Lucent Compact Switch
The Lucent Technologies Compact Switch offers an ideal solution for
service providers who need a simple solution for single switch applications.
Delivering a host of legacy and next generation features and capabilities in
a single chassis, the Compact Switch offers quick and easy installation and
outstanding reliability. Multiple applications can be simultaneously supported
on the same platform, furnishing providers with a broad range of business
and residential service offerings as well as compelling economics. Deployed
in numerous domestic and international networks, the Compact Switch
provides the ideal solution for carriers who wish to offer next-generation
packet-based services in addition to traditional residential or business
services. The Compact Switch is equally at home in greenfield or cap-and-
grow environments.
Benefits
• Full softswitch performance in a
single platform
• Built-in CLASS/Custom calling
features are available to both TDM
and IP subscribers; the Lucent
Feature Server is available for
delivering advanced services
• Supports a rich mix of legacy and
VoIP applications concurrently
• Industry-leading density reduces
power and space requirements
• Highly scalable platform delivers
very low cost per subscriber
Applications
• Carrier-grade switch for suburban, rural and remote service areas
• Ideal solution for cap-and-grow environment
• Local, tandem, ISDN, Centrex and long distance calling
• GR-303 host for remote access nodes including wireless local
loop equipment
Features
• Scales up to 100,000 subscribers
• Supports LNP, 800 calling, operator services, and CALEA on-switch
• Supports IP Endpoints and interoffice IP connections
• Supports a comprehensive set of Class 5 end office and Tandem
features and a suite of revenue generating CLASS, Custom and
next-generation services
• Low power consumption and ultra compact footprint mountable
on 23” open rack
• Supports standardized protocols and open interfaces
• Supports basic and enhanced 911 services
• RUS accepted

To learn more about our
comprehensive portfolio, please
contact your Lucent Technologies
Sales Representative or:
Call 1 888 4 LucentSM
Visit our web site at
www.lucent.com.
This document is for planning purposes
only, and is not intended to modify or
supplement any Lucent Technologies
specifications or warranties relating to
these products or services. The
publication of this information in this
document does not imply freedom from
patent or other protective rights of
Lucent Technologies or others.
Specifications are subject to change
without notice.
Copyright © 2005
Lucent Technologies, Inc.
All rights reserved.
Compact Switch v2 08/05
Technical Specifications
1.Protocol Support
IP Protocols: BICC, MEGACO, MGCP, SIP/SIP-T, SigTran, TCP, UDP, RTP, RTCP
SS7 Protocols: ANSI and ITU/ETSI, Q.767, ISUP, TCAP variants, IS-41, GSM
ISDN Protocols: Q.931 PRI, GR-1268 PRI, ETSI PRI
CAS Protocols: FG-D, CAMA MF, line or trunk supervision, DTMF
GR-303 interface
GR-1298/1299 AIN 0.2 compliance
AIN 0.1 for LNP and 800 services
2.Redundancy
1:1 system processor and switch fabric redundancy
1:N I/O module redundancy
3.Call Handling
450,000 BHCA
80,640 TDM DS0 ports, protected
21,504 VoIP DS0 ports, protected
G.711, G.726, G.729a/b, G.723.1, T.38 fax relay, echo cancellation (128 msec tail)
4.On-Switch Database
A high capacity (more than 100,000 subscribers) flexible database to store
subscribers, features, and routing information for both tandem and Class 5
applications
5.Operations
PlexView®Element Management System supports provisioning, performance
monitoring, and fault management
Billing: GR-1343 AMA interface, GR-1100 BAF or ASCII CDRs
Order Entry: manual or automated service order execution
Traffic Analysis and Reporting with customized report building
4000 seconds of announcements on-switch
Call Progress Tones on switch
3-way conferencing on-switch
CALEA support on-switch
6.Input/Output Support
28-port DS1, channelized: SF, ESF, B8ZS, AMI
28-port E1 channelized: CRC4, HDB3
3-port DS3/STS-1, channelized: VT1.5 or M13/C-Bit mapped, B3ZS
8-port DS3/STS-1, channelized: VT1.5 or M13/C-Bit mapped B3ZS
Triple OC-3, channelized: VC-1.5 or M13
Triple STM-1 channelized: VC-12
Quad 1000 Mbps Ethernet module with either: quad 1000 base-T, quad 1000 base-
LX, single mode or SX multi-mode interface using standard GBIC modules
7.Physical
24.5” H x 21.5” W x 18” D including cabling
180 lbs, fully loaded
-40 to –56.7 Vdc, 1450 watts fully loaded
NEBS CO and ETSI compliant operating environment
Redundant BITS timing support with internal Stratum 3 sources
CE and UL certified
