Ltech EX1S User manual

Technical Specs
Dimming Touch Panel
Input Voltage:
Output Signal:
Working Temp.:
Dimensions:
Package Size:
Weight(G.W.):
100~240Vac
RF 2.4GHz, DMX512
-30℃~55℃
L86×W86×H36(mm)
L113×W112×H50(mm)
225g
EX1S
F4-CC
Input Voltage:
Output Voltage:
Output Current:
Output Power:
Wireless Signal:
Working Temp.:
Dimensions:
Package Size:
Weight(G.W.):
12~48Vdc
3~46Vdc
CC 350/700/1050mA×4CH
1.05W~48.3W×4CH Max 193.2W
2.4GHz
-30℃~55℃
L175×W44×H30(mm)
L178×W48×H33(mm)
165g
F4-5A
F4-3A
CV Receiver
CV Receiver
Input Voltage:
Input Voltage:
Current Load:
Current Load:
Max Output Power:
Max Output Power:
Wireless Signal:
Wireless Signal:
Working Temp.:
Working Temp.:
Dimensions:
Dimensions:
Package Size:
Package Size:
Weight(G.W.):
Weight(G.W.):
5~24Vdc
5~24Vdc
5A × 4CH Max. 20A
3A × 4CH Max. 12A
100W/240W/480W(5V/12V/24V)
60W/144W/288W(5V/12V/24V)
2.4GHz
2.4GHz
-30℃~55℃
-30℃~55℃
L175×W44×H30(mm)
L125×W33×H20(mm)
L178×W48×H33(mm)
L127×W35×H24(mm)
150g
60g
Note: Receiver is sold separately.
Product Size:
Terminals:
100-240V
Power Input
ac DMX Signal
Output
Key Functions:
When the touch panel is off, Long press to turn on/off the buzzer
When the touch panel is on ,Long press to match code.
Installation Instruction:
CC Receiver
Brightness
Touch Slider
ON/OFF
Brightness+
Brightness-
Brightness Shortcut Keys
Scene-mode
Short press: play
Long press: save
(Dimming)
Ma ualn
Back box
Baseplate
Touch panel
Typical back box as below:
Uninstall
www. ltech-led. com
EX1 S F1 Re cei ver
F4-3 A F4 -5A/F4-CC
EX1S
European style 86 size

Update Time: 2016.06.27
Long press on the touch
panel, the indicator light of
all keys flicker.
Long press on the remote,
the indicator light stop
flicking, match successfully.
Long press the two keys on
the touch panel simultaneously
(about 3 second), if the indicator
light flicker 3 times, deactivate.
Long press the two keys on the touch panel B
simultaneously (about 3 seconds) until the indicator light
flicker several times, deactivate the matching successfully.
Multi-control Wiring:Match/Clear Code between Touch Panel & Receiver
Match/Clear Code between Touch Panel & Remote:
Match code:Clear code:
RF Wireless Wiring:
DMX Wiring:
ID learning button
ID learning button
Receiver
Receiver
Receiver
Receiver
Assuming that B match up
with A.
1.
1.
1.
1.
2.
2.
2.
2.
3.
3.
3.
Match code:Match code:
Clear code:
Clear code:
Method 1：When the touch panel is on and the wiring between the receiver and the lamps are correct.
Power on the receiver, and
complete step 2 within 10s.
Long press on the touch
panel, the lamps flicker.
Long press on the touch
panel, the lamps flicker.
Touch the slider in 5s, the
lamps stop flicking, match
successfully.
Touch the slider in 5s, the
lamps stop flicking, match
successfully.
Method 2：When the touch panel is on and the wiring between the receiver and the lamps are correct.
Short press “ID learning
button” on the receiver.
Method 1: Power on and off the receiver continuously 5 times,
buzzer long beep and lamps flicker twice, deactivate
the matching successfully.
for
If the
Method 2: Long press “ID learning button” on receiver for 5 seconds,
lamps flicker twice, If the deactivate the matching
successfully.
Long press on B, the
indicator lights of all keys
keep on after release.
Touch the slider on A in 5s,
when the indicator lights of
B turn off, match successfully.
Match/Clear Code between Touch Panels:
www. ltech-led. com
Connecting touch panel with DMX decoders can also realize
multi-control function.
*
*
After touch panel A realizes controlling the lamps, if B and
C are matched up with A , they can also control the lamps.
