Ltech Artnet-DMX-1 User manual

Artnet-DMX converter is the Ethernet Control System based on the Artnet protocol, used to convert
the Artnet network data package into DMX512 data, adopting high-speed ARM processor, stable and
reliable working. Following Artnet standard protocol, it supports RJ45 network interface and standard
DMX512 output interface.
Artnet-DMX-1
Artnet-DMX Converter
1
Artnet-DMX-1 Artnet-DMX Converter
DMX512/Artnet
12Vdc (with a power adaptor)
L120×W73×H45mm
290g
-30 ~65℃ ℃
Working temperature:
Artnet/DMX512
512 channels
warranty
5 years
Artnet-DMX-1
Output signal:
Power input:
Dimension:
Package Size:
Weight (G.W):
Input signal:
DMX channels:
1. Technical Specs
It is compatible with all the effects lighting control software which support Artnet protocol, widely used
in the LED dot matrix and the stage lighting control network in needing lots of DMX-512 data,
especially for TV station recorded scene, stage performances, entertainment and so on.
Artnet-DMX-1 can be configured in one of two ways: Artnet convert into DMX512, or DMX512 convert
into Artnet.
RJ45
Network Connection:
IP: Indoor use only
Isolation Ethernet Port: Transformer isolation
Current: 30mA@12Vdc
DMX Output Connection: XLR-3
3. Product Dimension:
Artnet input
Power Input
Universe Dip Switch
Mode Switcher
(Operation as follows)
Subnet Dip Switch
Status lamp
4. Interface Instruction:
12
OFF
ON
OFF
OFF
ON OFF
Diagrams
Switching modes operation instruction:
Functions
2
2. Performance Features
Artnet to DMX512 mode
DMX512 to Artnet mode
Testing function, generates full color gradient floating DMX data.170 pixels
Artnet-DMX-1 Artnet-DMX Converter
2.1 Based on Artnet protocol network data communication, accept network DMX data;
2.2 IP address is bound to Subnet, no need to reset, plug and play.
2.3 Manage Artnet on broadcast mode or unicast mode.
2.4 1 group input, 1 group output.
2.5 Set different network segments to avoid multiple sets Artnet data interference.
2.6 Compatible with the light software based on Artnet Protocol, control stage lighting and LED
lighting simultaneously.
2.7 Connect up to 256 DMX Universes to one network.
2.8 10BaseT Ethernet Port.
2.9 Data activity indicators
2.10 Configurable DMX output refresh rates.
www.ltechonline.com
L198×W78×H50mm

5. Conjunction Diagram:
Address setting instruction:
Universe/SubNet Dip Switch
1 2 345678 9 A B C D E F
0
Value 1 2 345678 9 10 11 12 13 14 150
Calculating method: Group address= Subnet×16 + Universe, IP Address=2.0.36.Group Address,
MAC Address=00-1B-14-20-24-Group Address
For example: Subnet: 2, Universe: B, Group Address=2×16 + 11 = 43, so the DMX output group
address is 43; Corresponding IP address is 2.0.36.43, MAC address is 00-1B-14-20-24-43.
3
DMX Input
DMX Output
Status lamp
Status lamp
Artnet to DMX mode
DMX to Artnet mode
Artnet-DMX-1 Artnet-DMX Converter
4
Artnet-DMX-1 Artnet-DMX Converter
7. Warranty Agreement:
7.1 We provide lifelong technical assistance with this product:
★This manual only applies to this model. We reserve the right to make changes without prior notice.
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company
only.
7.3 Repair or replacement as provided under this warranty is the exclusive remedy to the
customer. We shall not be liable for any incidental or consequential damages for breach
of any stipulation in this warranty.
7.2 Warranty exclusions below:
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
A 5-year warranty is given from the date of purchase. The warranty is for free repair or
replacement if cover manufacturing faults only.
Any man-made damages caused from improper operation, or connecting to excess voltage
and overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
6. Attention:
6.1 The product shall be installed and serviced by the qualified person.
6.7 If a fault occurs please return the product to your supplier. Do not attempt to fix this product
by yourself.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any
damages to the LED lights.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry
the current. Please also ensure that the cable is secured tightly in the connector.
6.4 Please check if the output voltage of the LED power supply used comply with the working
voltage of the product.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good
ventilation.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors, please
ensure it is mounted in a water proof enclosure.
Update Time: 2016.05.13
