Ltech DIN-DMX-5A User manual

+
++
+
--
--
M
MM
1 2
DIN-DMX-5A
DMX DECODER
(DIN Rail, Screw dual-use)
DIN-DMX-5A CV DMX Decoder:
112mm
100mm
44mm
12mm
11mm
36mm
11mm
67mm
12mm
22mm
27mm
6mm
35mm
35mm
24mm
Running light
DMX512 DECODER
M+
-
DIN-DMX-5A
001
DMX512 DECODER
M+
-
DIN-DMX-5A
MKEY
DMX512 DECODER
M+
-
DIN-DMX-5A
C-L
DMX512 DECODER
M+
-
DIN-DMX-5A
C-E C-L
DMX512 DECODER
DIN-DMX-5A
DMX IN
POWER
DMX OUT
OUTPUT
D+
D+
D+
CH2
D-
D-
D-
CH3
GND
CH1
GND
V+
DIN-DMX-5A DMX Decoder Manual DIN-DMX-5A DMX Decoder Manual
LTECH LTECH
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM [e-mail]
Tel: [phone] Fax: [phone]
warranty
5 years
1. Product Parameter:
Input Signal: DMX512
Input Voltage: DC5V DC24V
Max Load Current: 5A ×3CH Max 15A
Max Output Power: 75W/180W/360W/(5V/12V/24V)
Gray Scale Level: 0~256 Levels/CH
Frame Rate: Max 850 FPS
～DIN Rail: TS-35/7.5 or TS-35/15
Mounting: DIN Rail or Screw
Working Temperature: -30 55
Dimensions: L112×W35×H67(mm)
Package Size: L114×W37×H70(mm)
Weight (G.W): 120g
℃℃～
2. Product Size:
3. Function Key:
Can be installed on DIN rail
TS-35/7.5 or TS-35/15
DIN-DMX-5A DIN rail type decoder is designed to convert universal DMX512 signal into PWM signal, it
can work with DMX512 console, with 256 levels gray scale output per channel, realize 0-100% brightness
and various changing effects, can control single color, two color, RGB LED light.
. Simple, intuitive read and write DMX address, meanwhile have the self-testing
pattern function.
Display DMX address
in 3 digits digital tube
DIN rail, screw dual-use
The running lights flash quickly when input
DMX signal. Flash frequency depends on
received frame rate. The running light
flashes as usual without DMX input.
Short press: enter DMX decoder mode.
Long press: enter self-testing scene mode.
A. DMX Decoder Mode.
Address Setting:
In DMX Decoder Mode, first press "+" or "-" key to enter address setting. Changing
the DMX initial address when the 3 address value start to flicker. (Range:001-512)
Short press , add one more address, long press , address increase quickly.
Short press , subtract one more address, long press , address decrease quickly.
Short press to quit.
Long press and key
at the same time, set the
brightness output to linearity
curve (C-L).
Long press and key
at the same time, set the
brightness output to Gamma
curve (C-E)
Long press and key
at the same time, check the
present luminosity curve.

3 4 Update Time 2014.01.01：
NO.
MODE Description
Static RED
Static Green
Static Blue
Static Yellow
Static Purple
Static Cyan
Static White
7 Color Skipping
7 Color Smooth
P-1
P-2
P-3
P-4
P-5
P-6
P-7
P-8
P-9
EDR +GREEN=YELLOW
EDR +BLUE=PURPLE
GREEN+BLUE=CYAN
RED+GREEN+BLUE=WHITE
1
2
3
4
5
6
7
8
9
DMX512 DECODER
M+
-
DIN-DMX-5A
DMX IN
POWER
DMX OUT
OUTPUT
D+
D+
D+
CH2
D-
D-
D-
CH3
GND
CH1
GND
V+
DMX512 DECODER
M+
-
DIN-DMX-5A
DMX IN
POWER
DMX OUT
OUTPUT
D+
D+
D+
CH2
D-
D-
D-
CH3
GND
CH1
GND
V+
DMX512 DECODER
M+
-
DIN-DMX-5A
DMX IN
POWER
DMX OUT
OUTPUT
D+
D+
D+
CH2
D-
D-
D-
CH3
GND
CH1
GND
V+
DMX Input DMX Input
DMX Output DMX Output DMX Output
RRR
GGG
BBB
R
1R
1R
1
R
2R
2R
2
R
3R
3R
3
DMX Input
DMX512 DECODER
M+
-
DIN-DMX-5A
P-1
reS
+
-
Switch changing modes
by pressing key.
+
-
M
500W
POWER
NL
110 V
220V
NL
DC12V
LED LED LED
DMX Console Channel
CH1 0-255
CH2 0-255
CH3 0-255
DMX Decoder Output Channel
Each DIN-DMX-5A decoder occupied 3 DMX addresses when connecting the DMX console.
For instance, defaulting the initial address for the DMX decoder is 1, please find their
corresponding relationships in the following form.
CH1 LED R)PWM 0-100% (
CH2 PWM LED G)0-100% (
CH3 PWM LED B)0-100% (
5. DMX Dimming Instruction:
6. Attention:
7. Warranty Agreement:
1) The product shall be installed and serviced by a qualified person.
2) This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please
ensure it is mounted in a water proof enclosure.
3) Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.
6) Ensure all wire connections and polarities are correct before applying power to avoid any damages to the
LED lights.
7) If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
1) We provide lifelong technical assistance with this product:
A 5-year warranty is given from the date of purchase. The warranty is for free repair or replacement
and covers manufacturing faults only.
For faults beyond the 5-year warranty we reserve the right to charge for time and parts.
2) Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and
overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
3). Repair or replacement as provided under this warranty is the exclusive remedy to the customer. LTECH
shall not be liable for any incidental or consequential damages for breach of any stipulation in this warranty.
4) Any amendment or adjustment to this warranty must be approved in writing by LTECH only.
★This manual only applies to this model. Ltech reserves the right to make changes without prior notice.
4. Conjunction Diagram:
DIN-DMX-5A DMX Decoder Manual DIN-DMX-5A DMX Decoder Manual
LTECH LTECH
ZHUHAI LTECH ELECTRONIC TECHNOLOGY CO., LTD. WWW.LTECHONLINE.COM [e-mail]
Tel: [phone] Fax: [phone]
Digital Tube Display
(press +/- to switch)
Fixed Speed, 1 color per second,
Fixed Speed, transient time 2 second,
residence time 1 second
B. Self-testing Scene Mode.
C. Restore the Default Parameter: Long press keys at the same time,
Restore the default parameter, digital tube display "RES".
Default parameters: DMX decoder mode, DMX base address is 1, Gamma curve,
self-test in No.1 pattern status.
Long press “M” key to enter self-testing scene mode.
