Lumens PS400 User manual

English - 1
PS400
Digital Visualizer
Quick Start Guide

English - 2
1. Product Content
Main Unit Quick Start Guide User Manual
Download Card Power Cord USB Cable

C-Video Cable VGA Cable Remote
2. Product Overview
1. Camera Head
2. Camera arm
3. Lamp
4. Backlight
5. Remote controller slot
6. CF card slot
7. Lamp lock
8. Control Panel
9. Button Function Guide
10. IR sensor (for controller)
11. IO connector
11

English - 3
3. Installation Process
3.1 Input /Output Connection
3.1.1 Connecting VGA out to Monitor or Projector
3.1.2 Connecting DVI out to Monitor or Projector
3.1.3 Connecting S-Video/C-Video to TV
DIP switch setting
【Notice】1. The DIP setting will be taken effect after restarting the device.
2. No VGA output once S-Video/C-Video output is turn on.
3. NTSC：USA、Ta i w an 、Panama、Philippine、Canadian、Chile、Japan、
Korea、Mexico
4. PAL: Besides above NTSC listed countries.
Monitor
Pro
j
ector
Monitor
Projector
TV
ON
OFF
NTSC
ON
OFF
PAL

English - 4
3.1.4 Connecting VGA in to Computer
3.1.5 Connecting USB to Computer
Connect to USB port then install the supplied queue program. Please refer to
queue installation Instruction for more information.
【Notice】Don’t connect the Digital Visualizer to PC Until USB Driver has been
installed properly.
3.1.6 RS232 to Computer
Connect to RS232 port then execute RS232 command.
3.1.7 Plug in the power outlet
PC Notebook
PC Notebook
PC Notebook
AC Outlet

English - 5
3.2 Initial Setup
3.2.1 Setup the Digital Visualizer
1. Pull up the arm and camera head then turning the camera head
toward the platform
2. Press and slide the latches (Lamp release) to release the lamp lock
then Pull up the lamp arms.
3. Rotate the folded lamp to face the platform as the arrow shows.
※Note：The angle of the camera head/lamp arm/lamp head is limited.
Do not turn it forcefully when it reaches the maximal angle
3.2.2 Power On
※Note：Before using the Digital Presenter, make sure that you have
connected it to the computer, video source or other output devices.
Please refer to the 3-1 section.
1. Press (the『POWER』button) for about 1 second to power on
the Digital Presenter. The red LED (flashing until the presenter is
started) turns to green.
2. Press the 『LAMP』button on the remote control to switch the side
lamp or backlight.
※Note: you may rotate the camera head appropriately for better lighting.




English - 6
4. Start to use
4.1 Select Input Source
The default input source is set as "Digital Visualizer", press 『Source』to
switch.
4.2 Zoom in/ out
Zoom in / out by pressing continuously
Remote
Monitor
Projector
PC Notebook
Keypad Remote
Keypad


English - 7
4.3 Auto Focus
Auto Focus by pressing once
4.4 Brightness Adjustment
4.5 A4/A5 Size
The default shooting area is A4 size, please『A5』to change.
Keypad
Remote
Keypad
Keypad

English - 8
4.6 Capture & Play Image:
Capture Live Image『Capture』or Play the captured image『Play』
4.7 OSD Menu
* Please refer to the Button Function Guide pasted on the front panel for simple
operation.
* More detail functions of OSD menu, please read the user manual.
* The updated information will be regularly released on Lumens web site,
please visit our web site http://www.lumens.com.tw for the most updated.
