Luminetic HMX Series User manual

Working Temperature
Working Humidity
-40°C~+45°C
15%~90%RH
Storing Temperature
IP Rating
-40°C~+65°C
IP66
Installation and wiring of luminaire must be in
accordance with all applicable local codes.
Installation, inspection, and maintenance of luminaires
should be performed by a qualified electrician.
DO NOT make or alter any open holes in the luminaire.
Do not modify the luminaire.
DO NOT install damaged product.
Make sure electrical power is OFF before and during
installation and maintenance.
Make sure the equipment is properly grounded.
Make sure the supply voltage is same as the rated
fixture voltage.
Only use luminaire in its intended location.
Make sure the luminaire is not covered with material
that will prevent convection or conduction cooling.
It’s suggested to perform visual, electrical, and
mechanical inspections on a regular basis.
Allow luminaire to cool before handling. Do not touch
enclosure or light source.
Installation Manual
Please read and follow all safety instructions. Save this manual for future reference!
WARNING
To avoid electric shock:
To perform maintenance:
HMX
SERIES
Luminaire Parameter
Wiring Diagram

HMX
SERIES
Installation
1
Fix the luminaire on the mounting bracket
by screws.
Adjust the angle of the luminaire and then
tighten the handle of the luminaire’s bracket.
luminetic.com.au
VISIT US ONLINE
Install the driver module in the suitable location.
2
Adjust the orientation of the luminaire to
achieve the desired lighting position and
fasten the screws.
3
Loosen the handle of the luminaire’s bracket.
4
5
