Lumena Radiata PACAMAN User manual

Full product range & more information: www.lumenalights.com
INSTRUCTION MANUAL
Radiata PACAMAN Timber Path Light 12v
THANK YOU FOR YOUR PURCHASE
PLEASE READ THESE INSTRUCTIONS CAREFULLY PRIOR TO INSTALLATION / MAINTENANCE
WARNINGS
•This is a Class 3 product (low voltage) no earth required.
•12V TRANSFORMER REQUIRED –sold separately
•This unit must be fitted by a competent person –if in doubt consult a qualified electrician.
•Always use the correct type and wattage of 12v transformer.
•To prevent electrocution, switch off mains supply before installing or maintaining this fitting. Ensure other persons cannot restore
the electrical supply without your knowledge.
•This light fitting should be connected to a circuit with a 30Ma RCD fitted.
•If replacing an existing fitting, make a careful note of the connections.
•Always switch off at the mains & allow the fitting to cool before commencing any electrical work or changing the bulb.
•Always use the correct type & wattage of bulb. Never exceed the wattage stated.
•All connections should be made as watertight as possible to avoid electrical shortage.
•The unit may get warm whilst on for a period of time.
•If the luminaire or cable is found to be damaged, cease use immediately.
RETURNS & DISPOSAL:
If purchased from a 3rd party, please contact your supplier.
If purchased direct, contact us by phone or email:
Lumena Lights Ltd, Centre 33 Long March, Daventry, NN11 4NR Tel: [phone] Email: [e-mail]
Our full returns policy is available on our website.
Waste Electrical Products should not be disposed of with household waste. Please check with your local authority or
contact us for more information. Please recycle packaging when possible. Producer Registration Number: WEE/KC3440XY
SPECIFICATIONS
Transformer Required: 12v AC (wattage dependent on total wattage of circuit)
Lamp Holder: MR16 (lamp supplied)
Colour Temperature: 3000K (Warm White) / 6000K (Daylight White)
IP Rating: IP65
Cable: H05RN-F 2 core rubber cable open end (non-armoured) –approx. 1.4m
Materials: Radiata Pine, Anodised Aluminium, Tempered Glass
Treatment: Pressure treated with Tanalith E preservative in accordance
with BS8417 to meet Use Class 4
Weight: 15KG (approx.)
Mounting: Root Mount (bury 3-400mm under ground)
Included: Bollard light, replaceable MR16 (fitted), back panel / cable cover (optional),
10 x pins per back panel
UK REGISTERED DESIGN: 6249431
✔✔✔✔✔
5 YEAR
GUARANTEE
see website for
more details
200mm
1300mm
(300 to 400mm
under ground)
95mm

Full product range & more information: www.lumenalights.com
INSTALLATION:
The sleeper is designed to be root-mounted into wet concrete or buried securely into compact earth. For extra
stability, attach a large wood screw into two sides of the sleeper approximately 200mm from the base. These
will act as anchors when set into wet concrete.
1. Prepare a mounting hole in the desired location to allow for a bollard depth
of at least 300mm (can vary depending on the required height above ground).
Ensure the diameter of the hole is at least 300mm to accommodate the width
of the sleeper, or slightly more if anchors are attached (see above). TIP: Carry
out placement check prior to final installation into wet concrete.
2. Connect the fitting to the transformer / extension cable via a junction box or
tubecon connector (see diagram for wiring information).
3. Check that you have correctly identified the supply wires, the connections are
tight and that no loose strands have been left out of the connection block.
4. Cut down the supplied back panel accordingly, based on the cable connection
method / location. If the existing cable is extended, the back panel does not
need to be cut down. If connecting to a junction box above ground level, the
back panel will need to be cut down.
5. Test the fitting prior to concreting in place for easier access to the cable.
6. OPTIONAL: attach a large wood screw to each side to act as an anchor
support
7. Mount the sleeper into the desired location using supports to hold the fitting upright. Concrete or earth must cover the
anchor and at least 100mm above.
8. Ensure the black, rubber o-ring / seal is securely in place around the luminaire, flush with the glass lens (fitting)
NOTES:
•CABLES: Neutral (N) = Blue, Live (L) = Brown. Colours of wire sleeving may
vary slightly –Test prior to use.
•2 core cable is not armoured. It is strongly recommended that any adjoining, low
voltage cable is laid within conduit (armoured preferred) for added protection.
•Mains cable leading to the transformer must be installed inside armoured conduit
(or armoured cable used) in accordance with the current Wiring Regulations.
•Ensure the transformer has plenty of surrounding airflow to prevent overheating
and install in a safe location away from possible damage. Lumena 12v AC
transformers are rated IP68 and can be buried if located inside a suitable burial
box with overflow.
•It is strongly recommended that the cable is concealed with a strip of wood for
further protection and aesthetics. Use a thin strip of Radiata Pine and pins
(provided). Please note, this will not affect the IP Rating.
SILICA GEL PROCEDURE:
A small pack of silica gel is located inside the luminaire behind the MR16. This should
not be removed. Condensation inside the luminaire is common due to the heat generated from lamps and cold weather
conditions externally, especially if installed on a damp day. The silica gel will collect the moisture inside the fitting, preventing this
from causing any issues. It is recommended that the silica gel is replaced when the light bulb is replaced, if not before, and the
white rubber o-ring and black rubber seal inspected for damage.
CLEANING & MAINTENANCE:
Occasional cleaning and care are recommended for this product. As a natural material, Radiata products will possess structural
features, such as knots, splits and twists. Due to the pressure treatment of this timber, it may have a slight blue appearance in
places, particularly around knots. This will fade over time as the timber naturally weathers. Please refer to our website for more
information on the best way to clean different materials.
