MEAT GRINDER LU-2107, LU-2106 User manual
Parts list
1. Motor unit
2. Reverse (R) /OFF button (O) /ON button
3. Grinder head locking button
4. Grinder head inlet
5. Food pusher
6. Food tray
7. Removable grinder head body
8. Feeder screw
9. Cutting blade
10. Cutting plates
11. Fixing ring
Cutting plates:
5mm –for cooking cutlets
7mm –for chopping
IMPORTANT SAFETY INSTRUCTIONS
•Please read this instruction manual carefully before use and keep in a safe place for future reference.
•This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or instruction concerning use of appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
•Before the first connecting of the appliance check that voltage indicated on the rating label corresponds to the mains voltage in your
home.
•Home use only. Do not use for industrial purposes.
•Do not use the meat grinder for any other purposes than those described in this instruction manual.
•After transportation of storage at low temperatures allow the appliance to stay at room temperature for at least 2 hours before use.
•Do not disassemble the appliance when it is plugged to the power supply. Always unplug the meat grinder from the power supply when
not in use and before cleaning.
•To protect against the risk of electric shock, DO NOT IMMERSE THE APPLIANCE IN WATER OR IN ANY OTHER LIQUIDS.
•Do not place the appliance on soft, unstable surface or cover it with a cloth while in operation as it may cause overheating or
breakdown.
•Keep away from children.
•Do not leave the meat grinder switched on when you do not use it.
•Do not use other attachments than those supplied.
•Do not overload the appliance.
•Keep the cord away from sharp edges and hot surfaces.
•Do not place the appliance near gas or electric oven or store at heated surface.
•The blades are very sharp, so handle them with care.
•Do not push products into the appliance by fingers while it is in use.
•If food becomes lodged in feeding tube, use pusher to push it down. If this doesn’t work, turn the motor off, unplug the appliance and
disassemble it to remove remaining food.
•Do not carry the unit by the food tray or head. Be sure to hold the housing with both hands.
•Do not operate after malfunction or damage of cord.
•Do not grind hard food, such as bones, nuts, ginger or other products with hard fiber.

2
•Do not operate for more than 5 minutes at one time. Turn off switch and let it rest for at least 10 minutes to cool down the
motor, otherwise the motor may be damaged.
•If in case of overloading the overheat protection system is activated, switch off the appliance by pressing the ON/O/R button to O
position, unplug it, and let the appliance cool down about 60 minutes, and then continue operation.
•Do not attempt to repair, adjust or replace parts in the meat grinder. Repair the malfunctioning appliance in the nearest service center.
•The grinder head may rotate slightly during the use, but it is normal.
•Do not over tighten the fixing ring to stop the movement. It may cause damage.
•Removable metal parts (screw, cutting knife, cutting plates) can be oxidized after use. It is normal.
BEFORE FIRST USE
•Unpack your appliance. Remove all packing materials.
•Check if all parts are in a set and not damaged.
•Clean all the parts according to the article «Cleaning and maintenance». Do not immerse motor unit into water.
•Dry thoroughly before use.
USING THE APPLIANCE
ASSEMBLING
1. Press the locking button, hold the head and insert into the inlet. When inserting please make sure that head must be slanted as
per arrow indicated (fig.1), then move the head anticlockwise so the head will be fastened tightly. (fig.2)
2. Place the feeder screw into the head, long end first, and turn to feed the screw slightly until it is set into the motor housing. (fig.3)
3. Place the cutting blade onto the feeder screw shaft with the blade facing the front as illustrated (fig.4). If it is not fitted properly,
meat will not be grinded.
4. Place the desired cutting plate next to the cutting blade, fitting into the slot. (fig.5)
5. Support or press the center of the cutting plate with one hand then screw the fixing ring tight with another hand (fig.6). Do not over
tighten. Place the food tray on the head and fix it into position (fig.7). Locate the unit on a firm place. The air passage at the bottom
and the side of the motor housing should be kept free and not blocked.
MINCING
1. Prepare the meat to be minced. Remove any bones and gristle. Never use frozen meat!
2. Cut the meat into pieces so that they easily fit the grinder head.
3. Place a bowl for minced meat under the grinder head.
4. Plug the unit in and switch ON/O/R button to ON position.
5. Put the meat in the tray; use the pusher to gently push the meat into the grinder head body. Never push the meat down with
your fingers.
6. After you finish operating the unit, switch ON/O/R button to O position, unplug it.

3
REVERSE FUNCTION
If the meat gets stuck in the feeder screw during operation, use the reverse function to release the jam.
1. Switch off the unit by switch the ON/O/R button to O position, wait until the motor stops completely. Then switch and hold down the
switch ON/O/R button to R positon for 5-10 seconds.
2. The feed screw starts rotating in the opposite direction and push out jammed food.
3. If this does not help, unplug the unit from the outlet, dissemble and clean it.
CLEANING AND MAINTENANCE
•Switch off the appliance and make sure that the motor has stopped completely.
•Unplug the appliance.
•Disassemble by reversing the assembling steps (fig.8).
•Press locking button and turn the whole grinder head in the direction of the arrow.
Remove the pusher and tray (fig.9).
•Clean all the attachments and parts right after use.
•Do not immerse motor unit, plug and power cord in water or keep in running water.
Wipe the motor unit with a damp cloth.
•Wash all the parts that have come in contact with meat in warm soapy water.
•Do not use abrasives, chlorine containing substances or organic solvents.
•The metal parts of the meat grinder are not to be washed in the dishwasher!
•Do not wash all metal parts with hot water which temperature above 40℃. Because it will accelerate metal parts oxidation.
•After washing please use dry cloth to wipe the metal parts.
•Wipe all the cutting parts (cutting knife, cutting plates) with vegetable oil.
•If the meat grinder won't be used for a long time, please wipe all the metal parts by vegetable oil-wet dishcloth.
CAUTION: The blades are sharp and therefore dangerous. Handle with care.
STORAGE
•Switch off and unplug the appliance; let it entirely cool.
•Complete all requirements of Chapter CLEANING AND MAINTENANCE.
•Keep the appliance in a dry cool place.
SPECIFICATION
Power supply
Mincing speed
Maximum
power
Net / Gross
weight
Gift box dimension (L x W x
H)
230 V, 50 Hz
up to 1,5 kg/min
2000 W
2,3 kg / 2,7 kg
270 mm х 215 mm х230 mm
WARRANTY DOES NOT APPLY TO CONSUMABLES (FILTERS, CERAMIC AND NON-STICK COATING, RUBBER SEALS, ETC.)
Production date is available in the serial number located on the identification sticker on the gift box and/or on sticker on the device. The
serial number consists of 13 characters, the 4th and 5th characters indicate the month, the 6th and 7th indicate the year of device
production. Producer may change the complete set, appearance, country of manufacture, warranty and technical characteristics of the
model without notice. Please check when purchasing device.

4
Manufacturer: “MARTA TRADE INC.”
c/o Commonwealth Trust Limited, P.O. Box 3321, Road Town, Tortola, UK
Manufacturer branch:
Cosmos Far View International Limited
Room 701, 16 apt, Lane 165, Rainbow North Street, Ningbo, China
EU importer: Marta Europe B.V.
www.multimarta.nl
Made in China
