Lumascape LS365 Installation instructions manual

10o
90o
60o
30o
BRACKET TOP VIEW
75MM (2.95IN)
2 X 8MM
12MM
DOME NUT
SPRING
WASHER
FLAT
WASHER
BRACKET
A
START
HERE
IMPORTANT INSTRUCTIONS
Lumascape Lighting Industries 2006©
T 1-(650)-595-LUMA(5862) 1-(650)-595-5820
LUMASCAPE USA INC
Free Call 1-866-695-LUMA(5862)
C1714US - 2007_03_REV-001
t90 Ct90 C A.C.N. 010 572 773
90o
For Installation LS365: UNDERWATER
1 32
5C MR16 LAMPS 9MR16 LAMPS5D MR16 LAMPS
4 5B PAR LAMPS5A PL LAMPS
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS.
instructions pertaining to a risk of fire, or injury to persons
WARNING - To reduce the risk of FIRE or INJURY:
1. Turn Off and allow to cool before replacing lamp.
2. Lamp gets hot quickly! Contact only switch/plug when turning on.
3. Do not touch hot lens, guard, or enclosure.
4. Keep lamp away from materials that may burn.
5. Do not touch the lamp at any time. Use a soft cloth. Oil from skin
may damage lamp.
DO NOT SHORTEN, INTERFERE OR DISCONNECT CABLE FROM FITTING. WARRANTY WILL BE VOID IF CABLE ASSEMBLY IS TAMPERED WITH.
If cable damaged replace with cable supplied by LUMASCAPE only.
WARNING
CAUTION - HOT BULBS. Keep Away From Curtains And Other Combustible Material.
140MM
(5.51IN)
80MM
(3.15IN)
160MM
(6.3IN)
Locate Fixtures
Site fixture in proximity to cabling. Use
discretion in locating fixtures as glass
can become very hot and may burn.
Mount Bracket to Fixture
Mount bracket supplied to fixture using the M10
dome nuts and washers as shown above.
Mount Fixture
Mount fixture to secure surface. Orientate
fixture as required and tighten nuts on bracket.
Connect Supply
Connect fixture to supply cable according to
local wiring rules.
Insert Lamp
Insert PL lamp into lampholder mounted on gear
tray in bottom of fixture. Insert reflector, locating
bottom into aluminium cup around lampholder.
Insert Lamp
Screw PAR38, or PAR30 lamp into
lampholder mounted on gear tray in bottom of
fixture. Ensure the lamp bottoms out in
lampholder.
Insert Lamp
Remove Hood and louvre from gimbal and
insert MR16 lamp into lampholder. Replace
hood and louvre.
SLIDE GIMBAL
VERTICALLY
GIMBAL
GIMBAL
LOCKING
SCREW
ALLEN KEY
SUPPLIED
ROTATE GIMBAL
Adjust vertical and rotational position of
gimbal
Rotate gimbal to aim light at target. Slide gimbal
vertically to minimise glare. Once positioned
tighten locking screw using Allen Key provided.
GIMBAL
ANGLE
ADJUST
SCREW
ALLEN KEY SUPPLIED
20o20o
40o
Adjust angular position of light
Aim the light at target by rotating the angle adjust
screw, with the Allen Key provided. The lamp has
a maximum adjust of 20 either side of vertical.
o
SEE OTHER SIDE FOR RE-LAMPING
www.lumascape.com
Further
information
over page
LAMP
REFLECTOR
LAMP
GIMBAL
LAMP
HOOD/
LOUVRE
MODELS
IP68 rated
FOR UNDERWATER USE
LS365
INC.
Lumascape USA Inc.
1300 Industrial Rd., Unit #19
San Carlos, CA 94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
DISCONTINUED PRODUCT

GEAR TRAY
GEAR TRAY CLIPS
GIMBAL
GIMBAL
GIMBAL
LOCKING
SCREW
ALLEN KEY
SUPPLIED
GIMBAL
BIMPORTANT INSTRUCTIONS
Lumascape Lighting Industries 2006©
t90 Ct90 C A.C.N. 010 572 773
90o
MODELS
IP68 rated
FOR UNDERWATER USE
LS365
5 RE-LAMPING6
3 54
1 2B MR162A
Test Fixture
Test to ensure fixture is operational. Allow to
burn uncovered for 30 minutes to allow any
moisture in fixture to evaporate.
Open / Re-lamp / Reseal
Ensure fixture is isolated from mains power.
Unscrew lid using Allen Key provided, or a 3mm
Allen Key. Remove any louvres or reflectors.
Replace lamp and Reseal Fixture.
LAMP SOURCE CONVERSION INSTRUCTION
Isolate and Open Fixture
Ensure fixture is electrically isolated. Unscrew lid
using a 3mm Allen key (provided) and remove.
Isolate and
Open Fixture
REFLECTOR
LAMP
HOOD/
LOUVRE
LAMP
Remove Lamp
Remove any reflectors or louvres.
Unscrew/Pull lamp from lampholder
and remove.
Remove Gimbal
Loosen gimbal locking screw with 3mm Allen
key, (provided). Remove gimbal and place
beside fixture.
GEAR TRAY
Remove Gear Tray
Unclip and remove gear tray, gripping via either
the two finger recesses or the lampholder.
Install New Gear
Install new gear tray by clipping into fixture,
aligning large clip on can with large recess on
gear tray as shown. Push down gently untill
clips spring over tray.
LID
Test and Reseal Fixture
Test and reseal fixture according to installations
4 to 6 on this sheet.
LID
LID
60
1545
30 MIN.
www.lumascape.com.au
For Installation LS365: UNDERWATER
1
2
6
5
3
4
Torque Pattern
Seal Fixture
Ensure seal and sealing surface is clean.
Clean glass if necessary. Tighten lid screws
using the 3mm Allen key supplied. Lumascape
recommends tightening in the above Torque
Pattern to 2.5 to 3 N.m.
DO NOT OVER TIGHTEN.
T 1-(650)-595-LUMA(5862) 1-(650)-595-5820
LUMASCAPE USA INC
Free Call 1-866-695-LUMA(5862)
C1714US - 2007_03_REV-001
INC.
Lumascape USA Inc.
1300 Industrial Rd., Unit #19
San Carlos, CA 94070, USA
T 1-(650)-595-LUMA(5862)
F 1-(650)-595-5820
E [email protected]
W www.lumascape.com
Warning: The Luminaire should only be used complete with its protective shield (cover)
DISCONTINUED PRODUCT
