Ltech LT-8048 User manual

2
4.3 DMX Dimming Instruction:
CH1 0-255
CH2 0-255
CH3 0-255
Each LT-8048 DMX decoder occupied 3 DMX
addresses when connecting the DMX console. PWM 0-100% (LED R)
PWM LED G)0-100% (
PWM LED B)0-100% (
CH1
CH2
CH3
DMX Console DMX Decoder
Dip Switch Operation:
4.
RDM Mode: The dip switch 1-10 are OFF.
FUN=ON (the 10th dip switch=ON)
Self-testing Mode:
FUN=OFF (the 10th dip switch=OFF)
DMX Mode:
Setting DMX addresses with dip switch 1-9
FUN=OFF (the 10th dip switch ) Mode=OFF DMX
4.1 How to set DMX address via dip switch:
E.g.1: Set Initial Address To 32. E.g.2: Set Initial Address To 37. E.g.3: Set Initial Address To 178.
001+004+032=37 002+016+032+128=178
4.2 Self-testing Mode:
DMX address value=the total value of (1-9), to get the place value when in “ON” position,
otherwise will be 0.
e.g., the defaulted initial address is 1, please find
their corresponding relationships in the form.
FUN=ON (the 10th dip switch = ON) Self-testing Mode
1=on 4=on 7=on 8=on 9=on2=on 5=on 3=on 6=on
Self-test
Function
1-9=off
Dip Switch
Static
Black Static Red
Static
Red
Static
Green
Static
Green
Static
Blue
Static
Blue
Static
Yellow
Static
Yellow
Static
Purple
Static
Purple
Static
Cyan
Static
Cyan
Static
White
Static
White
7 Colors
Jumping
7 Colors
Jumping
7 Colors
Smooth
7 Colors
Smooth
[Attn] When several dip switches are on, subjected to the highest switch value.
As the figure above shows, the effect will be 7 colors smooth at 7 speed level.
For changing effects (Dip Switch 8 9=on): /
DIP switch 1-7 is used to realize 7 speed
levels. (7=on, the fastest level)
OFF
ON
LT-8048
DMX/RDM 3CH CV DECODER
LT-8048 DMX/RDM 3CH CV Decoder LT-8048 DMX/RDM 3CH CV Decoder
Dimming Range:
Working Temperature:
Package Size:
Weight (G.W.):
0~100%
-30℃~65℃
L135×W70×H50(mm)
305g
1. Product Parameter:
Input Signal:
Input Voltage:
Current Load:
Output Power:
DMX512 Socket:
DMX512, RDM
12~48Vdc
4A×3CH 12A
144W/432W/576W(12V/36V/48V)
XLR-3, Green Terminal
Max.
Max.
LT-8048
2. Product Size:
3. Configuration Diagram:
1
Power Input
Socket
Green
Terminal
(with amplifier
function)
XLR-3
Address
Dip Switch
LED Lamps
Connection
Socket
www.ltech-led.com
LT-8048 w
communication, achieves remote management of reading and writing DMX address (DMX master controller
must recognize the RDM protocol). Equipped with DMX standard XLR-3, green terminal interface. Realize
0-100% dimming or different lighting effect; workable with single color, bi-color or RGB LED lamps.
ith the standard RDM remote device management protocol, supports DMX512 signal bi-directional

4
6. Attention:
7. Warranty Agreement:
6.1 The product shall be installed and serviced by the qualified person.
6.2 This product is non-waterproof. Please avoid the sun and rain. When installed outdoors please ensure
it is mounted in a water proof enclosure.
6.3 Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
6.4 Please check if the output voltage of the LED power supply used comply with the working voltage of
the product.
6.5 Please ensure that adequate sized cable is used from the controller to the LED lights to carry the current.
Please also ensure that the cable is secured tightly in the connector.
6.6 Ensure all wire connections and polarities are correct before applying power to avoid any damages to
the LED lights.
6.7 If a fault occurs, please return the product to your supplier. Do not attempt to fix this product by yourself.
7.1 We provide lifelong technical assistance with this product:
A 5-year warranty is given from the date of purchase. The warranty is for free repair or replacement
if cover manufacturing faults only.
For faults beyond the 5-year warranty, we reserve the right to charge for time and parts.
7.2 Warranty exclusions below:
Any man-made damages caused from improper operation, or connecting to excess voltage and
overloading.
The product appears to have excessive physical damage.
Damage due to natural disasters and force majeure.
Warranty label, fragile label and unique barcode label have been damaged.
The product has been replaced by a brand new product.
7.3
7.4 Any amendment or adjustment to this warranty must be approved in writing by our company only.
★ This manual only applies to this model. reserve the right to make changes without We prior notice.
Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
We shall not be liable for any incidental or consequential damages for breach of any stipulation
in this warranty.
5.2 The connection diagram of two DMX terminals:
Update Time: 2016.09.23
3
5. Wiring Diagram:
LT-8048 is equipped with 2 types DMX terminals for users’ selection. The
diagram takes XLR-3 terminal as a example, same connecting method for the
green terminal (with amplifier function) .
5.1 Decoder can be connected to a variety of standard DMX512 devices:
*
An amplifier is needed when more than 32 decoders are connected, signal amplification should not be more than
5 times continuously.
*
terminal resistor at the end of each line.
If the recoil effect occurs because of longer signal line or bad line quality, please try to connect 0.25W 90-120Ω
www.ltech-led.com
5.3 The connection diagram of :AMP signal amplifier terminal
XLR-3 Connected in Parallel Green Terminal Connected in Parallel
*
when too many DMX decoders are connected or signal line is too long, signal
amplification should be no more than 5 times continuously.
AMP interface can be used for signal amplification
These 2 terminals can be connected in a mixed way.
LT-8048 DMX/RDM 3CH CV Decoder LT-8048 DMX/RDM 3CH CV Decoder
