Please Read Before Installing
Signature SeriesTM Button Kits
HKS-3B, HKS-4B
Installation Instructions
Overview
The Signature Series Button Kits may be used to add
engraving to Signature Series keypads to clearly iden-
tify each button’s function.
HKS-3B
Important Notes
Mounting: Ensure all keypads are correctly wired and
mounted before installing button kits or wallplates.
Ensure keypads are free from debris (e.g. plaster,
spackling compound) before installing button kits or
wallplates.
Cleaning: To clean, wipe with a clean damp cloth.
DO NOT use any chemical cleaning solutions.
HKS-4B

Lutron Electronics Co., Inc.
7200 Suter Road
Coopersburg, PA 18036-1299
Made and printed in the U.S.A. 7/03 P/N 043-117 Rev. A
Technical and Sales Assistance
If you need assistance, call the toll-free Lutron
Technical Support Center. Please provide exact
model number when calling.
[phone] (U.S.A., Canada and the Caribbean)
Other countries call:
Tel: [phone]
Fax: [phone]
Visit our Web site at www.lutron.com
1. Remove the faceplate and currently installed button
kit (see Faceplate and Button Kit Removal).
2. Align the screw holes of the new button kit with the
corresponding holes in the keypad. Attach the button
kit using the screws provided.
3. Attach the faceplate to the keypad by pressing at the
top and bottom of the faceplate until it snaps in
place.
Installation
1. Remove faceplate.
(HKS-4B shown)
2. Remove button kit.
(HKS-4B shown)
Using the included
wooden removal
tool, remove the
faceplate from the
keypad by gently
prying it from the
bottom.
Faceplate and Button Kit Removal
Mounting Diagram
Keypad
Button Kit
Faceplate
Wallbox
(optional - Lutron
Model # WBOX-
SA1-Q1)
Keypad
Mounting
Screws
Button Kit
Mounting
Screws
