englewood, CO 80112
[phone] or [phone] (outside U.S.) FAX [phone]
Ask for document number X3.131-1994 (SCSI-2) or X3.253
(SCSI-3 Parallel Interface)
ENDL Publications
14426 Black Walnut Court
Saratoga, CA 95070
[phone]
Document names: SCSI Bench Reference, SCSI Encyclopedia,
SCSI Tutor
Prentice Hall
113 Sylvan Avenue
Englewood Cliffs, NJ 07632
[phone]
Ask for document number ISBN 0-13-796855-8, SCSI: Understanding
the Small Computer System Interface
LSI Logic World Wide Web Home Page
www.lsil.com

Preface v
PCI Special Interest Group
2575 N. E. Katherine
Hillsboro, OR 97214
[phone]; [phone] (International); FAX [phone]
SCSI SCRIPTS™ Processors Programming Guide, Order Number
S14044.A
Conventions Used in This Manual
The word assert means to drive a signal true or active. The word
deassert means to drive a signal false or inactive.
Hexadecimal numbers are indicated by the prefix “0x” —for example,
0x32CF. Binary numbers are indicated by the prefix “0b” —for example,
0b0011.0010.1100.1111.
Revision Record
Revision Date Remarks
1.0 6/95 First version.
2.0 7/96 Revised technical manual.
2.1 3/01 All product names changed from SYM to LSI.

vi Preface

Contents vii
Contents
Chapter 1 General Description
1.1 TolerANT®Technology 1-2
1.2 LSI53C810A Benefits Summary 1-3
1.2.1 SCSI Performance 1-3
1.2.2 PCI Performance 1-4
1.2.3 Integration 1-4
1.2.4 Ease of Use 1-4
1.2.5 Flexibility 1-5
1.2.6 Reliability 1-5
1.2.7 Testability 1-6
Chapter 2 Functional Description
2.1 SCSI Core 2-1
2.1.1 DMA Core 2-2
2.2 SCRIPTS Processor 2-2
2.2.1 SDMS Software: The Total SCSI Solution 2-3
2.3 Prefetching SCRIPTS Instructions 2-3
2.3.1 Opcode Fetch Burst Capability 2-4
2.4 PCI Cache Mode 2-4
2.4.1 Load and Store Instructions 2-5
2.4.2 3.3 V/5 V PCI Interface 2-5
2.4.3 Loopback Mode 2-5
2.5 Parity Options 2-5
2.5.1 DMA FIFO 2-8
2.6 SCSI Bus Interface 2-11
2.6.1 Terminator Networks 2-11
2.6.2 Select/Reselect During Selection/Reselection 2-11
2.6.3 Synchronous Operation 2-13

viii Contents
2.7 Interrupt Handling 2-15
2.7.1 Polling and Hardware Interrupts 2-15
Chapter 3 PCI Functional Description
3.1 PCI Addressing 3-1
3.1.1 Configuration Space 3-1
3.1.2 PCI Bus Commands and Functions Supported 3-2
3.2 PCI Cache Mode 3-3
3.2.1 Support for PCI Cache Line Size Register 3-3
3.2.2 Selection of Cache Line Size 3-4
3.2.3 Alignment 3-4
3.2.4 Memory Read Multiple Command 3-7
3.2.5 Unsupported PCI Commands 3-8
3.3 Configuration Registers 3-9
Chapter 4 Signal Descriptions
4.1 PCI Bus Interface Signals 4-5
4.1.1 System Signals 4-5
4.1.2 Address and Data Signals 4-6
4.1.3 Interface Control Signals 4-7
4.1.4 Arbitration Signals 4-8
4.1.5 Error Reporting Signals 4-8
4.2 SCSI Bus Interface Signals 4-9
4.2.1 SCSI Bus Interface Signals 4-9
4.2.2 Additional Interface Signals 4-10
Chapter 5 Operating Registers
Chapter 6 Instruction Set of the I/O Processor
6.1 Low Level Register Interface Mode 6-1
6.2 SCSI SCRIPTS 6-2
6.2.1 Sample Operation 6-3
6.3 Block Move Instructions 6-5
6.3.1 First Dword 6-6
6.3.2 Second Dword 6-12
6.4 I/O Instruction 6-13

Contents ix
6.4.1 First Dword 6-13
6.4.2 Second Dword 6-22
6.5 Read/Write Instructions 6-23
6.5.1 First Dword 6-23
6.5.2 Second Dword 6-23
6.5.3 Read-Modify-Write Cycles 6-23
6.5.4 Move To/From SFBR Cycles 6-24
6.6 Transfer Control Instructions 6-27
6.6.1 First Dword 6-27
6.6.2 Second Dword 6-35
6.7 Memory Move Instructions 6-36
6.7.1 First Dword 6-38
6.7.2 Second Dword 6-38
6.7.3 Third Dword 6-38
6.7.4 Read/Write System Memory from a SCRIPTS
Instruction 6-39
6.8 Load and Store Instructions 6-39
6.8.1 First Dword 6-40
6.8.2 Second Dword 6-41
Chapter 7 Electrical Characteristics
7.1 DC Characteristics 7-1
7.2 TolerANT Technology 7-6
7.3 AC Characteristics 7-10
7.4 PCI Interface Timing Diagrams 7-12
7.4.1 Target Timing 7-13
7.4.2 Initiator Timing 7-17
7.5 PCI Interface Timing 7-26
7.6 SCSI Timings 7-27
7.7 Package Drawings 7-33
Appendix A Register Summary
Index
Customer Feedback

x Contents
Figures 1.1 LSI53C810A System Diagram 1-7
1.2 LSI53C810A Chip Block Diagram 1-8
2.1 DMA FIFO Sections 2-8
2.2 LSI53C810A Host Interface Data Paths 2-10
2.3 Active or Regulated Termination 2-12
2.4 Determining the Synchronous Transfer Rate 2-15
4.1 LSI53C810A Pin Diagram 4-2
4.2 Functional Signal Grouping 4-4
5.1 Register Address Map 5-2
6.1 SCRIPTS Overview 6-5
6.2 Block Move Instruction Register 6-8
6.3 I/O Instruction Register 6-16
6.4 Read/Write Register Instruction 6-25
6.5 Transfer Control Instruction 6-30
6.6 Memory to Memory Move Instruction 6-37
6.7 Load and Store Instruction Format 6-42
7.1 Rise and Fall Time Test Conditions 7-8
7.2 SCSI Input Filtering 7-8
7.3 Hysteresis of SCSI Receiver 7-8
7.4 Input Current as a Function of Input Voltage 7-9
7.5 Output Current as a Function of Output Voltage 7-9
7.6 Clock Timing 7-10
7.7 Reset Input 7-11
7.8 Interrupt Output Waveforms 7-11
7.9 PCI Configuration Register Read 7-13
7.10 PCI Configuration Register Write 7-14
7.11 Target Read 7-15
7.12 Target Write 7-16
7.13 OpCode Fetch, Nonburst 7-17
7.14 Burst Opcode Fetch 7-18
7.15 Back-to-Back Read 7-19
7.16 Back-to-Back Write 7-20
7.17 Burst Read 7-22
7.18 Burst Write 7-24
7.19 Initiator Asynchronous Send 7-27
7.20 Initiator Asynchronous Receive 7-28

Contents xi
7.21 Target Asynchronous Send 7-29
7.22 Target Asynchronous Receive 7-30
7.23 Initiator and Target Synchronous Transfers 7-30
7.24 100 LD PQFP (UD) Mechanical Drawing (Sheet 1 of 2) 7-34
Tables 2.1 Bits Used for Parity Control and Observation 2-6
2.2 SCSI Parity Control 2-7
2.3 SCSI Parity Errors and Interrupts 2-7
3.1 PCI Bus Commands and Encoding Types 3-9
3.2 PCI Configuration Register Map 3-10
4.1 Power and Ground Signals 4-3
4.2 System Signals 4-5
4.3 Address and Data Signals 4-6
4.4 Interface Control Signals 4-7
4.5 Arbitration Signals 4-8
4.6 Error Reporting Signals 4-8
4.7 SCSI Bus Interface Signals 4-9
4.8 Additional Interface Signals 4-10
5.1 Synchronous Clock Conversion Factor 5-10
5.2 Asynchronous Clock Conversion Factor 5-11
5.3 Examples of Synchronous Transfer Periods and
Rates for SCSI-1 5-13
5.4 Examples of Synchronous Transfer Periods and
Rates for Fast SCSI 5-14
5.5 SCSI Synchronous Offset Values 5-15
6.1 SCRIPTS Instructions 6-3
6.2 Read/Write Instructions 6-26
7.1 Absolute Maximum Stress Ratings 7-2
7.2 Operating Conditions 7-2
7.3 SCSI Signals—SD[7:0]/, SDP/, SREQ/, SACK/ 7-3
7.4 SCSI Signals—SMSG, SI_O/, SC_D/, SATN/, SBSY/,
SSEL/, SRST/ 7-3
7.5 Input Signals—CLK, SCLK, GNT/, IDSEL, RST/, TESTIN 7-3
7.6 Capacitance 7-4
7.7 Output Signals—MAC/_TESTOUT, REQ/ 7-4
7.8 Output Signal—IRQ/ 7-4
7.9 Output Signal—SERR/ 7-5

xii Contents
7.10 Bidirectional Signals—AD[31:0], C_BE/[3:0], FRAME/,
IRDY/, TRDY/, DEVSEL/, STOP/, PERR/, PAR/ 7-5
7.11 Bidirectional Signals—GPIO0_FETCH/,
GPIO1_MASTER/ 7-6
7.12 TolerANT Technology Electrical Characteristics 7-7
7.13 Clock Timing 7-10
7.14 Reset Input Timing 7-11
7.15 Interrupt Output 7-11
7.16 PCI Timing 7-26
7.17 Initiator Asynchronous Send (5 Mbytes/s) 7-27
7.18 Initiator Asynchronous Receive (5 Mbytes/s) 7-28
7.19 Target Asynchronous Send (5 Mbytes/s) 7-29
7.20 Target Asynchronous Receive (5 Mbytes/s) 7-30
7.21 SCSI-1 Transfers (SE, 5.0 Mbytes/s) 7-31
7.22 SCSI-2 Fast Transfers (10.0 Mbytes/s (8-Bit Transfers),
40 MHz Clock) 7-31
7.23 SCSI-2 Fast Transfers (10.0 Mbytes/s (8-Bit Transfers),
50 MHz Clock) 7-32
A.1 Configuration Registers A-1
A.2 SCSI Registers A-2

LSI53C810A PCI to SCSI I/O Processor 1-1
Chapter 1
General Description
Chapter 1 is divided into the following sections:
•Section 1.1, “TolerANT®Technology”
•Section 1.2, “LSI53C810A Benefits Summary”
The LSI53C810A PCI to SCSI I/O processor brings high-performance I/O
solutions to host adapter, workstation, and general computer designs,
making it easy to add SCSI to any PCI system.
The LSI53C810A is a pin-for-pin replacement for the LSI53C810 PCI to
SCSI I/O processor. It performs fast SCSI transfers in Single-Ended (SE)
mode, and improves performance by optimizing PCI bus utilization.
The LSI53C810A integrates a high-performance SCSI core, a PCI bus
master DMA core, and the LSI Logic SCSI SCRIPTS™ processor to
meet the flexibility requirements of SCSI-1, SCSI-2, and future SCSI
standards. It is designed to implement multithreaded I/O algorithms with
a minimum of processor intervention, solving the protocol overhead
problems of previous intelligent and nonintelligent adapter designs.
The LSI53C810A is fully supported by the LSI Logic Storage Device
Management System (SDMS™), a software package that supports the
Advanced SCSI Protocol Interface (ASPI). SDMS software provides
BIOS and driver support for hard disk, tape, removable media products,
and CD-ROM under the major PC operating systems.
The LSI53C810A is packaged in a compact rectangular 100-pin Plastic
Quad Flat Pack (PQFP) package to minimize board space requirements.
It operates the SCSI bus at 5 Mbytes/s asynchronously or 10 Mbytes/s
synchronously, and bursts data to the host at full PCI speeds. The
LSI53C810A increases SCRIPTS performance and reduces PCI bus
overhead by allowing instruction prefetches of 4 or 8 Dwords.

1-2 General Description
Software development tools are available to developers who use the
SCSI SCRIPTS language to create customized SCSI software
applications. The LSI53C810A allows easy firmware upgrades and is
supported by advanced SCRIPTS commands.
1.1 TolerANT®Technology
The LSI53C810A features TolerANT technology, which includes active
negation on the SCSI drivers and input signal filtering on the SCSI
receivers. Active negation actively drives the SCSI Request,
Acknowledge, Data, and Parity signals HIGH rather than allowing them
to be passively pulled up by terminators. Active negation is enabled by
setting bit 7 in the SCSI Test Three (STEST3) register.
TolerANT receiver technology improves data integrity in unreliable
cabling environments where other devices would be subject to data
corruption. TolerANT receivers filter the SCSI bus signals to eliminate
unwanted transitions, without the long signal delay associated with
RC-type input filters. This improved driver and receiver technology helps
eliminate double clocking of data, the single biggest reliability issue with
SCSI operations. The TolerANT input signal filtering is a built in feature
of all LSI Logic fast SCSI devices. On the LSI53C8XX family products,
the user may select a filtering period of 30 or 60 ns, with bit 1 in the SCSI
Test Two (STEST2) register.
The benefits of TolerANT technology include increased immunity to noise
when the signal is going HIGH, better performance due to balanced duty
cycles, and improved fast SCSI transfer rates. In addition, TolerANT SCSI
devices do not cause glitches on the SCSI bus at power-up or
power-down, so other devices on the bus are also protected from data
corruption. TolerANT technology is compatible with both the Alternative
One and Alternative Two termination schemes proposed by the American
National Standards Institute.

LSI53C810A Benefits Summary 1-3
1.2 LSI53C810A Benefits Summary
This section provides an overview of the LSI53C810A features and
benefits. It contains these topics:
•SCSI Performance
•PCI Performance
•Integration
•Ease of Use
•Flexibility
•Reliability
•Testability
1.2.1 SCSI Performance
To improve SCSI performance, the LSI53C810A:
•Complies with PCI 2.1 specification
•Supports variable block size and scatter/gather data transfers
•Minimizes SCSI I/O start latency
•Performs complex bus sequences without interrupts, including
restore data pointers
•Reduces Interrupt Service Routine (ISR) overhead through a unique
interrupt status reporting method
•Performs fast SCSI bus transfers in SE mode
– up to 7 Mbytes/s asynchronous
– 10 Mbytes/s synchronous
•Increases performance of data transfers to and from the chip
registers with new load and store SCRIPTS instruction
•Supports target disconnect and later reselect with no interrupt to the
system processor
•Supports execution of multithreaded I/O algorithms in SCSI
SCRIPTS with fast I/O context switching

1-4 General Description
1.2.2 PCI Performance
To improve PCI performance, the LSI53C810A:
•Bursts 2, 4, 8, or 16 Dwords across PCI bus with 80-byte DMA FIFO
•Prefetches up to 8 Dwords of SCRIPTS instructions
•Supports 32-bit word data bursts with variable burst lengths.
•Bursts SCRIPTS opcode fetches across the PCI bus
•Performs zero wait-state bus master data bursts faster than
110 Mbytes/s (@ 33 MHz)
•Supports PCI Cache Line Size register
1.2.3 Integration
Features of the LSI53C810A which ease integration include:
•3.3 V/5 V PCI interface
•Full 32-bit PCI DMA bus master
•DMA controller using Memory-to-Memory Move instructions
•High-performance SCSI core
•Integrated SCRIPTS processor
•Compact 100-pin PQFP packaging
1.2.4 Ease of Use
The LSI53C810A provides:
•Direct PCI-to-SCSI connection
•Reduced SCSI development effort
•Support for the ASPI software standard using SDMS software
•Compatibility with existing LSI53C7XX and LSI53C8XX family
SCRIPTS
•Direct connection to PCI and SCSI SE bus
•Development tools and sample SCSI SCRIPTS
•Maskable and pollable interrupts

LSI53C810A Benefits Summary 1-5
•Three programmable SCSI timers: Select/Reselect, Handshake-to-
Handshake, and General Purpose. The time-out period is
programmable from 100 µs to greater than 1.6 seconds
•SDMS software for complete PC-based operating system support
•Support for relative jump
•New SCSI Selected As ID (SSAID) bits for use when responding with
multiple IDs
1.2.5 Flexibility
The LSI53C810A provides:
•High level programming interface (SCSI SCRIPTS)
•Support for execution of tailored SCSI sequences from main system
RAM
•Flexible programming interface to tune I/O performance or to adapt
to unique SCSI devices
•Flexibility to accommodate changes in the logical I/O interface
definition
•Low level access to all registers and all SCSI bus signals
•Fetch, Master, and Memory Access control pins
•Support for indirect fetching of DMA address and byte counts so that
SCRIPTS can be placed in a PROM
•Separate SCSI and system clocks
•Selectable IRQ pin disable bit
•Ability to route system clock to SCSI clock
1.2.6 Reliability
Enhanced reliability features of the LSI53C810A include:
•2 kV ESD protection on SCSI signals
•Typical 300 mV SCSI bus hysteresis
•Average operating supply current of 50 mA
•Protection against bus reflections due to impedance mismatches

1-6 General Description
•Controlled bus assertion times (reduces RFI, improves reliability, and
eases FCC certification)
•Latch-up protection greater than 150 mA
•Voltage feed-through protection (minimum leakage current through
SCSI pads)
•High proportion (> 25%) of pins power and ground
•Power and ground isolation of I/O pads and internal chip logic
•TolerANT technology, which provides:
– Active negation of SCSI Data, Parity, Request, and Acknowledge
signals for improved fast SCSI transfer rates.
– Input signal filtering on SCSI receivers improves data integrity,
even in noisy cabling environments.
1.2.7 Testability
The LSI53C810A provides improved testability through:
•Access to all SCSI signals through programmed I/O
•SCSI loopback diagnostics
•SCSI bus signal continuity checking
•Support for single step mode operation
•Test mode (AND tree) to check pin continuity to the board
A system diagram showing the connections of the LSI53C810A in a PCI
system is pictured in Figure 1.1. A block diagram of the LSI53C810A is
pictured in Figure 1.2.

LSI53C810A Benefits Summary 1-7
Figure 1.1 LSI53C810A System Diagram
PCI Bus LSI53C810A
40 MHz Oscillator or
SCSI Bus
Peripheral
Bulkhead
CPU Box
CPU Baseboard
SCSI Term Connection
SCSI Connection
Optional Internal
Connection to PCI
VDD VSS
Bus Clock

1-8 General Description
Figure 1.2 LSI53C810A Chip Block Diagram
PCI Master and Slave Control Block
Data
FIFO
80 Bytes SCSI
SCRIPTS Operating
Registers Configuration
Registers
SCSI FIFO and SCSI Control Block
TolerANT Technology Drivers and Receivers
SE SCSI Bus
PCI
