Lumascape LS365LED User manual


LUMASCAPE
1300 Industrial Rd, Unit #19
San Carlos, CA 94070, USA
T [phone]
W www.lumascape.com
Free Call : [phone]
FORM IN0158US
 IN0158US - 24/04/15
 Underwater
 LS365LED


(IP68)
WARNING
Opening luminaire will void warranty
Never use electronic transformers
with LED luminaires
It is strongly recommended to a use
Lumascape transformer
Install in accordance with National
Electric Code, ANSI/NFPA 70 or the Canadian
Electrical Code, Part I (CEC), CSA C22.1
CAUTION OVERVIEW
• Luminaire is factory sealed. Do not remove cover.
• The luminaire should only be used complete with its
protective shield (cover).
• Do not shorten, interfere or disconnect cable from luminaire.
Warranty will be void if cable assembly is tempered with.
• If cable is damaged replace with cable supplied by
Lumascape only.
• Do not use power tools to tighten screws.
• Do not overtighten screws.
Ø 7.9 in (200 mm)
Ø 7.9” (200 mm)
0.1 in (3 mm)
0.1” (3 mm)
0.6 in (16 mm)
0.6” (15 mm)
LS6074 Mounting Plate
(optional accessory)
Luminaire is factory sealed.
DO NOT REMOVE COVER.
Aim luminaire as desired and
tighten dome nuts to lock
luminaire tilt into position.
Run the cable out and connect to
a suitable source of power.
Secure luminaire to mounting surface using
a suitable non-corrosive fastener. One 5/16
in (8 mm) stainless steel masonry anchor is
recommended for concrete mounting.
Luminaire may also be mounted using the
optional LS6074 Mounting Plate depicted below
Power supply must be
isolated prior to connection or
disconnection of cables. Failure
to do so will result in damage to
the luminaire components.
140MM
(5.51IN)
80MM
(3.15IN)
160MM
(6.3IN)

Copyright ©2015 LUMASCAPE

Should you experience any difficulty, please contact Lumascape directly: phone [phone] or email [email protected]
IF IN DOUBT, PLEASE CALL
IN0158US - 24/04/15

Mains Voltage
Single Color
0-10 V Dimmable
Wire Colour Designation
Black Active
White Neutral
Green Earth
Orange 0-10 V Output
Blue 0-10 V Input
Red N/A
Low Voltage
RGB
Wire Colour Designation
White AC 1
Black AC 2
Orange Com+
Red Red
-
Green Green -
Blue Blue -
