Extinguishing Control Panel
Series LC216
• Actuation and monitoring of up to
127 extinguishing systems or 127
fl ooding zones
• Fully integrated into Fire Detection
Control Panel Series BC216
• Individual control panel or fl exibly
expandable control panel network
• Suitable for all system sizes
• Optional hardware redundancy
• EN 54, EN 12094-1, VdS certifi ed
Fire is a permanent threat to life and property. There-
fore, immediate response to a fi re is imperative. The
main objective of the Extinguishing Control Panels Se-
ries LC216 is to alarm and to react in time and, conse-
quently, save lives and protect property. For decades
LST have focused their aims to undertaking unrivaled
efforts in order to realize new innovations in the security
area. Research, development and production are loca-
ted within LST premises, thus guaranteeing fl exible and
reliable individual solutions.
Using a 32-bit multiprocessor system, the Extinguishing
Control Panels Series LC216 ensure topmost effi ciency
and speed – prerequisites for saving lives and minimi-
zing damage to property.
Description
The Extinguishing Control Panel Series LC216 is an
extended Fire Detection Control Panel Series BC216
with additional functions for the control of extinguishing
systems. Nevertheless, all functions of the fi re detec-
tion control panel remain intact. Therefore, a combined
use as fi re detection and extinguishing control panel is
provided as standard.
The Extinguishing Control Panels Series LC216 compri-
se the following types of control panels:
• The Extinguishing Control Panel LC216-1 for an extin-
guishing system with one fl ooding zone according to
EN 12094-1 or with up to 8 fl ooding zones without
compliance to EN 12094-1.
• The networked Extinguishing Control Panel LCnet216
for up to 127 extinguishing systems. The LCnet216
consists of several sectional control panels, which
are interconnected via the Global Security System
Network GSSnet and thereby form a decentralised
extinguishing control system. Each extinguishing sys-
tem can control up to 32 fl ooding zones, and each
LCnet sectional control panel can administrate up to
8 fl ooding zones. A maximum of 127 fl ooding zones
can be controlled by an Extinguishing Control Panel
LCnet216.
The Extinguishing Control Panel Series LC216 fulfi ls
all compulsory requirements as well as the options of
EN 12094-1, EN 54-2 and EN 54-4 and is VdS certi-
fi ed.
The networked Extinguishing Control Panel LCnet216
can be easily implemented with a redundant design of
the extinguishing control.

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
LC216_DBL_LST_EN_0806.PDF • PAGE 2
ABuilding Safety. Building Security.
System design
The Extinguishing Control Panel LC216-1 can be used
to realize an extinguishing system with one fl ooding
zone according to EN 12094-1. In an extinguishing
system that does not require a design according to
EN 12094-1, up to 8 fl ooding zones can be actuated.
The function of the Extinguishing Control Panel LC216-1
is integrated into the Fire Detection Control Panels
BC216-1 and BC216-1CE and can be enabled by means
of an options circuit.
In the networked Extinguishing Control Panel LCnet216,
up to 127 extinguishing systems with a total of 127
fl ooding zones can be implemented. Each extinguishing
system can control up to 32 fl ooding zones, and each
LCnet sectional control panel can administrate up to 8
fl ooding zones.
The Extinguishing Control Panel LCnet216 can be imp-
lemented with all types of Fire Detection Control Panels
Series BC216 that are suitable for networking.
These are
• the BCnet sectional control panel with operating
unit BC216-2 and without operating unit BC216-3
in a wall-mount cabinet,
• the BCnet Sectional Control Panel Extension
BCE216-3LG for installation into a BCnet Sectional
Control Panel BC216-2 or BC216-3,
• the fi re detection control panel with operating unit
BC216-1CE with installed Network Interface Modu-
le NIF5-1M, and the BCnet sectional control panel
without operating unit BC216-3CE, for installation
into a 19“ housing, as well as
• the Fire Detection Control Panel Modules
BCM216-3EPS, BCM216-3E and BCM216-3ELG
for sliding into a 19“ rack.
A redundant design of the extinguishing control panel
according to EN 12094-1 can be implemented by
means of the fi re detection control panel modules in
19“ slide-in technology.
Other versions of the Fire Detection Control Panel Series
BC216 can be implemented according to EN 12094-1
– without redundancy – with one fl ooding zone per
BCnet sectional control panel.

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
LC216_DBL_LST_EN_0806.PDF • PAGE 3
ABuilding Safety. Building Security.
Features
The extinguishing control function is fully integrated into
the Fire Detection Control Panel Series BC216. The Ex-
tinguishing Control Panel Series LC216 comprises the
following additional features:
• The Extinguishing Control Panel LC216-1 serves for
the actuation of an extinguishing system with up to
8 fl ooding zones. By means of the networked Extin-
guishing Control Panel LCnet216, up to 127 extingu-
ishing systems can be actuated. Each extinguishing
system can control up to 32 fl ooding zones, each
LCnet sectional control panel can administrate up to
8 fl ooding zones. A maximum of 127 fl ooding zones
can be controlled by an Extinguishing Control Panel
LCnet216.
• All zones with automatic fi re detectors or manual call
points can be used for the actuation of the extinguis-
hing system. The respective detectors and detector
zones are assigned to the individual fl ooding zones
by defi ning combinations and dependencies.
• Input signals for the actuation of the extinguishing
system can be received through zone inputs in con-
ventional or ADM technology, as well as via fi re briga-
de interface inputs.
The ADM technology allows to connect detectors,
signalling devices as well as monitor and control mo-
dules in intelligent analogue ring bus technology. A
safe supply of the loop elements is achieved through
the redundant cable path. Therefore, standard fi re
detection cable can be used for wiring.
• Various zone and input types, such as „Emergency
hold device“, „Manual mode“, „Extinguishing medium
active“ or „Reset extinguishing system“ provide spe-
cifi c functions for the actuation of the extinguishing
system.
• For the actuation of valves or signalling equipment,
various types of actuation are available, which can
be assigned to any outputs of the control panel or
to an ADM control module. The activation of these
actuations is timed according to EN 12094-1.
• The condition of fl ooding zones or extinguishing sys-
tems can be output by the status outputs of the con-
trol panel or via ADM modules. Furthermore, status
LEDs can be freely parameterised as optical conditi-
on display.
• Depending on the size of the fl ooding zone and the
capacity of the extinguishing agent cylinders, for
each fl ooding zone the actuation of further fl ooding
zones can be unblocked or blocked.
• In the appropriate authorisation level, a fl ooding zone
can be operated at the display and operating unit of
the fi re detection control panel. In addition to disab-
lements, enablements and toggling between manual
and automatic mode, it is also possible to test the
signalling equipment for pre-alarm and evacuation
alarm.
• The Extinguishing Control Panel Series LC216 can
be comfortably parameterised via PC by using the
Windows Parameter Setup Software PARSOFT. The
clear user interface allows an almost self-explanato-
ry defi nition of the system confi guration and thereby
minimizes the requirement for training. The entered
parameters can be loaded into the control panel after
an automatic verifi cation for technical correctness.
In addition to all compulsory functions of EN 12094-1,
the extinguishing control panel fulfi ls the following opti-
ons of this standard:
• Delay of extinguishing signal
• Signal representing the fl ow of extinguishing agent
• Monitoring of the status of components
• Emergency hold device
• Control of fl ooding time
• Initiation of secondary fl ooding
• Manual only mode
• Triggering signals to equipment within the system
• Extinguishing signals to spare cylinders
• Triggering of equipment outside the system
• Emergency abort device
• Control of extended discharge
• Release of the extinguishing media for selected fl oo-
ding zones
Advanced features
Redundant design
The Extinguishing Control Panel Series LC216 can be
optionally implemented with a hardware-redundant de-
sign. A redundant design is required according to the
standard EN 12094-1 for fi xed gas extinguishing sys-
tems, if one sectional control panel actuates more than
one extinguishing area.
A redundant design of the extinguishing control panel
can be implemented by means of the fi re detection
control panel modules in 19“ slide-in technology. The
parameterisation of the redundant extinguishing control
panel is fully supported by the Parameter Setup Softwa-
re PARSOFT.

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
LC216_DBL_LST_EN_0806.PDF • PAGE 4
ABuilding Safety. Building Security.
Specifi cations
Extinguishing Control Panel LC216-1
Number of extinguishing systems 1
Number of fl ooding zones max. 8
Extinguishing Control Panel LCnet216
Number of extinguishing systems per sectional control panel 1
Total number of extinguishing systems max. 127
Number of fl ooding zones per sectional control panel max. 8
Number of fl ooding zones per extinguishing system max. 32
Total number of fl ooding zones max. 127
Extinguishing control licence for 8 fl ooding zones
Approvals
CE marking 0786–CPD–20267
as pure extinguishing control panel VdS G206046
as combined fi re detection and extinguishing control panel VdS G206089
FT 14/423/06 (Austria)
Order number 218024
Order name Extinguishing Control/8-Area Licence LC216-8LB
Extinguishing control licence
The extinguishing control function is enabled in the
Extinguishing Control Panel LC216-1 and in any LCnet
sectional control panel by installing an appropriately pa-
rameterised options circuit. This control panel LC216-1
or LCnet sectional control panel can be used for the
actuation of up to 8 fl ooding zones.
The options circuit is part of the Extinguishing Cont-
rol/8-Area Licence LC216-8LB.
