Lumberjack HG2000 Installation manual

+
SAFETY AND OPERATING MANUAL
2000W Multi-flow Heat Gun
HG2000
ORIGINAL INSTRUCTIONS
HG2000

TABLE OF CONTENTS
Welcome to Lumberjack!
Dear customer, Congratulations on your purchase. Before using the
Product for the first time please be sure to read these instructions for use.
They provide you with all information necessary for using the product safely and to
ensure its long service life.
Closely observe all safety information in these instructions!
General Power Tool Safety Warnings………………………………….…......01
Symbols & Cable Rating Chart ……….……………………………………………06
Machine Details and Product features……….…………………………….….07
Operation…………………………………………………………………………………….08
Maintenance and Cleaning………………………………………………………….09
Lumberjack Guarantee…………………………………………………………………10
HG2000

HG2000 01
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings and
all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for
future reference. The term "power tool" in
the warnings refers to your electric (corded)
power tool or battery-operated (cordless) power
tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use
any adapter plugs with grounded power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with grounded surfaces,
such as pipes, radiators, ranges and
refrigerators.There is an increased risk of
electric shock if your body is grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A
moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off position before connecting to
power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.

HG2000 02
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such
preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused
by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the work
to be performed. Use of the power tool for
operations different from those intended could
result in a hazardous situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts. This will ensure that the safety of the power
tool is maintained.
b) If the replacement of the supply cord is
necessary, this has to be done by the
manufacturer or its agent in order to avoid a
safety hazard.
6. Battery Tool Use and Care
a) Recharge only with the charger specified by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury or fire.
GENERAL POWER TOOL SAFETY WARNINGS

HG2000 03
GENERAL POWER TOOL SAFETY WARNINGS
c) When Battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal object
that can make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
D) User abusive conditions, liquid may be
ejected from the battery; Avoid contact. If
contact accidentally occurs, flush with copious
amounts of water. If liquid contacts eyes, seek
medical help immediately. Liquid ejected from
the batter may cause irritation or burns.
7. Additional Safety and working
Instructions
7.1. Dust from materials such as lead-containing
coatings, some wood types, minerals and
metals can be harmful to one’s health and
cause allergic reactions, leading to respiratory
infections and/or cancer. Materials containing
asbestos may only be worked by specialists.
Observe the relevant regulations in your country
for the materials to be worked.
7.2. Prevent dust accumulation at the
workplace. Dust can easily ignite.
8. Additional Warnings for Heat guns.
8.1. Workplace Safety
8.1.a. Always work in a well ventilated area.
Gases, vapours and fumes generated during
operation are frequently dangerous to human
health.
8.1.b. If Handled Carelessly, the tool can cause
fire, therefore:
-Be alert, aware and careful when using the too
in places where combustible materials are
stored;
-Do not keep the hot air stream aimed at the
same place for a long period;
-Do not use the tool in explosive environments;
-Be aware that heat can be transferred to
combustible materials located beyond yout field
of vision;
-Always place the tool on its base after use and
allow to cool down before storing;
-Never leave your tool unattended while it is
turned on.
8.1.c. Do not point the nozzle with hot air at
other persons, animals and towards the places
where flammable materials are stored.
8.2. Electrical safety
8.2.a. Do not use the device when it rains or
under high humidity conditions. It may result in
injuries or death caused by electric shock.
8.2.b. When operating the hot air gun outdoors
always use a residual current device (RCD). The
use of RCD reduces the risk of electric shock.
8.2.c. Before each use check the tool, its power
cord and plug for any damage. If any damage is
found, stop working and have the tool
repaired. Using a defected device can be
dangerous to health and life. Never open its
housing as the tool does not contain any user
serviceable parts.
8.2.d. Do not put any objects into the nozzle. It
may result in damage to the tool and electric
shock.

HG2000 04
GENERAL POWER TOOL SAFETY WARNINGS
8.2.e. The power cord should be placed
behind the tool at all times during operation.
8.2.f. Do not point the hot air stream at the
power cord and do not touch the power cord
with the nozzle when hot. It may result in
damage to its insulation and electric shock.
8.2.g. Do not carry or hang the tool on its
power cord.
8.2.h. Do not use a power tool with it power
cord damaged. Do not touch the power cord
when damaged; if the damage to power cord
occurs during operation; unplug the cord
from the mains socket. Damaged power cords
increase the risk of electric shock.
8.3. Personal safety
8.3.a. When processing plastics, paints,
varnishes and other materials, flammable and
toxic gases are generated. Do not use the tool
near flammable materials and explosive
gases.
8.3.b. To provide protection against vapours
and fumes wear a special mask protecting
against dusts and vapours emitted by lead-
containing paints and bear in mind the safety
of other persons staying at your workplace.
8.3.c. Danger of burns! Never touch the
nozzle when hot. Always wear protective
gloves.
8.3.d. Do not look into the nozzle when the
tool is on.
8.3.e. Always wear safety goggles when
operating the tool.
8.3.f. Do not use the tool as a hair dryer! The
hot air emitted by the hot air gun exceeds the
temperature of ait provided by a hair dryer.
8.4. Working instructions and use tips
8.4.a. Protect the hot air gun against impacts
and surface damage caused by sharp objects.
8.4.b. Before you use the tool always check air
inlet and outlet for any obstacles restricting a
free air flow.
8.4.c. Do not burn the paint as it may result in
fire. Keep the paint away from the nozzle, as it
can ignite after some period
8.4.d. Do not obstruct either air inlet or nozzle
outlet as it can result in excessive temperature
and damage to the tool. Do not keep the hot air
outlet closer than 5cm from the surface
processed.
8.4.e. Do not put the nozzle on any object
during and directly after operation. Do not
place the on its side. Whenever you wish to put
the hot air gun aside, set in a vertical position.
8.4.f. When you stop using the tool, during
breaks or carrying out any maintenance
operations (e.g. inspections, cleaning,
adjustments) always unplug the power cord
from the mains socket
8.4.g. Never allow children to use the tool.

HG2000 05
GENERAL POWER TOOL SAFETY WARNINGS
9. Using an Extension Cable.
9.1. If an extension cable is required, use an
approved triple core extension cable suitable
for the power input of the tool.
9.2. Grounded tools always require a three wire
extension cable.
9.3. As the distance from the supply outlet
increases you must use a heavier gauge
extension cable. Using extension cables with
inadequately sized wire causes a serious drop in
voltage, resulting in loss of power and possible
tool damage.
9.4. The smaller the gauge number of the wire
the greater the capacity of the cord.
9.5. When using a cable reel, always unwind the
cable completely.

SYMBOLS AND POWER RATING CHART
Danger! –Read the operating
instructions to reduce the risk of
injury.
Caution! Wear safety goggles.
Caution! Wear ear defenders. The
impact of noise can cause
damage to hearing.
Amperes
7.5M
15M
25M
30M
45M
60M
0 –2.0
6
6
6
6
6
6
2.1 –3.4
6
6
6
6
6
6
3.5 - 5.0
6
6
6
6
10
15
5.1 –7.1
10
10
10
10
15
15
7.1 –12.0
15
15
15
15
20
20
12.1 –20.0
20
20
20
20
25
-
Caution! Risk of Injury! Do
not reach into the running
saw blade.
Caution! Wear a dust mask.
TS254EL 06
HG2000 06

TS254EL 08
HG2000 06
MACHINE DETAILS AND PRODUCT FEATURES
Machine Details
Specifications:
Mains Voltage ‐ 220-240V / 50Hz
Power Consumption ‐ 2000W
Operating temp (1/2) ‐ 50°C/50~600°C
Air flow, approx ‐ 250~500L/min
Display operating temp* - -20…+70°C
Device class ‐ 2
Ingress protection (IP) ‐ IPX0
Weight ‐ 0.85kg
Package Contents:
1 x HG2000 Heat gun
1 x Triangle scraper
4 x nozzle attachments
Product Features
1. Portable Power Tool
2. Small dimensions
3. Ergonomic Design
4. Low noise emission
5. High speed air flow
6. Adjustment of operating temperature
and speed of airflow
Intended Use
The tool is intended for removing paint
coats, shaping and welding plastics and
fitting shrinking plastic tubing. It can also
be used to soften adhesives and defrost
water pipes. Do not use the tool in
professional applications. Any use in
applications other than indicated or
modification by the user is prohibited and
results in the warranty being null and void,
waiving the manufacturer’s liability for
damage.

HG2000 07
OPERATION
Before you start
1. Make sure that power supply
parameters meet the requirements
provided on the tool nameplate
2. Make sure the tool is in the off
position. Connecting the tool to the mains
socket while in the on position can result
in injury as the hot air gun starts
immediately.
3. When your workplace is too far to plug
the tool directly into the mains socket,
use and extension cord with a cable
cross-section meeting the tools
requirements. Extension cords should be
as short as possible. When in use
extension cords must be fully uncoiled.
During Operation
1. Switching On/Off
- To turn the tool on, set the on/off
switch (7) to mode 1 or 2. In both modes
the tool turns on with the air flow and
temperature values set before it was
turned off for the last time.
- To turn the tool off, set the on/off
switch (7) to position 0 until resistance is
felt.
- After a long period of operation at high
temperatures put the tool aside after
selecting mode 1 for a short period to
allow it to cool down.
2. Overheat protection
When the heater temperature is too high
(e.g. the air flow is restricted) the overheat
protection switches it off automatically,
however the blower remains on. When the
tool cools down to operation temperature,
the heater switches on again.
Operation modes
1. Warm air mode 1
- In mode 1 it is possible to adjust the air
flow rate. The temperature is always set to
50°C.
- The warm air in mode 1 is suitable for
cooling down heated objects or for drying a
paint coat. It can also be used to cool the
tool before putting away or replacing its
nozzle.
Note. After switching from hot air blow
settings (at higher temperatures), it takes
certain time to cool the tool down to 50°C.
During cooling the display (3) shows actual
temperature at the nozzle outlet.
When switching from hot air to warm air or
vice versa, the tool remains on current air
flow settings.
2. Hot air mode 2
- In mode 2 it is possible to adjust air flow
rate and temperature. While changing from
warm air mode to hot air mode, the
temperature is automatically set to the
value of the last hot air mode operation.

HG2000 08
OPERATION
3. Air flow adjustments
- The air flow rate can be controlled using
buttons for air flow settings (4) and (5).
1 bar –minimum air flow (approx.
250L/min)
5 bars –maximum air flow (approx.
500L/min)
- The air flow can be increased by
pressing the temperature increase button
(4) or decreased using the decrease
button (5).
- Pressing the button increases or
decreases the air flow by one step until
max or min limit is reached.
4. Temperature Adjustment
- Temperature adjustment is possible only
when the hot air mode 2 is selected.
- While changing the temperature setting,
the tool needs a short period to heat the
air stream up or cool it down to reach the
target temperature.
- the target temperature can be increased
in degrees by 10°C by pressing the
temperature increase button (2), or
decreased by pressing the temperature
decrease button (6).
Working Tips
NOTE! Avoid holding the tool perpendicular to
surface being processed. It results in hot air
reflection and creates a feedback of hot air
being sucked into the motor. It results in
increasing temperature inside the motor and
damage to the tool. The Heat gun should be held
at an angle of approx. 45° to the surface being
processed.
- The distance between the nozzle and object
being processed depends on the material, but
cannot be lower than 5cm.
- before you turn the tool off, set the
temperature to minimum and select the
maximum air flow for a short period (more than
ten seconds) to cool down the heating element.
It will extend the life of your tool.
- To cool the hot tool down or to have both
hands free put the hot air gun vertically onto a
horizontal surface see fig (B)
NOTE: be especially careful when working with
the tool aside! There’s a risk of burns caused by
its hot nozzle or hot air stream.

TS254EL 09
Maintenance and Cleaning
Cleaning and maintenance
-Keep the tool clean and provide unrestricted
air flow
- Protect the hot air gun against any
penetration of water, dust and other small
objects
- Do not clean the plastic housing with
chemical agents. Use a slightly damp cloth and
soap. Allow the tool housing to dry under
natural conditions before you start to use it
again.
- Check the power cord for technical shape on
a regular basis and replace it immediately
when any damage is found
- In case of technical problems please contact
our service team.

HG2000 10
LUMBERJACK GUARANTEE
1. Guarantee
1.1 Lumberjack guarantees that for a period of
12 months from the date of purchase the
components of qualifying products (see clauses
1.2.1 to 1.2.8) will be free from defects caused
by faulty construction or manufacture
1.2 During this period, Lumberjack, will repair or
replace free of charge any parts which are
proved to be faulty in accordance with
paragraph 1.1 providing that:
1.2.1 You follow the claims procedure set out in
clause 2.
1.2.2 Lumberjack and its Authorised Dealers are
given reasonable opportunity after receiving
notice of the claim to examine the product.
1.2.3If asked to do so by lumberjack or its
Authorised Dealer, you return the product at
your own cost to Lumberjack’s or the supplying
Authorised Dealer’s Premises -
For the examination to take place clearly stating
the Returns Material Authorisation Number given.
1.2.4 The fault in question is not caused by
industrial use, accidental damage, fair wear and
tear, wilful damage, neglect, incorrect electrical
connection, misuse, alteration or repair of the
product without approval.
1.2.5 The product has been used in a domestic
environment only.
1.2.6 The fault does not relate to consumable
items such as blades, bearings, drive belts or other
wearing parts which can reasonably be expected
to wear at different rates depending on usage.
1.2.7 The product has not been used for hire
purposes.
1.2.8 The product has been purchased by you, as
the guarantee is not transferable from a private
sale.

TG2000 11
LUMBERJACK GUARANTEE
2. Claims Procedure
2.1 In the first instance please contact the
Authorised Dealer who supplied the product to
you. In our experience many initial problems
with machines that are thought to be fault due
to faulty parts are actually solved by correct
setting up or adjustment of the machine. A good
Authorised Dealer should be able to resolve the
majority of these issues much more quickly than
processing a claim under the guarantee. If a
return is requested by the Authorised Dealer or
Lumberjack, you will be provided with a Returns
Material Authorisation Number which must be
clearly stated on the returned package, and any
accompanying correspondence. Failure to
provide a Returns Material Authorisation
Number may result in item being refused
delivery.
2.2 Any issues with the product resulting in a
potential claim under the guarantee must be
reported to the Authorised Dealer from which it
was purchased within 48 hours of receipt.
2.3 If the authorised Dealer who supplied the
product to you has been unable to satisfy your
query, any claims made under this guarantee
should be made directly to Lumberjack. The
claim itself should be made in a letter setting out
the date and place of purchase, giving a brief
explanation of the problem which has led to the
claim.
2.4 Please note that it is essential that the letter of
claim reaches Lumberjack on the last day of this
guarantee at the latest. Late claims will not be
considered.
3. Limitation of Liability.
3.1 We only supply products for domestic and
private use. You agree not to use the product for
any commercial, business or resale purposes and
we have no liability to you for any loss of profit,
loss of business, business interruption or loss of
business opportunity.
3.2 This guarantee does not confer any rights
other than these expressly set out above and does
not cover any claims for consequential loss or
damage. This guarantee is offered as an extra
benefit and does not affect your statutory rights
as a consumer.
4. Notice
This guarantee applies to all product purchased
from an Authorised Dealer of Lumberjack within
the United Kingdom. Terms of guarantee may vary
in other countries.
